8W-97 POWER DISTRIBUTION - SERVICE INFORMATION
TABLE OF CONTENTS
page page
POWER DISTRIBUTION - SERVICE
INFORMATION
DESCRIPTION ..........................1
OPERATION ............................1
SPECIAL TOOLS
POWER DISTRIBUTION SYSTEMS .........2
MODULE-INTEGRATED POWER
DESCRIPTION ..........................3
OPERATION ............................3
REMOVAL .............................3
INSTALLATION ..........................4
IOD FUSE
DESCRIPTION ..........................4
OPERATION ............................4
JUNCTION BLOCK
DESCRIPTION ..........................5
OPERATION ............................5
REMOVAL .............................6
INSTALLATION ..........................6
POWER DISTRIBUTION CENTER
DESCRIPTION ..........................7
OPERATION ............................7
REMOVAL .............................7
INSTALLATION ..........................8
POWER OUTLET
REMOVAL .............................8
INSTALLATION ..........................8
POWER DISTRIBUTION - SERVICE INFORMATION
DESCRIPTION
The power distribution system for this vehicle consists of the following components:
•Cigar Lighter Outlet
•Front Control Module (FCM)
•Integrated Power Module (IPM)
•Power Distribution Center (PDC)
•Power Outlets
Refer to Wiring Diagrams for complete circuit schematics.
The power distribution system also incorporates various types of circuit control and protection features, including:
•Automatic resetting circuit breakers
•Blade-type fuses
•Cartridge fuses
•Relays
OPERATION
The power distribution system for this vehicle is designed to provide safe, reliable, and centralized distribution points
for the electrical current required to operate all of the many standard and optional factory-installed electrical and
electronic powertrain, chassis, safety, security, comfort and convenience systems. At the same time, the power dis-
tribution system was designed to provide ready access to these electrical distribution points for the technician to use
when conducting diagnosis and repair of inoperative circuits. The power distribution system can also prove useful
for the sourcing of additional electrical circuits that may be required to provide the electrical current needed to oper-
ate many accessories that the vehicle owner may choose to have installed.
HB 8W-97 POWER DISTRIBUTION - SERVICE INFORMATION 8W - 97 - 1

SPECIAL TOOLS
POWER DISTRIBUTION SYSTEMS
8W - 97 - 2 8W-97 POWER DISTRIBUTION - SERVICE INFORMATION HB

MODULE-INTEGRATED POWER
DESCRIPTION
The Integrated Power Module (IPM) is a combination
of the Power Distribution Center (PDC) (1) and the
Front Control Module (FCM) (2). The IPM is located in
the engine compartment, next to the battery. The
power distribution center mates directly with the (FCM)
to form the IPM. The (PDC) is a printed circuit board
based module that contains fuses and relays, while
the FCM contains the electronics controlling the IPM
and other functions. The IPM connects directly to the
battery positive via a stud located on top of the unit.
The ground connection is via electrical connectors.
The IPM provides the primary means of voltage distri-
bution and protection for the entire vehicle.
OPERATION
All of the current from the battery and the generator output enters the integrated power module via a stud on the top
of the module. Internal connections of all of the power distribution center circuits is accomplished by a combination
of bus bars and a printed circuit board.
REMOVAL
1. Disconnect the negative and positive battery
cables.
2. Unsnap cover and remove the B+ terminal nut from
the integrated power module (IPM). Remove the
B+ cable.
3. Remove the IPM from the retaining bracket (1).
4. Disconnect the connectors from the (IPM).
5. Remove the Front Control Module (FCM) (2) retain-
ing screws.
6. Disconnect the front control module by pulling it
straight off the integrated power module.
HB 8W-97 POWER DISTRIBUTION - SERVICE INFORMATION 8W - 97 - 3

INSTALLATION
1. Install the Front Control Module (FCM) (2) to the
Integrated Power Module (IPM).
2. Connect the electrical connectors to the IPM (1).
3. Install the IPM to the retaining bracket.
4. Install the B+ cable and nut on the IPM B+ termi-
nal. Snap the cover in place.
5. Connect the negative and positive battery cables.
IOD FUSE
DESCRIPTION
All vehicles are equipped with an Ignition-Off Draw (IOD) fuse that is disconnected within the Integrated Power Mod-
ule when the vehicle is shipped from the factory. Dealer personnel are to reconnect the IOD fuse in the Integrated
Power Module as part of the preparation procedures performed just prior to new vehicle delivery. The following cir-
cuits are protected by the IOD fuse:
•Cluster (CCN)
•Diagnostic Connector
•Map Lamps
•Glove Box Lamp
•Courtesy Lamps
•Radio
•Underhood Lamp
OPERATION
The term ignition-off draw identifies a normal condition where power is being drained from the battery with the igni-
tion switch in the Off position. The IOD fuse feeds the memory and sleep mode functions for some of the electronic
modules in the vehicle as well as various other accessories that require battery current when the ignition switch is
in the Off position. The only reason the IOD fuse is disconnected is to reduce the normal IOD of the vehicle elec-
trical system during new vehicle transportation and pre-delivery storage to reduce battery depletion, while still allow-
ing vehicle operation so that the vehicle can be loaded, unloaded and moved as needed.
The IOD fuse is disconnected from Integrated Power Module when the vehicle is shipped from the assembly plant.
Dealer personnel must reconnect the IOD fuse when the vehicle is being prepared for delivery in order to restore full
electrical system operation. Once the vehicle is prepared for delivery, the IOD function of this fuse becomes trans-
parent and the fuse that has been assigned the IOD designation becomes another Fused B(+) circuit fuse.
The IOD fuse can be used by the vehicle owner as a convenient means of reducing battery depletion when a vehi-
cle is to be stored for periods not to exceed about thirty days. However, it must be remembered that disconnecting
the IOD fuse will not eliminate IOD, but only reduce this normal condition. If a vehicle will be stored for more than
about thirty days, the battery negative cable should be disconnected to eliminate normal IOD; and, the battery
8W - 97 - 4 8W-97 POWER DISTRIBUTION - SERVICE INFORMATION HB

should be tested and recharged at regular intervals during the vehicle storage period to prevent the battery from
becoming discharged or damaged.
JUNCTION BLOCK
DESCRIPTION
An electrical Junction Block (JB) (1) is concealed
behind the left outboard end of the instrument panel
cover. The JB combines the functions previously pro-
vided by a separate fuseblock module and relay cen-
ter, serves to simplify and centralize numerous
electrical components, and to distribute electrical cur-
rent to many of the accessory systems in the vehicle.
It also eliminates the need for numerous splice con-
nections and serves in place of a bulkhead connector
between many of the engine compartment, instrument
panel, and body wire harnesses.
The molded plastic JB housing has integral mounting
brackets that are secured with two screws to the left
instrument panel end bracket. The left end of the
instrument panel cover has a snap-fit fuse access
panel that can be removed for service of the JB. A
fuse puller and spare fuse holders are located on the
back of the fuse access cover, as well as a fuse lay-
out to help ensure proper fuse identification.
The JB unit cannot be repaired and is only serviced
as an assembly. If any internal circuit or the JB hous-
ing is faulty or damaged, the entire JB unit must be
replaced.
OPERATION
All of the circuits entering and leaving the JB do so through wire harness connectors, which are connected to the JB
through integral connector receptacles molded into the JB housing. Internal connection of all of the JB circuits is
accomplished by an intricate combination of hard wiring and bus bars.
HB 8W-97 POWER DISTRIBUTION - SERVICE INFORMATION 8W - 97 - 5

REMOVAL
1. Disconnect and isolate the battery negative cable.
2. Remove the cowl trim cover (Refer to 23 - BODY/
INTERIOR/COWL TRIM COVER - REMOVAL).
3. Remove the mounting fasteners (3).
4. Disconnect the electrical harness connectors and
remove Junction Block (1).
5. Transfer components as necessary.
INSTALLATION
1. Connect wire harness connectors to the Junction
Block (JB) (1).
2. Position JB and install mounting fasteners (3).
3. Install cowl trim cover (Refer to 23 - BODY/INTE-
RIOR/COWL TRIM COVER - INSTALLATION).
4. Connect the battery negative cable.
8W - 97 - 6 8W-97 POWER DISTRIBUTION - SERVICE INFORMATION HB

POWER DISTRIBUTION CENTER
DESCRIPTION
All of the electrical current distributed throughout this
vehicle is directed through the Power Distribution Cen-
ter (PDC) (1). The molded plastic PDC housing is
located in the left front corner of the engine compart-
ment, just behind the battery. The PDC houses the
generator cartridge fuse and maxi-type cartridge
fuses, which replace all in-line fusible links. The PDC
also houses blade-type fuses, relays, and a fuse
puller.
OPERATION
All of the current from the battery and the generator output enters the PDC through two cables with eyelets that are
secured with nuts to the two B(+) terminal studs located just inside the inboard end of the PDC housing. The PDC
cover is unlatched and removed to access the battery and generator output connection B(+) terminal studs, the
fuses, the relays, the joint connectors and the engine wire harness in-line connector.
REMOVAL
1. Disconnect and isolate the battery negative cable.
2. Depress retaining tabs on the side on the PDC (1).
3. Disconnect electrical harness connectors (2) and
remove PDC.
HB 8W-97 POWER DISTRIBUTION - SERVICE INFORMATION 8W - 97 - 7

INSTALLATION
1. Connect electrical harness connectors to Power
Distribution Center (PDC).
2. Position PDC and engage into the retaining tabs.
3. Connect the battery negative cable.
POWER OUTLET
REMOVAL
1. Disconnect and isolate the battery negative cable.
2. Pull the cigar lighter knob and element out of the cigar lighter receptacle base, or unsnap the protective cap from
the power outlet receptacle base.
3. Look inside the cigar lighter or power outlet receptacle base and note the position of the rectangular retaining
bosses of the mount that secures the receptacle base to the panel.
4. Insert a pair of external snap ring pliers into the cigar lighter or power outlet receptacle base and engage the tips
of the pliers with the retaining bosses of the mount.
5. Squeeze the pliers to disengage the mount retaining bosses from the receptacle base and, using a gentle rock-
ing motion, pull the pliers and the receptacle base out of the mount.
6. Pull the receptacle base away from the instrument panel far enough to access the instrument panel wire harness
connector.
7. Disconnect the instrument panel wire harness connector from the cigar lighter or power outlet receptacle base
connector receptacle.
8. Remove the cigar lighter or power outlet mount from the instrument panel.
INSTALLATION
1. Connect the instrument panel wire harness connector to the cigar lighter or power outlet receptacle base con-
nector receptacle.
2. Install the cigar lighter or power outlet mount into the instrument panel.
3. Align the splines on the outside of the cigar lighter or power outlet receptacle base connector receptacle with the
grooves on the inside of the mount.
4. Press firmly on the cigar lighter or power outlet receptacle base until the retaining bosses of the mount are fully
engaged in their receptacles.
5. Install the cigar lighter knob and element into the cigar lighter receptacle base, or the protective cap into the
power outlet receptacle base.
6. Connect the battery negative cable.
