Boiler Condensate Pump
Installation Instructions
INSTALL

PH-0.8-LC
2
1. Carefully unpack the unit, check for damage and make sure that all of the required parts are included. The units
are thoroughly tested before packaging to ensure safe delivery and operation. If there is any sign of damage due to
shipment, return it to the place of purchase for repair or replacement.
2. Choose a mounting location near the air-conditioner or boiler. The pump must be mounted level and the inlet must
be below the lowest drain.
• Fully automatic operation
• Low noise, ball-bearing motor with thermal protector
• Check valve to prevent back-ow of liquid into the unit
• Overow safety alarm switch
• Compact size
The PH-0-8LC condensate pump is designed to automatically remove condensate uid from an air-conditioner,
evaporator coil and/or an oil or gas condensing warm boiler. This pump is made from a tough ABS plastic body to resist
corrosion and impact.
MODEL PH-0.8-LC
Max ow 150 lph
Max head 3m
Tank capacity 0.8 litres
Volts 230V / 65 VA
Hz 50Hz
Discharge size 9.5mm (3/8”)
High-level alarm Volt free
Height 128mm
Length 185mm
Width 86mm
Weight 1.0kg
Cable length 1.95m
FEATURES
FEATURES
SPECIFICATION
INSTALLATION
FOR FURTHER INSTALLATION ADVICE PLEASE CALL THE TECHNICAL SUPPORT HELPLINE ON 0115 900 5858.
