dji LIGHTBRIDGE User manual

©2014 DJI. All Rights Reserved. 1
DJI LIGHTBRIDGE
User Manual V1.0
2014.08

©2014 DJI. All Rights Reserved. 2
Disclaimer
Thank you for purchasing the DJI LIGHTBRIDGE. Please visit the DJI LIGHTBRIDGE page on www.dji.com
regularly to keep up with product information, technical updates and manual corrections. Information in this
manual is subject to change without notice in line with product upgrades and updates.
Users must comply with local radio transmission laws and regulations when using this product. In using this
product, you hereby agree to this disclaimer and signify that you have understood all points completely. When
assembling this product, follow all instructions carefully. The manufacturer and seller assume no liability for any
damage or injury arising from the use of this product.
DJI is a registered trademark of DJI. Names of product, brand, etc., appearing in this manual are trademarks or
registered trademarks of their respective owner companies. This product and manual are copyrighted by DJI
with all rights reserved. No part of this product or manual shall be reproduced in any form without the prior
written consent or authorization of DJI.

©2014 DJI. All Rights Reserved. 3
Profile
A complete DJI LIGHTBIRDGE comprises of an air system and a ground system. It is a high definition video
transmitter, flight controller On Screen Display (OSD) and supports remote controls using the 2.4GHz
frequency band. As it is small, power efficient and highly sensitive, the DJI LIGHTBRIDGE can be used for
many activities. The air system must be attached to the aircraft and the ground system must be connected to a
monitor to display the video and flight controller OSD information.
When the DJI LIGHTBRIDGE transmits the video and flight controller OSD information, the air system is the
transmitter while the ground is the receiver. The air system pulls video from the camera and OSD information
from the flight controller then modulates it and transmits to the ground system. The ground system then
receives the information, demodulates it and sends it to a monitor or mobile device. The DJI LIGHTBRIDGE
App, available for smart devices is required for an ideal viewing experience.
When the DJI LIGHTBRIDGE transmits the remote control signal the ground system works as a transmitter
while the air system works as a receiver. The ground system can connect to two remote controls, one for
aircraft and the other for gimbal control. A DJI flight control system with DBUS port is required as the built in
receiver only supports the DJI DBUS protocol.
* 2.4GHz remote controls must be connected correctly to the ground system. Incorrect connection may lead to
malfunction due to interference.

©2014 DJI. All Rights Reserved. 4
Caution
Aircraft in flight can cause serious damage or injury. Please fly safely at all times.
Assembly Cautions
(1) Install antennas before powering on ground system or air system.
(2) Point air system antennas downward when in use, do not twist or bend antennas. Avoid obstructing
antennas to ensure transmission quality.
(3) Keep both ends of air system antennas as further as possible to achieve optimal transmission
performance. In addition, keep these antennas away from metals.
(4) Use only DJI approved antennas and installed them correctly. Other antennas are incompatible.
(5) Only 2.4GHz remote control can be connected to ground system of DJI LIGHTBRIDGE. Chose the
remote control with PPM trainer output.
(6) 2.4GHz remote controls must be connected to ground system for aircraft and gimbal control through
training ports. RF functions must be switched off.
(7) Do not create shorts or open circuits when soldering.
(8) Do not rotate gimbal if connected to camera HDMI port using DJI AV gimbal. This will cause gimbal
or HDMI cable damage.
(9) Disconnect HDMI cable from the camera when powering on the DJI non-HD gimbal. Failure to do so
might damage HDMI cable.
(10) Keep HDMI cable away from on-board GPS module.
(11) Do not modify DJI LIGHTBRIDGE.
Usage Cautions
(1) Check that all connections are correct and firm before every use.
(2) Check ground system battery capacity before every use. If the battery capacity is lower than 25%,
charge ground system. If ground system powers off, the air system will enter failsafe mode.
(3) Check environment before every use to ensure no 2.4GHz device interference (e.g. other 2.4GHz
remote controls, Phantom 2 Visions).
(4) Check remote control channels using DJI LIGHTBRIDGE Assistant before every use to ensure a good
connection and normal functionality.
(5) The air system built-in receiver will go into failsafe mode if the remote control and ground system are
disconnected during use.
(6) Turn smart device sound volume to maximum to hear alarms more clearly, e.g. bad remote control
signal and low aircraft battery capacity.

©2014 DJI. All Rights Reserved. 5
(7) Flight control system OSD work best when more than 6 GPS satellites are searched.
(8) Land slowly (≤1.5m/s) with the Phantom 2, as rapid landings can cause it to spin.
Others
(1) We strongly recommend using as many DJI parts as possible.
(2) If you have problems you cannot resolve, please contact your dealer or DJI customer service.

©2014 DJI. All Rights Reserved. 6
Contents
Disclaimer.......................................................................................................................................................................................................2
Profile ............................................................................................................................................................................................................. 3
Caution........................................................................................................................................................................................................... 4
Contents........................................................................................................................................................................................................ 6
In the Box...................................................................................................................................................................................................... 7
1 Introduction............................................................................................................................................................................................... 9
1.1 Air system....................................................................................................................................................................................... 9
1.2 Ground System ...........................................................................................................................................................................11
2 Installation................................................................................................................................................................................................13
2.1 Air System Installation.............................................................................................................................................................13
2.1.1 Installing Antennas.............................................................................................................................................................13
2.2 Ground System Installation ..................................................................................................................................................13
2.2.1 Installing Antennas ...........................................................................................................................................................13
2.2.2 Remote Control Connection .......................................................................................................................................14
2.2.3 Remote Control Configuration...................................................................................................................................14
2.2.4 Video Output Connection............................................................................................................................................16
2.3 Connection Scenario ..............................................................................................................................................................16
2.3.1 DJI HD Gimbal ...................................................................................................................................................................16
2.3.2 DJI non-HD Gimbal .........................................................................................................................................................21
2.3.3 Phantom 2 Mode.............................................................................................................................................................23
2.3.4 DIY Mode...........................................................................................................................................................................24
3 Using DJI LIGHTBRIDGE..................................................................................................................................................................26
3.1 Master-Slave Mode..................................................................................................................................................................26
4 Using DJI LIGHTBRIDGE App........................................................................................................................................................27
4.1 Downloading DJI LIGHTBRIDGE App.............................................................................................................................27
4.2 Register and Login .................................................................................................................................................................27
4.3 DJI LIGHTBRIDGE App Usage......................................................................................................................................... 30
4.4 DJI LIGHTBRIDGE App Settings.......................................................................................................................................31
4.5 Using Ground System ...........................................................................................................................................................35
5 Assistant...................................................................................................................................................................................................36
5.1 Installing Driver and Assistant.............................................................................................................................................36
5.2 Using Assistant.........................................................................................................................................................................36
5.2.1 Using LIGHTBRIDGE Assistant...................................................................................................................................37
5.2.2 Remote Control Channel Settings ...........................................................................................................................37
5.2.3 Firmware Upgrade..........................................................................................................................................................39
6 Specification............................................................................................................................................................................................41
7 Appendix .................................................................................................................................................................................................42
7.1 Supported DJI Products........................................................................................................................................................42
7.2 Relinking.....................................................................................................................................................................................42
7.3 Recharging Ground System................................................................................................................................................42
7.4 Supported Resolution ...........................................................................................................................................................43
7.5 Supported Remote Control ............................................................................................................................................... 44
8 FAQ...........................................................................................................................................................................................................45
FCC and IC Statements ........................................................................................................................................................................48

©2014 DJI. All Rights Reserved. 7
In the Box
Modules
Air System ×1
Ground System ×1
Air system paddle antenna ×2
Air system antenna ×3
Ground system antenna ×2
Air System Cables
GIMBAL cable ×1 (A)
If used with PHANTOM 2, connect cable to
reserved 6-PIN port on central board for air system
power supply and OSD info input.
DBUS cable ×1
Connect to flight control system DBUS port for
communication.
Air system power and CAN cable ×1
Connect to Air system GIMBAL port,
one end for power, the other for CAN port.
AV cable ×1
Connect camera’s AV output to AV input port.
HDMI cable (D-D) ×1
Connection for camera’s HDMI output.

©2014 DJI. All Rights Reserved. 8
Ground System Cables
Remote control cable ×1
For remote control training port connection.
Connect red port 1 to a remote control for aircraft
control and black port 2 to a remote control for
gimbal control.
Remote control training cable×1
Connect the red jack to the aircraft remote
control to control.
Training port cables（rectangle）×2
Remote control training port connection.
Charger ×1
Connect to ground system when charging.
USB upgrade cable ×1
Connect to a PC when upgrading firmware.
Optional Packet
Optional packet
(1)
HDMI cable (D-D) ×1
Ground system holder ×1
Smart phone holder ×1
Optional packet
(2)
HDMI cable for Zenmuse ×1

©2014 DJI. All Rights Reserved. 9
1 Introduction
1.1 Air system
Front View
[1] Gimbal Port
This port be connected to the G7 port on a DJI HD gimbal or to other ports for the functions listed below:
a) Power supply: (V+,V-) On-board battery (3S~6S) power connection. Non-DJI HD gimbal users must
use a seperate power cable or air system power CAN cable to connect air system and on-board
battery.
b) CAN-Bus: (L,H) OSD information from the flight system. For non-DJI HD gimbal users, connect to
the CAN-Bus port (for DJI A2 user, use the CAN 1 Bus port) on the flight control system with a
seperated CAN-Bus cable.
c) DVSB: (G-,+) DVSB video input from DJI HD gimbal.
[2] DBUS port
Connect built in receiver interface to DJI flight control system DBUS port, usually located on the main
controller labled X2. No other receiver requried when DBUS is used. The A2’s built in reciever will
automatically be disabled when DBUS port is used.
[3] Upgrade port
Connect to PC to upgrade firmware using DJI LIGHTBRIDGE Assistant.
[4] Link button
Press to link air system with ground system.
[5] CONTROL indicator
Remote control link indicator displays communtation status of air and ground systems.
Indicator
Description
Action
Linking in progress.
Link button has been pressed. Air system is
attempting to link with ground system.
Signal detected but not linked.
Link required.
Successful link.
Normal.
[]1[]2[]3[]4[]5[]6

©2014 DJI. All Rights Reserved. 10
No detected signal.
Power on Ground system. Check distance
between ground and air systems.
[6] Video indicator
Video link indicator shows video source transmission status.
Indicator
Description
Instruction
AV/HDMI signal detected and functioning
normally.
Normal.
AV/HDMI signal detected. Transmission
failed.
Air system or ground system power
cycle required.
No video source detected.
Check camera and connection.
Top View
[1] Ventilation inlet
Do not obstruct ventilation fan outlet to ensure maximum cooling efficiency.
Side View
[1] HDMI In Port
Connect to HDMI input device. Maximum input rate is 1920*1080@60fps.
[2] AV Port
Connect to AV input, including:
a) AV output from camera
b) AV output from DJI AV gimbal control unit (GCU)
[]1
[]1[]2
