Directed Electronics 4103 Series User manual

Model 4103
Remote Start
Owner’s Guide
© 2008 Directed Electronics, Vista, CA
G4103L 2008-07

Contents
Government Regulations ....................................................................................5
Warning! Safety first .........................................................................................7
What is Included ............................................................................................9
Important Information ........................................................................................9
System Maintenance .................................................................................9
Your Warranty..........................................................................................9
Transmitter Functions........................................................................................10
Standard Configuration ...........................................................................10
Using Your System .........................................................................................11
Locking..................................................................................................11
Unlocking ..............................................................................................11
Disabling the Starter Kill without a transmitter. ............................................11
Remote Start...........................................................................................12
Rear Defogger........................................................................................13
Valet Take-Over ......................................................................................14
Car finder..............................................................................................15
Timer Mode ...........................................................................................15
Starter Anti-Grind Circuitry.......................................................................16
Disabling the Remote Start system .............................................................16
Rapid Resume Logic ........................................................................................17
Programming options.......................................................................................18
Glossary of Terms............................................................................................19
Convenience Expansions .................................................................................20
Quick Reference Guide....................................................................................23
Limited lifetime consumer warranty ....................................................................25

5
© 2008 Directed Electronics. All rights reserved.
Government Regulations
This device complies with Part 15 of FCC rules. Operation is subject to the fol-
lowing two conditions: (1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that
may cause undesirable operation.
This equipment has been tested and found to comply with the limits for a class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential instal-
lation. This equipment generates and can radiate radio frequency energy and,
if not installed and used in accordance with the instruction manual, may cause
harmful interference to radio communications. However, there is no guarantee
that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television, which can be determined by
turning the equipment OFF and ON, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
• Consult the dealer or an experienced radio / TV technician for help.
This device complies with the Industry Canada Radio Standards Specification
RSS 210. Its use is authorized only on a no-interference, no-protection basis; in
other words, this device must not be used if it is determined that it causes harm-
ful interference to services authorized by IC. In addition, the user of this device
must accept any radio interference that may be received, even if this interference
could affect the operation of the device.
Warning:
Changes or modications not expressly approved by the party responsible for
compliance could void the user’s authority to operate this device.

6© 2008 Directed Electronics. All rights reserved.

7
© 2008 Directed Electronics. All rights reserved.
Warning! Safety first
The following safety warnings must be observed at all times:
Due to the complexity of this system, installation of this product must only be
performed by an authorized Directed dealer.
When properly installed, this system can start the vehicle via a command signal
from the remote control transmitter. Therefore, never operate the system in an
enclosed area or partially enclosed area without ventilation (such as a garage).
When parking in an enclosed or partially enclosed area or when having the
vehicle serviced, the remote start system must be disabled using the installed
toggle switch. It is the user’s sole responsibility to properly handle and keep out
of reach from children all remote control transmitters to assure that the system
does not unintentionally remote start the vehicle. THE USER MUST INSTALL A
CARBON MONOXIDE DETECTOR IN OR ABOUT THE LIVING AREA ADJA-
CENT TO THE VEHICLE. ALL DOORS LEADING FROM ADJACENT LIVING
AREAS TO THE ENCLOSED OR PARTIALLY ENCLOSED VEHICLE STORAGE
AREA MUST AT ALL TIMES REMAIN CLOSED. These precautions are the sole
responsibility of the user.
Use of this product in a manner contrary to its intended mode of operation may
result in property damage, personal injury, or death. (1) Never remotely start the
vehicle with the vehicle in gear, and (2) Never remotely start the vehicle with
the keys in the ignition. The user must also have the neutral safety feature of the
vehicle periodically checked, wherein the vehicle must not remotely start while
the car is in gear. This testing should be performed by an authorized Directed
dealer in accordance with the Safety Check outlined in the product installation
guide. If the vehicle starts in gear, cease remote start operation immediately and
consult with the authorized Directed dealer to x the problem.

8© 2008 Directed Electronics. All rights reserved.
After the remote start module has been installed, contact your authorized dealer
to have him or her test the remote start module by performing the Safety Check
outlined in the product installation guide. If the vehicle starts when performing
the Neutral Safety Shutdown Circuit test, the remote start unit has not been
properly installed. The remote start module must be removed or the installer must
properly reinstall the remote start system so that the vehicle does not start in gear.
All installations must be performed by an authorized Directed dealer.
OPERATION OF THE REMOTE START MODULE IF THE VEHICLE STARTS IN
GEAR IS CONTRARY TO ITS INTENDED MODE OF OPERATION. OPERAT-
ING THE REMOTE START SYSTEM UNDER THESE CONDITIONS MAY RESULT
IN PROPERTY DAMAGE OR PERSONAL INJURY. YOU MUST IMMEDIATELY
CEASE THE USE OF THE UNIT AND SEEK THE ASSISTANCE OF AN AU-
THORIZED Directed DEALER TO REPAIR OR DISCONNECT THE INSTALLED
REMOTE START MODULE. DIRECTED WILL NOT BE HELD RESPONSIBLE OR
PAY FOR INSTALLATION OR REINSTALLATION COSTS.
This product is designed for fuel injected, automatic transmission ve-
hicles only. Use of this product in a standard transmission vehicle is
dangerous and contrary the product's intended use.

9
© 2008 Directed Electronics. All rights reserved.
What is Included
The control module•
An HX receiver/antenna•
Two 4-button transmitters (P/N 474L)•
A push-button Valet switch•
Your warranty card•
A shut-down toggle switch•
Important Information
Congratulations on the purchase of your remote start keyless entry sys-
tem. This system has been designed to provide years of trouble-free
operation. By carefully reading this owner’s guide prior to using your
system, you will maximize the use of this system and its features. Addi-
tional or replacement copies of this guide can be printed by accessing
the Directed Electronics internet website at www.directed.com .
➢System Maintenance
The system requires no specific maintenance. Your remote is powered
by a miniature 3V lithium battery that lasts approximately one year
under normal use. When the battery weakens, the LED on the remote
will dim and operating range will be reduced.
➢Your Warranty
Your warranty card must be completely filled out and returned within
10 days of purchase. Your product warranty will not be honored if your
warranty card is not returned. Make sure that you receive the warranty
card from your dealer.

10 © 2008 Directed Electronics. All rights reserved.
Transmitter Functions
The receiver uses a computer-based learn routine to learn the transmitter
buttons. The transmitter buttons indicated in all of the instructions in this
manual correspond to a Standard Configuration transmitter.
➢Standard Configuration

Button
The locking and panic functions are controlled by pressing

on the
transmitter for one second.

Button
The unlocking function is controlled by pressing on the transmitter
for one second.
Button
Silent Mode™ and an optional auxiliary function are controlled by
pressing . Silent Mode works by pressing for less than one
second. The optional trunk release output is controlled by pressing and
holding for 1.5 seconds.
Button
The remote start function of your system is controlled by pressing this
button for one second.
Buttons + +
When simultaneously pressed these buttons control the rear window
defogger during remote starting.

11
© 2008 Directed Electronics. All rights reserved.
Using Your System
➢Locking
Pressing for one second locks the system by activating the starter
kill and locking the doors (if the door locks are connected). The horn
will honk (if connected) and the parking lights will flash once to confirm
locking of the system. The Failsafe®Starter Kill (if installed) will also
prevent the vehicle’s starter from cranking.
➢Unlocking
Pressing for one second unlocks the doors (if connected). The horn
will honk twice (if connected) and the parking lights will flash twice to
confirm unlocking of the system. The optional Failsafe®Starter Kill will
be deactivated.
➢Disabling the Starter Kill without a transmitter.
If your remote transmitter is lost or damaged, you can manually over-
ride the starter kill. To do this, you must have the vehicle's ignition key
and know where the Valet button is located. Be sure to check with the
installer for the location of the Valet button.
To override the starter kill, turn the igni-
tion on and press the Valet button
within 10 seconds. The vehicle should
start. If it does not start, you may have
waited too long; turn the ignition off and repeat the process.
Location of Valet button: ____________________

12 © 2008 Directed Electronics. All rights reserved.
➢Panic Mode
If you are threatened in or near your vehicle, you can attract attention
by trig ger ing the system with your transmitter. Just press for 1.5
seconds to enter Panic Mode. In Panic Mode, the horn will honk and
the parking lights will flash for 30 seconds. To stop Panic Mode at
any time, press , or on the transmitter.
Note: In order for Panic Mode to be effective, the vehicle’s horn (or
optional siren) as well as the vehicle's parking lights must be con-
nected.
➢Remote Start
This feature allows you to remotely start and run your vehicle for a
programmable period of time. This makes it possible to warm up the
engine, as well as adjust the interior temperature of the vehicle with
the climate control system. If interior heating or cooling is desired, the
climate controls must be preset, and the fan blower must be set to the
desired level prior to remote starting the vehicle.
Important! (1) Never remotely start the vehicle with the vehicle
in gear, and (2) Never remotely start the vehicle with the key in the
ignition.
To remote start the vehicle:
Press the1. button twice for 1 second on the transmitter.
The parking lights will flash to confirm that the vehicle will attempt2.
to start.
Release the3. button as soon as the parking lights flash. (In
gasoline vehicles, the engine will start 4 seconds after the parking
lights flash. In diesel vehicles, the engine will start when the WAIT-
TO-START timer has expired.)

13
© 2008 Directed Electronics. All rights reserved.
Once the vehicle has started, it will run for the pre-programmed4.
period of time (12, 24, or 60 minutes) or until a shutdown input
is triggered.
When you are ready to drive the vehicle:
Insert the ignition key and turn it1.
to the ON (not the START) posi-
tion.
Press the brake pedal.2.
Note: If the brake pedal is pressed before the key is in the ON position,
the engine will shut down.
While the vehicle is running during remote start operation, the system
will monitor the vehicle and will automatically shut down the engine if the
system receives any of the following shut-down inputs:
The brake pedal is pressed.•
The hood is opened.•
The shutdown toggle switch is put into the OFF position.•
The pre-programmed run time (12, 24, or 60 minutes) has elapsed.•
Transmitter button• is pressed 1 time to start the vehicle.
➢Rear Defogger
To turn the rear defogger output OFF:
Simultaneously press & release the1. + + buttons on the
remote control.
The lights will flash 2 times.2.
The rear defogger output will no longer activate when the vehicle3.
is remote started.

14 © 2008 Directed Electronics. All rights reserved.
Note: If the remote start is on the parking lights will turn off then flash
2-times before returning to their normal output and the defogger output,
if active, will cease.
To turn the rear defogger output ON:
Simultaneously press & release the1. + + buttons on the
remote control.
The lights will flash 3 times.2.
The rear defogger output will once again activate when the ve-3.
hicle is remote started.
Note: If the remote start is on the lights will turn off then flash 3-times
before returning to their normal output and the defogger output will
activate as programmed.
➢Valet Take-Over
The Valet Take-Over feature allows the vehicle to remain running after
the key has been removed from the ignition. This feature is useful for
occasions when you wish to exit and lock the vehicle for short periods
of time, but would like to leave the motor running and the climate
controls on.
To perform Valet Take-Over:
Before turning off the engine, press and release1. on the trans-
mitter for 1 second.
Turn the ignition key to the OFF position. (The engine will stay2.
running.)
The vehicle will run for the pre-programmed period of time (12,3.
24, or 60 minutes) or until a shutdown input is triggered.

15
© 2008 Directed Electronics. All rights reserved.
➢Car finder
Car finder allows you to locate your vehicle, by having the system flash
the parking lights on your vehicle..
To activate:
Press and release the1. and buttons at the same time.
The lights flash 5 times slowly allowing you to locate your ve-2.
hicle.
➢Timer Mode
By pressing the remote and buttons the parking lights will flash 4
times and then start the vehicle and run for the set duration. The remote
start can be shut off by the transmitter by pressing the remote start button
and remain in timer mode, but if any other shut down zones or the
ignition becomes active the timer mode will cancel.
Press Timer mode buttons.1.
The vehicle will confirm with 4 parking light flashes.2.
A 1-second delay will start.3.
The system will start the car and will run for the specified duration,4.
unless shut down by the remote start button . If shut down with
the remote start button the system will remain in timer mode.
The system will start every 3 hours until canceled by the brake,5.
hood, or neutral safety shut-down wires.
Important! Timer Mode should be used only in open ar-
eas. Never start and run the vehicle in an enclosed space
such as a garage or carport.
To exit timer mode, turn the ignition switch on any time the engine is
running. The parking lights will flash 4 times, indicating timer mode

16 © 2008 Directed Electronics. All rights reserved.
has been exited.
➢Starter Anti-Grind Circuitry
Whenever the vehicle is remote started, advanced anti-grind circuitry
prevents the starter from engaging, even if the key is turned to the start
position. This prevents damage to the starter motor if the key is turned to
the start position during remote start operation.
Note: Anti-grind circuitry only works when the remote start system is
operating the motor and the optional Failsafe®Starter Kill relay is in-
stalled.
➢Disabling the Remote Start system
This feature allows your system's remote start unit to be temporarily
disabled to prevent the vehicle from being remote started accidentally.
This feature is useful if the vehicle is being serviced or stored in an
enclosed area. To disable the remote start, move the shutdown toggle
switch to the OFF position. The switch can be installed in a location of
your choice. Check with your installer for recommended locations.
Location Of Shutdown Switch _________________________

17
© 2008 Directed Electronics. All rights reserved.
Rapid Resume Logic
This Directed Electronics system will store its current state to non-volatile
memory. If power is lost and then reconnected the system will recall the
stored state from memory. This means if the unit is in Locked Mode and
the battery is disconnected for any reason, such as servicing the car,
when the battery is reconnected the unit will still be in Locked Mode.
This applies to all states of the system.

18 © 2008 Directed Electronics. All rights reserved.
Programming options
Programming options control your system's normal, operational set-up.
Most options do not require additional parts, but some may require ad-
ditional installation labor. This system's programming options are listed
below, with the factory default settings in bold :
12 • ,24, or 60 minute run time. your system can be programmed
to allow the vehicle to run for 12, 24, or 60 minutes when remote
started.
3, 6, 9, or• 12 minute timer mode run time. Your system can be
programmed to allow the vehicle to run for 3, 6, 9, or 12 minutes
when remote started in timer mode. Can be set up to 16 minutes
by your installer.
Comfort closure is a programming option which closes the ve-•
hicle’s windows after remote locking.
Parking lights• flashing or constant. Your system can be programmed
to either flash or to turn on the parking lights constantly during the
entire remote start operation.
Ignition switch-controlled door-locking• on or off. With this feature
on, the doors will lock 3 seconds after the ignition key is turned on,
and unlock when the ignition key is turned off.
The horn honk confirmations for locking and unlocking can be•
programmed on or off. In order for this feature to be programmed
on, the horn must be connected to the system.

19
© 2008 Directed Electronics. All rights reserved.
Glossary of Terms
Control Unit: The “brain” of your system. Usually hidden underneath the
dash area of the vehicle. It houses the microprocessor which monitors
your vehicle and controls all system functions.
Failsafe® Starter Kill: An automatic switch controlled by your system
which prevents the vehicle’s starter from cranking whenever the system
is armed. The vehicle is never prevented from cranking when the system
is disarmed, in Valet Mode, or if the starter kill switch itself fails. Your
system has feature-ready circuitry for the starter kill, however installation
may require additional labor.
LED: A red light mounted on the main unit.
Transmitter: A hand-held, remote control which operates the various
functions of your system.
Valet Button: A small push button mounted at a discretionary location
inside the vehicle. It is used to override the Failsafe®Starter Kill when a
transmitter is lost or damaged.

20 © 2008 Directed Electronics. All rights reserved.
Convenience Expansions
Listed below are some of the many expansion options available for
use with your system. Some options may require additional parts and/
or labor. Please consult with your dealer for a complete list of options
available for use with this system.
Power Door Lock Control: Your system is capable of controlling many
types of power door lock systems; however, some door lock systems
may require extra parts. Consult with your dealer to determine which
type of locks your vehicle uses. The system can be programmed to lock
the doors when the ignition is turned on and to unlock them when the
ignition is turned off.
Power Trunk Release: The system’s auxiliary output can be programmed
to operate a factory power release for the vehicle's trunk or hatch. If
the factory release is not power-activated, Directed Electronics 522T
trunk-release solenoid can often be added.
Power Window Control: Power window control is provided with Di-
rected Electronics 529T or 530T systems. The 529T system will roll
up two windows automatically when the system is armed, or roll two
windows down by using the transmitter. The 530T will roll two win-
dows both up and down. The 530T also provides one touch switch
operation.
