DMX4ALL DMX-Player L User manual

DMX-Player L
User Manual

DMX-Player L 2
Description
The DMX-Player L is a DMX-StandAlone device. The scenes provided in the PC can
be loaded by USB on the device. Without PC the stored scenes can be reproduced.
The scene selection can occur in different ways. An application in the live operation
with connected PC is possible too.
Due to the easy handling the application is possible in decoration and presentation
sections.
RISC
CONTROLLER
IR
DECODER RESET
IR INPUT
SWITCH
CONTROL MEMORY
PROGRAM
CONTROL DMX
INTERFACE DMX-OUT
POWER
CONTROL RTC
LED-DIMMER* LED-OUT
DIGITAL
CONTROL
DIGITAL
INPUT
Energy Saving Design:
By modern switch-power-supply-technology it will be generated less warmth
considerably and therefore the energy consumption is lowered.
Data Sheet
-Voltage supply: 7-24V DC / 250mA (Without LED-Dimmer BABY)
-DMX-OUT: 192 Channels
-Internal clock (RTC)
-Digital control-input for control per button
-Program-Trigger up to 16 Timer possible
-Brightness-control per UP/DOWN button, Poti or IR
-Playback rate per UP/DOWN button, Poti or IR
-Scenes Selection:
- first 10 per button
- first 16 per button-Matrix 4x4
- first 25 per button-Matrix 5x5
- up to 250 scenes per numerical keypad with ENTER and BLACKOUT
- first 10 per RC5 IR-remote control
-USB-Connection to transfer the scenes or as a PC DMX-Interface in live
operations
-8Kbyte Stand-Alone-Memory (up to 32kByte with 24C256 possible)
-DMX-LED-Dimmer BABY to attach
-Board-dimensions: 64,2mm x 82mm

DMX-Player L 3
Installation USB
The Interface installation happens in two parts.
Part 1: Installation the USB-driver
-Put the DMX interface to a free USB port of your PC.
There appears the announce-ment
which was found new hardware.
-Follow the hardware assistant and select for the drivers source Other Source
specify and afterwards the place for the driver
-Certify the located driver with Next and complete the driver’s installation with
Finish/Complete.
Part 2: Installation Vitrual COM-Port
-After the installation of the USB driver a USB-Serial-Port will be automatically
identify.
There also appears the announcement new hardware was found:
- Follow the hardware assistant and select for the drivers source Other Source
specify and afterwards the place for the driver
- Certify the located driver with Next and complete the driver’s installation with
Finish/Complete.
The installation can differ according to the used operating system and drivers
version.
Current
driver you can find on ou
r hom
e
page
www.dmx4all.de

DMX-Player L 4
Connections
USB Connection
LED
-
Display
RED - POWER OK
GREEN- DMX OK
Connection
GND
DMX-
DMX+
Voltage supply
GND - 0V
V+ - + 7 - 24V DC
DIG IN - Control Input
Control
-
Access
1 - PRG1 11 - SPD+
2 - PRG2 12 - SPD-
3 - PRG3 13 - INTENS+
4 - PRG4 14 - INTENS-
5 - PRG5 15 - PRG+
6 - PRG6 16 - IR
7 - PRG7 17 - SCL
8 - PRG8 18 - SDA
9 - PRG9 19 - GND
10 - PRG10 20 - +5V
For wiring see the following
pages
Scene
memory
EEPROM 8k (24C64)
(Standard)
EEPROM 32k /24C256)
LED
-
Dimmer
Expandability
for DMX-LED-Dimmer BABY
which is available as
equipment
TWI
-
Interface
1
GND
SDASCL
+5V
NC NC

DMX-Player L 5
Program selection
The selection of the deposited scenes can occur by different wirings. Which wiring is
used, must be configured in the Setup-Menu or the DMX-Configurator (For this see
the part Configuration).
The last selected scene will be recorded and after re-starting automatically
launched.
►See „Running one scene after power on“
Selection per 10 button
The first 10 stored scenes can be called directly about up to 10 buttons.
Connection:
PRG1 PRG2
GND
1 2
PRG3
3
PRG10
10
Selection about Button-Matrix 4x4 or 5x5
With a Matrix-wiring it is possible to call up to 25 Programs per one button.
Connection Matrix 4x4:
PRG1 PRG2 PRG3 PRG4
PRG5
1 2 3 4
PRG6
5 6 7 8
PRG7
9 10 11 12
PRG8
13 14 15 16

DMX-Player L 6
Connection Matrix 5x5:
PRG1 PRG2 PRG3 PRG4
PRG6
1 2 3 4
PRG7
6 7 8 9
PRG8
11 12 13 14
PRG9
16 17 18 19
PRG5
5
10
15
20
PRG10
21 22 23 24 25
Selection about numeric keypad with ENTER and BLACKOUT
The input of the executive scene happens with the numeric keypad and next ENTER.
The programs 1 up to 250 are possible.
In addition, with the switch BLACKOUT the blackout function can be switched-on and
switched-off with the key. The button ENTER automatically switches off the blackout
function.
Exampel: Scene 28: ‚2’ + ‚8’ + ‚ENTER’
Scene 146: ‚1’ + ‚4’ + ‚6’ + ‚ENTER’
Connection:
PRG1 PRG2 PRG3
PRG4
1 2 3
PRG5
4 5 6
PRG6
7 8 9
PRG7
BLACK
OUT 0 ENTER
Selection about 8-Bit binary Signal
With the 8-Bit binary control-signal up to 250 scenes can be called. Therefore the 8
bits of the binary signal have to be established at the entrances PRG1 to PRG8.

DMX-Player L 7
Brightness Setting
The brightness setting can be carried out per UP/DOWN button or Potentiometer.
INTENS+ INTENS-
GND
+ -
+5V
GND
INTENS+
INTENS-
10k
Wiring with UP/DOWN button Wiring with Potentiometer
During the operation the brightness value will be saved with the UP/DOWN-
buttons and retained during shutdown the DMX-Player L.
Speed Setting
The speed setting can be carried out per UP/DOWN button or Potentiometer.
SPD+ SPD-
GND
+ -
+5V
GND
SPD+
SPD-
10k
Wiring with UP/DOWN button Wiring with Potentiometer
During the operation the speed value will be saved with the UP/DOWN-buttons
and retained during shutdown the DMX-Player L.

DMX-Player L 8
Cable length
The DMX-Player L ought to operate at the Control-Connection with cables as short
as possible.
Recommended are cable lengths up to 0,5 meters!
To raise the operating safety resistors can be provided as shown in the following
picture from the signal input (INx) to the +5V connection.

DMX-Player L 9
Program StandAlone-function
The DMX-Player L has a user programmable StandAlone-function. The Scenes
arranged in the PC (programmes) will be transferred once to the interface and then
can be replayed.
The software DMX-Configurator serves for the production and programming of the
scenes. Under the menu point Settings→Communication settings the interface above
which the DMX-Configurator finds the connected hardware will be set.
In the left part there is the scenes admin. Here the scenes can be set up and fixed in
the order.
The right part shows the step admin. Every Scene exists of one step at least. For the
setting of different DMX values there are controller available. These are marked with
the channel number. To reach all 512 DMX channels, you must select the DMX
channel area with the underneath horizontal racketeer. For every step different DMX-
values can be set for every channel.
Furthermore for every step the fade time and residence time will be set with Fade
Time and Wait Time.
You can write the provided scenes in the Stand-Alone-memory of the DMX-Player L.
The transfer of the scenes to the interface can be started under Hardware→Write
data.
Attention: This process can last some time! Please, do not break off the transfer and
wait for certification of the DMX-Configurator.
Scenes-admin
Step-admin
Timer-
Setting

DMX-Player L 10
Executing a Scene after starting
After starting a specific scene can be replayed. For this, by compilating the scene in
the DMX-Configurator the Default Scene on Start has to be assigned. If this is
assigned, the selected scene under Default Scene on Start will be achieved by
starting the DMX-Player L.
Configuring the DMX-Player L
The DMX-Player L can be configured about the DMX-Configurator from the version
1.5. Select therefore Settings→Hardware settings by connected DMX-Player L. It
appears the following dialogue:
The configuration is transferred
and stored by OK to the DMX-
Player L.
The first 6 selection fields fix
the connected button
configuration. Only one
choice is possible
Configurating the used
remote control: RC5 remote
or DMX4ALL LED
Configurating the
DIG IN
control input
Fade between Scenes
allows fading between
scenes
Fill DMX
outputs 512 DMX-
channels, from channel 193
with the value 0.
Configurate the
PROG+
control signal
START/STOP program
allows a stop of a running
scene by repeated pushing
the scene button

DMX-Player L 11
Internal Clock (RTC)
The DMX-Player L disposes of an internal clock with which scenes can be start at
adjustable times.
Time setting
Select in the DMX-Configurator
Hardware→Syncronize Clock .
Now the topical PC-PC-system-time will
transferred on the DMX-Player L.
Digital Input Control DIG IN
The digital Input Control DIG-IN of the DMX-Player L can be configured as follows:
(see DMX-Player L configuration)
-Process next program
-Switch On/AOFF
-ON/OFF (short activity)
and brightness setting (long activity)
-Process next program (short activity)
and brightness setting (long activity)
-Process „Default scene on start”
The wiring of the Input control will be carried out as shown in the following view:
7-24V
GND
GND
V+
DIG IN
DMX-Player L

DMX-Player L 12
IR-Operation
The DMX-Player L allows an IR-Operation by means of external IR-Sensor. An IR-
Sensor is connected to the Pin 16 of the Control connection.
The stored scenes can be called by IR-remote control.
The DMX-Player L can be used by DMX4ALL LED remote control.
Operating with DMX4ALL LED-Remote control
The program selection happens about the keys 1,2,3 ... 9,0 according to the
programs from the 1 up to 9. The key 0 is for a free colour setting.
About the keys + and – the brightness and the speed is adjustable as well as is
possible for a program selection.
After actuating the key SPEED, the speed is adjustable;
After actuating the key PROG SELECT, the programs are selectable;
After actuating the key R, Gor B, the brightness is adjustable.
A separate setting for Red, Green and Blue is not
possible.
The switch BLACK OUT activates and deactivates
the BlackOut-function. Besides the brightness
setting will be persist.
The switch FLASH activates and deactivates the
Flash-function (all 100%). Besides the brightness
setting will be persist.

DMX-Player L 13
Dimensions
All details in mm
View from the components side (USB-Connection right)

DMX-Player L 14
CE-conformity
This assembly (board) is controlled by a microprocessor and
uses high frequency (8MHz). To get the characteristics of the
assembly in relation to the CE-conformity, an installation in a
compact metal casing is necessary.
Risk-Notes
You purchased a technical product. Conformable to the best available technology the
following risks should not excluded:
Failure risk: The device can drop out partially or completely at any time without
warning. To reduce the probability of a failure a redundant system structure is
necessary.
Initiation risk: For the installation of the board, the board must be connected and
adjusted to foreign components according to the device paperwork. This work can
only be done by qualified personnel, which read the full device paperwork and
understand it.
Operating risk: The Change or the operation under special conditions of the
installed systems/components could as well as hidden defects cause to breakdown
within the running time.
Misusage risk: Any nonstandard use could cause incalculable risks and is not
allowed.
Warning: It is not allowed to use the device in an operation, where the safety of
persons depend on this device.

DMX4ALL GmbH
Reiterweg 2A
D-44869 Bochum
Germany
Last changes: 29.09.2016
© Copyright DMX4ALL GmbH
All rights reserve. No part of this manual may be reproduced in any form (photocopy, pressure, microfilm or in another
procedure) without written permission or processed, multiplied or spread using electronic systems.
All information contained in this manual was arranged with largest care and after best knowledge. Nevertheless errors are to be
excluded not completely. For this reason I see myself compelled to point out that I can take over neither a warranty nor the legal
responsibility or any adhesion for consequences, which decrease/go back to incorrect data. This document does not contain
assured characteristics. The guidance and the characteristics can be changed at any time and without previous announcement.
