Congratulations
Congratulations on the purchase of your state-of-the-art security system.
Reading this owner’s guide prior to using your system will help maxi-
mize the use of your system and its many features. For more informa-
tion please visit the below website:
http://www.pythoncarsecurity.com – For general and additional
guide information.
For any additional questions please contact your authorized Directed
dealer or contact Directed at 1-800-753-0600.
What you get
Welcome to the best generation of vehicle security. Your system con-
tains everything you need.
Responder LC remote controls
1-way companion remote controls
AC adapter for charging your remote controls
This owner’s guides
Quick reference cards
Warranty cards
AUX
Warranty
Card
Owner’s
Guide
Quick
Reference Card
G3303P 2009-11

Important information
Your Warranty
Your system comes with a warranty. Please make sure you receive the
warranty registration card and proof of purchase from your dealer
indicating the product was installed by an authorized Directed dealer.
Your product warranty must be validated within 10 days of purchase.
You can validate it online at www.prodregister.com/directed or com-
plete and return the warranty registration card.
Quick Reference Card
Carry this card with you to reference your system’s many features.
Replacement Remote Controls
If additional remote controls are desired, please see your authorized
dealer or visit us at www.directedstore.com to order. Part numbers
are: 7351P for Responder LC 2-way remote control and 7153P for
the 1-way companion remote control.

Contents
Getting Started.................................................................................................... 4
Charging the Remote Control ................................................................ 4
Keys to using this Manual ..................................................................... 5
Responder LC 2-Way...........................................................................................6
Status Screen Icons..............................................................................................8
Using your System............................................................................................. 11
Commands and Confirmations ............................................................ 11
Performing Commands ....................................................................... 11
Responder LC Command table ............................................................ 12
Basic Commands (Direct Access) ........................................................................ 13
Arm ................................................................................................. 13
Disarm ............................................................................................. 13
AUX/Trunk........................................................................................ 14
Remote Start /AUX 1/ AUX 4 ............................................................. 14
Advanced Commands: (Level 1) ......................................................................... 15
Silent Arm......................................................................................... 15
AUX 1.............................................................................................. 15
Advanced Commands: (Level 2) ......................................................................... 16
Sensor Bypass ................................................................................... 16
Remote Valet .................................................................................... 16
AUX 2.............................................................................................. 16
Advanced Commands: (Level 3) ......................................................................... 17
Sensor Silent Arm* ............................................................................ 17
AUX 3.............................................................................................. 17
Alarm Report*................................................................................... 18
Advanced Commands: (Level 4) ......................................................................... 19
Full Silent Arm* ................................................................................. 19
AUX 4.............................................................................................. 19
Responder LC Configuration............................................................................... 20
Navigating Menus and Options .......................................................... 20
Button Operation ............................................................................... 20
Access Menu Items ............................................................................ 20
Main Menu....................................................................................................... 21
Setup Remote Menu: .......................................................................... 21
Remote Start Info ............................................................................... 22
Runtime Alert..................................................................................... 22
Car 2............................................................................................... 23
BackLight.......................................................................................... 23
Temp Unit ......................................................................................... 23
Button Beep....................................................................................... 23
System Type ...................................................................................... 23

Clock Set .......................................................................................... 24
Review ............................................................................................. 24
Exit .................................................................................................. 24
Sensor Adjust: ................................................................................... 24
Pair a Responder LC remote control: .................................................... 24
Demo Mode:..................................................................................... 25
Power Off: ........................................................................................ 26
Exit: ................................................................................................. 26
Alarm Features ................................................................................................. 27
Normal Arm Protection....................................................................... 27
Sensor Silent Arm Protection................................................................ 27
Full Silent Arm Protection .................................................................... 28
Sensor Warn-away Messages ............................................................. 28
Full Trigger Messages......................................................................... 28
Emergency Override .......................................................................... 28
Trigger Zone Fault Report.................................................................... 29
Alarm Report when Disarming............................................................. 29
Alarm Report when Requested............................................................. 30
Nuisance Prevention (NPC)................................................................. 30
Remote and System Operations.......................................................................... 31
Passive Arming*................................................................................ 31
Auto Re-arming*................................................................................ 31
Valet Mode ....................................................................................... 32
Power Save....................................................................................... 32
Rapid Resume ................................................................................... 32
Automatic Remote Updates ................................................................. 32
Out of Range .................................................................................... 33
No Remote Output............................................................................. 33
Car Select......................................................................................... 33
Vehicle Recovery System (VRS) ............................................................ 34
1-way Companion Remote Control..................................................................... 35
Accessing Commands ........................................................................ 36
Button Auto Lock................................................................................ 36
Car Select......................................................................................... 36
Programming .................................................................................... 37
Battery Information (1-way) ................................................................. 38
Low Battery Alerts .............................................................................. 38
Battery Replacement........................................................................... 38
System Expansion Options................................................................................. 39
Battery Information (Responder LC)..................................................................... 41
Low Battery....................................................................................... 41
Battery Life........................................................................................ 42
Battery Disposal ................................................................................ 43

Glossary of Terms.............................................................................................. 44
Government Regulations .................................................................................... 46
Additional information....................................................................................... 47
Interference....................................................................................... 47
Upgrades and Batteries ...................................................................... 47
Water/Heat Resistance ...................................................................... 47
Limited lifetime consumer warranty ..................................................................... 48

4© 2009 Directed Electronics. All rights reserved.
Getting Started
Your remote control is powered by an internal rechargeable battery
that can only be serviced by an authorized Directed dealer. Due to
transit and storage time prior to your purchase, the battery charge
may have depleted. To ensure proper operation, check the battery
level and connect the battery charger if not fully charged. See Bat-
tery Information and Status Screen Icons sections for more information
about the battery.
Charging the Remote Control
Plug the AC adapter into a 110V AC outlet. Insert the mini-USB1.
connector into the mini-USB port located on the side of the
remote control (see diagram under Responder LC 2-way). The
text field will display CHARGE to indicate the remote control is
charging (The remote remains operational while charging and
can command the system).
Once fully charged the text field will display2. FULL .
The remote control is then ready for use. Disconnect the mini-3.
USB end from the remote control first and then the AC adapter
from the AC outlet.
Note The remote control remains operational while charging and
can command the system.
If the battery is excessively depleted when the charger is
connected, functionality may be delayed while it charges to
the minimum voltage required to operate the display, after
which normal charging resumes.

5
© 2009 Directed Electronics. All rights reserved.
Keys to using this Manual
Specific actions (in bold type) and style conventions are used consis-
tently throughout this manual, they are as follows:
Press:s implies pushing in and releasing a button.
Hold:s is used after “press” actions when a button needs to be
held in position for an extended period of time, typically several
seconds.
ARMED
s this style denotes the text which appears in the text field
portion of the display during operations described in the manual.
If the text string is too long for the text field, it then plays and loops
sequentially word by word.
Italicizeds words denote section/sub headings in this guide and
can be located through the table of contents.
An asterisk (*) when used after a word or phrase denotes thats
additional details can be found in related sections usually noted
at the bottom of the page or end of the section.

6© 2009 Directed Electronics. All rights reserved.
Responder LC 2-Way
Command
Buttons
Display
Function Button
Mini-USB Port
Internal
Antenna
Feature Description
Internal Antenna Used for transmitting and receiving information
Display Status screen - the upper portion of the display contains status
icons for the system, siren, alarm zones, and remote control
Text field - the lower portion of display shows the clock,
command confirmations, page messages and programming
menus
Command Buttons (4) Used to perform arming, disarming and auxiliary channel
commands
Function Button Used to access function levels for commands, configuration
menus for programming, and car selection
Mini-USB Port The battery charger plugs into this port

7
© 2009 Directed Electronics. All rights reserved.
Control Center
Control Center
Button
Control Center
LED
The control center, typically located on the upper part of the front
windshield sends and receives commands or messages to and from
your system. It consists of:
The In-vehicle system antenna, for 2 way communication.s
The control center LED, as a visual indicator of the system’s sta-s
tus.
The control center button, for placing the system into valet mode*s
and to perform the emergency override** operation.
* See Remote and System Operations section for details.
** See Alarm Features for details.

8© 2009 Directed Electronics. All rights reserved.
Status Screen Icons
1
ALL
Text Field
Status Screen
Icons
The table below describes all the status screen icons.
Icon Description
System Status
Armed: The system is armed, the alarm is enabled
Locked: The system is locked in valet, the alarm is disabled
Disarmed: The system is disarmed, the alarm is disabled
Unlocked: The system is unlocked in valet, the alarm is disabled
Siren Status
Siren is disabled for sensor triggers; remote is paged for all trig-
gers (sensor silent arm)
+ ALL Siren is disabled for all triggers; remote is paged for all triggers
(full silent arm)
Zone Status
On during warn-away and full trigger message output
On during trunk zone full trigger output and aux/trunk channel
activation
On during fault report to indicate the trunk is open and
bypassed when arming

9
© 2009 Directed Electronics. All rights reserved.
Icon Description
Zone Status
On during a sensor zone full trigger output
On during fault report to indicate a sensor is active and
bypassed when arming
On during the door zone full trigger output
On during fault report to indicate a door is open and bypassed
when arming
On during a hood zone full trigger output
On during fault report to indicate the hood is open and
bypassed when arming
On when remote is set to command the system programmed
as car 1*
On when remote is set to command the system programmed
as car 2*
Remote Control Status
Bars indicate battery level is full, ¾,½,¼ or empty
On while the remote control is transmitting a command
On while the remote control is receiving a message
On with out of range fault tone to indicate the remote failed to
receive a command confirmation
Pager on: The remote will wake up to listen for messages
Pager off: The remote will not wake up to listen for messages
The remote will vibrate when messages are received
The remote will emit beeps and tones when messages are
received

10 © 2009 Directed Electronics. All rights reserved.
Icon Description
Text field Displays the clock, message text and feature menus
On after the garage open** message has been received
On after the garage closed** message has been received
Remote start is active, the engine is running (with optional
remote start module only)
* This icon not present until the car 2 is turned on in the Setup Remote
configuration menu.
** This icon not present until the remote is paired with an optional
garage door opener.

11
© 2009 Directed Electronics. All rights reserved.
Using your System
Commands and Confirmations
Commands, basic or advanced, are used to activate system fea-
tures and are performed by pressing one of the command buttons.
Basic commands control the most often used security features while
advanced commands control more specialized features and request
reports.
Confirmations for basic or advanced commands are indicated
first by siren chirps and parking light flashes, and then by text, icons
and beeps or tones on the remote control. A description of each
feature confirmation is found in the Basic Commands and Advanced
Commands sections.
Performing Commands
Perform basic commands by pressing one of the command buttons
while in the direct access level. Direct access is available while the
text field displays the clock. Perform advanced commands by first
accessing one of the function Levels and then pressing one of the com-
mand buttons while within a level. Function Levels are available when
the text field displays LEVEL 1,2,3 or 4.
Advanced Command example: Silent Arm
Press1. the
button once to access function level 1, the text
field will display LEVEL 1 .
Press2. the
button while LEVEL 1 text is still on to perform the
silent arm command.
The Responder LC remote will display3. SILENT ARMED in the
text field and update the status screen icons.

12 © 2009 Directed Electronics. All rights reserved.
Responder LC Command table
Button
Level Direct Access x 1
LEVEL 1
x 2
LEVEL 2
x 3
LEVEL 3
x 4
LEVEL 4
Arm/Lock
(Panic)
Silent Arm Sensor
Bypass
Sensor Silent
Arm
Full Silent
Arm
Disarm/Unlock Silent Disarm Remote Valet Car Finder
Remote Start*/
Aux 1/4**
A U XAux/Trunk AUX 1 AUX 2 AUX 3 AUX 4
Advance Level
Change Car
(3s), Enter
programming
(8s)
Alarm
Report
* Available only with optional remote start module installation
** This button can command either aux 1 or aux 4 if turned on by
an authorized Directed dealer.

13
© 2009 Directed Electronics. All rights reserved.
Basic Commands (Direct Access)
Arm
Press and release
The alarm arms, doors lock (if connected), and the siren
chirps and parking lights flash once. The ARMED text and beeps play
to confirm and the system status icons update. If valet mode* is on,
the doors lock and the VALET text and tone play. Exit valet mode to
arm the alarm normally.
If a trigger zone fault is detected the siren chirps once again and the
trigger zone fault report** plays.
To Arm and Panic
Press and hold
The alarm arms (or locks in valet) and, after 2 seconds, sounds
the siren and flashes the parking lights. The PANIC text and
siren tones play to confirm. Press the or button to stop
the output.
Disarm
Press and release
The alarm disarms, doors unlock (if connected), and the siren chirps
and parking lights flash twice. The DISARM text and beeps play to
confirm and the system status icons update. If valet mode* is on, the
doors unlock and the VALET text and tone play.
More than 2 siren chirps and remote beeps indicate a trigger has oc-
curred. The DISARM text is replaced by the alarm report.**
6:30

14 © 2009 Directed Electronics. All rights reserved.
AUX/Trunk
Press and hold AUX
The trunk opens (if connected) when this button is pressed for 2 sec-
onds. The TRUNK text and tones play to confirm.
Remote Start /AUX 1/ AUX 4
Press and release
Remote Start***
Activates (or if on, deactivates) the remote starter. The engine and
parking lights turn on or off accordingly. The REMOTE START ON
text and tones play, or the REMOTE START OFF text and tones play
to confirm. The icon is displayed in the status screen while the
engine is running.
AUX 1/AUX 4****
Activates (or if on, deactivates) the aux 1 or aux 4 output. The
programmed text and on tones or off tones play to confirm, (See
System Expansion Options).
* See Remote and System Operations for details.
** See Alarm Features for details.
*** Available only with optional Remote Start module installation.
**** This feature must be turned on by an authorized Directed dealer.

15
© 2009 Directed Electronics. All rights reserved.
Advanced Commands: (Level 1)
Press and release the button 1 time.
Silent Arm
Press and release
The alarm arms, doors lock (if connected), and the parking lights flash
once. The SILENT ARMED text plays to confirm and the system status
icons update. Valet mode* or trigger zone fault report** messages
may be received.
Silent Disarm
Press and release
The alarm disarms, doors unlock (if connected), and the parking lights
flash twice. The SILENT DISARM text plays to confirm and the system
status icons update. The alarm report** may replace the silent disarm
text.
AUX 1
Press and release AUX
Activates (or if on, deactivates) the aux 1 output. The programmed
text and on tones or off tones play to confirm, (See System Expansion
Options).
* See Remote and System Operations section for details.
** See Alarm Features for details.
level 1

16 © 2009 Directed Electronics. All rights reserved.
Advanced Commands: (Level 2)
Press and release the button 2 times.
Sensor Bypass
Press and release
Performing the sensor bypass command will incrementally bypass sen-
sor operations and be confirmed as follows:
Warn-away bypass: The parking lights flash 2 times,s
BYPASS WARN 1 beep and 1 fault tone play to confirm. Sensors
will be activated for full trigger levels of impact only.
Warn-away full trigger bypass: The parking lights flash 3 times,s
BYPASS FULL , 1 beep and 2 fault tones play to confirm. Sensors
will not be activated for any level of impact.
Sensor Bypass off: The parking lights flash 1 times BYPASS OFF
and 1 beep play to confirm. Sensors are fully operational.
If disarmed, NOT AVAILABLE and a fault tone will play.
Remote Valet
Press and release
Enters (or if on, exits) valet mode. The VALET text and beeps (1 for
on, 2 for off) play to confirm and the system status icons update. See
Valet Mode for more details
AUX 2
Press and release AUX
Activates (or if on, deactivates) the aux 2 output. The programmed
text and on tones or off tones play to confirm, (See System Expansion
Options).
level 2

17
© 2009 Directed Electronics. All rights reserved.
Advanced Commands: (Level 3)
Press and release the button 3 times.
Sensor Silent Arm*
Press and release
The alarm arms, doors lock, the siren chirps and parking lights flash 3
times. The SENSOR SILENT ARM text and beeps play to confirm and the
system and siren status icons update.
Car finder
Press and release
The siren emits one long chirp and the parking lights flash for 10
seconds. The CAR FINDER text and beeps play to confirm. The
parking light flashes stop if armed or disarmed while car finder is in
progress.
AUX 3
Press and release AUX
Activates (or if on, deactivates) the aux 3 output. The programmed
text and on tones or off tones play to confirm, (See System Expansion
Options).
level 3
