Dnake IP-2WIRE User manual

IP-2WIRE Converters are used to extend the Ethernet IP signals via 2Wire
cable in the existing 2Wire network of building.
In the field application, IP-2WIRE Converters could be applied to connection,
distribution and conversion of signals for the IP devices(Flat camera, Indoor
Monitor, Outdoor panel, etc.) via the 2Wire cable with 128bit AES and guaranteed
QoS for loss sensitive application. In addition, the system can connect to the
Internet via IP-2WIRE Master Converter.
This system is suited for transformation project of old buildings which can
remain 2Wire cables. It can save troubles of cable wiring and infrastructures
rebuilding as well as reduce the cost of projects.
1. Field Application
IP-2WIRE
48V Power Adapter
Master Converter
CAT-5 e
Weak power box
IP-2WIRE Slave Converter
RVV 2*1 .0
CAT-5 e
Electric Lock
Internet
RVV 2*0 .5
RVV 2*0 .5
Quick Start Guide
*4

2. Connection Diagram
LAN
2Wire
Power
2Wire
Connection
Step 1. Hardware Check and Preparation
Please check if there is any product defect.
Prepare :
1) Network cable
2) 2Wire cable
3) 48VDC Power supply to .( Please check the
cable length, spec. and connection status)
4) 2.0/2.5mm Slot Screw Driver.
IP-2WIRE Master Converter
3. Installation Steps
LAN
2Wire
Power
2Wire
Connection
Input
DC48V
!Output
DC12V
!
IP-2WIRE Master Converter IP-2WIRE Slave Converter

Step 2. Installation
In general, IP-2Wire Master Converter is set in weak power box. The LAN
interface can be connected to the Internet, and another interface is connected to
2-wire system.
Outdoor panel connects to two-wire system through IP-2Wire Slave Converter
which can support up to 4 indoor monitors.
Connect a 48V DC power supply into IP-2WIRE Master Converter to provide
power to the entire system, including the outdoor panel and indoor monitor.
All devices are in 2Wire Link Mode. They will find each other and establish basic
level encrypted communication.
4. LED Indicator
To show the working status of the device, the converter provides three LED
signals:
Power : Red LED is always on.
2Wire Connection: If green LED is always on, it means 2Wire Link Mode. If the
LED flashes slowly, it means 2Wire Unlink Mode.
LAN : Green LED is the Ethernet connection indicator. When the module is
transmitting or receiving through Ethernet, the LED toggles with 250ms period.

Power over Ethernet (POE) Function
IP-2WIRE Master Converter supports IEEE 802.3af, 12.95W PD.
IP-2WIRE Slave Converter supports IEEE 802.3at-compliant PSE.
Installation Warnings
Do not use the converter near the harsh (temperature, humidity, cabling
quality) installation site.
If the converter is flooded with water or other liquid materials, please turn off
the power source, disconnect all the cables of the converter and contact DNAKE
technical team for after service.
Do not use converter under the condition of temperature over 50℃ for
converter's operation performance and lifetime.
