Directed Electronics Python 460HP User manual

MOD E L
460HP

Directed Electronics, Inc. ("Directed") promises to the original purchaser to repair or
replace with acomparable reconditioned model any Directed unit (hereafter the "unit"),
excluding without limitation the siren, the remote transmitters, the associated sensors and
accessories, which proves to be defective in workmanship or material under reasonable use
during the lifetime
of the vehicle provided the following conditions are met: the unit was
professionally installed and serviced by an authorized Directed dealer; the unit will be pro-
fessionally reinstalled in the vehicle in which it
was originally installed by an authorized
Directed dealer; and the unit
is returned to Directed, shipping prepaid with alegible copy
of the bill of sale or other dated proof of purchase bearing the following information: con-
sumer's name, telephone number and address; the authorized dealers name, telephone
number and address; complete product description, including accessories; the year, make
and model
of the vehicle; vehicle license number and vehicle identification number. All
components other than the unit, including without limitation the siren, the remote trans-
mitters and the associated sensors and accessories, carry aone-year warranty from the date
of purchase of the same. This warranty is non-transferable and is automatically void if: the
original purchaser has not completed the warranty card and mailed it within ten
(l0) days
of the date of purchase to the address listed on the card; the unit's date code or serial num-
ber
is defaced, missing or altered; the unit has been modified or used in amanner con-
trary to
its intended purpose; the unit has been damaged by accident, unreasonable use,
neglect, improper service, installation or other causes not arising
out of defects in materi-
als or construction. The warranty does not cover damage to the unit caused by installa-
tion or removal
of the unit. Directed, in its sole discretion, will determine what consti-
tutes excessive damage
and may refuse the return of any unit with excessive damage. TO
THE MAXIMUM EXTENT ALLOWED BY LAW, ALL WARRANTIES, INCLUD-
ING BUT NOT LIMITED TO EXPRESS WARRANTY, IMPLIED WARRANTY,
WARRANTY
OF MERCHANTABILITY, FITNESS FOR PARTICULAR PURPOSE
AND WARRANTY OF NON-INFRINGEMENT OF INTELLECTUAL PROPERTY,
ARE EXPRESSLY EXCLUDED;
AND DIRECTED NEITHER ASSUMES NOR
AUTHORIZES ANY PERSON OR ENTITY TO ASSUME FOR IT ANY DUTY,
OBLIGATION
OR LIABILITY IN CONNECTION WITH ITS PRODUCTS.
DIRECTED DISCLAIMS AND HAS ABSOLUTELY NO LIABILITY FOR ANY
AND ALL ACTS OF THIRD PARTIES INCLUDING ITS AUTHORIZED DEAL-
ERS OR INSTALLERS. DIRECTED SECURITY SYSTEMS, INCLUDING THIS
UNIT, ARE DETERRENTS AGAINST POSSIBLE THEFT. DIRECTED IS NOT
OFFERING AGUARANTEE OR INSURANCE AGAINST VANDALISM, DAM-
AGE
OR THEFT OF THE AUTOMOBILE, ITS PARTS OR CONTENTS; AND
HEREBY EXPRESSLY DISCLAIMS ANY LIABILITY WHATSOEVER, INCLUD-
ING WITHOUT LIMITATION, LIABILITY FOR THEFT, DAMAGE AND/OR
VANDALISM. THIS WARRANTY DOES NOT COVER LABOR COSTS FOR
MAINTENANCE, REMOVAL OR REINSTALLATION OF THE UNIT OR ANY
©2005 directed electronics, inc. all rights reserved

CONSEQUENTIAL DAMAGES OF ANY KIND. IN THE EVENT OF ACLAIM
OR A DISPUTE INVOLVING DIRECTED OR ITS SUBSIDIARY, THE PROPER
VENUE SHALL
BE SAN DIEGO COUNTY IN THE STATE OF CALIFORNIA.
CALIFORNIA STATE
LAWS AND APPLICABLE FEDERAL LAWS SHALL APPLY
AND GOVERN THE DISPUTE. THE MAXIMUM RECOVERY UNDER ANY
CLAIM AGAINST
DIRECTED SHALL BE STRICTLY LIMITED TO THE
AUTHORIZED DIRECTED DEALER'S PURCHASE PRICE OF THE UNIT.
DIRECTED SHALL NOT BE RESPONSIBLE FOR ANY DAMAGES WHATSOEV-
ER,
INCLUDING BUT NOT LIMITED TO, ANY CONSEQUENTIAL DAMAGES,
INCIDENTAL DAMAGES, DAMAGES
FOR THE LOSS OF TIME, LOSS OF
EARNINGS, COMMERCIAL LOSS, LOSS OF ECONOMIC OPPORTUNITY
AND THE LIKE. NOTWITHSTANDING THE ABOVE, THE MANUFACTURER
DOES
OFFER ALIMITED WARRANTY TO REPLACE OR REPAIR THE CON-
TROL MODULE AS DESCRIBED ABOVE. Some states do not allow limitations on
how long an implied warranty will last or the exclusion or limitation of incidental or con-
sequential damages. This warranty
gives you specific legal rights and you may also have
other rights that vary from State to State.
This product may
be covered by aGuaranteed Protection Plan ("GPP"). See your autho-
rized Directed dealer for details
of the plan or call Directed Customer Service at 1-800-
876-0800. Directed security systems, including this unit, are deterrents against possible
theft. Directed
is not offering aguarantee or insurance against vandalism, damage or theft
of the automobile, its parts or contents; and hereby expressly disclaims any liability what-
soever, including without limitation, liability for theft, damage and/or vandalism.
Directed does
not and has not authorized any person or entity to create for it any other
obligation, promise, duty or obligation in connection with this security system.
Make sure you have
all of the following information from your dealer:
Aclear copy
of the sales receipt, showing the following:
.. Date of purchase
",. Your full name and address
)0 Authorized dealer's company name and address
)0 Type of alarm installed
.)0 Year, make, model and color of the automobile
.)00 Automobile license number
>- Vehicle identification number
)0 All security options installed on automobile
)0 Installation receipts
ii
©2005 directed electronics, inc. all rights reserved

1
standard transmitter configuration 2
expaJ'lded. transmitter configuration 2
what is included. 3
. 'nfo' 3
unportant 1 rmanon. . . . . . . . . . . . . . . . . . . . . . . .
system maintenance 4
your warranty 4
fcclid notice 4
transmitter functions 5
Standard configuration 5
Expanded configuration G
using your sy-stem 7
. . 7
active armIng .
. . 8
passIve arming .
multi-level security arming 9
arming while driving 10
disarming
11
high security disarm 11
disarming without atransmitter 12
silent mode
13
panic mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
valet mode ..................................................... 13
nuisance prevention® circuitry 14
diagnostics 16
arming diagnostics 16
disarming diagnostics 17
system status chirps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
table
of zones 18
interpreting zone diagnostics 18
code hopping 19
high frequency 20
owner recognition . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
rapid resume logic 21
power sa.ver mode ... . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
programming options 22
installation options 25
vehicle recovery system (vrs~) 26
arming the vrs® 27
vrs® triggered sequence 27
disarming the
vrs® 28
glossary of terms 30
security &convenience expansions .. . . . . . . . . . . . . 32
quick reference guide 35
©2005 directed electronics, inc. all rights reserved

controls the ArmIDisarm function.
____ • .•.• -1
controls the Panic function.
~u~1 controls Silent Mode™ and an Auxiliary Output.
L~~----:"':'_!'--l' and I~ together control an Auxiliary Output.
(* With optional four-button transmitter only.)
controls the Arm function.
controls the Disarm function.
I!i»~ controls Silent Mode™ and an Auxiliary Output.
controls the Panic function.
2
r--"-.l
l-...------' and ~_,,_c jpressed together control an Auxiliary Output.
©2005 directed electronics. inc, all rights reserved

.~ One control module
>Apair of three-button transmitters
)p, A Stinger® Doubleguard® dual-stage shock sensor (on-board
the control module)
.",. The Revenger® Soft Chirp® six-tone programmable siren
'> The red status LED indicator light
"JIptP, Apush-button Valet button
~, Your warranty registration
.)the. Failsafe® Starter Kill ready circuitry (may require additional
labor)
)p" HF+ external receiver/antenna
Congratulations
on the purchase of your state-of-the-art vehicle
security system. This system has been designed to provide years
of trouble-free operation. Due to the complexity of this system,
it must be installed by an authorized dealer only. Installation
of
this product by anyone other than an authorized dealer voids the
warranty. All dealers are provided with preprinted dealer certifi-
cates to verify
that they are authorized.
This owner's guide should help you to get the most
out of your
system. Please take the time to read it prior to using the system.
©2005 directed electronics, inc. all rights reserved 3

4
~ system maintenance
The system requires no specific maIntenance. Your remote
control is powered by asmall, lightweight 3volt lithium battery
that will last approximately one year under normal use. When
the battery weakens, operating range will be reduced and the
LED on the remote will dim.
~ your warranty
Your warranty registration must be returned and the bar code
serial number must not be removed. If the warranty registration
is not returned, you do not have awarranty. It is also necessary
to keep your proof of purchase, which reflects that the product
was installed by an authorized dealer. Make sure that you receive
the warranty registration from your dealer.
~ fcc/id notice
This device complies with Part 15 of FCC rules. Operation is
subject to the following two conditions: (1) This device may not
cause harmful interference, and (2) This device must accept any
interference received, including interference that may cause
undesired operation.
Changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to
operate this device.
©2005 directed electronics, inc. all rights reserved

.tlansmittel tUDctioDS "_ .
The system uses a computer-based learn routine to learn the
transmitter buttons. This makes it possible to assign any trans-
mitter
button to any system function. The transmitter initially
comes programmed
with Standard Configuration, but may also
be customized by
an authorized dealer. The buttons in all of the
instructions in this manual correspond to a Standard
Configuration transmitter.
~ Standard configuration
Button
The arming and disarming functions are controlled by pressing
this
button for one second.
Button
Silent Mode ™ and an optional auxiliary function are controlled
by pressing this
button. (Silent Mode works by pressing this
button for less than one second before arming or disarming. An
optional auxiliary function, such as trunk release, can be
controlled by pressing this
button for 1.5 seconds.)
The auxiliary output controls _
j J! ~'
I~»i: Button
Lr ,j
The panic feature is controlled by pressing this button for two
seconds.
©2005 directed electronics, inc. all rights reserved 5

6
~drj-: and :~~r. Buttons
An optional auxiliary convenience or expansion function that
you have added to your system can be activated by pressing these
buttons simultaneously.
The auxiliary output controls _
~ Expanded configuration
(Available with optional four-button transmitter.)
: Button
The arming function is controlled by pressing this button for
one second.
Button
The disarming function is controlled by pressing this button for
one second.
Silent
Mode ™ and an optional auxiliary function are controlled
by pressing this
button. (Silent Mode works by pressing this
button for less than one second before arming or disarming. An
optional auxiliary function, such as trunk release, can be
controlled by pressing this
button for 1.5 seconds.)
The auxiliary output controls _
r-'-'"~--"l
I~l Button
.~.,..~_."~,/
The panic feature is controlled by pressing this button for two
seconds.
©2005 directed electronics, inc, all rights reserved

..... ~.: and (,~J Buttons
An optional auxiliary convenience or expansion function that
you have added to your system can be activated by pressing these
buttons simultaneously.
The auxiliary output controls _
The buttons used in the instructions in this manual correspond
to the standard configuration. Remember, this
is not the only
way your transmitter may be set up.
It can be custom configured
to meet your needs.
1"··_··_·_····1
t.~J active arming
You can activate, or arm, the system by pressing on your
transmitter for one second.
When the system arms, you will hear
ashort siren sound,
or chirp, and the parking lights will flash
once.
If the vehicle's power door locks have been connected to the
system, the doors will lock.
While the system
is armed, the status LED will flash approximately
once per second, indicating that the system
is actively protecting
your vehicle.
If you hear asecond chirp after arming, and see the
status LED flashing in groups, refer to the Diagnostics section
of
this guide. This extra chirp is called Bypass Notification.
© 2005 directed electronics, inc. all rights reserved 7

~ passive arming
The system also can be programmed to arm itself automatically
(called passive arming).
If the system is programmed for passive
arming, it will automatically arm
30 seconds after the ignition is
turned off and the system "sees" you leave the vehicle by opening
and closing adoor. Whenever the system is in its 30-second
passive-arming
countdown, the status LED will flash twice as
fast as it does when the system is armed. The siren will chirp one
time 20 seconds after the last
door has been closed. The system
is not actually armed at that point. The system arms and the
doors lock (ifconnected
and programmed for passive locking) at
the
30 second mark, but the siren will not chirp. The early chirp
provides you with a10-second warning prior to arming.
note: If any protected entry point (such as adoor or a
switch-protected
trunk or hood) is open, the system will
not passively arm (unless forced passive arming is pro-
grammed on).
See Programming Options section of this
guide. Additionally, each time aprotected entry
is trig-
gered during the arming countdown, the 30-second
countdown starts over.
When armed, your vehicle is protected as follows:
•Light impacts will trigger the Warn Away® signal. When
triggered, the siren will chirp and the parking lights will flash
for afew seconds.
",. Heavy impacts will trigger the system. The triggered
sequence
is between 1-180 seconds of constant siren and
flashing parking lights.
8©2005 directed electronics, inc. all rights reserved

>- If a door is opened, the system will immediately start
chirping
the siren and flashing the parking lights. Three
seconds later, the siren
output changes to acontinuous blast.
This progressive response
gives you time to disarm the sys-
tem with your transmitter if you inadvertently open the door
while the system
is armed, while still providing an instant
response (even
if the door is immediately closed).
>- Turning on the ignition key will trip the same two-stage
response
as opening adoor.
,>. The optional starter kill prevents the vehicle's starter from
cranking.
["1 multi-level security arming
'-, --- - .' ---·-----------1
I note: The Multi-Level Security Arming feature is only I
Iavailable with the optional four-button transmitter pro- I
Igrammed to the expanded configuartions. I
"--.....-,.. ... '--_. __ . ---'
Multi-Level Security Arming allows you to select which of the
security system's inputs or sensors will be active
and which will
be bypassed at the time that the system
is armed. (See the Table
of Zones section of this guide.) Pressing [~'] again within five
seconds of arming the security system will activate the Multi-
Level SecurityArming feature. Each time
i-g'! is pressed again, a
____ ~ __ ._._.J
different security level is selected. The different security levels
can be selected as follows:
)I. Press [iJ one time: The siren chirps once. The system is
armed.
© 2005 directed electronics, inc. all rights reserved 9

.... Press [~lJ a second time within five seconds: The siren
chirps twice followed by a
long chirp. Zone 2 is now
bypassed.
>Press [BJ three times followed by along chirp. Zone 4 is
now bypassed.
)10- Press :-g"l afourth time within five seconds: The siren chirps
,- *-1
four times followed by along chirp. Zones 2 and 4are now
bypassed.
.". Press
raJ afifth time within five seconds: The siren chirps
five times followed by along chirp .. All input zones, except
the ignition, are now bypassed.
>- Continued pressing of [iJ will begin the Multi-Level
Security Arming cycle over again.
I
!
note: Multi-Level Security Arming only applies to asin- 1
gle arming cycle. Once the systen1 is disarmed and then I
!re-armed, all the zones will be active again. 1
L.,'', • __ ._ •. _'' __ ,••, •• ,_, __ ,.....__ ._, ._, •• , ••• _. __ ••••.•. __ ."",,, •• ' " .• ", __ • ._ •••.••• , ._. __ ,."., .• __ ., __ ,_,."
[~] arming while driving
Your system can be armed while driving the vehicle. Simply press
._---_ .•.. ,
~""" __ ._." __ .,,',,j on your transmitter for ('NO seconds while the vehicle is
running or while the ignition is on. The siren will chirp once and
then once more to indicate that the ignition
is on. The security
system will not respond to any input except the door triggers and the
Failsafe® Starter Kill (ifiristalled) will not be activated. The security
system will disarm automatically whenever the ignition
is turned of[
The siren will chirp twice and the LED will stop flashing.
10 ©2005 directed electronics, inc. all rights reserved

note: If programmed for the optional Vehicle Recovery
System (VRS®) feature, arming with the transmitter will
arm the VRS® feature. (See VRS® section of this guide.)
L _
~ disarming
To disarm the system, press t~liJ. You will hear two chirps,
and the parking lights will flash twice. If the power locks are
connected to the system, the doors will unlock.
If the siren chirps
either four or
five times when disarming, refer to the Diagnostics
section of this guide. This is called Tamper Alert.
r:.! high security disarm
.------1
This security system offers High Security Disarm. High Security
Disarm
is afeature that makes it possible to silence and reset the
system while it
is triggering, without disarming the system. If the
system
is triggered and the siren has been sounding for longer
than
six seconds, pressing [i/;-~:~::--~J on the remote transmitter will
stop the trigger
and return the unit to the armed state. The
system will not disarm, but rather reset. This prevents you from
disabling the system should you wish to disarm it without visu-
ally checking the vehicle. Pressing
ii~ __ ~~~~J, after resetting the
system, will disarm the system; pressing this
button during the
first
six seconds of the triggered sequence will disarm the security
system immediately.
The six second timer is provided for your
convenience, in case the system
is accidentally triggered.
© 2005 directed electronics. inc. all rights reserved
11

important! The unit can be programmed to respond to
one to five pulses of the Valet button for the disarm func-
tion.
Be sure to check with the installer for the desired
programmmg.
I:+J disarming without a transmitter
This feature allows you to disarm the security system without the
remote transmitter should it be lost, damaged, or disabled. In order
to disarm the system without aremote transmitter, you
must have
the vehicle's ignition key and know where the Valet button is
located. Be sure to check with the installer for the location and the
number of presses of theValet button required to disarm the system.
To
disarm the security system,
turn the ignition to the ON posi-
tion. Press
the Valet button the
preset number of times (one to
five times) within 15 seconds.
After 5seconds, the system will
now disarm. If the system does
not disarm, you may have waited
too long;
turn the ignition off and on and try again.
Location of Valet Button, _
Number of Pulses, _
r- -------------------------
!
!
I
I
I
L
r:+l silent mode
l.. ~_~_~i
12 ©2005 directed electronics, inc. all rights reserved

To temporarily turn off the arm or disarm chirps, use Silent
Mode TM. Simply press §_~J for less than one second before
arming or disarming,
and the confirmation chirp(s) will be elim-
inated for that one operation only.
If you want the arm/disarm
chirps turned
off permanently, your dealer can do this for you.
note: The Warn Away® response to lighter impacts is
bypassed if the system is armed using Silent Mode. This
ensures that no chirps will be emitted by the siren in an
area you want chirp-free.
The system is still fully capable
of triggering, only the Warn Away® response is bypassed.
[~] panic mode
If you are threatened in or near your vehicle, you can attract
attention by triggering the system with your transmitter. Just
press
[~l for two seconds, and you will enter Panic Mode. The
siren will sound and the parking lights will flash for the
programmed siren duration. To stop Panic Mode at any time,
press
r~l on the remote transmitter again.
L_" __ ,,,,-!
[-_·'--"-1
L~J valet mode
You can prevent your security system from automatically arming
and triggering by using Valet Mode. This
is very useful when
washing the vehicle or having it serviced. In Valet Mode, the
security system will
not arm, even with the remote transmitter,
but all convenience functions (door locks, trunk release, etc.)
will continue to work normally.
To enter or exit Valet Mode:
© 2005 directed electronics, inc. all rights reserved 13

1. Turn the ignition on.
2. Turn the ignition off.
3. Press
and release the Valet
switch within 10 seconds.
The status LED will light solidly if you are entering Valet Mode,
and it will go out if you are exiting Valet Mode.
To enter or exit Valet Mode using the transmitter:
1. Open any vehicle door.
2. Press :i-------:.
I.. •.•. _ .. _.-. .•..... " .....•. _..... .. }
,,
3. Press iY~i.
4 P
ia-------] .
.ress l~: iagaIn.
The status LED will light solidly if you are entering Valet Mode,
and it will go out if you are exiting Valet Mode.
~ nuisance prevention® circuitry
Your system has Directed's Nuisance Prevention® Circuitry
(NPC). It prevents annoying repetitive trigger sequences due to
faulty door
pin switches or environmental conditions such as
thunder, jackhammers, airport noise, etc.
Example
If the alarm triggers three times within a60-minute period and
each time the same sensor
or switch triggers the alarm, NPC will
interpret those triggers
as false alarms. After the third trigger, NPC
ignores, or bypasses, that sensor or switch (along with any other
sensors or switches sharing the same zone) for 60 minutes.
If the bypassed sensor tries to trigger the system while it is being
14 ©2005 directed electronics, inc. all
rights reserved

bypassed, the GO-minute bypass period will start over. This
ensures that asensor that continually triggers will remain
bypassed.
Doors are covered by
NPC differently; if the alarm is triggered
by an open
door for three full cycles, the doors will be bypassed
until the trigger ceases.
note: Arming and disarming the system does not reset this
function! The only ways to reset abypassed zone are for it
to not trigger for 60 minutes, or to turn on the ignition. If
testing your system, it is important to remember that the
NPC prcgramming can cause zones to be bypassed and
appear to stop working. If five chirps are heard when dis-
arming, NPC has been engaged. If you wish to clear the
NPC memory, turn the ignition key on.
NPC is programmable. See Programming Options section of this
guide.
©2005 directed electronics, inc. all rights reserved 15

fiiagnDstic£---------------_._-----------
The microprocessor at the heart of your security system is
constantly monitoring all of the switches and sensors that are
connected to it. It detects any faulty switches and sensors and
prevents them from disabling the entire system. The micropro-
cessor will also record
and report any triggers that occurred
during your absence. Refer to the System Status Chirps and
Table of Zones charts for diagnostic information.
l_~.l arming diagnostics
If the system is armed while an input is active (door open, sensor
triggering, etc.) the
unit will chirp once when arming and then
one more tIme afew seconds later. This is called Bypass
Notification.
note: Bypass Notification will not occur when using
SileGt
Mode™ or if chirps have been programmed OFF.
The security system will ignore the input that was active when
the system was armed, until the input goes away. Three seconds
later the system will
monitor that input normally. For example,
if your vehicle has interior light exit delay, and you arm the
system before the interior light goes out, you may hear Bypass
Notification chirps.
Once the light shuts off, however, the doors
are
monitored normally.
16 ©2005 directed electronics. inc. all rights reserved

~J disarming diagnostics
Extra disarm chirps are the Tamper Alert. If four chirps are heard
when disarming, the system
was triggered in your absence. If five
chirps are heard, azone was triggered so many times that Nuisance
Prevention® Circuitry has bypassed that zone. In either
case, the
status LED will indicate which
wne was involved. (See Table of
Zonessection of this guide.) The system will retain this information
in its memory, and continue to chirp four
or five times each time it
is disarmed, until the next time the ignition key is turned on.
r~l system status chirps
L,,_,_.J
The siren will chirp when arming/disarming the system. The
pattern of chirps will audibiy report the system's status as
described below.
Action
Arm
Arm
Disarm
Disarm
Disarm
Number of Chirps
1
1 (3 second delay), 1
2
4
5
Description
System armed
System
armed with
zone actlve
System disarmed
System disarmed with
zone violation report
System disarmed
NPC
active
©2005 directed electronics, inc. all rights reserved 17
