Directed Electronics Python 990 User manual

MMooddeell999900
➤
OOwwnneerr’’ssGGuuiiddee

i
© 2006 directed electronics—all rights reserved
lliimmiitteeddlliiffeettiimmeeccoonnssuummeerrwwaarrrraannttyy
Directed Electronics ("Directed") promises to the original purchaser to repair or replace
with a comparable reconditioned model any Directed unit (hereafter the "unit"), exclud-
ing without limitation the siren, the remote transmitters, the associated sensors and acces-
sories, which proves to be defective in workmanship or material under reasonable use dur-
ing the lifetime of the vehicle provided the following conditions are met: the unit was pro-
fessionally installed and serviced by an authorized Directed dealer; the unit will be pro-
fessionally reinstalled in the vehicle in which it was originally installed by an authorized
Directed dealer; and the unit is returned to Directed, shipping prepaid with a legible copy
of the bill of sale or other dated proof of purchase bearing the following information: con-
sumer's name, telephone number and address; the authorized dealers name, telephone
number and address; complete product description, including accessories; the year, make
and model of the vehicle; vehicle license number and vehicle identification number. All
components other than the unit, including without limitation the siren, the remote trans-
mitters and the associated sensors and accessories, carry a one-year warranty from the date
of purchase of the same. This warranty is non-transferable and is automatically void if: the
original purchaser has not completed the warranty card and mailed it within ten (10) days
of the date of purchase to the address listed on the card; the unit's date code or serial num-
ber is defaced, missing or altered; the unit has been modified or used in a manner con-
trary to its intended purpose; the unit has been damaged by accident, unreasonable use,
neglect, improper service, installation or other causes not arising out of defects in materi-
als or construction. The warranty does not cover damage to the unit caused by installa-
tion or removal of the unit. Directed, in its sole discretion, will determine what consti-
tutes excessive damage and may refuse the return of any unit with excessive damage. TO
THE MAXIMUM EXTENT ALLOWED BY LAW, ALL WARRANTIES, INCLUD-
ING BUT NOT LIMITED TO EXPRESS WARRANTY, IMPLIED WARRANTY,
WARRANTY OF MERCHANTABILITY, FITNESS FOR PARTICULAR PURPOSE
AND WARRANTY OF NON-INFRINGEMENT OF INTELLECTUAL PROPERTY,
ARE EXPRESSLY EXCLUDED; AND DIRECTED NEITHER ASSUMES NOR
AUTHORIZES ANY PERSON OR ENTITY TO ASSUME FOR IT ANY DUTY,
OBLIGATION OR LIABILITY IN CONNECTION WITH ITS PRODUCTS.
DIRECTED DISCLAIMS AND HAS ABSOLUTELY NO LIABILITY FOR ANY
AND ALL ACTS OF THIRD PARTIES INCLUDING ITS AUTHORIZED DEAL-
ERS OR INSTALLERS. DIRECTED SECURITY SYSTEMS, INCLUDING THIS
UNIT, ARE DETERRENTS AGAINST POSSIBLE THEFT. DIRECTED IS NOT
OFFERING A GUARANTEE OR INSURANCE AGAINST VANDALISM, DAM-
AGE OR THEFT OF THE AUTOMOBILE, ITS PARTS OR CONTENTS; AND
HEREBY EXPRESSLY DISCLAIMS ANY LIABILITY WHATSOEVER, INCLUD-
ING WITHOUT LIMITATION, LIABILITY FOR THEFT, DAMAGE AND/OR
VANDALISM. THIS WARRANTY DOES NOT COVER LABOR COSTS FOR
MAINTENANCE, REMOVAL OR REINSTALLATION OF THE UNIT OR ANY

ii © 2006 directed electronics—all rights reserved
CONSEQUENTIAL DAMAGES OF ANY KIND. IN THE EVENT OF A CLAIM
OR A DISPUTE INVOLVING DIRECTED OR ITS SUBSIDIARY, THE PROPER
VENUE SHALL BE SAN DIEGO COUNTY IN THE STATE OF CALIFORNIA.
CALIFORNIA STATE LAWS AND APPLICABLE FEDERAL LAWS SHALL APPLY
AND GOVERN THE DISPUTE. THE MAXIMUM RECOVERY UNDER ANY
CLAIM AGAINST DIRECTED SHALL BE STRICTLY LIMITED TO THE
AUTHORIZED DIRECTED DEALER'S PURCHASE PRICE OF THE UNIT.
DIRECTED SHALL NOT BE RESPONSIBLE FOR ANY DAMAGES WHATSOEV-
ER, INCLUDING BUT NOT LIMITED TO, ANY CONSEQUENTIAL DAMAGES,
INCIDENTAL DAMAGES, DAMAGES FOR THE LOSS OF TIME, LOSS OF
EARNINGS, COMMERCIAL LOSS, LOSS OF ECONOMIC OPPORTUNITY
AND THE LIKE. NOTWITHSTANDING THE ABOVE, THE MANUFACTURER
DOES OFFER A LIMITED WARRANTY TO REPLACE OR REPAIR THE CON-
TROL MODULE AS DESCRIBED ABOVE. Some states do not allow limitations on
how long an implied warranty will last or the exclusion or limitation of incidental or con-
sequential damages. This warranty gives you specific legal rights and you may also have
other rights that vary from State to State.
This product may be covered by a Guaranteed Protection Plan ("GPP"). See your autho-
rized Directed dealer for details of the plan or call Directed Customer Service at 1-800-
876-0800. Directed security systems, including this unit, are deterrents against possible
theft. Directed is not offering a guarantee or insurance against vandalism, damage or theft
of the automobile, its parts or contents; and hereby expressly disclaims any liability what-
soever, including without limitation, liability for theft, damage and/or vandalism.
Directed does not and has not authorized any person or entity to create for it any other
obligation, promise, duty or obligation in connection with this security system.
Make sure you have all of the following information from your dealer:
A clear copy of the sales receipt, showing the following:
➤Date of purchase
➤Your full name and address
➤Authorized dealer's company name and address
➤Type of alarm installed
➤Year, make, model and color of the automobile
➤Automobile license number
➤Vehicle identification number
➤All security options installed on automobile
➤Installation receipts

1
© 2006 directed electronics—all rights reserved
lliimmiitteeddlliiffeettiimmeeccoonnssuummeerrwwaarrrraannttyy..................................................................................ii
ssttaannddaarrddttrraannssmmiitttteerrccoonnffiigguurraattiioonn................................................
..................................33
wwhhaattiissiinncclluuddeedd................................................
..............................................................44
iimmppoorrttaannttiinnffoorrmmaattiioonn...............
.....................................................................................44
your warranty. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
fcc/id notice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
caution. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
rreemmootteeccoonnt
trroollddiiaaggrraamm....................................................................................................77
ssttaannddaarrddrreemmootteeccoonnffiigguurraattiioonn..........................................................
..............................88
ssyysstteemmmmaaiinntteennaannccee..................................................
......................................................99
ttrraannssmmiitttteerrffuunnccttiioonnss.......................
...............................................................................1100
standard configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
standard icon configurations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
rreemmootteeooppeerraattiioon
naannddpprrooggrraammmmiinnggiinnssttrruuccttiioonnss..........................................................1155
system signal paging features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
programmable remote control features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
uussiinnggyyo
ouurrssyysstteemm..........................................................................................
..............1188
warning! safety first . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
active arming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
passive arming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
multi-level security arming. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
arming while driving . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
disarming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
high security disarm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
disarming without a transmitter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
silent mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
panic mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
valet mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
remote start . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
valet take-over . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
short-run/turbo . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
timer mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
rear defogger . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
ssaaffeettyyffeeaattuurreess..................................................................
..............................................3333
starter anti-grind circuitry . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
disabling the remote start system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
over and under rev protection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
shut down inputs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
nuisance prevention circuitry . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
ddiiaaggnnoossttiiccss......................................
..............................................................................3366
ttaabblleeooffccoonntteennttss

2© 2006 directed electronics—all rights reserved
arming diagnostics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
disarming diagnostics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
system status chirps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
table of zones . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
interpreting zone diagnostics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
ccooddeehhooppppiinngg......................................................................................
........................4400
hhiigghhffrreeqquueennccyy...........................................................
.................................................4411
oowwnneerrrreeccooggnniittiioonn..............................
........................................................................4411
rraappiiddrreessuummeellooggiicc.......
.................................................................................................4422
p
poowweerrssaavveerrmmooddee........................................................................................................4422
pprrooggrraammmmiinnggrreemmootteeccoonnttrroollffeeaattuurreess..........................................
................................4433
To enter programming mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
To exit programming mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Page notification (Beep or Vibrate). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Illumination (On or Off) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Sensor icon selection (hood/trunk). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Page mode (On/Off) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
pprrooggrraammmmiinnggooppttiioonnss...........................................
.......................................................4444
gglloossssaarryyoofftteerrmmss.........................
.................................................................................4499
qquuiicckkrreeffeerreennccee
gguuiiddee....................................................................................................5511

3
© 2006 directed electronics—all rights reserved
ssttaannddaarrddttrraannssmmiitttteerrccoonnffiigguurraattiioonn
controls the AArrmmand PPaanniiccOn/Off function.
controls the DDiissaarrmmand PPaanniiccOff function.
controls SSiilleennttMMooddee™™and AAuuxxiilliiaarryychannel 22output.
controls the RReemmootteeSSttaarrttfunction.
and pressed together control the TTiimmeerrmode.
and pressed together control TTuurrbboo//SShhoorrttRRuun
n.
and pressed together control channel 44output.
and pressed together control channel 5 output.
and and pressed together control the rear
defogger.
and pressed together control channel 6 output.

4© 2006 directed electronics—all rights reserved
wwhhaattiissiinncclluuddeedd
➤A control module
➤SST 2 way receiver/antenna
➤One four-button transmitter
➤A Stinger™ DoubleGuard® two-stage shock sensor
➤A Revenger™ Soft Chirp™ six-tone programmable siren
➤A blue status LED indicator light
➤A push-button Valet switch
➤Your warranty registration
➤A shut-down toggle switch
iimmppoorrttaannttiinnffoorrmmaattiioonn
Congratulations on the purchase of your combination remote
start alarm system. Due to the complexity of this system, it must
be installed by an authorized dealer only. Installation of this
product by anyone other than an authorized dealer voids the
warranty. All dealers are provided with a preprinted dealer certifi-
cate to verify authorization.
By carefully reading this Owner's Guide prior to using your
system, you will maximize the use of this system and its features.
You can print additional or replacement copies of this manual by
accessing our web site at www.directed.com.

5
© 2006 directed electronics—all rights reserved
your warranty
Your warranty registration must be completely filled out and
returned within 10 days of purchase. Your product warranty
will not be validated if your warranty registration is not returned.
Make sure you receive the warranty registration from your dealer.
It is also necessary to keep your proof of purchase, which reflects
that the product was installed by an authorized dealer.
fcc/id notice
This device complies with Part 15 of FCC rules. Operation is
subject to the following two conditions: (1) This device may not
cause harmful interference, and (2) This device must accept any
interference received, including interference that may cause
undesirable operation.
Changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to
operate this device.
IIVVUU,,IInnvveehhiicclleerreecceeiivveerruunniitt
To satisfy FCC RF exposure compliance the device and its
antenna must maintain a separation distance of 20 cm or more
from a person’s body, except for the hand and wrists, to satisfy
RF exposure compliance.
HHHHUU,,hhaannddhheelldduunniitt
To satisfy FCC RF exposure compliance requirements, this
device should be used in hand-held, hand operated
configurations only. The device and its antenna must maintain
➜
➜

6© 2006 directed electronics—all rights reserved
a separation distance of 20 cm or more from the person’s body,
except for the hand and wrists, to satisfy RF exposure compli-
ance. This device is designed to be used in a person’s hands and
its operating configurations do not support normal transmis-
sions while it is carried in pockets or holsters next to a persons’
body.
caution
This product is designed for fuel injected, automatic transmis-
sion vehicles only. Use of this product in a standard transmission
vehicle is dangerous and contrary the product's intended use.
➜

7
© 2006 directed electronics—all rights reserved
rreemmootteeccoonnttrroollddiiaaggrraamm
note:The Program button is located on the back of
the remote.

8© 2006 directed electronics—all rights reserved
ssttaannddaarrddrreemmootteeccoonnffiigguurraattiioonn
1. Auxiliary Channel Out
2. Receive Indicator
3. Signal Indicator
4. Transmit Indicator
5. Lock Status Indicator
6. Unlock Status Indicator
7. Arming Status Indicator
8. Disarming Status Indicator
9. Door Switch Input Indicator
10. Warn Away®Response Indicator
11. Siren Status Indicator
12. Battery Level Indicator
13. Trigger Response Indicator
14. Hood Switch Input Indicator
15. Ignition Switch Input Indicator
16. Sensor Response Indicator
17. Sensor 1 Indicator—Full Trigger and Warn Away®
18. Sensor 2 Indicator—Full Trigger and Warn Away®
19. Trunk Switch Input Indicator
20. Vibrate Mode Indicator
21. Remote Start Indicator
22. Disarm Button
23. Remote Start Button
24. Auxiliary Button
25. Arm Button

9
© 2006 directed electronics—all rights reserved
ssyysstteemmmmaaiinntteennaannccee
This system needs no specific maintenance beyond remote
control battery replacement. The remote is powered by a 1.5V
AAA battery.
The Battery Level indicator has four level indicators that serve as
a visual indication of battery charge. When the battery reaches a
low charge level that requires replacement, the remote control
will generate a single notification chirp, and the Battery Level
indicator will flash continuously.
Battery Replacement
Gently pull the end of the battery door away from the top of the
remote control then slide the door up to expose the battery and
remove the expired battery. Place the new battery into the remote
control observing the correct polarity. When power is returned
the remote control will light all icons in the LCD and generate all
beeper tones once.
EMPTY
REPLACE
FULL

10 © 2006 directed electronics—all rights reserved
ttrraannssmmiitttteerrffuunnccttiioonnss
The receiver uses a computer-based Learn Routine to learn the
transmitter buttons. This makes it possible to assign any remote
transmitter button to any receiver function. The transmitter
initially comes programmed with Standard Configuration, but
may also be customized by an authorized dealer. The buttons in
all of the instructions in this manual correspond to a Standard
Configuration transmitter.
standard configuration
Button
The arming function is controlled by pressing this button for one
second. Pressing and holding this button for more than 3 seconds
will trigger the panic mode.
Button
The disarming function is controlled by pressing this button for
one second. Pressing this button during panic mode will turn off
the panic mode.
Button
Silent Mode™ and an optional auxiliary function are controlled
by this button. (Silent Mode works by pressing this button for
less than one second before arming or disarming. An optional
auxiliary function, such as trunk release, can be controlled by
pressing this button for 1.5 seconds.)
The auxiliary output controls __________________________.
➜

11
© 2006 directed electronics—all rights reserved
Button
The remote start feature is turned On/Off by pressing this button
twice.
and Buttons
The remote start timer mode function of the system is controlled
by pressing these buttons simultaneously.
and Buttons
The Turbo/Short Run feature is controlled by these buttons (refer
to the Turbo/Short Run section for additional details).
and Buttons
An optional auxiliary convenience or expansion function that
you have added to your system can be activated by pressing these
buttons simultaneously.
The auxiliary output controls __________________________.
and Buttons
An optional auxiliary convenience or expansion function that
you have added to your system can be activated by pressing these
buttons simultaneously.
The auxiliary output controls __________________________.
and and Buttons
When simultaneously pressed these buttons control the rear
window defogger during remote starting.

12 © 2006 directed electronics—all rights reserved
and Buttons
An optional auxiliary convenience or expansion function that
you have added to your system can be activated by pressing these
buttons simultaneously.
The auxiliary output controls __________________________.
standard icon configurations
Icon
The transmit icon will be displayed while the remote control is
transmitting a command to the vehicle.
Icon
The receive icon will be displayed while the remote control is
receiving a page from the vehicle.
Icon
The signal icon will be displayed if a command is transmitted to
the vehicle but a command page is not received.
Icon
The armed status icon will be displayed when the system is locked
and armed.
Icon
The disarmed status icon will be displayed when the system is
unlocked and disarmed.
Icon
The disarm icon will flash while the system is disarming.
➜

13
© 2006 directed electronics—all rights reserved
Icon
The arm icon will flash while the system is arming.
Icon
The door icon will be displayed to indicate that a door is open
when arming the system (Bypass Notification) or opened when
the system is armed (Tamper Alert).
Icon
The warn icon will be displayed if the Warn Away®response has
been triggered while the system is armed.
Icon
The siren icon will be displayed as an indicator that the siren is
sounding.
Icon
The alarm icon will be displayed if the system has been violated,
and will continue to be displayed until the 60-second siren cycle
is complete.
Icon
The vibrate icon will be displayed when the Vibrate Mode is on.
Icon
The battery level icon is always displayed as an indicator of
Battery charge.
Icon
The start icon will be displayed while the vehicle is remote started.

14 © 2006 directed electronics—all rights reserved
Icon
The trunk icon will be displayed to indicate that the trunk is
open when arming the system (Bypass Notification) or opened
when the system is armed (Tamper Alert).
Icon
The Sensor 1 icon will be displayed if the Dual-Stage shock sensor
has been triggered as a full-triggered or Warn Away® sequence.
Icon
The Sensor 2 icon will be displayed if an additional Dual-Stage
sensor has been triggered as a full-triggered or Warn Away®
sequence.
Icon
The hammer icon will flash when either Sensor 1 or 2 has been
triggered as either a Warn Away®response or triggered sequence.
Icon
The ignition icon will be displayed to indicate that the ignition is
on when arming the system (Bypass Notification) or turned on
when the system is armed (Tamper Alert).
Icon
The hood icon will be displayed to indicate that the hood is open
when arming the system or (Bypass Notification) opened when
the system is armed (Tamper Alert).
note: If Page Mode has been turned off, the start icon will
remain when performing key take over until a button on
the transmitter has been pressed.

15
© 2006 directed electronics—all rights reserved
Number Icons
When either of the channel 2, 4 or 5 outputs is activated the
appropriate icon will be displayed for five seconds.
rreemmootteeooppeerraattiioonnaannddpprrooggrraamm--
mmiinnggiinnssttrruuccttiioonnss
The remote start system operates at 434 MHz and incorporates
Directed’s proprietary XHF2 out-board Responder Technology remote
control. The high frequency combined with Binary Data communica-
tion achieves superior range with two-way communication.
system signal paging features
A page is the signal the control module sends to the remote control
as confirmation of receipt of a command or alarm system status.
When the remote control receives a page it will generate a page
notification to the user (notifications are audible beeps or remote
vibration) and the LCD Icons will display the current system status.
Command Page
When a command (arm/disarm, remote start, or auxiliary
channel) from the remote control is sent and received, the system
will send a command page back to confirm receipt.
note: When the system is in Valet mode, the remote con-
trol will show the lock (5) and unlock (6) icons, but will
not generate a command page.
➜

16 © 2006 directed electronics—all rights reserved
Alarm Page
If the alarm system is triggered while armed, an Alarm Page will
be sent to the remote control. After receipt of an Alarm Page, the
LCD icons will display the alarm system status information and
the remote control will generate Alarm Page alerts.
An Alarm Page alert is a single beep or vibration from the remote
control every 60 seconds to alert the user that the alarm system
was triggered and will continue until the alarm page is cleared.
Page Recognition Mode
The remote control will leave a zone icon illuminated when it has
received a triggered response and will wait for you to recognize
the violation. Press any button on the remote control, the LCD
information and Alarm Page alerts will be cleared.
note: The remote control buttons will not send a com-
mand to the system until the alarm page is cleared.
note: If the transmitter is paged with an Alarm Page and
the WarnAway®is triggered before the Alarm Page is
relieved the transmitter will report the WarnAway®only
until the system is disarmed.

17
© 2006 directed electronics—all rights reserved
programmable remote control features
To enter programming mode
Press the Program button on the back of the remote or hold the
four remote control buttons on the front of the remote simultane-
ously until one long beep is heard. Programming Mode has now
been entered.
Page Notification
The remote control can be programmed to notify the user of a
page by audibly beeping or remote vibration.
Beep Mode
Beep Mode includes alarm arm/disarm diagnostic beeps and
distinctive two-tone remote start beeps.
Vibrate Mode
Vibrate Mode makes page notification silent but does not include
diagnostic information or distinctive remote start notification.
Illumination
Illumination for the LCD display can be programmed on or off.
When programmed on the LCD will illuminate every time the
remote control receives a page or transmits a command.
Programming illumination on will decrease the life expectancy of
the battery.
Beep/Vibrate Mode
Within five seconds of entering Programming Mode, press .
The remote control will beep once for on, twice for off. The
vibrate icon (13) will also turn on/off with each press.
➜
