OWNER'S MANUAL
Operatingand Servicing
Instructions
Please read these
instructions carefully before
usingyour Vision CanisterTM.
Let us help you put your
cleaner together or answer
any questions, call:
1-800-321-1134 (USA)
1-800-661-6200 (Canada)
website: www.dirtdevil.corn
For quick reference, please recordyour vacuum
informationbelow.
Model
#:
Mfg. Code:
(Mfg, code located on the lower backsideof cleaner)

CONGRATULATIONS
You are now the proud owner of the Dirt Devil Vision CanisterTM,with Power You
Can SeeTM!The unique bagless design provide hassle-free emptying, yet delivers
superior cleaningpower.
We trust your new purchasewill bring you many years of
satisfaction.
We are very proud of our products and hope that you are equally satisfied with
their quality and performance.
Thank you for your support of Dirt Devil products.
Visit our website at www.dirtdevil.com
TABLE OF CONTENTS
Feature Descriptions
............................................................... Page 4
HowTo Assemble ....................................................................... Page 5
HowTo Operate ........................................................................ Page5
Attachment Installation & Removal ........................................ Page 5
Dirt Container Removal & Replacement
...................................... Page 6
Filter Removaland Replacement ................................................ Page 6
Beltor Brush Roll Removaland Replacement ............................ Page 7
TroubleshootingGuide ................................................................. Page 8
LIMITED WARRANTY
To the consumer, RoyalAppliance Mfg. Co. warrantsthis vacuum cleaner to be free of defects in materialor workmanship commencing upon the date of the original pur-
chase. Refer to your vacuum cleaner carton for the lengthof warrantyand save your original sales receiptto validate start of warranty per~od.
Ifthevacuum cleaner should becomedefectivewithin thewarrant period, we will repair or replace any defective partsfree of charge. The complete machinemust bedeliv-
ered
gceg&i to an ROYALAuthorizedSales &Warranty ServiceJtation Please includecompletedescriptionof the problema of purchase, copy of originalsales receipt
and your nam?, aJdressand telephonenumber. Ifyou are not near a Warranty Station, call the factory for assistanceat USA 1-&0-321-11311 CANADA: 1-800-661-6200.
Use only genulne Royal replacementparts.
The warranty does not includeunusualwear, damageresultingfrom accidentor unreasonableuse of the vacuum cleaner. Thiswarrantydoesnot cover belts, brushes,bags,
bulbsor fan damage. This warrant does not cover unauthorized repairs. This warranty gives you specific legal rights and you may also have other rights. (Other rights
may vary from stateto state inthe 6SA).

CONSUMER INFORMATION
THlS VACUUM IS INTENDED FOR HOUSEHOLD USE ONLY.
IMPORTANT SAFETY l NSTRUCTIONS
When you use an appliance, basic precautionsshould always be followed, including the following:
* READ ALL INSTRUCTIONSBEFORE USING THlS APPLIANCE
ALWAYS FOLLOW THESE SAFETY INSTRUCTIONS
* DO NOT LEAVE CLEANER UNATTENDED
WARNING - FULLY ASSEMBLE CLEANER BEFORE OPERATING.
WARNING: TO REDUCE THE RISK OF FIRE,
ELECTRIC SHOCK OR INJURY:
Do not leave appliance when plugged in. Unplug from outlet when not in use and beforeservicing.
Do not use outdoorsor on wet surfaces.
Do not allow to be used as atoy. Close attention is necessary when used by or near children.
Use only as described in this manual. Use only manufacturer's recommendedattachments.
Do not use with damaged cord or plug. Ifappliance is notworking as itshould, has been dropped, damaged, left outdoors, or dropped
into water, return itto a service center for inspection.Call 1-800-321-1134for the nearest servicecenter.
Do not pull or carry by cord, use cord as a handle, close a door on cord, or pull cord around sharp edges or corners. Do not run appliance
over cord. Keep cord away from heated surfaces.
Do not unplug by pullingon cord. To unplug, grasp the plug, notthe cord.
Do not handle plug or appliancewith wet hands.
Do notputany object intoopenings. Do not use with any opening blocked; keep free of dust, lint, hair and anythingthat may reduce air flow.
Keep hair, loose clothing, fingers, and all parts of body away from openings and movingparts.
Turn off all controls before unplugging.
Use extra care when cleaning on stairs.
Do not use to pick up flammableor combustible liquids, such as gasoline, or use in areas where they may be present.
Look on your vacuum cleaner and follow all label and marking instructions.
Do not use an extensioncord with this cleaner.
Keep end of hose, wands and other openings away from your face and body. Keep your hands, feet, hair and clothing away from moving parts;
especiallythe revolvingbrush.
Do not use the vacuum cleaner without dirt container andlor filters in place.
Storethe vacuum cleaner indoors. Put the vacuum cleaner away after use to prevent trippingaccidents.
Do not pick up anything that is burningor smoking, such as cigarettes, matches, or hot ashes.
* Hold plug when rewindingonto cord reel. Do not allow plugto whip when rewinding.
The hose contains electricalwires. Do not use when damaged, cut, or punctured.Avoid picking up sharp objects.
* Always turn off this appliancebeforeconnecting or disconnectingeither hose or motorizednozzle.
Approved by the Vacuum Cleaner Manufacturer's Association ExecutiveCommittee, April
29, 1987.
SAVE THESE INSTRUCTIONS
WARNING: TO reduce the risk of electric shock, this appliance has a polarized plug (one blade is wider than the other). This
plugwill fit in a polarizedoutlet only one way. Ifthe plug does notfit fully inthe outlet, reversethe plug. Ifit still does notfit, contact
a qualified electrician to install the proper outlet. Do not change the plug in any way.
I I
NOTE: RETURN WARRANTY CARD TO REGISTER YOUR CLEANER

FEATURES
See Thru Dirt Container
Carry Handle
Microfresh Exhaust Filter
Tool Caddy*
Easy Glide Wheels
Dirt Cup Pleated Filter
Rolling Caster Wheel
Power Nozzle*
Brushroll OnIOff Switch
HoseAdaptor
Hose*
Extension Wands
External Cord Connection
OnIOff 1Variable Speed Control
Cord Rewind Button
Bare Floor Brush* (not stored on unit)
Dust Brush
Power Cord
Crevice Tool
*Attachments vary per model

4.
Cwd Vndbutton OdOff
/ Variable
......
Diagram 1 .. Dlagram 2 Diagram 3 Diagram 4
Lme up hose adapter wth hose
Sl~de hpse adapterintohoseinlet plugmrdln~ocanster Powerwtchon
canister and cord rewlnd but-
mlet onface of deaner.
and turn dodcwise to lock.
ton.
I I
Diagram 5 Diagram 6
Depress power switch with yourfootto turn the PFerPak
-
Rebactabbpower cord
nozzleon
POWER NOZZLEASSEMBLY (REFER TO FIGUREA).
WARNING: TO REDUCETHE RlSK OF INJURY FROM MOVINGPARTS - UNPLUGCLEANER BEFORE
CONNECTINGOR DISCONNECTINGPOWER NOZZLE.
1. Snaptogetherthe two interlockingwands untilpinlocksin place.
2. Pushassembledwands into power nozzle.
3. Presscord into slotsonbackofwands.
4. Inserthandleendof hoseintoassembledwands.
5. Plugpowernozzlecord into hose.
HOSE INSTALLATIONAND REMOVAL
WARNING: TO REDUCETHE RlSK OF INJURY - UNPLUGCLEANER BEFOREREMOVINGOR
INSTALLINGHOSE.
1. Holdhose adapterso that cord isonthe bottom.
2. Lineup adapter with hoseinletholeonfaceof cleaner (Diagram 1).
3. Slide adapter intohose inlet holeand turn clockwiseto lock (Diagram 2).
4. Give hose a slighttugto besure itis in place securely.
5. Plugendof externalhose cord intooutlet oncanister belowthe hoseattachmentarea (Diagram 3).
HOW TO OPERATE:
1. Plugpowercord into electrical outlet.
2. Turncanister "on" bydepressingcenterswitch labeled"push"on powercontrol button(Diagram 4).
3. Selectproperspeedby rotatingdial. Speed rangesfrom highto low.
4. Selectcarpet or barefloor cleaning.
a. Carpet Cleaning
- Depress power switchwithyour foot toturnthe power nozzle "on".
Besure brushroll is rotatingfor effectivecleaningand grooming.
b. Bare Floor Cleaning
- Power nozzle: Depressthe powerswitchagaintoturn the power
nozzleoff. Besure brushrollstopsrotating. Bare Floor Brush: Disconnectpower nozzle
and attach brushto wands. NOTE: to reduce the risk ofinjury
- unplug cleaner before con-
nectingor disconnectingpower nozzle.
ATTACHMENT INSTALLATIONAND REMOVAL
1. Chooseany of the handy accessoriesto meetyour various cleaningneeds. Then simply push
it
firmly intothe hoseorwand end.
2. The hosecan beused aloneorwith many combinations of wands andtools. Pushthewand into
the hosehandleuntilthe pinlocksinto place.
3. To removethe tool, pullapart gently. You maygently rotatethe attachment backandforth a little
to makethe removaleasier. To unlock thewand, pushpin, rotate andthenpullapart.
AUTO CORD WRAP
1. Pushbuttonfor automatic cord rewind(Diagram4).
2. Retractablecord isonthe backofthe canister (Diagram6).
5
FIGUREA
PowerNozzle

Diagram 1
Remove dirt container by ling from the front
~iagh~ 2
Tlt biit'co$a~nersbajght up and out of canister.
Dhgram 3
Rh filter to empty and dean cfrt amkina-.
CLEANING DlRT CONTAINER & FILTER
WARNING: TO REDUCETHE RlSK OF INJURY FROM MOVING PARTS - UNPLUGCLEANER BEFORE SERVICING.
REMOVE
& EMPTY DlRT CONTAINER: FOR BEST RESULTS EMPTY DlRT CONTAINERAFTER EACH USE.
WARNING: DO NOT USE DlRTCONTAINER HANDLETO CARRY CLEANER.
1. Removedirt container by liftingfrom the front (Diagram 1). Tilt dirt containerstraight upandout of canister(Diagram
2. Removefilter assembly to em~tvand clean dirt container(Diagram3). 2).
3. Beforereplacingfilter, shakedirtbom filter. NOTE:
d he pkatedfilter is attachedto the dirt container lid. Itcan be cleanedperiodically
byshakingor brushingthe dirt out ofthe pleats. After continuoususage the filter mayneedto bereplaced.
4. Placethe tab onthe front of the dirt containerinthe slot onthe frontof the canisterwhen returningthe dirt container to its position,
and lock handleinplace (Diagram 1).
CLEANINGDlRT CONTAINER:
1. Use a sponge and lukewarmwater to wipe compartmentclean. Letdry completelybefore usingagain.
Diagram 1
Diagram 2
Remove dlrtwnta~ner from canister. ~ Replace filler.
-9-3.-
~~thi.filbrcover~~repboe~ustiil-
ter.
FILTER REMOVAL & REPLACEMENT
WARNING: TO REDUCETHE RlSK OF INJURY FROM MOVINGPARTS - UNPLUG BEFORESERVICING.
1. Removedirt containerfrom canister (Diagram 1).
2. To replacefilter-remove filter assemblyfrom dirt container (Dia gram 2). Discardold filter. Replacewith newfilter.
3. To replace exhaust filter ontop of the cleaner
- liftthefilter cover (Diagram3). Removeand replacethefiltercassette (Diagram 4).
Closefilter cover.
4. Placethe tabon thefrontof the dirt container inthe slot onthefrontof the canisterwhen returningthedirt container to its position
(Diagram 1).
5. Filterreplacementscanbeordered bycallingtollfree 1-800-321-1 134.Filter part#2-260440-000. Exhaust Filter part #2-260230-000.
MICRO FRESH EXHAUSTFILTER
-Our uniquefiltrationsystemfor over 99.9% "freshexhaustair.
-Ideal for allergysufferers.

WARNING: TO REDUCE RISK OF PERSONALINJURY - UNPL
Problem
I Possible Reasons
Cleanerwon't run
Cleanerwon't pick-up
or low suction
1. Power cord notfirmly pluggedintooutlet.
2. Cord notconnectedto cleaner.
3. Blownfuse or tripped breaker
.
4. Needsservice.
1
. D irtcontainernot installedcorrectly.
2. Dirtcontainerfull.
3. Brushrollworn.
4. Brokenor worn belt
5. Cloggedfilter.
6. Nozzleldirtpassagehoseclogged.
7. Properspeed not selected.
8. Brush roll is turned off.
Dustescapingfrom cleaner 1. D irtContainerfull.
2. Dirt Containernot installedcorrectly.
3. Hosenotinstalledcorrectly.
4. Handleseal.
Cleanertools won't pick up 1. Hoseclogged.
2. Hoseinletclogged.
3. Dirtcontainerfull.
4. Filterclogged.
Possible Solutions
1. Plugunitinfirmly.
2 . Connect cordto cleaner - Pg. 5.
3. Checkfuse or breaker. Replacefu selreset breaker.
4. Take to service centeror call 1-800-321-1 134.
1
. ReviewDirtContainer Removaland Replacement-Pg 6.
2. Empty DirtContainer-Pg. 6.
3. Replacebrushroll-Pg. 7.
4. Replacebelt-Pg. 7.
5. Rem ove filter and clean-Pg. 6.
6. Removebasenozzle cover; removeobstruction OR
6. Removehose; removeobstruction.
7. Sel ect speed - Pg. 5.
8. Tum brush roll on - Pg. 5.
1. Empty Dirt Container-Pg. 6.
2.
ReviewDirtContainer Removaland Replacement-Pg. 6.
3. ReviewHoseInstallation-Pg. 5.
4. Checkhandleassembly.
1. Removehoseandtools; removeobstruction-Pg.
5
2.
Removehoseandclean inlet.
3. Em ptydirt container-Pg.
6.
4. CI eanfilter-Pg. 6.
ANY OTHER SERVICING SHOULD BE DONE BYAN AUTHORIZED SERVICE REPRESENTATIVE
CUSTOMER SERVICE
(1-800-321-1134)
Inthe event that further assistanceisrequired, see your Yellow Pagesfor an authorized Royal Dealer. Costs of any transport ationto
andfrom any placeof repair are to bepaidby the owner. Theservice parts used inthis unitareeasily replaced and readily available
from an authorized Royal Dealeror retailer. Always identify your cleaner bythe model numberwhen requestinginformationor o rder-
ingreplacement parts. (The modelnumberappearsonthe bottomof the cleaner.)
