DIVERSITECH ClearVue User guide

PUMP™
ClearVue Pump
System Installation

Contents
Introduction
3 Variable Speed and Li
5 Floatless Sensor™
7 Other Features
System Installation
9 Unpacking, Pump Location and Mounting
10 Electrical and High Level Alarm Connection
11 Inlet and Outlet Tubing Connections
12 Electrical Installation Requirements and Safety Switch Connections
Operation
12 Power, Pump Test, and Normal Operation
13 Variable Li, Cleaning, and Homeowner Instruction
Reference and Troubleshooting
14 Button Reference Chart
15 LED Indicator Reference Chart
Technical Information
16 Troubleshooting Guide
18 General Data and Safety Information

PUMP
™
Introducing…..ClearVue
Thank you for the purchase of the ClearVue™ condensate pump.
ClearVue™ automatically removes condensate water just like a standard
condensate pump but with many customer inspired improvements.
Variable Speed and Li - See page 3 and 4.
Floatless Sensor™ - See page 5.
With DiversiTech’s Floatless Sensor™ technology, ClearVue™ eliminates
the oat switch - one of the most common problems with conventional
condensate pumps.
ClearVue™ uses patent pending water
sensing technology to detect condensate so that there are no more
stuck oats!
ClearVue™ also features a see-through tank to give the
service tech and homeowner a clear view of water, blockage, and
buildup in the tank. This clear tank allows for quick troubleshooting due
to normal buildup caused by daily condensate generation.
™

Variable Speed and Li
ClearVue pump’s floatless sensor technology senses how fast water is filling the tank
and determines how hard the ClearVue needs to pump in a given installation, then
pumps only to that height. If there is a partial clog in the drain line, ClearVue figures
that out, and pumps a little harder. If the clog doesn’t clear, ClearVue goes into a
cleaning cycle and pulses the discharge water to try to dislodge the clog.
The variable lift in ClearVue assures that the pump impeller is spinning only as fast as
is needed to lift the condensate water to the height needed. A slower spinning impeller
means significantly less noise than conventional condensate pumps. Variable speed is a
proven, quieting feature in furnace blower motors. This electronically controlled
technology is now available in a condensate pump - ClearVue by DiversiTech.

™

CHECK FOR
SHIPMENT
DAMAGE

Variable Li
ClearVue pump features variable speed and lift. ClearVue pumps only as hard as it
needs to, in a given installation, to lift the condensate water away. The lower the lift, the
slower the pump runs, and the quieter the operation.

Button Function
Manually test motor operation
Manually drain water from
pump
Run a clean cycle
Activate or deactivate the
audible alarm
Silence the audible alarm
(when enabled)

LED Indicator
Light
Status
Solid Green LED
Solid Amber LED
Solid Amber LED &
Flashing Red LED
Solid Amber LED &
Flashing Red LED &
Flashing White LED
Flashing White LED
Flashing White LED
& Solid Amber LED
Flashing Blue LED Indicates that pump sensors are operational.

Symptom Possible Condition

Corrective Action

120 Volt version
Rated Voltage
Rated Current Draw
Input Type
Head Height
Flow Rate at Zero Head
Maximum Rated Inlet
Flow Rate
Temperature Rating
Product Dimensions
Product Weight
Inlet Height from Base
Included Accessories
Wiring Color
References
120 Volts / 60 Hz
1.9 Amps
USA 3-prong plug
22 ft. maximum
1.6 GPM
500mL/min
t$POUJOVPVTEVUZ'˚
t.BYJOMFUUemperature 160F˚
t/PUTVJUable for contact with steam or gasses that exceed 160F˚
11.8” x 5.9“ x 6.7”
5 lbs.
w
t*OTUSVDUJPO4IFFUt4Uainless Steel Hang Tabs
t1MVH1rotector
t Remote Shutoff Leads with Insulated Terminals
t1olyethelene Inlet Covers (3)
Black - Live/Hot
WhitF/FVUral
Green - Ground
All installations must conform tP/&$BOEMPDBMDPEFSequirements

©2013 DiversiTech Corporation
DOC00039
6650 Sugarloaf Parkway
Duluth, GA 30097
678.542.3600
800.995.2222
678.542.3700 Fax
Send edits / corrections / comments on this
catalog to [email protected]
About DiversiTech
%JWFSTJ5FDI$PSQPSBUJPOJT/PSUI"NFSJDBTlargest manufacturer of equipment pads and a
leading manufacturer and supplier of compo-
nents and related products for the heating,
ventilating, air conditioning, and refrigeration
(HVACR) industry.
Headquartered in the Atlanta, GA metropolitan
area, DiversiTech manufactures a suite of
products which includes a wide range of
mechanical, electrical, chemical, and structural
parts for HVACR and electrical systems, and
swimming pool installations. The company
maintains manufacturing and distribution
facilities in key U.S. locations, Europe, and in the
Far East. DiversiTech has enjoyed a continued
history of successful growth and has acquired
industry-recognized names including Devco®
Enterprises, Wagner® Manufacturing, The Black
Pad®, Hef-T-Pad , and Specialty Chemical.
Patents Pending
