dji M300 Quick setup guide

Need help? Email support@fieldofviewllc.com or call 701-203-3757 x3
1
DJI M300 Integration Guide
1. Secure the GeoSnap PPK M300 mounting bracket using the 4 screws and included hex
key to the top of the drone.
Need help? Email support@fieldofviewllc.com or call 701-203-3757 x3
2
2. Place the GeoSnap PPK on top of the M300 mounting bracket. You must first insert the
tab of the GeoSnap PPK into the front receptacle on the M300 mounting bracket. Then
press down and turn the two quarter-turn studs clockwise until a click is felt to lock the
GeoSnap PPK in place. Lift up on the GeoSnap PPK to ensure it is locked in place.
Need help? Email support@fieldofviewllc.com or call 701-203-3757 x3
3
3. Attach the cable routing clip in the location shown and route the GeoSnap PPK-to-
hotshoe module cable through the clip.
(The left cable routing clip pictured but not circled is only used when interfacing with
the Auxiliary 6-pin connector for specialized integrations or when using MicaSense
cameras.)
Need help? Email support@fieldofviewllc.com or call 701-203-3757 x3
4
4. Plug the GeoSnap PPK-to-hotshoe module cable into the 8-pin connector from the side
of the GeoSnap PPK.
5. When you’re ready to fly, plug in the red battery power connector on the GeoSnap PPK.
Need help? Email support@fieldofviewllc.com or call 701-203-3757 x3
5
Offsets:
Single SKYPORT Configuration
Dual SKYPORT configuration
Bottom-center of SKYPORT-to-
antenna L1 phase center offset:
Bottom-center of SKYPORT
I-to-antenna L1 phase
center offset:
Bottom-center of SKYPORT
II-to-antenna L1 phase
center offset:
X offset: +0.041 meters
Y offset: -0.094 meters
Z offset: +0.271 meters
X offset: +0.123 meters
Y offset: -0.094 meters
Z offset: +0.271 meters
X offset: -0.041 meters
Y offset: -0.094 meters
Z offset: +0.271 meters
SKYPORT I
SKYPORT II
