Doepke RTZ 2 User manual

Änderungen und Irrtümer vorbehalten
Ausgabe 07/07
Treppenlicht - Zeitschalter
Treppenlichtautomat elektronisch
Abschalt-Vorwarnung
Nachschaltbar, Langzeitfunktion programmierbar
Energiesparfunktion
Betriebsart Stromstoßschalter wählbar
Geringes Schaltgeräusch
Hohe Schaltkapazität, 80A Einschaltspitzenstrom
Automatische 3/4 - Leitererkennung
Glimmlampenlast bis zu 100mA
Baubreite 17.5 mm
Installationsbauform
Technische Daten
1. Funktionen
Elektronischer Treppenlicht-Zeitschalter mit Abschalt-Vorwarnung.
Der Steuereingang erlaubt den Anschluss von Tastern mit insgesamt
bis zu 100mA Glimmlampenstrom und ermöglicht die Verwendung in
3- oder 4-Leiter-Schaltung. Über die angeschlossenen Taster ist das
Gerät nachschaltbar, sowie durch einen langen Tastendruck abschaltbar
(Energiesparfunktion). Durch "pumpen" lässt sich der Nachlauf auf ein
mehrfaches der frei einstellbaren Zeit t erhöhen.
Je nach Ausführungsvariante können folgende Betriebsarten über die
Bedienelemente an der Front gewählt werden:
TW Zeitautomatik mit Abschaltvorwarnung
T Zeitautomatik ohne Abschaltvorwarnung
1 Dauerlicht (EIN)
0 Ausgeschaltet
P Stromstoßschalter ohne Zeitfunktion (nur Typen mit Option P)
PN Stromstoßschlater nullspannungssicher (nur Typen mit Option PN)
2. Zeitbereiche
Einstellbereich
Zeitverzögerung: 0,5 - 12min (in Funktion T, TW)
3. Anzeigen
Grüne LED U ON: Versorgungsspannung liegt an
Gelbe LED ON/OFF: Stellung des Ausgangsrelais
4. Mechanische Ausführung
Gehäuse aus selbstverlöschendem Kunststoff, Schutzart IP40
Befestigung auf Profilschiene TS 35 gemäß EN 50022
Einbaulage: beliebig
Berührungssichere Zugbügelklemmen nach VBG 4 (PZ1 erforderlich),
Schutzart IP20
Anzugsdrehmoment: max. 1Nm
Klemmanschluss:
1 x 0.5 bis 2.5mm² mit/ohne Aderendhülse
1 x 4mm² ohne Aderendhülse
2 x 0.5 bis 1.5mm² mit/ohne Aderendhülsen
2 x 2.5mm² flexibel ohne Aderendhülsen
5. Versorgungskreis
Versorgungsspannung: Klemmen L - N
Nennspannung:
Type RTZ 2: 230V AC
Type RTZ F: 230V AC
Toleranz: -15% bis +10%
Nennverbrauch: 2VA (1,0W)
Nennfrequenz: AC 48 bis 63Hz
Einschaltdauer: 100%
Wiederbereitschaftzeit: 500ms
Überbrückungszeit: -
Restwelligkeit bei DC: -
Abfallspannung: >30%
Überspannungskategorie: III (entspricht IEC 60664-1)
Bemessungsstoßspannung: 4kV
6. Ausgang
1 Schließer Klemmen L - 18
Bemessungsspannung: 250V AC
Schaltleistung Gerät angereiht (Abstand <5mm):
10A Dauerstrom
Schaltleistung Gerät nicht angereiht (Abstand >5mm):
16A Dauerstrom
Einschaltspitzenstrom: 80A
Mechanische Lebensdauer: 30 x 106Schaltspiele
Elektrische Lebensdauer:
Ohmsche Last: 105Schaltspiele bei 16A 250V
Glühlampenlast: 80.000 Schaltspiele bei 1000W 250V
7. Steuereingang B1
Anschluss potentialbehaftet: Taster B1-N (3-Leiter Schaltung)
Taster B1-L (4-Leiter Schaltung)
Glühlampenlast: max. 100mA parallel zu den Tastern
Überlastschutz: ja, elektronisch
8. Zusätzlicher Steuereingang (nur RTZ F)
Anschluss: Steuerspannung an Klemmen C1(+)-C2
Ansteuerspannung: 8...230V AC/DC
Galvanische Trennung: ja, Basisisolierung
Überspannungskategorie: III. (entspricht IEC 60664-1)
Bemessungsstoßspannung: 4kV
9. Genauigkeit
Grundgenauigkeit: ±5% vom Skalenendwert
Einstellgenauigkeit: <15% vom Skalenendwert
Wiederholgenauigkeit: ≤2%
Spannungseinfluss: -
Temperatureinfluss: ≤1%
10. Umgebungsbedingungen
Umgebungstemperatur: -25 bis +55°C (entspricht IEC 68-1)
Lagertemperatur: -25 bis +70°C
Transporttemperatur: -25 bis +70°C
Relative Luftfeuchtigkeit: 15% bis 85%
(entspricht IEC 721-3-3 Klasse 3K3)
Verschmutzungsgrad: 2, im eingebauten Zustand 3
(entspricht IEC 664-1)
Vibrationsfestigkeit: 10 bis 55 Hz 0.35mm
(entspricht IEC 68-2-6)
Stoßfestigkeit: 15g 11ms
(entspricht IEC 68-2-27)
11. Gewicht
Einzelverpackung: 106g
RTZ 2, RTZ F

Subject to alterations and errors
Release 07/07
Staircase lighting timer
Staircase lighting timer electronic
Switch-off warning
Retrigger, time extension function programmable
Energy saving function
Impulse switch mode selectable
Low switching noise
High switching capacity, 80A peak inrush current
Automatic 3/4 - wire detection
Push-button glow lamp load up to 100mA
Width 17.5 mm
Installation design
Technical data
1. Functions
Electronic staircase lighting timer with switch-off warning.
The control input allows the connection of pushbuttons with total glow lamp
load up to 100mA and enables the application in 3- or 4-wire circuits.
The unit can be retriggered via the connected pushbuttons.
A long keypress will switch off the light (energy saving function).
A fast sequence of pushes (pumping) will extend the period to a multiple of
the selected value. Depending upon distinct type, the following operating
methods can be selected by the controls on the unit:
TW Automatic timer with switch-off warning
T Automatic timer without switch-off warning
1 Steady light (ON)
0 Switch-off
P Impulse switch mode without time function (only types with option P)
PN Impulse switch mode power fail latch (only types with option PN)
2. Time range
Adjustment range
Time: 0,5 - 12min (in function T, TW)
3. Indicators
Green LED U ON: indication of supply voltage
Yellow LED ON/OFF: indication of relay output
4. Mechanical design
Self-extinguishing plastic housing, IP rating IP40
Mounted on DIN-rail TS 35 according to EN 50022
Mounting position: any
Shockproof terminal connection accordting to VBG 4 (PZ1 required),
IP rating IP20
Tightening torque: max. 1Nm
Terminal capacity:
1 x 0.5 to 2.5mm² with/without multicore cable end
1 x 4mm² without multicore cable end
2 x 0.5 to 1.5mm² with/without multicore cable end
2 x 2.5mm² flexible without multicore cable end
5. Input circuit
Supply voltage: terminals L - N
Nominal voltage:
Type RTZ 2: 230V AC
Type RTZ F: 230V AC
Tolerance: -15% to +10%
Rated consumption: 2VA (1,0W)
Rated frequency: AC 48 to 63Hz
Duty cycle: 100%
Reset time: 500ms
Hold-up time: -
Residual ripple for DC: -
Drop out voltage: >30%
Overvoltage category: III (according to IEC 60664-1)
Rated surge voltage: 4kV
6. Output
1 normally open contact terminals L - 18
Rated voltage: 250V AC
Switching capacity (distance <5mm):
10A continuous current
Switching capacity (distance >5mm):
16A continuous current
Start-up peak (20ms): 80A
Mechanical life: 30 x 106operations
Electrical life:
Resistive load: 105operations at 16A 250V
Lamp load: 80.000 operations at 1000W 250V
7. Control input B1
Connection not potential free: pushbutton B1-N (3-conductor circuit)
pushbutton B1-L (4-conductor circuit)
Glow lamp load: max. 100mA parallel to each pushbuttons
Overload prodection: yes, electronic
8. Additional control input (only RTZ F)
Connection: control voltage on terminals C1(+)-C2
Voltage range: 8...230V AC/DC
Galvanic isolation: yes, basic isolation
Overvoltage category: III. (according to IEC 60664-1)
Rated surge voltage: 4kV
9. Accuracy
Base accuracy: ±5% of maximum scale value
Adjustment accuracy: <15% of maximum scale value
Repedition accuracy: ≤2%
Voltage influence: -
Temperature influence: ≤1%
10. Ambient conditions
Ambient temperature: -25 to +55°C (according to IEC 68-1)
Storage temperature: -25 to +70°C
Transport temperature: -25 to +70°C
Relative humidity: 15% to 85%
(according to IEC 721-3-3 class 3K3)
Pollution degree: 2, if built in 3
(according to IEC 664-1)
Vibration resistance: 10 to 55 Hz 0.35mm
(according to IEC 68-2-6)
Shock resistance: 15g 11ms
(according to IEC 68-2-27)
11. Weight
Single packing: 106g
RTZ 2, RTZ F

Subject to alterations and errors
Functions
RTZ 2, RTZ F
C1 C2
L
B1 N
L
N
8-230V
AC/DC
+-
18
18 L
B1 N
17,5mm
44mm
60mm
87mm
45mm
5mm
Switch-ON
Retrigger
Time extension function (pumping)
Switch-OFF
Operating possibilities at B1 in mode T and TW:
Function automatic timer (T, TW)
After the pushbutton at B1 has been pressed, the output relay R
closes (terminals L-18) and the set interval t begins. If the pushbutton
is pressed again before the interval t has expired, the interval
begins again (restart function complies with EN 60669-2-3). Rapid,
multiple pressing of the pushbutton (pumping) adds 2, 3 or more
time intervals to extend the time up to 60min. Prolonged pressure on
the button (>2s) aborts the interval running and switches the relay
off (energy saving function). In the TW mode the device provides a
switch-off warning (in accordance with DIN 180-158-2) by generating
short pulses (flashing) at 30s, 15s and 5s prior to switch-off. The additional control input C1-C2 can be used in the T and TW modes to
control the staircase lighting timer with a voltage of 8 to 230V AC/DC. This
input can be used to start and restart the cycle. It cannot be used for switch-
off (energy saving function) or for programming long intervals (pumping).
Impulse switch mode (P), (PN):
In this mode, every keypress toggles the output relay R (flip-flop). In
function P, the output relay R remains in off-position, whenever the
supply voltage is applied.
In function PN, the output relay R switches into on-position after
applying the supply voltage U, if the output relay R was in on-position
last before power failure.
The output relay R switches into on-position, if a short voltage impulse
(<2s) is applied to the additional control input (C1-C2). (central ON)
A longer voltage impulse (>2s) opens the output relay R. (central OFF)
Connections
B1
t
R2t 3t
<2
s
>2
s
<2
s
>2
s
t
15s 10s 5s
TW T
U
C1-C2
B1
R
P
<2s >2
s
>2
s
>2
s
<2
s
U
C1-C2
B1
R
PN
<2s >2
s
>2
s
>2
s
<2
s
Mode
Mode
C1 C2
L
B1 N
L
N
8-230V
AC/DC
+-
18
18 L
B1 N
3-wire-circuit
4-wire-circuit with attic illumination
Dimensions

Änderungen und Irrtümer vorbehaltenÄnderungen und Irrtümer vorbehalten
Funktionsbeschreibung
RTZ 2, RTZ F
C1 C2
L
B1 N
L
N
8-230V
AC/DC
+-
18
18 L
B1 N
17,5mm
44mm
60mm
87mm
45mm
5mm
Einschalten
Nachschalten
Langzeitfunktion (pumpen)
Abschalten
Bedienmöglichkeiten an B1 bei Zeitautomatik:
Funktion Zeitautomatik (T, TW)
Nach Drücken des Tasters B1 schließt das Ausgangsrelais R
(Klemmen L-18) und die eingestellte Zeit t beginnt zu laufen. Wird
der Taster noch vor Ablauf der Zeit t erneut gedrückt, beginnt die Zeit
wieder neu zu laufen (Nachschaltfunktion entspricht EN 60669-2-3).
Schnelles, mehrfaches Drücken des Tasters (pumpen) führt zu einer
Aufsummierung von 2, 3 oder mehreren Zeitintervallen bis zu 60min.
Ein langer Tastendruck (>2s) bricht die laufende Zeit ab, und das
Relais schaltet aus (Energiesparfunktion). In der Funktion TW erzeugt
das Gerät zur Abschalt-Vorwarnung (entsprechend DIN 180-15-2)
kurze Impulse (flackern) in den Zeitpunkten 30s, 15s und 5s vor der
Abschaltung.
Der zusätzliche Steuereingang C1-C2 ermöglicht im Modus T und TW
die Ansteuerung des Treppenlichtautomaten durch eine Spannung
von 8 bis 230V AC/DC. Über diesen Eingang lässt sich der Zeitablauf
starten und nachschalten. Das Abschalten (Energiesparfunktion) und
die Programmierung längerer Zeiten (pumpen) ist über diesen Eingang
nicht möglich.
Stromstoßmodus (P), (PN):
Im Stromstoßmodus führt jede Tastenbetätigung an B1 zum
Umschalten des Ausgangsrelais T. In der Funktion P ist das
Ausgangsrelais R nach Anlegen der Versorgungsspannung immer
abgefallen. In der Funktion PN zieht das Relais R nach Anlegen der
Versorgungsspannung sofort an, falls es vor dem Spannungsausfall
angezogen war.
Durch Anlegen eines kurzen Spannungsimpulses (<2s) an den
zusätzlichen Steuereingang C1-C2 wird das Relais R eingeschaltet
(zentral EIN).
Ein längerer Spannungsimpuls (>2s) bewirkt die Abschaltung des
Relais R (zentral AUS).
Anschlussbilder
B1
t
R
2t 3t
<2
s
>2
s
<2
s
>2
s
t
15s 10s 5s
TW T
U
C1-C2
B1
R
P
<2s >2
s
>2
s
>2
s
<2
s
U
C1-C2
B1
R
PN
<2s >2
s
>2
s
>2
s
<2
s
Mode
Mode
C1 C2
L
B1 N
L
N
8-230V
AC/DC
+-
18
18 L
B1 N
3-Leiter-Schaltung
4-Leiter-Schaltung mit Dachbodenbeleuchtung Abmessungen
This manual suits for next models
3
Table of contents
Languages:
Popular Lighting Equipment manuals by other brands

GENI
GENI MOVING HEAD OBY-5 user manual

American Lighting
American Lighting CL-CSA Series installation instructions

PureEdge Lighting
PureEdge Lighting ZSD-2S Series installation instructions

Philips
Philips 910503700745 installation instructions

Luminaire led
Luminaire led LVP1212 LED Series installation guide

lumen8
lumen8 Liberty 7HEX12 user manual

MARELD
MARELD PERFORMANCE Series instruction manual

Emos
Emos LED600 Ultra installation instructions

LaMotte
LaMotte WaterLink SpinTouch 3580 quick start guide

LITESHEET
LITESHEET BriteCor AC BWB installation manual

OSF
OSF POOLcontrol-40.net Installation and operating instructions

Safavieh
Safavieh TBL4292A quick start guide
