DK2 OPW480EV User manual

Customer Service / Monday-Friday 8am-4pm EST / 1-888-277-6960 www.dk2.com
DK2 USA WEST
3311 MEADE AVENUE STE
E DOCK 13, LAS VEGAS, NEVADA
89102 USA
DK2 USA EAST
3750 SOUTH AVENUE
NORTH UNIT, TOLEDO, OHIO
43615 USA
DK2 CORPORATE HEAD OFFICE
5330 MAINWAY
BURLINGTON, ONTARIO
L7L6A4 CANADA
OPW480EV
2200 PSI 2.4 GPM 57.6V LIION POWERED
PRESSURE WASHER
USER MANUAL
LiFePO4
ADVANCED LI-ION TECHNOLOGY

2| OPW480EV man.
WARRANTY
PLEASE DO NOT RETURN TO THE STORE
YOU HAVE A 1-YEAR WARRANTY AND DK2 WILL REPLACE A DEFECTIVE PART FOR FREE. CALL US AT 1-888-
277-6960 FOR FAST WARRANTY PARTS AND QUESTIONS.
WHAT IS COVERED – 1-YEAR LIMITED WARRANTY INCLUDED
DK2 Inc. warrants to the original purchaser that product will be free and clear of manufacturing defects in
workmanship and materials under normal use and service for a period of one (1) year from the date of the original
purchase. If within one (1) year from the original date of purchase this product fails due to defect in material or
workmanship, DK2 Inc. will repair, replace, or supply any covered defective part at our option. DK2 Inc. is 1-year
parts only warranty no labor.
Upon expiry of one (1) year, DK2 Inc. will have no further liability related to the product. DK2 Inc. does not authorize
any party, including its authorized distributors or dealers, to oer any other warranty on behalf of DK2 Inc.
THIS WARRANTY DOES NOT COVER OR APPLY TO:
a) Damage to the product due to misuse, mishandling and abuse
b) Improper installation, maintenance and storage
c) Expendable parts such as nuts and bolts, pins and springs, wiring and switch components, hydraulic hoses
and fittings, cutting teeth, cutting chains, cutting blades, throttles, belts and tires.
d) Normal wear and tear
e) Consequential damage & incidental damages such as damage to persons or property
PROCEDURE FOR OUTDOOR POWER EQUIPMENT WARRANTY
Within the one (1) year warranty period, the purchaser of the product can CALL 1-888-277-6960 or contact us on
www.dk2.com. Notify us of the claimed defect and provide proof of original purchase. At this time the validity
of the claim will be determined, and if approved replacement parts will be issued. No returned product will be
accepted under warranty unless accompanied by an RGA# issued by DK2 Inc.
DAMAGED FREIGHT
Damage to your product caused by freight mishandling is NOT covered under warranty. If your freight arrives
damaged, REFUSE it. Inspect your product when it arrives, otherwise if you accept it, you will be responsible for
filing any freight claims with the delivery company. DK2 Inc. warranty excludes damage to product.
RESOLUTION FOR A DEFECTIVE PRODUCT.
Call us at 1-888-277-6960 between 8am-4pm Monday to Friday EST.
ENGLISH

v.230419 | 3
ONLINE RESOURCES
LEARN MORE ABOUT YOUR PRODUCT
Visit your product’s web page by visiting detailk2.com/shop-
battery-power-equipment/p/opw480ev-k or scan the QR code
on the left.
PURCHASING REPLACEMENT PARTS
In need of replacement parts? visit detailk2.com/shop-parts or
scan the QR code on the left.
VIEW THIS USER MANUAL ON YOUR PHONE
Scan the QR code on the left to view this product’s user manual
on your mobile device.
ENGLISH

4| OPW480EV man.
TABLE OF CONTENTS
WARRANTY..........................................................................2
ONLINE RESOURCES .................................................................3
TABLE OF CONTENTS ................................................................4
TECHNICAL SPECIFICATIONS..........................................................5
SECTION I • SAFETY ..............................................................6
SAFETY CONVENTIONS ..............................................................7
IMPORTANT SAFETY INFORMATION....................................................7
SAFETY DECALS .....................................................................8
SAFETY DEFINITIONS.................................................................8
GENERAL SAFETY INFORMATION ......................................................9
SPECIFIC SAFETY RULES.............................................................10
GETTING TO KNOW YOUR MACHINE ..................................................12
SECTION II • ASSEMBLY ..........................................................13
CHECK THE PACKING................................................................14
STEP 1: FRAME FEET .................................................................14
STEP 2: WHEELS ....................................................................15
STEP 3: NOZZLE PANEL ..............................................................16
STEP 4: HIGH PRESSURE CONNECTION ............................................... 17
STEP 5: NOZZLE & HOSE............................................................. 17
SECTION III • OPERATION.........................................................18
OPERATING INSTRUCTIONS ..........................................................19
WATER SUPPLY .....................................................................19
BEFORE SPRAYING ..................................................................19
USING THE DETERGENT .............................................................20
CLEARING BLOCKAGE ...............................................................20
STARTING THE MACHINE ............................................................21
STOPPING THE MACHINE ............................................................21
SECTION IV • MAINTENANCE .....................................................22
BEFORE EACH USE ..................................................................23
REPLACEMENT PARTS ...............................................................23
MODIFICATIONS ....................................................................23
WATER SUCTION FILTER .............................................................23
PUMP OIL CHANGE..................................................................23
SECTION V • PARTS & SCHEMATICS ...............................................24
SCHEMATICS .......................................................................25
PARTS LIST .........................................................................26
ENGLISH

v.230419 | 5
TECHNICAL SPECIFICATIONS
MODEL NUMBER OPW480EV
BATTERY 57.6V Max, 1,024Wh, 20Ah LiFePO4
MOTOR 2,000W (4,000W Max) 3,500 RPM cordless brushless EV-grade motor
TORQUE 4.1 ft/lb (5.5 Nm) rated
18.4 ft/lb (25 Nm) peak
CHARGER 120V AC/DC 200W
WHEELS & TIRES Never-flat
PUMP 3-piston axial cam
MAX PRESSURE 2,200 PSI (150 Bar)
MAX FLOW RATE 2.4 GPM (9.0 LPM)
DIMENSIONS 29.5” (L) x 31.5” (W) x 41.3” (H)
74.9 cm (L) x 80 cm (W) x 104.9 cm (H)
WEIGHT 104.6 lb (47.4 kg)
SHIPPING DIMENSIONS 26.8” (L) x 22.1” (W) x 18.5” (H)
68 cm (L) x 56 cm (W) x 47 cm (H)
SHIPPING WEIGHT 114.6 lb (52 kg)
WARRANTY 1-year limited
ENGLISH

SECTION I • SAFETY

v.230419 | 7
SAFETY CONVENTIONS
DANGER! This indicates a hazardous situation, which, if not avoided, will result in death or
serious injury.
WARNING! This indicates a hazardous situation, which, if not avoided, could result in death
or serious injury.
CAUTION! This indicates a hazardous situation, which, if not avoided, may cause minor or
moderate injury.
ADDITIONAL INFORMATION AND POTENTIAL CHANGES
We reserve the right to discontinue, change, and improve our products at any time without notice
or obligation to the purchaser. The descriptions and specifications contained in this manual were
in eect at printing. Equipment described within this manual may be optional. Some illustrations
may not be applicable to your machine.
IMPORTANT SAFETY INFORMATION
WARNING! Read and understand the complete User Manual before assembling
or using this product. Failure to comprehend and comply with warnings,
cautions and instructions for assembly and operation could result in serious
injury or death.
WARNING! Do not permit children to operate this equipment at any time. Do not permit
others that have not read and understood the complete User Manual to operate this
equipment. Operation of power equipment can be dangerous. It is the sole responsibility
of the operator to understand the assembly and safe operation of this product.
DANGER! INTENDED USE: Do not use this machine for any purpose other than pressure
washing, for which it was designed. Any other use is unauthorized and may result in serious
injury or death.
DANGER! PERSONAL PROTECTIVE EQUIPMENT: When operating
this machine, it is essential that you wear safety gear including goggles
or safety glasses, steel-toed shoes and tight-fitting gloves (no loose
cus or draw strings). Always wear ear plugs or sound-deafening
headphones to protect against hearing loss when operating this
pressure washer.
CAUTION! Do not wear loose clothing or jewelry that can be caught
by moving parts of the machine. Keep clothing and hair away from all moving parts of the
machine.
ENGLISH

8| OPW480EV man.
SAFETY DECALS
Make sure all safety warning decals are attached and in readable condition.
Please call DK2 at 1 [phone] if you need help replacing missing or defaced safety decals.
SAFETY DEFINITIONS
The purpose of safety decals and symbols is to attract your attention to possible dangers. The
safety symbols, and their explanations, deserve your careful attention and review in order to
safely operate this machine. The safety warnings do not eliminate any danger, the purpose of
these warnings is to bring awareness to the dangers of the machine. The instructions or warnings
they give are not substitutes for proper accident prevention measures and care while using the
product.
57.6V 2,200 PSI Li-ion PRESSURE WASHER
NETTOYEUR À PRESSION 2 200 PSI 57,6V Li-ion
RATED PRESSURE / PRESSION NOMINALE :
PERMISSIBLE PRESSURE / PRESSION ADMISSIBLE :
RATED FLOW / DÉBIT NOMINAL :
MAX FLOW / DÉBIT MAX :
MOTOR POWER / PUISSANCE DU MOTEUR :
2,200 PSI
2,500 PSI
2.2 GPM (8.5 LPM)
2.4 GPM (9 LPM)
2000W (MAX 4000W)
WARNING / ATTENTION
(EN) RISK OF FLUID INJECTION: High pressure spraying can penetrate skin. DO
NOT spray at people or animals. Turn water hose o when changing quick-connect
tips. Make sure quick-connect tips are secured in quick-connect socket. RISK OF
BURNS: DO NOT touch the motor. RISK OF EYE INJURY: Spray may propel objects.
Always wear safety glasses. RISK OF INJURY: Gun kicks back. Hold with both hands.
DO NOT REMOVE THIS LABEL.
(FR) RISQUE D'INJECTION DE LIQUIDE : La pulvérisation à haute pression peut
pénétrer la peau. NE PAS pulvériser sur des personnes ou des animaux. Débranchez
le tuyau d'arrivée de l’eau lorsque vous changez les embouts à connexion rapide.
Assurez-vous que les embouts à connexion rapide sont sécurisés dans une prise à
connexion rapide. RISQUE DE BRÛLURES : NE PAS toucher le moteur. RISQUE DE
BLESSURE AUX YEUX : Le jet peut propulser des objets. Portez toujours des lunettes
de sécurité. RISQUE DE BLESSURE : Le pistolet rebondit. Tenez avec les deux mains.
NE PAS RETIRER CETTE ÉTIQUETTE.
ENGLISH

v.230419 | 9
GENERAL SAFETY
INFORMATION
WARNING! Keep guards in place and
in working order. Never operate the
tool with any guard or cover removed.
Make sure all guards are operating
properly before each use.
CAUTION! Remove adjusting
keys and wrenches. Form habit
of checking to see that keys and
adjusting wrenches are removed from
tool before turning it on.
WARNING! To reduce the risk of
injury, keep children and visitors
away. All visitors should wear safety
glasses and be kept a safe distance
from the work area.
WARNING! Keepthe area ofoperation
clear of all persons, particularly small
children, and pets.
DANGER! Do not start or operate the
engine in a confined space, building,
near open windows, or in other
unventilated space where dangerous
carbon monoxide fumes can collect.
Carbon monoxide, a colorless,
odorless, and extremely dangerous
gas, can cause unconsciousness or
death.
CAUTION! Use the right tool. Don’t
force tool or attachment to do a job it
was not designed for. Don’t use tool
for a purpose not intended.
DANGER! Dress appropriately. Wear
long pants and long sleeves. Do not
wear loose-fitting clothing, neckties,
or jewelry. These items can get caught
and draw you into moving parts.
Rubber gloves and non-skid footwear
are recommended when working
outdoors. Also, wear protective hair
covering to contain long hair.
WARNING! Do not operate the
equipment while barefoot or when
wearingsandalsorsimilarlightweight
footwear. Wear protective footwear
that will protect your feet and improve
your footing on slippery surfaces.
CAUTION! Exercise caution to avoid
slipping or falling.
WARNING! Always wear eye
protection. Following this rule will
reduce the risk of serious personal
injury.
WARNING! Don’t overreach or stand
on a ladder, rooftop, or other unstable
support. Keep proper footing and
balance at all times.
CAUTION! Use only recommended
accessories. The use of improper
accessories may cause risk of injury.
CAUTION! Follow the maintenance
instructions specified in this manual.
CAUTION! Check damaged parts.
Before further use of the tool, a guard
or other part that is damaged should
be carefully checked to determine
that it will operate properly and
perform its intended function. Check
for alignment of moving parts, binding
of moving parts, breakage of parts,
mounting, and any other conditions
that may aect its operation. A guard
or other part that is damaged must
be properly repaired or replaced by a
qualified service center to avoid risk
of personal injury.
WARNING! Never leave tool running
ENGLISH

10 | OPW480EV man.
unattended. Turn power o. Don’t
leave the tool until it comes to a
complete stop.
WARNING! Keep the motor and
battery free of grass, leaves, or
grease to reduce the change of a fire
hazard.
CAUTION! Follow manufacturer’s
recommendations for safeloading,
unloading, transport, and storage of
machine.
CAUTION! Be thoroughly familiar
with controls. Know how to stop the
product and bleed pressure quickly.
CAUTION! Keep the tool dry, clean,
and free from oil and grease. Always
use a clean cloth when cleaning.
Never use brake fluids, gasoline,
petrolium products, or any solvents to
clean tool.
WARNING! Stay alert and exercise
control. Watch what you are doing
and use common sense. Do not
operate the tool when you are tired.
Do not rush.
DANGER! Do not operate the product
while under the influence of drugs,
alcohol, or any medication.
CAUTION! Check the work area
before each use. Remove all objects
such as rocks, broken glass, nails,
wire, or string which can be thrown or
become entangled in the machine.
WARNING! Do not use tool if switch
does not turn it o. Have the switch
replaced by a qualified service center.
WARNING! Before cleaning,
repairing, or inspecting, shut o
the motor and battery and ensure
all moving parts have stopped and
cooled down completely.
CAUTION! Avoid dangerous
environment. Don’t use in damp or
wet locations or expose to rain. Keep
work area well lit.
WARNING! Do not operate around
dry brush, twigs, cloth rags, or other
flammable materials.
WARNING! Risk of injection or injury
- Do not direct discharge stream at
persons.
SPECIFIC SAFETY
RULES
DANGER! Never direct water stream
toward people or pets, or any
electrical device.
CAUTION! Before starting any
cleaning operation, close doors and
windows, clear the area to be cleaned
of debris, toys, outdoor furniture,
or other objects that could create a
hazard.
WARNING! Never pick up or carry
machine while the engine is running.
WARNING! Never start the machine
if ice has formed in any part of the
equipment.
DANGER! Do not use acids,
alkalines, solvents, flammable
material, bleaches, or industrial
grade solutions in this product. These
products can cause physical injuries to
the operator and irreversable damage
to the machine.
ENGLISH

v.230419 | 11
CAUTION! Always operate the
machine on a level surface. If the
engine is on an incline, it could seize
due to improper lubrication (even at
the maximum lubricant level).
WARNING! High-pressure jets can be
dangerous if subject to misuse. The
jet must not be directed at persons,
animals, electrical devices, or the
machine itself.
WARNING! Hold the trigger handle
securely with both hands. Expect
the trigger handle to move when
the trigger is pulled due to reaction
forces. Failure to do so could cause
loss of control and injury to yourself
and others.
DANGER! Never attempt to make
any adjustments while the motor or
battery are running.
WARNING! Protective covers must
always cover rotating parts when the
motor or battery is running.
CAUTION! Check nuts and bolts for
looseness before each use. A loose
bolt or nut may cause serious engine
problems.
CAUTION! Before storing, allow
the motor and battery to come to a
complete stop, and allow them time
to cool o completely.
CAUTION! When servicing use only
recommended replacement parts.
Use of any other parts may create a
hazard or cause product damage.
CAUTION! ONLY use cold water.
WARNING! Make sure minimum
clearance of 3 feet is maintained from
combustible materials.
CAUTION! Never spray close to the
surface to be cleaned as you can
damage the surface.
CAUTION! After stopping the motor
and battery, always pull the trigger
on the trigger handle to relieve
stored pressure in the high-pressure
hose. Failure to do so could result in
serious personal injury.
WARNING! For outdoor use only.
WARNING! Ensure the high-pressure
hose is properly connected before
using the product.
ENGLISH

12 | OPW480EV man.
GETTING TO KNOW YOUR MACHINE
1Motor
2Battery
3Lower Frame
4Handle
5Frame Foot
6Panel
7Wheel
8Soap tank
9Lance
10 Spray Gun Handle
11 Nozzle
12 Hose
1
2
8
9
10
11
12
5
3
6
7
4
ENGLISH

SECTION II • ASSEMBLY

14 | OPW480EV man.
CHECK THE PACKING
Open and unpack all items, leave lots of working space, and inspect all parts.
Upon inspection of parts, if you find any missing or damaged parts, please call DK2 at 1 (888) 277-
6960 or contact [email protected]. Please do not return to the store.
NOTE: Every machine is tested during production, there may be a few drops of water inside the
pump assembly.
STEP 1: FRAME FEET
Install the frame feet (14) to the lower frame (13) using the hardware provided.
ENGLISH

v.230419 | 15
STEP 2: WHEELS
NOTE: Please ensure the machine is kept in an upright position for this step.
Install the axle (10) into the axle support tube on the lower frame (7), tighten the bolt to secure
in place. Fit a wheel (8,9) to the axle and secure using the locking nut provided, and repeat this
process for the next wheel.
ENGLISH

16 | OPW480EV man.
STEP 3: NOZZLE PANEL
Install the nozzle panel (5) to the upper frame (20) and secure using the nuts and bolts provided.
WARNING! Check the capacity of pump oil and ensure it is filled.
ENGLISH

v.230419 | 17
STEP 4: HIGH PRESSURE CONNECTION
Connect the high-pressure hose (A) to the unit’s high pressure outlet. Connect the high-pressure
hose to the trigger (B). Insert the lance (C) into the trigger. Press firmly against the spring tension
and twist the coupling into the locked position.
STEP 5: NOZZLE & HOSE
To insert a nozzle, pull back the quick-connect at the end of the
lance, insert the nozzle and release the quick-connect.
WARNING! Ensure the nozzle is securely inserted. If it isn’t,
it can fly out and cause serious injury or damage to property.
Connect the hose to the water inlet connector.
A
B C
ENGLISH

SECTION III • OPERATION

v.230419 | 19
OPERATING INSTRUCTIONS
DANGER! Read and understand the complete User Manual before assembling or using
this equipment! Failure to comprehend and comply with these warnings, cautions, and
instructions for assembly and operation could result in serious injury or death.
DANGER! Do not permit children to operate this equipment at any time.
DANGER! Do not permit others that have not read and understood the complete User
Manual to operate this equipment. Operation of the equipment can be dangerous. It is the
sole responsibility of the operator to understand the assembly and safe operation of this
equipment.
Please refer to Section II • Safety in this User Manual for an extensive list of warnings and
precautions to follow prior to operating this equipment.
WATER SUPPLY
WATER SUPPLY FROM WATER MAIN
• Connect a water supply hose (not included) to the water inlet connection of the pressure
washer.
• Turn on the water supply and pull the trigger until the water is continually flowing out of
the nozzle.
WATER SUPPLY FROM A CONTAINER
• Unscrew the coupling part for the water inlet.
• Screw the suction hose with filter (not included) onto the water connection of the unit.
• Hang the filter in the container.
• Vent the unit before operation.
• Unscrew the high-pressure line at the high-pressure outlet of the unit.
• Switch on the unit and let it run until water is free of bubbles at the high-pressure outlet.
• Switch o the unit and screw on the high-pressure hose again
BEFORE SPRAYING
Pull the trigger to eliminate trapped air
and wait for a steady flow of water to
emerge from the spray nozzle.
NOTE: To prevent accidental operation,
the trigger is fitted with a locking
mechanism.
ENGLISH

20 | OPW480EV man.
USING THE DETERGENT
(FIG. 1) It is recommended to use good quality pressure washer
detergent for use with this pressure washer. Please follow the
instructions on the fluid container. Most automobile detergents
are a combination of a detergent and wax solution. The viscosity
(thickness) of the detergent will increase in cold weather. It is
recommended that this type of detergent is diluted with water
before filling the container. When using wash and wax combination
solutions we recommend that they are diluted before use. As a
general guide, we would recommend a dilution ratio of 50/50.
However a trial and error process would determine the ideal dilution ratio for a particular detergent.
NOTE: A thick, viscous detergent will not flow freely from the detergent container and the residue
from this can cause a blockage in the flow system. After using the detergent, the system should
be flushed thoroughly using ample amounts of water. To activate detergent delivery, fit the black
LOW PRESSURE nozzle to the end of the lance. Suction and mixing will occur automatically as the
water flows through the pump.
CLEARING BLOCKAGE
(FIG. 2) If at any time the flow rate stutters or shows inconsistency,
release the trigger and switch OFF the machine. Squeeze the
trigger to relieve any pressure and check the jet in the end of the
lance for any blockage. If blockage is suspected, use some wire
to clean inside the nozzle.
FIG. 1
FIG. 2
ENGLISH
