Dirt Devil DQC-DVB-HKA User manual

DQC-DVB
DRY
vac
Dust
DQC-DVB-HKA_UG_20140912_color print_003-ok.indb 1 28/07/2015 10:33 AM

Thank you for buying this Vac & Dust.
Taking care of your hard floors
The Vac & Dust is designed to make cleaning sealed hard floors regularly, as effective and
efficient as possible and this user guide will help you get the most out of your machine.
Maintaining your hard floors will ensure they keep their appearance for longer and smell fresh
and clean.
Taking care of your Vac & Dust
Also inside this guide are instructions on maintaining your new machine, so that it’s always
ready when you are, to tackle your hard floors.
DQC-DVB-HKA_UG_20140912_color print_003-ok.indb 2 28/07/2015 10:33 AM

8Don’t use this Vac & Dust if it has been dropped, damaged,
immersed in water or left outdoors.
8Don’t run over the charger cord or use Vac & Dust if
the power cord or plug is damaged. Please contact our
authorized dealer or service center
8Don’t handle the plug or use the Vac & Dust with wet hands.
8Don’t throw the Vac & Dust into fire or expose to high
temperatures, as the Vac & Dust contains a rechargeable
nickel cadmium battery which may cause damage or burst.
8Don’t pull or carry this Vac & Dust by the charger cord.
8Don’t use the charger cord as a handle, pull the charger
cord around corners or sharp edges or close a door over the
power cord.
8Don’t unplug Vac & Dust by pulling on the charger cord.
8Don’t attempt to remove blockages with sharp objects as this
may cause damage to your Vac & Dust.
8Don’t use the Vac & Dust with incorrect voltage as this may
result in damage or injury to the user. The correct voltage is
listed on the ratings label.
8Don’t vacuum up hot coals, cigarette butts, matches or
smoking hot burning items or use in an area where there
may be harmful fluids (chlorine, bleach, and ammonia drain
cleaner).
This Vac & Dust is intended for household use only and NOT
for commercial or industrial use.
• This Vac & Dust does not stay upright without constant
support.
• Only use the Vac & Dust indoors and keep the area you’re
cleaning well lit.
• Keep fingers, hair and loose clothing from moving parts and
openings whilst using the Vac & Dust.
• This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning
use of the appliance in a safe way and understand the
hazards involved.
• Children shall not play with the appliance. Cleaning and
user maintenance shall not be made by children without
supervision.
• Only Dirt Devil recommended tools and accessories should
be used with this Vac & Dust.
 
Basic safety precautions
8Always make sure the filter and dirt container are fitted
correctly before using your Vac & Dust.
8Always turn off and unplug the Vac & Dust before carrying
out any maintenance.
8Turn off all controls on the Vac & Dust before disconnecting
or connecting the power cord. After use always wrap the
power cord around the cord clips provided.
8Take extra care when cleaning on the stairs.
8Always replace the fuse in the plug with a 13amp fuse.
8Always protect the power cord from heated surfaces or near
open flames.
8Use only CE approved 13amp extension cords, non-approved
extension cords may overheat. Care should be taken to
arrange the extension cord as it can be a trip hazard.
8Always carry the Vac & Dust by the handle.
8Store your Vac & Dust in a cool, dry area.
Do’s
Dont’s
Before we get started
DQC-DVB-HKA_UG_20140912_color print_003-ok.indb 3 28/07/2015 10:33 AM

Washable Microfibre dusting pad
Charger
Included with your
machine
Vac & Dust
DQC-DVB-HKA_UG_20140912_color print_003-ok.indb 4 28/07/2015 10:33 AM

Getting to know your machine
Name Vac & Dust
Model no DQC-DVB-HKA
Part Number 1-1-135190-00
Charger Input voltage 100-240V~
Battery voltage 10.8V
Cordless
Weight 1.8kg
Filter (Type 85)
Quick Clean Microfibre Pads (Type 1)
Technical Specification
Subject to technical change without notice.
Storage hook
Power button
Upper handle
Dirt container release button
Vacuum nozzle
Filter
Dirt container
Frame for cleaning pad
Charging port
DQC-DVB-HKA_UG_20140912_color print_003-ok.indb 5 28/07/2015 10:33 AM

Assembling your Vac & Dust
Charging your Vac & Dust
Getting started

The machine must be charged for 24 hrs before use. Only use charger supplied by Dirt Devil.
NOTE: This machine is not free standing
Push the handle into the
main body until it locks
into place
The charging light
will Illuminate when
charger is connected
and charging
Once fully charged
the illuminating light
will go out
Remove the machine
from charge
Support Vac & Dust
whilst charging or use
storage hook to hang
where it can easily be
charged
Plug your charger
into the back of
your machine
Plug your charger into
main wall socket
Slide the frame of your machine into the cleaning pad
pocket one side at a time
DQC-DVB-HKA_UG_20140912_color print_003-ok.indb 6 28/07/2015 10:33 AM

Depress the power
button to turn machine
on and off
Use the microfibre pad to pick up fine
debris like dirt, dust and pet hair. Use
vacuum to suck up any left over debris
Using your machine
IMPORTANT: Always support Vac & Dust during use
Emptying the Dirt Container
Gently push the filter into
the dirt container
To refit the dirt container tilt so that the bottom aligns
first, then gently push until it locks into place
Grasp the center tab on
the filter and pull out of
the dirt container
To empty the Vac &
Dust depress the release
button to remove the dirt
container
Empty contents from
the container, shake and
lightly tap filter against bin
to remove remaining dirt
DQC-DVB-HKA_UG_20140912_color print_003-ok.indb 7 28/07/2015 10:33 AM

Maintenance
Important: DO NOT USE BLEACH or FABRIC SOFTENER. For best results, wash the microfibre cloth after every use
Depress the release button
to remove the dirt container
Hold filter under warm
running water (max
40°C) to rinse. DO NOT
use soap/detergent. Tap
excess water out of filter
Gently push the dry filter
back into the dirt container
Allow filter to
COMPLETELY DRY for
at least 24 hours before
refitting into the dirt
container
To refit the dirt container tilt
so that the bottom aligns
first, then gently push until it
locks into place
Grasp the center tab on
the filter and pull out of
the dirt container
Shake and lightly tap the
filter against the bin to
remove dirt
Maintaining your filter
Maintaining your Washable Microfibre
dusting pad
Machine washable at warm temperature (40°C max).
Always use a mild detergent and lay flat to dry completely
before re-using
For best results tap out filter after every use and wash periodically
40°C MAX
24hr
DQC-DVB-HKA_UG_20140912_color print_003-ok.indb 8 28/07/2015 10:33 AM

Depress the release
button to remove the dirt
container
Check dirt air path is clear of dust and debris above
the dirt container and below the base of Vac & Dust
Storage
Maintenance
Important: Store in a cool dry area
NOTE
Switch off and unplug
Use storage hook to hang
Vac & Dust where is can
easily be charged
Clearing a blockage
Always switch off and uplug Vac & Dust
before carrying out any maintenance.
Ensure filter is fully dry (at least 24 hours
drying time) before refitting into the dirt
container and is replaced every 6 months.
DQC-DVB-HKA_UG_20140912_color print_003-ok.indb 9 28/07/2015 10:33 AM

• Check the ‘This pack contains’ panel on the box to make
sure the part is included with your machine.
• Ensure the handle is fitted correctly and pushed fully on to
the main body.
• Battery may not be fully charged. If using the Vac & Dust
for the first time the initial charge should be 24 hours. The
charging light will illuminate when charger is connected and
charging, once fully charged the illuminating light will go out.
• Dirt container may be full and may need to be emptied.
• Filter may need to be washed please allow 24 hours to dry
before refitting.
• Clear any blockages from the machine.
• Empty dirt container, remove and wash filter allowing
24 hours to dry before refitting.
• Dirt container may not be fitted correctly. To refit the dirt
container tilt so that the bottom aligns first, and then gently
push until it locks into place.
• Poor suction can be caused due to battery power becoming
low and may need to have a full re-charge.
• Clear any blockages from the machine.
SolutionIf
Troubleshooting
There is an
accessory
missing
Vac & Dust will
not switch on
Vac & Dust won’t
pick up or poor
suction
Dust escaping
from Vac & Dust
DQC-DVB-HKA_UG_20140912_color print_003-ok.indb 10 28/07/2015 10:33 AM

DQC-DVB
DRY
VAC
DUST
DQC-DVB-HKA_UG_20140912_color print_003-ok.indb 11 28/07/2015 10:33 AM

感謝您購買Vac & Dust真空吸塵機！
護理您的地板
Vac & Dust能有效能和有效率地清潔密封硬木地板，令您的地板保養後更耐看，氣味清
新、乾淨。
本使用手冊將幫助您使用本機。
Vac & Dust的護理方法
本手冊包含吸塵機的保養方法，若有疑難請參閱有關指引。
DQC-DVB-HKA_UG_20140912_color print_003-ok.indb 12 28/07/2015 10:33 AM

8若此Vac & Dust曾從高處墜下、損壞、浸水或置
於室外，切勿使用。
8切勿擠壓充電器電線或插頭損壞時使用Vac & Dust。
請聯絡我們的授權經銷商或服務中心
8手部沾濕時，切勿觸碰插頭或使用Vac & Dust。
8切勿將Vac & Dust投入火中或暴露於高溫下，這
樣或會對Vac & Dust內含的充電式鎳鎘電池造成
損壞或爆裂。
8切勿扯拉電線拖拽Vac & Dust。
8切勿使用充電線作為手柄，在角落或邊緣銳利處
拉扯充電線，或關門時夾住電線。
8切勿透過拉拽充電線拔下Vac & Dust。
8切勿嘗試用尖銳物體去除堵塞，否則可能會損壞
您的Vac & Dust。
8確保Vac & Dust使用電壓得當，否則可能導致設
備損壞或對使用者造成傷害。產品標籤上已列出
正確的電壓。
8切勿用於吸熱煤、煙頭、火柴或正在冒煙的物
品，或用於有可能含有害液體的範圍，如氯、漂
白劑和氨水的清潔劑。
感謝您購買Vac & Dust真空吸塵機！
此部Vac & Dust僅供家居使用，不得用於商業或工業用途。
• 此部Vac & Dust沒有支撐便無法保持直立。
• 僅在室內使用Vac & Dust，並保持清潔，範圍內沒
有障礙物。
• 使用Vac & Dust時，請勿讓手指、頭髮或寬鬆衣服
接近可轉動的部件和吸塵機吸口。
• 8歲或以上的兒童以及體力、感官或精神上有障礙
者，也可以使用本產品，但必須有他人在場監督
或指導安全使用的方式，並了解當中的危險。
• 請小心監督兒童，確保他們不會把本裝置當作玩
具。若無人監督，請勿讓兒童清潔和維修本機。
• 僅可將Dirt Devil推薦的工具和配件用於Vac & Dust
之上。
請保留說明書以供日後使用。
基本的安全預防措施
8確保使用您的Vac & Dust之前，已正確安裝過濾
網和集塵筒。
8進行任何保養之前，務必關閉Vac & Dust並拔掉
電源。
8斷開或連接電源線之前，關閉Vac & Dust的所有
操作。使用完畢後，緊記用附帶的線夾繞好電線。
8清潔樓梯時要格外小心。
8電源線須遠離明火或受熱表面。
8僅使用CE認證的13安培延長線，未經許可的延長
線可能會導致過熱。延長線有絆倒的危機，使用
時請特別注意。
8請使用手柄來搬動Vac & Dust。
8請將Vac & Dust存放於陰涼乾燥處。
參照用法
禁止用法
開始使用前
DQC-DVB-HKA_UG_20140912_color print_003-ok.indb 13 28/07/2015 10:33 AM

可水洗超細纖維除塵墊
本機隨附物品
Vac & Dust
充電器
DQC-DVB-HKA_UG_20140912_color print_003-ok.indb 14 28/07/2015 10:33 AM

了解本機
名稱 Vac & Dust
型號 DQC-DVB
產品編號 1-1-135190-00
輸入電壓 100-240V~
電池電壓 10.8V
無線
重量 1.8kg
過濾網（類型85）
快速清潔微纖維墊（類型1）
技術規格
如有技術變更，恕不另行通知。
掛鉤
開關按鈕
上部手柄
集塵筒分離掣
真空吸頭
過濾網
集塵筒
清潔墊刷頭
充電插口
DQC-DVB-HKA_UG_20140912_color print_003-ok.indb 15 28/07/2015 10:33 AM

組裝Vac & Dust
入門
使用前，請仔細閱讀「開始使用前」部分
注意：本機不能單獨直立
將手柄推入主機，
直至鎖定到位
為Vac & Dust充電
重要事項：使用本機前必須充電24小時。僅使用Dirt Devil隨附的充電器。
連接充電器和充電
時，指示燈會亮起
充滿電後，指示燈
會熄滅
拔下充電器
充電時須支撐
Vac & Dust，或使
用掛鉤掛在容
易充電的地方
將充電器插入本
機背面的充電口
將充電器插入電插頭
將刷頭塞進清潔墊袋子，一次塞一邊
DQC-DVB-HKA_UG_20140912_color print_003-ok.indb 16 28/07/2015 10:33 AM

按下電源按鈕來開啟和
關閉本機
微纖維墊適用於清掃污垢、
灰塵和寵物毛髮等碎屑。吸
頭適用於吸走任何殘留碎屑
產品操作
重要事項：使用Vac & Dust時須握著手柄
清空集塵筒
輕推過濾網以裝入集
塵筒
將集塵筒底部對準後放
入直至鎖定到位
抓緊過濾網中間位置
並輕輕拉離集塵筒
要清空Vac & Dust，按下分
離掣以取下集塵筒
將筒內灰塵清空，
搖抖及輕敲集塵筒
抖出殘留灰塵
DQC-DVB-HKA_UG_20140912_color print_003-ok.indb 17 28/07/2015 10:33 AM

保養
重要事項：切勿使用漂白劑或衣物柔順劑。每次使用後，清洗微纖維清潔布以獲得最佳效果
按下分離掣以取下集塵筒
用溫暖的自來水（最高
40°C）沖洗過濾網。
切勿使用肥皂/洗滌
劑。輕拍過濾網以除去
多餘水漬
將過濾網輕輕推回入集
塵筒
過濾網須乾透最少24
小時方可重新放入集
塵筒內
將集塵筒底部對準後
放入直至鎖定到位
抓緊過濾網中間位置並
輕輕拉離集塵筒
在廢紙簍內搖抖及輕敲
過濾網以倒掉垃圾
保養過濾網
保養可水洗超細纖維除塵墊
可溫水機洗（最高溫度40°C）。使用溫和的洗潔精，
攤開平放至完全乾燥後方可再使用
每次使用後，取出過濾網並定期清洗，以獲得最佳使用效果
最高40°C
24hr
DQC-DVB-HKA_UG_20140912_color print_003-ok.indb 18 28/07/2015 10:33 AM

按下分離掣以取下
集塵筒
確保集塵筒上和Vac & Dust底座下方的吸塵通
路中沒有灰塵和碎屑
收納
保養
重要事項：存放在陰涼乾燥的地方
注意
關閉電源及把充電器
拔出
使用掛鉤將Vac & Dust掛
在易於充電之處
清除堵塞
請務必關閉Vac & Dust並拔掉電源以進
行任何保養。
過濾網重新放入集塵筒前，確保過濾
網已乾透（最少24小時），並每6個月
更換一次。
DQC-DVB-HKA_UG_20140912_color print_003-ok.indb 19 28/07/2015 10:33 AM

• 檢查包裝盒上的「包裝隨附物品」板面，以確保該部件
已隨本機一同提供。
• 確保正確安裝手柄並連接到主機。
• 電池沒有充滿電。初次使用Vac & Dust時，應先充電24小
時。連接充電器和充電時，指示燈會亮起；充滿電後，
指示燈會熄滅。
• 集塵筒可能已滿，需要清空。
• 過濾網可能需要清洗，並須乾透最少24小時方可重新放
入集塵筒內。
• 清除本機的任何堵塞。
• 清空集塵筒，取出過濾網清洗，確保過濾網乾透24小時
方可重新放入集塵筒內。
• 集塵筒或安裝不正確。將集塵筒底部對準後放入直至鎖
定到位。
• 吸力不佳或由電量較低引致，可能需要重新充電。
• 清除本機的任何堵塞。
解決方法問題描述
常見問題
缺漏附件
Vac & Dust 無法
啟動
Vac & Dust沒有吸
力或吸力不佳
塵屑從Vac & Dust
溢出
DQC-DVB-HKA_UG_20140912_color print_003-ok.indb 20 28/07/2015 10:33 AM
