DMI LED BALLOON LIGHT User manual

LED
BALLOON
LIGHT
OWNER’S
MANUAL
dmitools.com 385.449.2700
dmitools.com 385.449.2700

INTRODUCTION
Congratulations on your purchase of your
LED Light Balloon.
This manual includes assembly and product
use information. Please read the manual
carefully before using to ensure proper use
and safety while operating and transporting
your Light Balloon.
Read this manual carefully before operating this
machine. The Owner’s Manual should stay
with the machine if it is sold.
DO NOT THROW AWAY USER MANUAL
dmitools.com 385.449.2700

IMPORTANT MANUAL INFORMATION
This is the safety alert symbol. It is used to alert you to
potential personal injury hazards. Obey all safety messages
that follow this symbol to avoid possible injury or death.
This symbol is also used to indicate a hazardous situation
which, if not avoided, could result in serious injury or death.
For replacement parts, service and additional accessories,
please contact us.
We are constantly improving products and reserves the
right to make product changes at any time without notice
and with no obligation to any products designed or
manufactured at any time. This manual contains the most
current product information available at the time of printing,
there may be minor discrepancies between your product
and this manual. If there is any question or concern please
contact our dealer.
This manual should be considered a permanent part of this
Light Balloon and should remain with this product
when resold.
*Product specififications are subject to change without notice.
WARNING:
USING THIS PRODUCT FOR ANY OTHER
PURPOSE OR IN ANY OTHER WAY THAN EXPLAINED
IN THE OWNER'S MANUAL COULD LEAD TO DEATH
OR SERIOUS INJURY.
WARNING:KEEP OUT OF REACH OF CHILDREN.
WARNING:CHILDREN CAN SUFFOCATE BY PLAYING
INSIDE UNINFLATED BALLOON COVER. TO AVOID
RISK PLEASE KEEP BALLOON COVER AWAY
FROM CHILDREN & BABIES.
WARNING:
PLEASE READ AND UNDERSTAND
MANUAL COMPLETELY BEFORE OPERATING THE
MACHINE.
TABLE OF CONTENTS
1. Safety Information
1.1Falling or tipping over
1.2 Electrical shock
1.3 Operation in weather conditions
1.4 Fire/Explosion
1.5 High temperature
1.6 Modifification to unit
2. Product Description
3. Control Function
4. Preparation & Operation
4.1 Tripod preparation & operation
5. Maintenance, Storage & Transport
6. Consumer Information
4
4
4
5
5
5
5
6
8
9
10
12
14
dmitools.com 385.449.2700

1. SAFETY INFORMATION
1.1 WARNING: FALLING OR TIPPING OVER
Set up and place the tripod on a flflat level surface.
Ensure that all legs of the tripod are completely
extended and the screw knob on the bracket
connecting the legs and the tripod center at the base
is fifirmly tightened. Do not use on unlevel surface.
Never transport or move a fully assembled LED
Balloon Light. Never move while LED unit is on
the tripod or while the tripod unit is extended. If the
unit must be moved or transported, turn off power,
remove the LED unit and then close the tripod as
indicated by the instructions in the owner’s manual.
Make sure the LED unit is properly fastened to the
tripod before use. Firmly tighten the screw knobs
before use.
Before extending or retracting the telescoping
function on the tripod, be sure that the two knobs are
loosened. For retraction fifirmly grip and brace the led
unit to avoid sudden retraction. Failure to do which
may result in damage to the product or serious injury.
Do not operate this unit in conditions with wind gusts
at or over 15 MPH.
After extending the tripod, fifirmly tighten the screw
knob. Failure to fifirmly tighten screw knobs could result
in sudden retraction of the tripod, resulting in serious
injury or death.
1.2 WARNING: ELECTRICAL SHOCK
DO NOToperate this unit in areas exposed to water.
Turn power OFF and unplug before handling the unit.
Failure to do so may result in electrical shock, serious
injury or death.
DO NOT operate when in rain or snow.
NEVER touch the machine with wet hands or electrical
shock may occur.
Connect the ground lead of the machine to the ground
terminal of the power source.
Extension cords should be protected by a tough
flflexible rubber sheath (IEC245) or the equivalent to
withstand mechanical stresses.
1.3 OPERATION IN WEATHER CONDITIONS
DO NOT OPERATE IN RAIN, SNOW OR WIND AT OR
OVER 15 MPH
DO NOT OPERATE IN POOR WEATHER CONDITIONS
1.4 CAUTION: FIRE/EXPLOSION
Please use in a ventilated area.
1.5 CAUTION: HIGH TEMPERATURE
DO NOT touch LED unit when product is turned on.
This may result in burns or other serious injury. Always
wait at least 10 minutes to handle after turning power
to the unit off.
1.6 CAUTION: MODIFICATION TO UNIT
DO NOTmodify or remove any parts from the unit.
Modififications and removal of parts may lead to
serious harm or death. All parts are designed for
intended use of this product. Any modifification or
removal of parts violates all warranties and
agreements, and may lead to serious harm or death.
4 5
dmitools.com 385.449.2700

dmitools.com 385.449.2700

3. CONTROL FUNCTION
400 Watt LED Balloon Light control function is simple. Plug it
in and flflip the ON/OFF Toggle Switch to ON.
products come with a versatile molded plug with a folding
ground prong as well as a ground clamp. Whenever
available use the power cord plug utilizing the ground
prong. If the power source receptacle does not have a
ground terminal, use the green ground clamp and fasten to
the power source’s ground terminal.
4. PREPARATION
& OPERATION
8 9
dmitools.com 385.449.2700

4.1 TRIPOD PREPARATION AND OPERATION
Select a level surface to set up the tripod. Allow for a
minimum of 3x3 feet for the tripod setup location.
Remove tripod from carrying case.
Carefully stand the tripod upright, with the three legs
pointing down and the LED Balloon Light mount on the top.
Loosen the screw knob at the base then pull the legs
apart spreading the 3 legs, while sliding the support
bracket down until it stops. Make sure legs are fully
extended.
Tighten the bottom most screw knob securing tripod legs.
Return to the top of the portion of the tripod. Loosen the
(2) screw knobs.
Mount the LED Balloon Light fifixture on the tripod’s LED
Balloon Light mount and fifirmly tighten the screw knob
fastening the LED Balloon Light fifixture to the LED
Balloon Light mount.
1. Three feet open in the same horizontal plane, three
feet on fitting screw locking, loosen the screw and
plunger, fixed screw, then loosen the hand vortex rod
nut, transferred to the best Angle to handle, start operation;
2. After the rise to the height of the need, locking hand
vortex in the screw nut and screw fixation screw, single
pole in hand, one foot on the foot pedal locking screw rod.
down instructions:
1. Loosen the plunger, screws and the screw rod and hand
vortex rod nut, start operation;
2. The decline in the process, need to hand in hand, to
maintain uniform.
For tripod transportation: retract completely, close tripod
legs, secure all screw knobs and place in the tripod
carry bag.
10 11
dmitools.com 385.449.2700

5. MAINTENANCE,
STORAGE
& TRANSPORT
We recommend cleaning the unit after every use.
Before performing maintenance make sure the unit is
turned off and unplugged from any power source.
Remove the Balloon Light cover. The Balloon Light cover
may be clean with warm water and a light soap solution.
To clean the air fifilter fifirst remove the 1 screws on the air
fifilter cover at the top of the LED unit. Second, remove th
e fifilter and use warm water to rinse the fifilter. Dry the
fifilter then reinsert the fifilter.
To clean the LED unit hardware, use compressed air and
gently blow out the interior and exterior of the unit.
We recommend changing the air fifilter every 6-12
months.
To maintain the tripod, simply wipe down with a cloth
and warm water. A light soap solution may be used.
Make sure to dry the unit after wetting.
After operation remove Balloon Light cover, fold and
store in protected area.
Alwaysstore the LED Unit and Tripod in their carry bags
to ensure additional protection during transport and
storage.
Storethe balloon light cover in a clean and dry place.
If the products are used in weather elements, always
clean and dry the products entirely before storage or
ransport.
MAINTENANCE
STORAGE & TRANSPORT
1213
dmitools.com 385.449.2700

6. CONSUMER
INFORMATION
The Part Number and Serial Number can be found on the
specififications sticker located on the side of the LED unit.
These are your products identifification numbers. Please
keep record of these numbers as well as the purchase
date.
Keep these ID numbers in a separate place in case your
product is stolen.
Use the Part Number and Serial Number when ordering
parts from a dealer.
CONSUMER INFORMATION
14 15
