DLS CRUISE CRPP-2.6CX User manual

User manual
Seat / Skoda / VW

Declaration of conformity
Welcome to DLS!
Thank you for buying a DLS Cruise CRPP-2.6CX. For us,
it’s all about the sound experience. We care deeply about
sound and construction quality. In order for your experience
to be as optimal as possible, it is important that you fully
read this manual, preferably before you start your
installation. Keep the manual in a safe and accessible place
for future reference.
Your speakers must be installed correctly in order to work
as intended. Make sure you have all necessary tools nearby
before starting and that you are completely confident in how
to proceed. If you feel the slightest uncertainty; feel free to
take the help of an experienced installer or a car audio
dealer.
DLS plug and play speakers for vehicles are manu-
factured in accordance with the EU directive EEC 95/54
(72/245/ EEC) and are marked with the approval
number. They are also marked in accordance with the
WEEE-directive 2012/19/EC. The products are also
produced in accordance with the EU RoHS directive
2015/863/EU.
Warranty
This coaxial speaker is covered by warranty, depending on
the conditions in the country where it is sold. If the speaker
is returned for service, please include the original dated
receipt with the product.
Winn Scandinavia AB
Elementvägen 15 - SE-702 27 Örebro - Sweden
Tel: [phone] - E-mail: [email protected]
www.dls.se
DLS speakers are engineered by DLS Sweden,
a part of:
Designed & Sound tuned in Sweden.
CRPP-2.6CX
DLS CRUISE
Content
Welcome
Pre installation
Dismount door panel
Remove door speaker
Mount door speaker
Running-in time
Specification speaker
Compatible car models
Product markings
Technical assistance
1
2
2
3
3
4
5
7
9
4

In most cases the screws used are Torx T30.
Unscrew them and store them in a safe place,
to re-use when re-mounting the door panel.
Use a wrench, size 10. Normally the bolt is located
at the underside of the door. Turn bolt 90 degrees.
Usually the clips/screws are placed by the white
rings. It may be different in your vehicle.
Dismount the door by removing the cover of the
door panel.
Hint: Use plastic PRY tools to avoid marks on
the panels and destroy the plastic clips.
Dismount door panel
Installation
Pre installation
Disconnect Battery
Included products:
2pcs Coaxial speakers
Included in box:
4pcs Adhesive foams for wrapping
4pcs Terminal crimp connectors
10pcs Blind rivets
1pc PRY Tool
1pc Manual
Before you start the process
of replacing speakers,
disconnect and secure the
negative terminal from your
battery/power source. This
will prevent the risk of
damaging yourself or the
products.
Place the disconnected terminal in a secure and
isolated location away from any possible
connection belonging to the battery/power source
system.
Some sound systems may vary in size of the door
speaker. Make sure that your vehicle has the same
size as this coaxial speaker, before you start the
assembly.
This is a generic mounting instruction. The
approach is similar to all of the described car
models. Some screws and clips may be placed
differently and depending on your car model.
The DLS CRPP-2.6CX can be installed instead of
DLS CRPP-2.6 but the OEM tweeter will in this
case, still be connected.
General info
2

Disconnect the window control panel, cables for
lights, speaker cable harness and any other
connections.
3
When the door panel is loose, start with softly
lifting it straight up, to remove the panel.
There are several electric and mechanical
connectors on the backside of the panel.
Release the door lock cable.
Use a 4mm drill to remove the rivets. Make sure
all remains from the old rivets are removed from
the inside of the door.
Just drill enough to remove the top of the rivets.
Mount door speakers
Place the new DLS driver in the hole for the
speaker. DLS recommends using a rivet tool (not
included in CRPP-2.6CX) and rivets to safely
mount the driver. (Step 3 might be done several
times)
Connect the speaker harness
Start the assembly of the door panel.
Reconnect all wires harness.
Connect all plugs to the door cover, reconnect the
unlocking device, place the door cover from the
top, by the window seal and push it gently down.
Make sure the clips are in place and can engage.
Give the door panel a push by the hand to attach
to the clips. Mount and fasten all screws to the
correct places.
Be careful when removing the panels and lids, so
there will be no marks.
Remove door speaker
The door speakers are fixed with rivets.

Finally
Start assembling the covers again to finish the work. Make sure that no screws or
clips are left over, reconnect the battery/power source terminal.
Finally, it’s time to play some good music and enjoy!
Running-in time
Allow the coaxial speaker to play for at least 15-20 hours in order to perform at its
possibly best. This run-in can be made with tone sweep or with just music.
Start at a moderate volume and increase the volume step by step during the running
in period. After the 15-20 hour run in session the performance and characteristics will
be in the correct condition.
For technical assistance, ask your car audio dealer where the product was sold or the distributor in your country. You
can always contact the DLS Helpdesk in Sweden at e-mail: [email protected]. Information can also be found on our WEB-
site www.dls.se. We follow a policy of continuous advancement in development. For this reason, all or part of the
specifications and designs may be changed without prior notice.
4
DLS Support
Car Model Year Front speaker Rear speaker
MAN TGE 2017-2022 CRPP-2.6CX*
SEAT ALTEA 2004-2015 CRPP-2.6CX* CRPP-2.6CX*
SEAT ALTEA XL 2004-2015 CRPP-2.6CX* CRPP-2.6CX*
SEAT ARONA 2018-2021 CRPP-2.6CX* CRPP-2.6CX*
SEAT AROSA 1997-2004 CRPP-2.6CX*
SEAT ATECA 2016-2021 CRPP-2.6CX* CRPP-2.6CX*
SEAT CORDOBA II 2002-2009 CRPP-2.6CX* CRPP-2.6CX*
SEAT IBIZA III 2001-2008 CRPP-2.6CX* CRPP-2.6CX*
SEAT IBIZA IV 2008-2017 CRPP-2.6CX*
SEAT IBIZA V 2018-2021 CRPP-2.6CX* CRPP-2.6CX*
SEAT LEON 2000-2005 CRPP-2.6CX*
SEAT LEON II 2006-2012 CRPP-2.6CX* CRPP-2.6CX*
SEAT MII 2012-2021 CRPP-2.6CX*
SEAT TOLEDO II 1994-2004 CRPP-2.6CX*
SEAT TOLEDO III 2004-2009 CRPP-2.6CX* CRPP-2.6CX*
SEAT TOLEDO IV 2012-2019 CRPP-2.6CX*
SKODA CITIGO 2012-2021 CRPP-2.6CX* CRPP-2.6CX*
SKODA FABIA I 1999-2007 CRPP-2.6CX* CRPP-2.6CX*
SKODA FABIA II 2007-2014 CRPP-2.6CX* CRPP-2.6CX*
SKODA FABIA III 2015-2021 CRPP-2.6CX* CRPP-2.6CX*
SKODA KAMIQ 2019-2021 CRPP-2.6CX* CRPP-2.6CX*
SKODA KAROQ 2018-2021 CRPP-2.6CX* CRPP-2.6CX*
SKODA KODIAQ 2017-2022 CRPP-2.6CX* CRPP-2.6CX*
SKODA OCTAVIA II 2004-2013 CRPP-2.6CX* CRPP-2.6CX*
SKODA OCTAVIA III 2013-2019 CRPP-2.6CX* CRPP-2.6CX*
SKODA ROOMSTER 2006-2015 CRPP-2.6CX* CRPP-2.6CX*
SKODA RAPID 2012-2021 CRPP-2.6CX* CRPP-2.6CX*
SKODA SCALA 2019-2021 CRPP-2.6CX* CRPP-2.6CX*
SKODA SUPERB 2008-2015 CRPP-2.6CX*
SKODA SUPERB 2016-2021 CRPP-2.6CX* CRPP-2.6CX*
SKODA YETI 2009-2017 CRPP-2.6CX* CRPP-2.6CX*
SKODA YETI II 2018-2021 CRPP-2.6CX*
Car Model Year Front speaker Rear speaker
VW ARETON 2017-2021 CRPP-2.6CX*
VW AMAROK 2010-2021 CRPP-2.6CX* CRPP-2.6CX*
VW ATLAS 2010-2021 CRPP-2.6CX*
VW NEW BEETLE 1997-2011 CRPP-2.6CX* CRPP-2.6CX*
VW BEETLE 2011-2021 CRPP-2.6CX*
VW BORA 1998-2005 CRPP-2.6CX* CRPP-2.6CX*
VW BORA VARIANT 1999-2005 CRPP-2.6CX* CRPP-2.6CX*
VW C-Trec 2016-2021 CRPP-2.6CX* CRPP-2.6CX*
VW CADDY 2020-2021 CRPP-2.6CX*
VW CRAFTER II 2017-2021 CRPP-2.6CX*
VW EOS 2006-2011 CRPP-2.6CX*
VW GOLF IV 1997-2004 CRPP-2.6CX* CRPP-2.6CX*
VW GOLF V 2004-2008 CRPP-2.6CX* CRPP-2.6CX*
VW GOLV VI 2008-2014 CRPP-2.6CX* CRPP-2.6CX*
VW GOLF VII 2012-2020 CRPP-2.6CX* CRPP-2.6CX*
VW GOLF VIII 2020-2021 CRPP-2.6CX* CRPP-2.6CX*
VW ID 3 2020- CRPP-2.6CX*
VW ID 4 2021- CRPP-2.6CX*
VW JETTA 2005-2010 CRPP-2.6CX* CRPP-2.6CX*
VW JETTA VII 2015-2021 CRPP-2.6CX* CRPP-2.6CX*
VW LAVIDA 2008-2018 CRPP-2.6CX* CRPP-2.6CX*
VW LAVIDA PLUS 2018-2021 CRPP-2.6CX* CRPP-2.6CX*
VW LUPO 1998-2005 CRPP-2.6CX*
VW MAGOTAN 2013-2016 CRPP-2.6CX* CRPP-2.6CX*
VW MAGOTAN 2017-2021 CRPP-2.6CX*
VW NIVUS 2020-2021 CRPP-2.6CX* CRPP-2.6CX*
VW PASSAT 1996-2005 CRPP-2.6CX* CRPP-2.6CX*
VW PASSAT 2005-2015 CRPP-2.6CX* CRPP-2.6CX*
VW PASSAT 2015-2021 CRPP-2.6CX*
VW POLO IV 2001-2009 CRPP-2.6CX* CRPP-2.6CX*
VW POLO V 2009-2016 CRPP-2.6CX* CRPP-2.6CX*
VW POLO VI 2017-2021 CRPP-2.6CX* CRPP-2.6CX*
VW NEW SANTANA 2012-2021 CRPP-2.6CX* CRPP-2.6CX*
VW SCIROCCO 2008-2017 CRPP-2.6CX* CRPP-2.6CX*
VW T6.1 MULTIVAN 2020-2021 CRPP-2.6CX*
VW TAREK 2018-2021 CRPP-2.6CX* CRPP-2.6CX*
VW TAYRON 2019-2021 CRPP-2.6CX*
VW TERAMONT 2018-2021 CRPP-2.6CX*
VW THARU 2018-2021 CRPP-2.6CX* CRPP-2.6CX*
VW TIGUAN 2007-2021 CRPP-2.6CX* CRPP-2.6CX*
VW TOURAN 2003-2021 CRPP-2.6CX*
VW T-CROSS 2019-2021 CRPP-2.6CX* CRPP-2.6CX*
VW T-ROC CAB 2020-2021 CRPP-2.6CX* CRPP-2.6CX*
VW T-ROC 2017-2021 CRPP-2.6CX* CRPP-2.6CX*
VW UP E-UP! 2011-2021 CRPP-2.6CX* CRPP-2.6CX*
VW VENTO 2010-2020 CRPP-2.6CX* CRPP-2.6CX*
Disclaimer
* DLS CRPP-2.6CX is not compatible if your vehicle is with the original Premium Hi-fi system/Dynaudio
system/Fender Audio system, or sound system with 8” door speakers.

Woofer 6.5” / 165 mm with glass fiber cone
Tweeter 1” / 25 mm silk dome tweeter with accessories
RMS Power 90 W
MAX Power 180 W
Impedance 3 Ohm
Sensitivity 90dB 1W / 1M
Freq. range 65 Hz - 25 kHz
Crossover 4.8 kHz 6dB / Oct with Mundorf caps
DLS Cruise CRPP-2.6CX Tweeter
Technical Specification:
Size 1” / 25.4 mm
Voice Coil Material CCAW voice coil / Aluminium former
Frame Glass Fiber Reinforced ABS
Magnet Neodymium / Copper shorting ring
Cone Natural silk dome
DLS Cruise CRPP-2.6CX Woofer
Technical Specification
Size 6.5” / 165 mm
Voice Coil Size 1” / 25mm
Voice Coil Material CCAW voice coil / Kapton former
Basket Glass Fiber Reinforced ABS
Magnet Ferrite
Cone Glass Fiber
Suspension Rubber
Electro-Acoustic Parameters
Re 2.7 Ohm
Fs 74.4 Hz
Mms 10.7 gr
Cms 0.426
Vas 11.1L
Qts 0.87
Qes 0.97
Qms 9.0
Bl 3.96 T.m
Spl 88.7 dB 1W/1M
Sd 139 cm²
Specifications
Art. no CK-CRPP-2.6CX
5
Impedance VS Frequency
Car Model Year Front speaker Rear speaker
MAN TGE 2017-2022 CRPP-2.6CX*
SEAT ALTEA 2004-2015 CRPP-2.6CX* CRPP-2.6CX*
SEAT ALTEA XL 2004-2015 CRPP-2.6CX* CRPP-2.6CX*
SEAT ARONA 2018-2021 CRPP-2.6CX* CRPP-2.6CX*
SEAT AROSA 1997-2004 CRPP-2.6CX*
SEAT ATECA 2016-2021 CRPP-2.6CX* CRPP-2.6CX*
SEAT CORDOBA II 2002-2009 CRPP-2.6CX* CRPP-2.6CX*
SEAT IBIZA III 2001-2008 CRPP-2.6CX* CRPP-2.6CX*
SEAT IBIZA IV 2008-2017 CRPP-2.6CX*
SEAT IBIZA V 2018-2021 CRPP-2.6CX* CRPP-2.6CX*
SEAT LEON 2000-2005 CRPP-2.6CX*
SEAT LEON II 2006-2012 CRPP-2.6CX* CRPP-2.6CX*
SEAT MII 2012-2021 CRPP-2.6CX*
SEAT TOLEDO II 1994-2004 CRPP-2.6CX*
SEAT TOLEDO III 2004-2009 CRPP-2.6CX* CRPP-2.6CX*
SEAT TOLEDO IV 2012-2019 CRPP-2.6CX*
SKODA CITIGO 2012-2021 CRPP-2.6CX* CRPP-2.6CX*
SKODA FABIA I 1999-2007 CRPP-2.6CX* CRPP-2.6CX*
SKODA FABIA II 2007-2014 CRPP-2.6CX* CRPP-2.6CX*
SKODA FABIA III 2015-2021 CRPP-2.6CX* CRPP-2.6CX*
SKODA KAMIQ 2019-2021 CRPP-2.6CX* CRPP-2.6CX*
SKODA KAROQ 2018-2021 CRPP-2.6CX* CRPP-2.6CX*
SKODA KODIAQ 2017-2022 CRPP-2.6CX* CRPP-2.6CX*
SKODA OCTAVIA II 2004-2013 CRPP-2.6CX* CRPP-2.6CX*
SKODA OCTAVIA III 2013-2019 CRPP-2.6CX* CRPP-2.6CX*
SKODA ROOMSTER 2006-2015 CRPP-2.6CX* CRPP-2.6CX*
SKODA RAPID 2012-2021 CRPP-2.6CX* CRPP-2.6CX*
SKODA SCALA 2019-2021 CRPP-2.6CX* CRPP-2.6CX*
SKODA SUPERB 2008-2015 CRPP-2.6CX*
SKODA SUPERB 2016-2021 CRPP-2.6CX* CRPP-2.6CX*
SKODA YETI 2009-2017 CRPP-2.6CX* CRPP-2.6CX*
SKODA YETI II 2018-2021 CRPP-2.6CX*
Car Model Year Front speaker Rear speaker
VW ARETON 2017-2021 CRPP-2.6CX*
VW AMAROK 2010-2021 CRPP-2.6CX* CRPP-2.6CX*
VW ATLAS 2010-2021 CRPP-2.6CX*
VW NEW BEETLE 1997-2011 CRPP-2.6CX* CRPP-2.6CX*
VW BEETLE 2011-2021 CRPP-2.6CX*
VW BORA 1998-2005 CRPP-2.6CX* CRPP-2.6CX*
VW BORA VARIANT 1999-2005 CRPP-2.6CX* CRPP-2.6CX*
VW C-Trec 2016-2021 CRPP-2.6CX* CRPP-2.6CX*
VW CADDY 2020-2021 CRPP-2.6CX*
VW CRAFTER II 2017-2021 CRPP-2.6CX*
VW EOS 2006-2011 CRPP-2.6CX*
VW GOLF IV 1997-2004 CRPP-2.6CX* CRPP-2.6CX*
VW GOLF V 2004-2008 CRPP-2.6CX* CRPP-2.6CX*
VW GOLV VI 2008-2014 CRPP-2.6CX* CRPP-2.6CX*
VW GOLF VII 2012-2020 CRPP-2.6CX* CRPP-2.6CX*
VW GOLF VIII 2020-2021 CRPP-2.6CX* CRPP-2.6CX*
VW ID 3 2020- CRPP-2.6CX*
VW ID 4 2021- CRPP-2.6CX*
VW JETTA 2005-2010 CRPP-2.6CX* CRPP-2.6CX*
VW JETTA VII 2015-2021 CRPP-2.6CX* CRPP-2.6CX*
VW LAVIDA 2008-2018 CRPP-2.6CX* CRPP-2.6CX*
VW LAVIDA PLUS 2018-2021 CRPP-2.6CX* CRPP-2.6CX*
VW LUPO 1998-2005 CRPP-2.6CX*
VW MAGOTAN 2013-2016 CRPP-2.6CX* CRPP-2.6CX*
VW MAGOTAN 2017-2021 CRPP-2.6CX*
VW NIVUS 2020-2021 CRPP-2.6CX* CRPP-2.6CX*
VW PASSAT 1996-2005 CRPP-2.6CX* CRPP-2.6CX*
VW PASSAT 2005-2015 CRPP-2.6CX* CRPP-2.6CX*
VW PASSAT 2015-2021 CRPP-2.6CX*
VW POLO IV 2001-2009 CRPP-2.6CX* CRPP-2.6CX*
VW POLO V 2009-2016 CRPP-2.6CX* CRPP-2.6CX*
VW POLO VI 2017-2021 CRPP-2.6CX* CRPP-2.6CX*
VW NEW SANTANA 2012-2021 CRPP-2.6CX* CRPP-2.6CX*
VW SCIROCCO 2008-2017 CRPP-2.6CX* CRPP-2.6CX*
VW T6.1 MULTIVAN 2020-2021 CRPP-2.6CX*
VW TAREK 2018-2021 CRPP-2.6CX* CRPP-2.6CX*
VW TAYRON 2019-2021 CRPP-2.6CX*
VW TERAMONT 2018-2021 CRPP-2.6CX*
VW THARU 2018-2021 CRPP-2.6CX* CRPP-2.6CX*
VW TIGUAN 2007-2021 CRPP-2.6CX* CRPP-2.6CX*
VW TOURAN 2003-2021 CRPP-2.6CX*
VW T-CROSS 2019-2021 CRPP-2.6CX* CRPP-2.6CX*
VW T-ROC CAB 2020-2021 CRPP-2.6CX* CRPP-2.6CX*
VW T-ROC 2017-2021 CRPP-2.6CX* CRPP-2.6CX*
VW UP E-UP! 2011-2021 CRPP-2.6CX* CRPP-2.6CX*
VW VENTO 2010-2020 CRPP-2.6CX* CRPP-2.6CX*
Disclaimer
* DLS CRPP-2.6CX is not compatible if your vehicle is with the original Premium Hi-fi system/Dynaudio
system/Fender Audio system, or sound system with 8” door speakers.

90
Ø 151
64.9
29.4
Ø
6
168.5
R6
Ø5.5
74.9
Car Model Year Front speaker Rear speaker
MAN TGE 2017-2022 CRPP-2.6CX*
SEAT ALTEA 2004-2015 CRPP-2.6CX* CRPP-2.6CX*
SEAT ALTEA XL 2004-2015 CRPP-2.6CX* CRPP-2.6CX*
SEAT ARONA 2018-2021 CRPP-2.6CX* CRPP-2.6CX*
SEAT AROSA 1997-2004 CRPP-2.6CX*
SEAT ATECA 2016-2021 CRPP-2.6CX* CRPP-2.6CX*
SEAT CORDOBA II 2002-2009 CRPP-2.6CX* CRPP-2.6CX*
SEAT IBIZA III 2001-2008 CRPP-2.6CX* CRPP-2.6CX*
SEAT IBIZA IV 2008-2017 CRPP-2.6CX*
SEAT IBIZA V 2018-2021 CRPP-2.6CX* CRPP-2.6CX*
SEAT LEON 2000-2005 CRPP-2.6CX*
SEAT LEON II 2006-2012 CRPP-2.6CX* CRPP-2.6CX*
SEAT MII 2012-2021 CRPP-2.6CX*
SEAT TOLEDO II 1994-2004 CRPP-2.6CX*
SEAT TOLEDO III 2004-2009 CRPP-2.6CX* CRPP-2.6CX*
SEAT TOLEDO IV 2012-2019 CRPP-2.6CX*
SKODA CITIGO 2012-2021 CRPP-2.6CX* CRPP-2.6CX*
SKODA FABIA I 1999-2007 CRPP-2.6CX* CRPP-2.6CX*
SKODA FABIA II 2007-2014 CRPP-2.6CX* CRPP-2.6CX*
SKODA FABIA III 2015-2021 CRPP-2.6CX* CRPP-2.6CX*
SKODA KAMIQ 2019-2021 CRPP-2.6CX* CRPP-2.6CX*
SKODA KAROQ 2018-2021 CRPP-2.6CX* CRPP-2.6CX*
SKODA KODIAQ 2017-2022 CRPP-2.6CX* CRPP-2.6CX*
SKODA OCTAVIA II 2004-2013 CRPP-2.6CX* CRPP-2.6CX*
SKODA OCTAVIA III 2013-2019 CRPP-2.6CX* CRPP-2.6CX*
SKODA ROOMSTER 2006-2015 CRPP-2.6CX* CRPP-2.6CX*
SKODA RAPID 2012-2021 CRPP-2.6CX* CRPP-2.6CX*
SKODA SCALA 2019-2021 CRPP-2.6CX* CRPP-2.6CX*
SKODA SUPERB 2008-2015 CRPP-2.6CX*
SKODA SUPERB 2016-2021 CRPP-2.6CX* CRPP-2.6CX*
SKODA YETI 2009-2017 CRPP-2.6CX* CRPP-2.6CX*
SKODA YETI II 2018-2021 CRPP-2.6CX*
Car Model Year Front speaker Rear speaker
VW ARETON 2017-2021 CRPP-2.6CX*
VW AMAROK 2010-2021 CRPP-2.6CX* CRPP-2.6CX*
VW ATLAS 2010-2021 CRPP-2.6CX*
VW NEW BEETLE 1997-2011 CRPP-2.6CX* CRPP-2.6CX*
VW BEETLE 2011-2021 CRPP-2.6CX*
VW BORA 1998-2005 CRPP-2.6CX* CRPP-2.6CX*
VW BORA VARIANT 1999-2005 CRPP-2.6CX* CRPP-2.6CX*
VW C-Trec 2016-2021 CRPP-2.6CX* CRPP-2.6CX*
VW CADDY 2020-2021 CRPP-2.6CX*
VW CRAFTER II 2017-2021 CRPP-2.6CX*
VW EOS 2006-2011 CRPP-2.6CX*
VW GOLF IV 1997-2004 CRPP-2.6CX* CRPP-2.6CX*
VW GOLF V 2004-2008 CRPP-2.6CX* CRPP-2.6CX*
VW GOLV VI 2008-2014 CRPP-2.6CX* CRPP-2.6CX*
VW GOLF VII 2012-2020 CRPP-2.6CX* CRPP-2.6CX*
VW GOLF VIII 2020-2021 CRPP-2.6CX* CRPP-2.6CX*
VW ID 3 2020- CRPP-2.6CX*
VW ID 4 2021- CRPP-2.6CX*
VW JETTA 2005-2010 CRPP-2.6CX* CRPP-2.6CX*
VW JETTA VII 2015-2021 CRPP-2.6CX* CRPP-2.6CX*
VW LAVIDA 2008-2018 CRPP-2.6CX* CRPP-2.6CX*
VW LAVIDA PLUS 2018-2021 CRPP-2.6CX* CRPP-2.6CX*
VW LUPO 1998-2005 CRPP-2.6CX*
VW MAGOTAN 2013-2016 CRPP-2.6CX* CRPP-2.6CX*
VW MAGOTAN 2017-2021 CRPP-2.6CX*
VW NIVUS 2020-2021 CRPP-2.6CX* CRPP-2.6CX*
VW PASSAT 1996-2005 CRPP-2.6CX* CRPP-2.6CX*
VW PASSAT 2005-2015 CRPP-2.6CX* CRPP-2.6CX*
VW PASSAT 2015-2021 CRPP-2.6CX*
VW POLO IV 2001-2009 CRPP-2.6CX* CRPP-2.6CX*
VW POLO V 2009-2016 CRPP-2.6CX* CRPP-2.6CX*
VW POLO VI 2017-2021 CRPP-2.6CX* CRPP-2.6CX*
VW NEW SANTANA 2012-2021 CRPP-2.6CX* CRPP-2.6CX*
VW SCIROCCO 2008-2017 CRPP-2.6CX* CRPP-2.6CX*
VW T6.1 MULTIVAN 2020-2021 CRPP-2.6CX*
VW TAREK 2018-2021 CRPP-2.6CX* CRPP-2.6CX*
VW TAYRON 2019-2021 CRPP-2.6CX*
VW TERAMONT 2018-2021 CRPP-2.6CX*
VW THARU 2018-2021 CRPP-2.6CX* CRPP-2.6CX*
VW TIGUAN 2007-2021 CRPP-2.6CX* CRPP-2.6CX*
VW TOURAN 2003-2021 CRPP-2.6CX*
VW T-CROSS 2019-2021 CRPP-2.6CX* CRPP-2.6CX*
VW T-ROC CAB 2020-2021 CRPP-2.6CX* CRPP-2.6CX*
VW T-ROC 2017-2021 CRPP-2.6CX* CRPP-2.6CX*
VW UP E-UP! 2011-2021 CRPP-2.6CX* CRPP-2.6CX*
VW VENTO 2010-2020 CRPP-2.6CX* CRPP-2.6CX*
Disclaimer
* DLS CRPP-2.6CX is not compatible if your vehicle is with the original Premium Hi-fi system/Dynaudio
system/Fender Audio system, or sound system with 8” door speakers.

7
DLS Cruise CRPP-2.6CX compatible car models
The DLS coaxial speaker is developed to be installed in the back door of your car. However, you can install
it as a front speaker in your system even if an OEM component kit is installed in your car. The tweeter level
will be different due to the placement of the tweeter in the coaxial speaker and your OEM tweeter will still
be connected, by default to your stereo.
DLS Cruise CRPP-2.6CX
More models on next page
Car Model Year Front speaker Rear speaker
MAN TGE 2017-2022 CRPP-2.6CX*
SEAT ALTEA 2004-2015 CRPP-2.6CX* CRPP-2.6CX*
SEAT ALTEA XL 2004-2015 CRPP-2.6CX* CRPP-2.6CX*
SEAT ARONA 2018-2021 CRPP-2.6CX* CRPP-2.6CX*
SEAT AROSA 1997-2004 CRPP-2.6CX*
SEAT ATECA 2016-2021 CRPP-2.6CX* CRPP-2.6CX*
SEAT CORDOBA II 2002-2009 CRPP-2.6CX* CRPP-2.6CX*
SEAT IBIZA III 2001-2008 CRPP-2.6CX* CRPP-2.6CX*
SEAT IBIZA IV 2008-2017 CRPP-2.6CX*
SEAT IBIZA V 2018-2021 CRPP-2.6CX* CRPP-2.6CX*
SEAT LEON 2000-2005 CRPP-2.6CX*
SEAT LEON II 2006-2012 CRPP-2.6CX* CRPP-2.6CX*
SEAT MII 2012-2021 CRPP-2.6CX*
SEAT TOLEDO II 1994-2004 CRPP-2.6CX*
SEAT TOLEDO III 2004-2009 CRPP-2.6CX* CRPP-2.6CX*
SEAT TOLEDO IV 2012-2019 CRPP-2.6CX*
SKODA CITIGO 2012-2021 CRPP-2.6CX* CRPP-2.6CX*
SKODA FABIA I 1999-2007 CRPP-2.6CX* CRPP-2.6CX*
SKODA FABIA II 2007-2014 CRPP-2.6CX* CRPP-2.6CX*
SKODA FABIA III 2015-2021 CRPP-2.6CX* CRPP-2.6CX*
SKODA KAMIQ 2019-2021 CRPP-2.6CX* CRPP-2.6CX*
SKODA KAROQ 2018-2021 CRPP-2.6CX* CRPP-2.6CX*
SKODA KODIAQ 2017-2022 CRPP-2.6CX* CRPP-2.6CX*
SKODA OCTAVIA II 2004-2013 CRPP-2.6CX* CRPP-2.6CX*
SKODA OCTAVIA III 2013-2019 CRPP-2.6CX* CRPP-2.6CX*
SKODA ROOMSTER 2006-2015 CRPP-2.6CX* CRPP-2.6CX*
SKODA RAPID 2012-2021 CRPP-2.6CX* CRPP-2.6CX*
SKODA SCALA 2019-2021 CRPP-2.6CX* CRPP-2.6CX*
SKODA SUPERB 2008-2015 CRPP-2.6CX*
SKODA SUPERB 2016-2021 CRPP-2.6CX* CRPP-2.6CX*
SKODA YETI 2009-2017 CRPP-2.6CX* CRPP-2.6CX*
SKODA YETI II 2018-2021 CRPP-2.6CX*
Car Model Year Front speaker Rear speaker
VW ARETON 2017-2021 CRPP-2.6CX*
VW AMAROK 2010-2021 CRPP-2.6CX* CRPP-2.6CX*
VW ATLAS 2010-2021 CRPP-2.6CX*
VW NEW BEETLE 1997-2011 CRPP-2.6CX* CRPP-2.6CX*
VW BEETLE 2011-2021 CRPP-2.6CX*
VW BORA 1998-2005 CRPP-2.6CX* CRPP-2.6CX*
VW BORA VARIANT 1999-2005 CRPP-2.6CX* CRPP-2.6CX*
VW C-Trec 2016-2021 CRPP-2.6CX* CRPP-2.6CX*
VW CADDY 2020-2021 CRPP-2.6CX*
VW CRAFTER II 2017-2021 CRPP-2.6CX*
VW EOS 2006-2011 CRPP-2.6CX*
VW GOLF IV 1997-2004 CRPP-2.6CX* CRPP-2.6CX*
VW GOLF V 2004-2008 CRPP-2.6CX* CRPP-2.6CX*
VW GOLV VI 2008-2014 CRPP-2.6CX* CRPP-2.6CX*
VW GOLF VII 2012-2020 CRPP-2.6CX* CRPP-2.6CX*
VW GOLF VIII 2020-2021 CRPP-2.6CX* CRPP-2.6CX*
VW ID 3 2020- CRPP-2.6CX*
VW ID 4 2021- CRPP-2.6CX*
VW JETTA 2005-2010 CRPP-2.6CX* CRPP-2.6CX*
VW JETTA VII 2015-2021 CRPP-2.6CX* CRPP-2.6CX*
VW LAVIDA 2008-2018 CRPP-2.6CX* CRPP-2.6CX*
VW LAVIDA PLUS 2018-2021 CRPP-2.6CX* CRPP-2.6CX*
VW LUPO 1998-2005 CRPP-2.6CX*
VW MAGOTAN 2013-2016 CRPP-2.6CX* CRPP-2.6CX*
VW MAGOTAN 2017-2021 CRPP-2.6CX*
VW NIVUS 2020-2021 CRPP-2.6CX* CRPP-2.6CX*
VW PASSAT 1996-2005 CRPP-2.6CX* CRPP-2.6CX*
VW PASSAT 2005-2015 CRPP-2.6CX* CRPP-2.6CX*
VW PASSAT 2015-2021 CRPP-2.6CX*
VW POLO IV 2001-2009 CRPP-2.6CX* CRPP-2.6CX*
VW POLO V 2009-2016 CRPP-2.6CX* CRPP-2.6CX*
VW POLO VI 2017-2021 CRPP-2.6CX* CRPP-2.6CX*
VW NEW SANTANA 2012-2021 CRPP-2.6CX* CRPP-2.6CX*
VW SCIROCCO 2008-2017 CRPP-2.6CX* CRPP-2.6CX*
VW T6.1 MULTIVAN 2020-2021 CRPP-2.6CX*
VW TAREK 2018-2021 CRPP-2.6CX* CRPP-2.6CX*
VW TAYRON 2019-2021 CRPP-2.6CX*
VW TERAMONT 2018-2021 CRPP-2.6CX*
VW THARU 2018-2021 CRPP-2.6CX* CRPP-2.6CX*
VW TIGUAN 2007-2021 CRPP-2.6CX* CRPP-2.6CX*
VW TOURAN 2003-2021 CRPP-2.6CX*
VW T-CROSS 2019-2021 CRPP-2.6CX* CRPP-2.6CX*
VW T-ROC CAB 2020-2021 CRPP-2.6CX* CRPP-2.6CX*
VW T-ROC 2017-2021 CRPP-2.6CX* CRPP-2.6CX*
VW UP E-UP! 2011-2021 CRPP-2.6CX* CRPP-2.6CX*
VW VENTO 2010-2020 CRPP-2.6CX* CRPP-2.6CX*
Disclaimer
* DLS CRPP-2.6CX is not compatible if your vehicle is with the original Premium Hi-fi system/Dynaudio
system/Fender Audio system, or sound system with 8” door speakers.

8
Car Model Year Front speaker Rear speaker
MAN TGE 2017-2022 CRPP-2.6CX*
SEAT ALTEA 2004-2015 CRPP-2.6CX* CRPP-2.6CX*
SEAT ALTEA XL 2004-2015 CRPP-2.6CX* CRPP-2.6CX*
SEAT ARONA 2018-2021 CRPP-2.6CX* CRPP-2.6CX*
SEAT AROSA 1997-2004 CRPP-2.6CX*
SEAT ATECA 2016-2021 CRPP-2.6CX* CRPP-2.6CX*
SEAT CORDOBA II 2002-2009 CRPP-2.6CX* CRPP-2.6CX*
SEAT IBIZA III 2001-2008 CRPP-2.6CX* CRPP-2.6CX*
SEAT IBIZA IV 2008-2017 CRPP-2.6CX*
SEAT IBIZA V 2018-2021 CRPP-2.6CX* CRPP-2.6CX*
SEAT LEON 2000-2005 CRPP-2.6CX*
SEAT LEON II 2006-2012 CRPP-2.6CX* CRPP-2.6CX*
SEAT MII 2012-2021 CRPP-2.6CX*
SEAT TOLEDO II 1994-2004 CRPP-2.6CX*
SEAT TOLEDO III 2004-2009 CRPP-2.6CX* CRPP-2.6CX*
SEAT TOLEDO IV 2012-2019 CRPP-2.6CX*
SKODA CITIGO 2012-2021 CRPP-2.6CX* CRPP-2.6CX*
SKODA FABIA I 1999-2007 CRPP-2.6CX* CRPP-2.6CX*
SKODA FABIA II 2007-2014 CRPP-2.6CX* CRPP-2.6CX*
SKODA FABIA III 2015-2021 CRPP-2.6CX* CRPP-2.6CX*
SKODA KAMIQ 2019-2021 CRPP-2.6CX* CRPP-2.6CX*
SKODA KAROQ 2018-2021 CRPP-2.6CX* CRPP-2.6CX*
SKODA KODIAQ 2017-2022 CRPP-2.6CX* CRPP-2.6CX*
SKODA OCTAVIA II 2004-2013 CRPP-2.6CX* CRPP-2.6CX*
SKODA OCTAVIA III 2013-2019 CRPP-2.6CX* CRPP-2.6CX*
SKODA ROOMSTER 2006-2015 CRPP-2.6CX* CRPP-2.6CX*
SKODA RAPID 2012-2021 CRPP-2.6CX* CRPP-2.6CX*
SKODA SCALA 2019-2021 CRPP-2.6CX* CRPP-2.6CX*
SKODA SUPERB 2008-2015 CRPP-2.6CX*
SKODA SUPERB 2016-2021 CRPP-2.6CX* CRPP-2.6CX*
SKODA YETI 2009-2017 CRPP-2.6CX* CRPP-2.6CX*
SKODA YETI II 2018-2021 CRPP-2.6CX*
Car Model Year Front speaker Rear speaker
VW ARETON 2017-2021 CRPP-2.6CX*
VW AMAROK 2010-2021 CRPP-2.6CX* CRPP-2.6CX*
VW ATLAS 2010-2021 CRPP-2.6CX*
VW NEW BEETLE 1997-2011 CRPP-2.6CX* CRPP-2.6CX*
VW BEETLE 2011-2021 CRPP-2.6CX*
VW BORA 1998-2005 CRPP-2.6CX* CRPP-2.6CX*
VW BORA VARIANT 1999-2005 CRPP-2.6CX* CRPP-2.6CX*
VW C-Trec 2016-2021 CRPP-2.6CX* CRPP-2.6CX*
VW CADDY 2020-2021 CRPP-2.6CX*
VW CRAFTER II 2017-2021 CRPP-2.6CX*
VW EOS 2006-2011 CRPP-2.6CX*
VW GOLF IV 1997-2004 CRPP-2.6CX* CRPP-2.6CX*
VW GOLF V 2004-2008 CRPP-2.6CX* CRPP-2.6CX*
VW GOLV VI 2008-2014 CRPP-2.6CX* CRPP-2.6CX*
VW GOLF VII 2012-2020 CRPP-2.6CX* CRPP-2.6CX*
VW GOLF VIII 2020-2021 CRPP-2.6CX* CRPP-2.6CX*
VW ID 3 2020- CRPP-2.6CX*
VW ID 4 2021- CRPP-2.6CX*
VW JETTA 2005-2010 CRPP-2.6CX* CRPP-2.6CX*
VW JETTA VII 2015-2021 CRPP-2.6CX* CRPP-2.6CX*
VW LAVIDA 2008-2018 CRPP-2.6CX* CRPP-2.6CX*
VW LAVIDA PLUS 2018-2021 CRPP-2.6CX* CRPP-2.6CX*
VW LUPO 1998-2005 CRPP-2.6CX*
VW MAGOTAN 2013-2016 CRPP-2.6CX* CRPP-2.6CX*
VW MAGOTAN 2017-2021 CRPP-2.6CX*
VW NIVUS 2020-2021 CRPP-2.6CX* CRPP-2.6CX*
VW PASSAT 1996-2005 CRPP-2.6CX* CRPP-2.6CX*
VW PASSAT 2005-2015 CRPP-2.6CX* CRPP-2.6CX*
VW PASSAT 2015-2021 CRPP-2.6CX*
VW POLO IV 2001-2009 CRPP-2.6CX* CRPP-2.6CX*
VW POLO V 2009-2016 CRPP-2.6CX* CRPP-2.6CX*
VW POLO VI 2017-2021 CRPP-2.6CX* CRPP-2.6CX*
VW NEW SANTANA 2012-2021 CRPP-2.6CX* CRPP-2.6CX*
VW SCIROCCO 2008-2017 CRPP-2.6CX* CRPP-2.6CX*
VW T6.1 MULTIVAN 2020-2021 CRPP-2.6CX*
VW TAREK 2018-2021 CRPP-2.6CX* CRPP-2.6CX*
VW TAYRON 2019-2021 CRPP-2.6CX*
VW TERAMONT 2018-2021 CRPP-2.6CX*
VW THARU 2018-2021 CRPP-2.6CX* CRPP-2.6CX*
VW TIGUAN 2007-2021 CRPP-2.6CX* CRPP-2.6CX*
VW TOURAN 2003-2021 CRPP-2.6CX*
VW T-CROSS 2019-2021 CRPP-2.6CX* CRPP-2.6CX*
VW T-ROC CAB 2020-2021 CRPP-2.6CX* CRPP-2.6CX*
VW T-ROC 2017-2021 CRPP-2.6CX* CRPP-2.6CX*
VW UP E-UP! 2011-2021 CRPP-2.6CX* CRPP-2.6CX*
VW VENTO 2010-2020 CRPP-2.6CX* CRPP-2.6CX*
Disclaimer
* DLS CRPP-2.6CX is not compatible if your vehicle is with the original Premium Hi-fi system/Dynaudio
system/Fender Audio system, or sound system with 8” door speakers.

The crossed-out wheelie bin symbol means that the product, literature and pac-
kaging included must be taken to separate collection at the end of their working
life. Do not dispose of these products as unsorted municipal waste: take them
for recycling. For info on your nearest recycling point, check with your local
waste authority.
This product has been granted with the CE certification mark to show that the
product follows the health, safety, and environmental protection standards for
products sold within the European Economic Area (EEA).
DLS products complies with the relevant provisions of the RoHS
Directive for the European Union. In common with all Electrical
and Electronic Equipment (EEE) the productshould not be
disposed of as household waste. Alternative arrangements may
apply in other jurisdictions.
aideMeliboMnaeporuEehtforentraplabolgasiSLD
Association, an organisation that focus on promoting the
custom made mobile media installations to consumers.
Product markings
We follow a policy of continuous advancement in development. For this reason all or part of
specifications & designs may be changed without prior notice. We reserve for possible typos,
factual or numeric errors that may have been printed on any products, package designs,
user manuals and/or other included accessories.
9
Car Model Year Front speaker Rear speaker
MAN TGE 2017-2022 CRPP-2.6CX*
SEAT ALTEA 2004-2015 CRPP-2.6CX* CRPP-2.6CX*
SEAT ALTEA XL 2004-2015 CRPP-2.6CX* CRPP-2.6CX*
SEAT ARONA 2018-2021 CRPP-2.6CX* CRPP-2.6CX*
SEAT AROSA 1997-2004 CRPP-2.6CX*
SEAT ATECA 2016-2021 CRPP-2.6CX* CRPP-2.6CX*
SEAT CORDOBA II 2002-2009 CRPP-2.6CX* CRPP-2.6CX*
SEAT IBIZA III 2001-2008 CRPP-2.6CX* CRPP-2.6CX*
SEAT IBIZA IV 2008-2017 CRPP-2.6CX*
SEAT IBIZA V 2018-2021 CRPP-2.6CX* CRPP-2.6CX*
SEAT LEON 2000-2005 CRPP-2.6CX*
SEAT LEON II 2006-2012 CRPP-2.6CX* CRPP-2.6CX*
SEAT MII 2012-2021 CRPP-2.6CX*
SEAT TOLEDO II 1994-2004 CRPP-2.6CX*
SEAT TOLEDO III 2004-2009 CRPP-2.6CX* CRPP-2.6CX*
SEAT TOLEDO IV 2012-2019 CRPP-2.6CX*
SKODA CITIGO 2012-2021 CRPP-2.6CX* CRPP-2.6CX*
SKODA FABIA I 1999-2007 CRPP-2.6CX* CRPP-2.6CX*
SKODA FABIA II 2007-2014 CRPP-2.6CX* CRPP-2.6CX*
SKODA FABIA III 2015-2021 CRPP-2.6CX* CRPP-2.6CX*
SKODA KAMIQ 2019-2021 CRPP-2.6CX* CRPP-2.6CX*
SKODA KAROQ 2018-2021 CRPP-2.6CX* CRPP-2.6CX*
SKODA KODIAQ 2017-2022 CRPP-2.6CX* CRPP-2.6CX*
SKODA OCTAVIA II 2004-2013 CRPP-2.6CX* CRPP-2.6CX*
SKODA OCTAVIA III 2013-2019 CRPP-2.6CX* CRPP-2.6CX*
SKODA ROOMSTER 2006-2015 CRPP-2.6CX* CRPP-2.6CX*
SKODA RAPID 2012-2021 CRPP-2.6CX* CRPP-2.6CX*
SKODA SCALA 2019-2021 CRPP-2.6CX* CRPP-2.6CX*
SKODA SUPERB 2008-2015 CRPP-2.6CX*
SKODA SUPERB 2016-2021 CRPP-2.6CX* CRPP-2.6CX*
SKODA YETI 2009-2017 CRPP-2.6CX* CRPP-2.6CX*
SKODA YETI II 2018-2021 CRPP-2.6CX*
Car Model Year Front speaker Rear speaker
VW ARETON 2017-2021 CRPP-2.6CX*
VW AMAROK 2010-2021 CRPP-2.6CX* CRPP-2.6CX*
VW ATLAS 2010-2021 CRPP-2.6CX*
VW NEW BEETLE 1997-2011 CRPP-2.6CX* CRPP-2.6CX*
VW BEETLE 2011-2021 CRPP-2.6CX*
VW BORA 1998-2005 CRPP-2.6CX* CRPP-2.6CX*
VW BORA VARIANT 1999-2005 CRPP-2.6CX* CRPP-2.6CX*
VW C-Trec 2016-2021 CRPP-2.6CX* CRPP-2.6CX*
VW CADDY 2020-2021 CRPP-2.6CX*
VW CRAFTER II 2017-2021 CRPP-2.6CX*
VW EOS 2006-2011 CRPP-2.6CX*
VW GOLF IV 1997-2004 CRPP-2.6CX* CRPP-2.6CX*
VW GOLF V 2004-2008 CRPP-2.6CX* CRPP-2.6CX*
VW GOLV VI 2008-2014 CRPP-2.6CX* CRPP-2.6CX*
VW GOLF VII 2012-2020 CRPP-2.6CX* CRPP-2.6CX*
VW GOLF VIII 2020-2021 CRPP-2.6CX* CRPP-2.6CX*
VW ID 3 2020- CRPP-2.6CX*
VW ID 4 2021- CRPP-2.6CX*
VW JETTA 2005-2010 CRPP-2.6CX* CRPP-2.6CX*
VW JETTA VII 2015-2021 CRPP-2.6CX* CRPP-2.6CX*
VW LAVIDA 2008-2018 CRPP-2.6CX* CRPP-2.6CX*
VW LAVIDA PLUS 2018-2021 CRPP-2.6CX* CRPP-2.6CX*
VW LUPO 1998-2005 CRPP-2.6CX*
VW MAGOTAN 2013-2016 CRPP-2.6CX* CRPP-2.6CX*
VW MAGOTAN 2017-2021 CRPP-2.6CX*
VW NIVUS 2020-2021 CRPP-2.6CX* CRPP-2.6CX*
VW PASSAT 1996-2005 CRPP-2.6CX* CRPP-2.6CX*
VW PASSAT 2005-2015 CRPP-2.6CX* CRPP-2.6CX*
VW PASSAT 2015-2021 CRPP-2.6CX*
VW POLO IV 2001-2009 CRPP-2.6CX* CRPP-2.6CX*
VW POLO V 2009-2016 CRPP-2.6CX* CRPP-2.6CX*
VW POLO VI 2017-2021 CRPP-2.6CX* CRPP-2.6CX*
VW NEW SANTANA 2012-2021 CRPP-2.6CX* CRPP-2.6CX*
VW SCIROCCO 2008-2017 CRPP-2.6CX* CRPP-2.6CX*
VW T6.1 MULTIVAN 2020-2021 CRPP-2.6CX*
VW TAREK 2018-2021 CRPP-2.6CX* CRPP-2.6CX*
VW TAYRON 2019-2021 CRPP-2.6CX*
VW TERAMONT 2018-2021 CRPP-2.6CX*
VW THARU 2018-2021 CRPP-2.6CX* CRPP-2.6CX*
VW TIGUAN 2007-2021 CRPP-2.6CX* CRPP-2.6CX*
VW TOURAN 2003-2021 CRPP-2.6CX*
VW T-CROSS 2019-2021 CRPP-2.6CX* CRPP-2.6CX*
VW T-ROC CAB 2020-2021 CRPP-2.6CX* CRPP-2.6CX*
VW T-ROC 2017-2021 CRPP-2.6CX* CRPP-2.6CX*
VW UP E-UP! 2011-2021 CRPP-2.6CX* CRPP-2.6CX*
VW VENTO 2010-2020 CRPP-2.6CX* CRPP-2.6CX*
Disclaimer
* DLS CRPP-2.6CX is not compatible if your vehicle is with the original Premium Hi-fi system/Dynaudio
system/Fender Audio system, or sound system with 8” door speakers.
