IS‐MD1R
Instructions for Installation andOperation
MiniDownlight
2/28/2022 1
⚠WARNINGS
• Read all instructions before starting to install fixtures.
• Retain these instructions for future reference.
• This product is for installation indoors only.
• DANGER - RISK OF FIRE, INJURY AND DEATH. This fixture must be installed in
accordance with local electrical codes and ordinances. All work must be done by a qualified
electrician.
• DANGER – RISK OF FIRE, INJURY AND DEATH. Make certain power is OFF from the
electrical panel before starting installation or attempting any maintenance.
• DANGER RISK OF FIRE INJURY AND DEATH. Do not damage insulation on wires. Do not
expose wires to sharp edges or objects.
• Secure and protect incoming supply wire and any control wire with a suitable cable restraint
(supplied by installer).
• Only supply voltage as labeled on the product.
• Fixture must be properly grounded.
• Do not install if any part appears to be damaged.
• This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause undesired
operation.
• Note: This equipment has been tested and found to comply with the limits for a Class B
digital device , pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed and
used in accordance with instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation . If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user
in encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and the receiver.
• Connect the equipment into an outlet on a circuit different for that to which the receiver is
connected.
• Consult the dealer or an experienced radio/TV technician for help.
• Conforme.CAN ICES-005 (B) / NMB-005 (B)

Classified
page2/28/2022 2
MiniDownlight
IS‐MD1R
www.lightolier.com
STEP2
STEP1
Confirmthatthereisnoelectricalpoweronthecircuitwheretheluminairewillbe
connected.
UsetheInstallationtemplateprovidedtomaketheholeintheceiling,ifneededyou
canusethedimensionsprovidedbelowfordifferentsizeluminaires:
3‐inchround.Ø3”(78mm)
4‐inchround Ø4‐1/4”(108mm)
4‐inchsquareØ4‐1/4”(108mm)
6‐inchround Ø6‐1/4”(158mm)
6‐inchsquareØ6‐1/4”(158mm)
8‐inchroundØ8‐1/4”(210mm)
installation

Classified
page2/28/2022 3
MiniDownlight
IS‐MD1R
www.lightolier.com
STEP4
STEP3
Openthespliceboxcoverandonlyremovetheknockoutneeded.Incomingwires
mustbesecuredwithanappropriaterestraint(providedbyinstaller).
Securethespliceboxtothebuildingstructureinaccordancewithapplicablecodes.
WARNING– AttachtheDriver/SpliceBoxtoasecurestructuralpartofthebuilding
perapplicablecodes.Use optional10footlongextensioncord(soldseparately)if
additionalcordlengthisneeded.Onlyoneextensioncordmaybeusedwitheach
luminaire.

Classified
page2/28/2022 4
MiniDownlight
IS‐MD1R
DriverWiring STEP5
WITHTHEPOWEROFF,makeelectricalconnectionsasshowninFig1below.
Note:SelectandadjustLumenandColorsettings(whereprovided)BEFOREinstallingthe
luminaireintotheceiling.
STEP6
Carefullyplaceallwiringintothespliceboxandclosethecover.
WARNINGRiskofFire‐ Becarefulnottocrushorcutwireswhenclosingthe
spliceboxcover.
WARNINGRISKOFFIRE,INJURYANDDEATH.Usewirenutsprovidedwhich
arethermallyratedforuseinaluminairesplicecompartment.Boxmustbe
grounded.
www.lightolier.com

Classified
page2/28/2022 5
MiniDownlight
IS‐MD1R
STEP8
Placethe cord from the Driver/Splice boxthrough the opening inthe ceiling and
connect ittothecordfromthefixturebyinsertingconnectors(1&2)andthen
securingthemtogetherusingthethreadedcollar.
*Note:SelectLumenandColorsettings(whereprovided)BEFOREinstallingtheluminaire
intotheceiling.
STEP7
Selectdesiredthecolortemperatureandlumenoutputwiththe
switches(seeimagebelow)BEFOREinstallingintheceiling.
www.lightolier.com

Classified
page2/28/2022 6
MiniDownlight
IS‐MD1R
www.lightolier.com
STEP9
Holdtheluminairetoinsertonespringthroughtheceilingholeandthenbendthe
otherspringupwardtoinsertitthroughthehole.
*Note:Usesuppliedgasketwhen
neededforairseal.
WARNINGRiskofFire ‐ Becarefulnottocrushorcutcordwhenroutingcordfrom
drivertoluminaire
