Welcome to
Docking Drawer
Simple to specify. Reduces clutter. Safe.
ETL Listed in-drawer electrical outlets
It’s time to clear clutter one drawer at a time
with Docking Drawer in-drawer electrical outlets.
Whether it’s in your home, closet, oce, or locker
room reduce clutter by getting all your cords, chargers,
personal technology and hair dryers out of the way with
simple to specify Docking Drawer in-drawer electrical outlet
solutions. Docking Drawers are purpose built, easy to install
and ETL Listed to UL962a and CSA-C22.2 offering safe, trouble
free operation while meeting building codes.
New and Improved! All outlets now come with an adjustable
rear mounting bracket for easier installation!
NEW
Docking Drawer
21 + 24 SLIM
FITS INTO TIGHT SPACES
2 MINUTE INSTALL
NO HARDWIRING

Solutions for Every Application
Reduce
Clutter.
Take control and clear
clutter. Docking Drawer
in-drawer electrical outlet
solutions are perfect
for today’s connected
homes, bathrooms,
kitchens, drop zones,
bars, locker rooms,
oces and more. Use
Docking Drawers where
ever you seek to clear
clutter and charge or
power your devices.
Safe.
To increase safety and minimize
risk, Docking Drawer in-drawer
electrical outlets include integrated
interlocking safety features.
Docking Drawer 21 + 24 SLIM
outlets feature a UL Listed circuit
breaker that prevents high
power devices from being used
to ensure safe operation. Style
Drawer and Mighty Drawer
feature a UL Listed thermostat
which cuts power to the
outlet in the event that the
surrounding temperature
exceeds 120˚F to minimize
risk with devices that are left
on when the drawer is closed.
Reliable.
Utilizing JTech Solutions
engineering expertise,
we built Docking Drawer
in-drawer electrical
outlets with high quality
materials. Then we
cycle test the assembly
over 500,000 times
representing opening
and closing the drawer
every 15 minutes for
over 30 years to ensure
a lifetime of trouble
free operation.
Outlets Features
•First and only ETL Listed in-drawer electrical outlet
•Interlocking safety features that cut power
to the outlet to minimize risk
•Adjustable rear mounting bracket allows
for ne tuning the arm alignment
•Simple to specify and easy to install
CHARGE POWER
Docking Drawer 21 + 24 SLIM Docking Drawer Slim USB Style & Mighty Drawer
• Phones • Phones • Hair Dryers
• Tablets • Tablets • Curling Irons
• Laptops • USB Flashlights • Flat Irons
• USB Flashlights • USB Speakers • Mixers
• USB Speakers • USB Ports • Items requiring full power
• Combination Outlet • No AC outlets • 2 GFCI AC Outlets
NEW

Specication Library
To help make specifying Docking Drawer outlets simple,
please visit the Specication Library. There you can
download mounting diagrams, DWG and STEP les,
installation manuals, brochures and more.
Please visit www.dockingdrawer.com and click on the
Specications button on our home page.
Simple
to Specify
With just 4 key installation requirements,
Docking Drawer solutions are simple
to specify.
First, conrm the minimum space behind
the drawer box. Second, conrm the
minimum width behind the drawer box
needed for the Docking Drawer outlet.
Third, conrm the minimum interior
drawer box height to accommodate
the receptacle box. Lastly, conrm the
maximum drawer extension to ensure
the drawer opens completely. Simple.



























  




















 


















 






  

























 


























 

Style Drawer
Part No. 0290-00011
1
2
3
4
Conrm
space behind
drawer box
Conrm
width behind
drawer box
Conrm
interior drawer
box height
Conrm
drawer
extension
Docking Drawer 21 + 24 SLIM
•Docking Drawer 21 + 24 SLIM outlet
dimensions have been greatly reduced
to t into standard cabinet specications.
• New quick install feature allows the Docking
Drawer 21 + 24 SLIM outlets to be installed in
less than 2 minutes and requires just 1 tool.
Also allows for easy drawer removal.
•Simple electrical planning and connection—
all Docking Drawer charging outlets now just
plug into an existing outlet.
•Docking Drawer 21 + 24 SLIM outlets ship
fully tested and assembled. Just take the
outlet of of the box, install with a few screws
and plug in the outlet to nish the installation.
NEW

Docking Drawer
21 SLIM
Docking Drawer
24 SLIM
Docking Drawer
Slim USB Style Drawer Mighty Drawer
Part Number (*White)
0290-00030
0290-00030W*
0290-00031
0290-00031W* 0290-00012 0290-00011
0290-00011W*
0290-00013
0290-00013W*
Warranty 1 year 1 year 1 year 1 year 1 year
Electrical
Connection
6’ Cord w/
NEMA 5 - 15 plug
6’ Cord w/
NEMA 5 - 15 plug
6’ Cord w/
NEMA 5 - 15 plug Hardwire Hardwire
Minimum space
behind drawer box
3” 3” 3” 4” 4”
Minimum width
behind drawer box
≥16” ≥17 1/2”≥14 5/8”≥13 3/8”≥14 7/8”
Minimum interior
drawer box height
2 3/4” 2 3/4” 3” 4” 4”
Maximum
drawer extension
18” 21” 21” 17” 20”
Cabinet Depth
21” 24” 24” 21” 24”
120V AC outlets 2 2 None 2 2
USB Ports 2 2 4 None None
LED Indicator No No No Yes Yes
GFCI No No No Yes Yes
Max Current
AC: 3 amps @ 120 VAC
USB: 3.6 amps @ 5 VDC
AC: 3 amps @ 120 VAC
USB: 3.6 amps @ 5 VDC 4.2 amps @ 5 VDC 20 amps 20 amps
Tamper Resistant Yes Yes N/A Yes Yes
Interlocking
Safety Feature
Circuit Breaker Circuit Breaker N/A Manual Reset
Thermostat
Manual Reset
Thermostat
ETL Listed to UL962a Yes Yes Yes Yes Yes
ETL Listed to CSA-C22.2 Yes Yes Yes Yes Yes
Docking Drawer 21 Slim
assembly, installation
manual, receptacle
Docking Drawer 24 Slim
assembly, installation
manual, receptacle
Slim USB Drawer
assembly, installation
manual, receptacle
Style Drawer
assembly, installation
manual, receptacle
Mighty Drawer
assembly, installation
manual, receptacle
Charging or
Powering Outlet
Charge low
power personal
technology devices
Charge low
power personal
technology devices
Charge up to
4 high power
USB devices
Power any device
up to 20A
Power any
device up to 20A
Examples
Laptops, Tablets,
Phones, Cameras,
MP3 Players, etc.
Laptops, Tablets,
Phones, Cameras,
MP3 Players, etc.
Phones, Tablets, etc.
without the use of an
AC adapter
Blow Dryers, Curling
Irons, Shavers, Small
Kitchen Appliances,
Power Tools and even
Electric Cars
Blow Dryers, Curling
Irons, Shavers, Small
Kitchen Appliances,
Power Tools and even
Electric Cars
102615
Docking
Drawer™
12893 Alcosta Blvd., Suite M
San Ramon, CA 94583
p530.205.3625
f925.886.3824
[e-mail]
Specications subject to change. Please visit www.dockingdrawer.com for the most current information.
www.dockingdrawer.com
