Docomo L-04B STYLE Series User manual

INSTRUCTION MANUAL
’10.5
L-04B
From land-line phones <Universal number>
From DOCOMO mobile phones
From land-line phones
International call access code
for the country you stay
2010.5 (1st Edition)
MMBB0383006
General Inquiries
<docomo Information Center>
Repairs
Loss or theft of FOMA terminal or payment of
cumulative cost overseas
<docomo Information Center>
※ For international call access codes for major countries and universal number international
prefix, refer to DOCOMO International Services website.
※ For international call access codes for major countries and universal number international
prefix, refer to DOCOMO International Services website.
International call access code
for the country you stay -81-3-6832-6600
*

(tollfree)
* You are charged a call fee to Japan when calling from a land-line phone, etc.
※ If you use L-04B, you should dial the number [phone]
(to enter '+', press and hold the '0' key for at least one second).
(available 24 hours a day) (available 24 hours a day)
<Universal number>
-8000120-0151*
* You might be charged a domestic call fee according to the call rate for the country you stay.
Failures encountered overseas
<Network Support and Operation Center>
-81-3-6718-1414*

(tollfree)
* You are charged a call fee to Japan when calling from a land-line phone, etc.
※ If you use L-04B, you should dial the number [phone]
(to enter '+', press and hold the '0' key for at least one second).
-8005931-8600 *
* You might be charged a domestic call fee according to the call rate for the country you stay.
If you lose your FOMA terminal or have it stolen, immediately take the steps necessary for suspending the use of the FOMA terminal.
If the FOMA terminal you purchased is damaged, bring your FOMA terminal to a repair counter specified by DOCOMO after returning to Japan.
Don't forget your mobile phone … or your manners!
When using your mobile phone in a public place, don't forget
to show common courtesy and consideration to others around you.
To prevent damage to the environment,
bring used battery packs to a docomo
service counter, a docomo agent or a
recycle center.
Sales:NTT DOCOMO, INC.
Manufacturer: LG Electronics Inc.
Universal number
international prefix
▶i-mode site iMenu ⇒お客様サポート (user support) ⇒ドコモショップ (docomo Shop) *In Japanese only
For Applications or Repairs and After-Sales Service, please contact the above-mentioned information center or the docomo Shop etc. near you on the NTT DOCOMO website or the i-mode site.
▶NTT DOCOMO website http://www.nttdocomo.co.jp/english/
Please confirm the phone number before you dial.
(Business hours: 9:00 a.m. to 9:00 p.m.)
From DOCOMO mobile phones
From DOCOMO mobile phones
(In Japanese only)
151 (toll free)
(No prefix)
* Unavailable from land-line phones, etc.
0120-005-250 (toll free)
* Service available in: English, Portuguese, Chinese, Spanish, Korean.
* Unavailable from part of IP phones.
(Business hours: 9:00 a.m. to 8:00 p.m. (open all year round))
(Business hours: 24 hours (open all year round))
From DOCOMO mobile phones
(In Japanese only)
113 (toll free) (toll free)
* Unavailable from land-line phones, etc.
(No prefix)
* Unavailable from part of IP phones.
From land-line phones
(In Japanese only)
0120-800-000
(toll free)
From land-line phones
(In Japanese only)
0120-800-000
* Unavailable from part of IP phones.
Universal number
international prefix

DOCOMO W-CDMA and GSM/GPRS Systems
Thank you for selecting the "docomo STYLE series L-04B".
Read this manual before use to correctly operate your L-04B.
Operation Description of L-04B
Operations of L-04B are described in this manual as well as "Guide" (installed in this FOMA terminal, Japanese
only) and "Instruction Manual (Detailed version, Japanese only)" (in PDF format).
b "Instruction Manual" (This Manual): Describes screen displays and operating procedures of basic functions.
b "Guide" (installed in this FOMA terminal, Japanese only): Describes the overview or operating procedures of
frequently used functions.
From L-04B: Stand-by display X7(for over 1 second)
b "Instruction Manual (Detailed version, Japanese only)" (in PDF format): Describes detailed information and
operating procedures of all functions.
From a PC, download it from the following DOCOMO website.
http://www.nttdocomo.co.jp/support/trouble/manual/download/index.html
* The URL and contents of the manual are subject to change without prior notice.
Accessories
L-04B FOMA terminal
(With Warranty and Back Cover L18)
Battery Pack L06 Instruction Manual (Japanese version) CD-ROM for L-04B
取扱説明書
Options compatible with this FOMA terminal → P79
• Note that "L-04B" is referred to as "FOMA terminal" in this manual.
• It is prohibited to copy all or part of this manual without permission.
• The screens or illustrations used in this manual are examples. The actual screens and illustrations may differ.
• This manual describes operations mainly using the default settings ("WATERLOO" in Kisekae Tool). If settings
are changed, screen displays or operations may differ from those described in this manual.

Introduction
P2
FOMA Terminal What You Can Do with L-04B Part Names and Functions Precautions
Handling Precautions
Basic Operation
P18
Before Using Screen Explanation Character Entry Sound/Screen Setting
Lock/Security
Connect
P36 Call Telephone Mail Phonebook
Search
P50 i-mode/Full Browser i-Channel
Enjoy
P54 Camera Music i-αppli i-motion
More Convenient
P62 Osaifu-Keitai Convenient Tools Data Management
Others
P70 Support Appendix Index
Contents
1

2
Introduction
• The FOMA terminal uses radio waves, therefore, it may
not function in locations where radio waves cannot
reach, such as in tunnels, underground, or in buildings;
outside the building where radio waves are weak or out
of FOMA service area. Even when you are in an upper
floor of a tall building and nothing blocks your view
outside, your FOMA terminal may not be able to receive
or transmit signals. Also, even when radio waves are
strong with three antenna bars displayed, and you are
not moving, communication may still be interrupted.
• Be considerate of other people around you in public or
where it is especially crowded or quiet.
• The FOMA terminal uses radio waves to communicate,
therefore, there is a possibility that calls may be
intercepted by third parties. The W-CDMA and GSM/
GPRS systems automatically encode signals for all
calls so even if third parties should intercept calls with
the receiver, they will hear only noise.
• The FOMA terminal sends and receives voice
communication as encoded digital data. When you are
operating the FOMA terminal while moving, sometimes
you may encounter weaker radio waves and the
transmitted digital data may not be correctly decoded
resulting in sound distortions.
• It is recommended that you save important data on a
microSD card. If you use a PC, use DOCOMO keitai
datalink to send and save data such as Phonebook
entries, mail messages, Schedule events, etc. to the
PC.
• When you use SSL for a secure connection, you
agree that you are responsible for any actions you
take. DOCOMO and the certifiers listed below do
not guarantee the safety of SSL for any activities of
customers while using SSL, and are not liable for any
damages incurred through using SSL.
Certifiers: VeriSign Japan K.K.,
Cybertrust Japan Co., Ltd.,
GlobalSign K.K.,
RSA Security Japan Ltd.,
SECOM Trust Systems Co., Ltd.
• The FOMA terminal supports FOMA Plus-Area and
FOMA HIGH-SPEED Area.
• The FOMA terminal can be used only via the FOMA
network provided by DOCOMO and DOCOMO's
roaming area.
• It is recommended that you make a backup of user-
defined data (Phonebook entries, Schedule events,
text memos, Record messages, voice memos, or
moving picture memos) saved in the FOMA terminal
by keeping the separate record or note of those data,
etc. and storing them at a separate location. DOCOMO
is not responsible for lost data due to failure, repair, or
replacement of the model of your FOMA terminal.
FOMA Terminal

3
Introduction
Guide (Japanese only) → P21
Guide pre-installed in the FOMA terminal allows you
to look for operating instructions of a desired
function. When you cannot refer to this manual, you
can search functions with Guide quickly.
Stand-by display X7(for over 1 second)
International roaming → P41
Your FOMA terminal, phone number, and mail
address that are used in Japan are available
overseas (supporting 3G and GSM areas).
i-Channel (Japanese only) → P53
You can receive graphic information such as news or
weather forecasts.
Also, you can obtain rich content created with Flash
by selecting your favorite channels from the Channel
list.
* This service is a fee-based service that requires
subscription.

Full browser → P51
You can browse web pages incompatible with i-mode
on the FOMA terminal in the same way as on a PC.
Camera functions → P54
You can capture still images (with auto focus) and
moving pictures using the camera with approx. 3.1 Mega
effective pixels (approx. 3.1 Mega recorded pixels).
Osaifu-Keitai → P62
You can download i-αppli that supports Osaifu-
Keitai to deposit electronic money to the IC card
on the FOMA terminal, check your balance or view
usage history using communication. DOCOMO
credit service, "DCMX" application, is pre-installed.
"iC transfer service" is also available, which allows
transfer of data on the IC card when you replace
your FOMA terminal.
* This FOMA terminal does not support
"iC communication".
Bar code reader → P63
By scanning a bar code or QR code with the camera,
you can access to the corresponding site or send a mail.
What You Can Do with L-04B

4
Introduction
Part Names and Functions
z
y
A
C
D
B
x
b
d
f
e
j
k
i
c
a
g
h
n
l
o
p
t
s
m
r
q
u
v
w
• The microSD card insertion position is underneath the battery pack inside the back cover. → P65
●Front ●Rear ●Left side ●Right side

5
Introduction
a Infrared port
b Earpiece
c Display
d MMenu key
Display the main menu.
e Navigation Left key
Display the received call list screen.
f gMail key
Display the mail menu.
g Navigation Down key
Display the Phonebook list screen.
h AStart key
Make/receive a call.
i Dial keys
Enter a phone number or character.
j * Public mode (Drive mode)
key
k Mouthpiece
l Charging light/Illumination
m CSet key
n Navigation Up key
Display a schedule.
o Ii-mode/i-αppli key
Display the i-mode menu.
p Navigation Right key
Display the redial list screen.
q GCamera key
Display the still image shooting
screen.
r PPower/Exit key
End a call or exit a function.
s QClear/i-Channel key
Display the channel list screen.
t #Manner mode key
u Camera
v mark
w Back cover
Do not remove the sticker on the
back side of the back cover. If
removing it, the IC card contents
may not be read or written.
x Photo light
y Speaker
z FOMA antenna
The FOMA antenna is
inside the FOMA terminal.
To communicate in better
condition, avoid covering the
antenna part with your hands.
A Strap hole
B Charging terminals
C External connector terminal
D lLock key
Press for over 1 second to set/
cancel the key lock.
Using earphones
Connect optional earphones compatible with
the external connector terminal.
If you use the incompatible earphones,
connect the optional conversion plug
adapter to the earphones.
Earphone terminal
(Flat type)
Flat plug for the
Flat-plug Earphone/
Microphone with Switch
Plug
Ex.: Connecting the Flat-plug Earphone/
Microphone with Switch (optional)

6
Introduction
Precautions (ALWAYS FOLLOW THESE PRECAUTIONS)
bBefore using your FOMA terminal, read these "Precautions"
carefully so that you can use it correctly. After reading these
precautions, keep this manual for later reference.
bBe sure to observe these precautions because they are
intended to protect you or others around you from causing
injury and to avoid damage to the property.
bThe symbols below indicate the levels of danger or damage
that may occur if the particular precaution is not observed and
the FOMA terminal is used improperly.
DANGER
This symbol indicates
that incorrect handling
may directly or
immediately cause death
or serious injury.
WARNING
This symbol indicates
that incorrect handling
poses a risk of causing
death or serious injury.
CAUTION
This symbol indicates
that incorrect handling
poses a risk of causing
injury or damage to the
product or property.
bThe following symbols indicate specific directions:
Don’t
Denotes things not to do (Prohibitions).
No
disassembly
Denotes not to disassemble.
No
wet hands
Denotes not to touch with wet hands.
No
liquids
Denotes not to use where it could get
wet or not to wet it.
Do
Denotes mandatory instructions
(matters that must be complied with).
Unplug
Denotes to unplug from the outlet.
b "Precautions" are explained in the following six sections:
General Precautions for FOMA Terminal, Battery Pack,
Adapter, and UIM ................................................................ P7
Precautions for FOMA Terminal........................................... P8
Precautions for Battery Pack............................................. P10
Precautions for Adapter .................................................... P11
Precautions for UIM........................................................... P13
Precautions on Using near Electronic Medical Equipment ... P13

7
Introduction
General Precautions for
FOMA Terminal, Battery
Pack, Adapter, and UIM
DANGER
Don’t
Do not use, store, or leave the
FOMA terminal and its
accessories in locations subject
to high temperatures, such as
near fire, in direct sunlight, or
inside a car under the hot sun.
Fire, burns, or injury may result.
Don’t
Do not put the battery pack,
FOMA terminal, adapter, or
UIM in heating appliances
such as microwaves or high
pressure containers.
Fire, burns, injury, or electric
shock may result.
No
disassembly
Do not disassemble or
remodel the FOMA terminal
and its accessories.
Fire, burns, injury, or electric
shock may result.
No
liquids
Do not get the FOMA terminal and
its accessories wet with water,
drinking water, pet urine, etc.
Fire, burns, injury, or electric
shock may result.
Do
Use battery packs and
adapters specified by NTT
DOCOMO.
Fire, burns, injury, or electric
shock may result.
WARNING
Don’t
Do not subject the FOMA
terminal and its accessories
to severe shocks, or throw
them.
Fire, burns, injury, or electric
shock may result.
Don’t
Keep conductive foreign
objects (metal, pencil lead,
etc.) away from the charging
terminals or external
connector. Do not insert such
objects inside the FOMA
terminal.
Fire, burns, injury, or electric
shock may result.
Don’t
Do not cover or wrap
the FOMA terminal or its
accessories with bedding, etc.
while using or charging.
Fire or burns may result.
Do
Make sure to turn off the
FOMA terminal before you
go to a place such as a gas
station where flammable
gas is generated, and do not
charge the FOMA terminal.
Catching fire may result.
If you use Osaifu-Keitai on the
premises of the gas station,
make sure to turn the power off
beforehand and use it. (If the IC
card lock is set, cancel the lock
and then turn the power off.)
Do
If you notice any strange
smells, overheating,
discoloration, or deformation
while using, charging, or
storing the FOMA terminal,
immediately take the
following actions:
● Remove the power plug from
the outlet or cigarette lighter
socket.
● Turn the FOMA terminal power
off.
● Remove the battery pack from
the FOMA terminal.
Fire, burns, injury, or electric
shock may result.

8
Introduction
CAUTION
Don’t
Do not place the FOMA
terminal and its accessories
in unstable places such as
wobbly tables or sloping
shelves.
The FOMA terminal or its
accessories may fall, resulting
in injury.
Don’t
Do not store the FOMA
terminal and its accessories
in humid or dusty places, or
in high temperatures.
Fire, burns, or electric shock may
result.
Do
If children use the FOMA
terminal, a guardian should
explain the safety instructions
and correct operations. The
guardian should also make
sure that the instructions are
followed during use.
Injury may result.
Do
Keep out of the reach of
babies and infants.
Accidental swallowing or injury
may result.
Do
Pay extra attention when you
use the FOMA terminal for an
extended period of time while
it is connected to the adapter.
If you use i-αppli or make a
videophone call for a long
time while charging, the FOMA
terminal, battery pack, or
adapter may become hot.
Some users who continuously
or repeatedly touch a hot
FOMA terminal may develop
rashes, itching, or eczema
depending on their physical
health or existing medical
conditions, or a low-
temperature bare skin burn
may result.
Precautions for FOMA
Terminal
WARNING
Don’t
Do not directly point the
infrared port at someone's
eyes during transmission.
Their eyes may be adversely
affected.
Don’t
Do not directly point the
infrared port at home
appliances with the infrared
device.
Malfunction of the infrared device
may cause an accident.
Don’t
Do not get liquids such as
water or foreign objects such
as metal pieces or flammable
materials into the UIM or
microSD card slot of the
FOMA terminal.
Fire, burns, injury, or electric
shock may result.
Do
Turn the FOMA terminal off in
places where use is prohibited
such as in airplanes or
hospitals.
Electronic devices or electronic
medical devices may be
adversely affected. If the FOMA
terminal is set to be turned
on automatically, cancel the
setting before turning it off. For
use in medical facilities, follow
instructions of each medical
facility. You will be punished if
you take activity prohibited by law
such as use of the FOMA terminal
in airplanes.
