DogWatch R9 User manual

Operating Instructions
R9/R9V and R7mini Receivers
R9 Receiver
R9 Vibration Receiver (R9V)
R7mini Receiver

The components of both the R9 and R9V (above) and the R7m are the same except
the R7m is smaller and uses a different battery.
Receiver Battery
Th e R7m, R9 and R9V all use a replaceable battery. Th e receivers are
waterproof when the battery cap is fully seated.
R9 and R9V Battery: The R9 and R9V receivers use a 3.6 volt lithium battery.
With normal use, battery life should be about two years for the R9 and
between one and two years for the R9V. The positive (+) end of the battery
must be inserted down.
R7m Battery: The R7m receiver is powered by a 3 volt (1/3 N) lithium battery.
With normal use, the battery should last about six months. The negative (-) end
of the battery must be inserted down.
R7m, R9 and R9
VReceiver
Insert battery NEGATIVE end down.
Resetting the Battery Status Light
1. Remove the old battery.
2. Let the receiver sit for five minutes before inserting a new battery.
If you forget to wait prior to inserting a new battery, the flashing red battery
status light will continue to flash for 24 hours before automatically resetting.
3. Insert a new battery.
Receiver Features
Status Light
■Start-Up When you first insert the battery into your receiver, the status light will flash
red and green. This indicates that the receiver has started properly. Once started, the
status light will continue to flash green once every 40 seconds indicating normal
operation. In the event that the light does not flash, check the battery to be sure that it
has been inserted properly.
■Training Level Indicator When programming the training level of your receiver, the
status light will flash green in conjunction with audible beeps (or vibrations if you have a
vibration receiver). The number of flashes will equal the training level you have chosen.
■Signal Field Indicator When testing the receiver in the signal field the status light will
flash green when the receiver is in the warning zone and will flash green and red when
the receiver is in the correction zone.
■Correction Alert (TattleTale™) You will be able to tell if your pet has entered the
correction area by looking at the status light. The status light will double flash green
every 40 seconds for 24-hours after the dog enters the boundary area.
■Battery Indicator This feature monitors the voltage level of the battery. When the
receiver detects that the battery has reached a low voltage level, the status light will
change from the normal blinking “green” every 30 seconds to blinking “red” every 10
seconds. This indicates that your battery is close to the end of its useful life and you
should change the battery within the next 3-4 days
AutoMemory™ When the receiver is set to Level 4, 5, or 6, our AutoMemory feature
automatically adjusts the correction level of the receiver if your pet enters the avoidance
zone. If the dog does not enter the signal field again in the next 24-hour period, the
receiver defaults to the original setting.
SETTING THE RECEIVER
Receiver Training Levels Your receiver provides eight training levels that allow you to
customize the training setting to your dog’s individual needs: Audible (or Vibration) Only,
Level 1 (extra low), Level 2 (low), Level 3 (low medium), Level 4 (medium), Level 5 (medium
high), Level 6 (high), and Level 7 (extra high).
When the receiver is shipped from the
manufacturer, it is set to Training Level 2 (low).
Changing the Receiver Settings If you need to change the Training Level on the receiver,
hold your test light magnet to the marked area on the side of the receiver. Hold the magnet
steady and you will hear a series of beeps that indicate the current training level. The
“Audible (or Vibration) Only” level is one long beep, Level 1 is one short beep, Level 2 is
two short beeps, Level 3 is three short beeps, etc. Vibration receivers will vibrate instead
of beep. The Training Level will continue to advance while the magnet is held in position.
When you reach the desired setting, pull the magnet away from the receiver. The receiver
is now set.
Magnet
Battery Cap Tool
Contact Post Wrench
Test Light
Adjustable
Collar Contact
Posts
Metal Lock Washer
Collar Bone
Training Level Adjustment Location
Status Light
3.6 Volt Battery (R9/R9
V )
Battery Cap
GentleFit
™
Contact Posts
(optional)
Insert R9/R9Vbattery POSITIVE end down.
Insert R7 battery NEGATIVE end down.
Using the magnet to set the
training level on the R7 Receiver
Using the magnet to set the
training level on the R9/R9VReceiver
The components of both the R9 and R9V (above) and the R7m are the same except
the R7m is smaller and uses a different battery.
Receiver Battery
Th e R7m, R9 and R9V all use a replaceable battery. Th e receivers are
waterproof when the battery cap is fully seated.
R9 and R9V Battery: The R9 and R9V receivers use a 3.6 volt lithium battery.
With normal use, battery life should be about two years for the R9 and
between one and two years for the R9V. The positive (+) end of the battery
must be inserted down.
R7m Battery: The R7m receiver is powered by a 3 volt (1/3 N) lithium battery.
With normal use, the battery should last about six months. The negative (-) end
of the battery must be inserted down.
R7m, R9 and R9VReceiver
Insert battery NEGATIVE end down.
Resetting the Battery Status Light
1. Remove the old battery.
2. Let the receiver sit for five minutes before inserting a new battery.
If you forget to wait prior to inserting a new battery, the flashing red battery
status light will continue to flash for 24 hours before automatically resetting.
3. Insert a new battery.
Receiver Features
Status Light
■Start-Up When you first insert the battery into your receiver, the status light will flash
red and green. This indicates that the receiver has started properly. Once started, the
status light will continue to flash green once every 40 seconds indicating normal
operation. In the event that the light does not flash, check the battery to be sure that it
has been inserted properly.
■Training Level Indicator When programming the training level of your receiver, the
status light will flash green in conjunction with audible beeps (or vibrations if you have a
vibration receiver). The number of flashes will equal the training level you have chosen.
■Signal Field Indicator When testing the receiver in the signal field the status light will
flash green when the receiver is in the warning zone and will flash green and red when
the receiver is in the correction zone.
■Correction Alert (TattleTale™) You will be able to tell if your pet has entered the
correction area by looking at the status light. The status light will double flash green
every 40 seconds for 24-hours after the dog enters the boundary area.
■Battery Indicator This feature monitors the voltage level of the battery. When the
receiver detects that the battery has reached a low voltage level, the status light will
change from the normal blinking “green” every 30 seconds to blinking “red” every 10
seconds. This indicates that your battery is close to the end of its useful life and you
should change the battery within the next 3-4 days
AutoMemory™ When the receiver is set to Level 4, 5, or 6, our AutoMemory feature
automatically adjusts the correction level of the receiver if your pet enters the avoidance
zone. If the dog does not enter the signal field again in the next 24-hour period, the
receiver defaults to the original setting.
SETTING THE RECEIVER
Receiver Training Levels Your receiver provides eight training levels that allow you to
customize the training setting to your dog’s individual needs: Audible (or Vibration) Only,
Level 1 (extra low), Level 2 (low), Level 3 (low medium), Level 4 (medium), Level 5 (medium
high), Level 6 (high), and Level 7 (extra high).
When the receiver is shipped from the
manufacturer, it is set to Training Level 2 (low).
Changing the Receiver Settings If you need to change the Training Level on the receiver,
hold your test light magnet to the marked area on the side of the receiver. Hold the magnet
steady and you will hear a series of beeps that indicate the current training level. The
“Audible (or Vibration) Only” level is one long beep, Level 1 is one short beep, Level 2 is
two short beeps, Level 3 is three short beeps, etc. Vibration receivers will vibrate instead
of beep. The Training Level will continue to advance while the magnet is held in position.
When you reach the desired setting, pull the magnet away from the receiver. The receiver
is now set.
Magnet
Battery Cap Tool
Contact Post Wrench
Test Light
Adjustable
Collar Contact
Posts
Metal Lock Washer
Collar Bone
Training Level Adjustment Location
Status Light
3.6 Volt Battery (R9/R9
V )
Battery Cap
GentleFit
™
Contact Posts
(optional)
Insert R9/R9Vbattery POSITIVE end down.
Insert R7 battery NEGATIVE end down.
Using the magnet to set the
training level on the R7 Receiver
Using the magnet to set the
training level on the R9/R9VReceiver
The components of both the R9 and R9V (above) and the R7m are
the same except the R7m is smaller and uses a different battery.
Receiver Battery
The R7m, R9 and R9V all use a replaceable battery. The receivers are
waterproof when the battery cap is fully seated.
R9 and R9V Battery: The R9 and R9V receivers use a 3.6 volt lithium battery.
With normal use, battery life should be about two years for the R9 and
between one and two years for the R9V. The positive (+) end of the battery
must be inserted down.
R7m Battery: The R7m receiver is powered by a 3 volt (1/3 N) lithium battery.
With normal use, the battery should last about six months. The negative (-) end
of the battery must be inserted down.
Resetting the Battery Status Light
1. Remove the old battery.
2. Let the receiver sit for five minutes before inserting a new battery. If you forget to
wait prior to inserting a new battery, the flashing red battery status light will continue
to flash for 24 hours before automatically resetting.
3. Insert a new battery.
R7m, R9 and R9V Receiver

Setting the Receiver
Receiver Training Levels Your receiver provides eight training levels that allow you to
customize the training setting to your dog’s individual needs: Audible (or Vibration)
Only, Level 1 (extra low), Level 2 (low), Level 3 (low medium), Level 4 (medium), Level
5 (medium high), Level 6 (high), and Level 7 (extra high). When the receiver is shipped
from the manufacturer, it is set to Training Level 2 (low).
Changing the Receiver Settings If you need to change the Training Level on the
receiver, hold your test light magnet to the marked area on the side of the receiver.
Hold the magnet steady and you will hear a series of beeps that indicate the current
training level. The “Audible (or Vibration) Only” level is one long beep, Level 1 is one
short beep, Level 2 is two short beeps, Level 3 is three short beeps, etc. Vibration
receivers will vibrate. The Training Level will continue to advance while the magnet is
held in position. When you reach the desired setting, pull the magnet away from the
receiver. The receiver is now set.
Receiver Features
Status Lights
• Start-Up When you first insert the battery into your receiver, the status light will
flash red and green. This indicates that the receiver has started properly. Once
started, the status light will continue to flash green once every 40 seconds
indicating normal operation. In the event that the light does not flash, check the
battery to be sure that it has been inserted properly.
• Training Level Indicator When programming the training level of your receiver, the
status light will flash green in conjunction with audible beeps (or vibrations if you
have a vibration receiver). The number of flashes will equal the training level you
have chosen.
• Signal Field Indicator When testing the receiver in the signal field the status light
will flash green when the receiver is in the warning zone and will flash green and
red when the receiver is in the correction zone.
• Correction Alert (TattleTale™) You will be able to tell if your pet has entered the
correction area by looking at the status light. The status light will double flash
green every 40 seconds for 24-hours after the dog enters the boundary area.
• Battery Indicator This feature monitors the voltage level of the battery. When the
receiver detects that the battery has reached a low voltage level, the status light
will change from the normal blinking “green” every 40 seconds to blinking “red”
every 10 seconds. This indicates that your battery is close to the end of its useful
life and you should change the battery within the next 3-4 days.
AutoMemory™ When the receiver is set to Level 4, 5, or 6, our AutoMemory feature
automatically raises the correction level of the receiver if your pet enters the avoidance
zone. If the dog does not enter the signal field again in the next 24-hour period, the
receiver defaults to the original setting.
The components of both the R9 and R9V (above) and the R7m are the same except
the R7m is smaller and uses a different battery.
Receiver Battery
Th e R7m, R9 and R9V all use a replaceable battery. Th e receivers are
waterproof when the battery cap is fully seated.
R9 and R9V Battery: The R9 and R9V receivers use a 3.6 volt lithium battery.
With normal use, battery life should be about two years for the R9 and
between one and two years for the R9V. The positive (+) end of the battery
must be inserted down.
R7m Battery: The R7m receiver is powered by a 3 volt (1/3 N) lithium battery.
With normal use, the battery should last about six months. The negative (-) end
of the battery must be inserted down.
R7m, R9 and R9VReceiver
Insert battery NEGATIVE end down.
Resetting the Battery Status Light
1. Remove the old battery.
2. Let the receiver sit for five minutes before inserting a new battery.
If you forget to wait prior to inserting a new battery, the flashing red battery
status light will continue to flash for 24 hours before automatically resetting.
3. Insert a new battery.
Receiver Features
Status Light
■Start-Up When you first insert the battery into your receiver, the status light will flash
red and green. This indicates that the receiver has started properly. Once started, the
status light will continue to flash green once every 40 seconds indicating normal
operation. In the event that the light does not flash, check the battery to be sure that it
has been inserted properly.
■Training Level Indicator When programming the training level of your receiver, the
status light will flash green in conjunction with audible beeps (or vibrations if you have a
vibration receiver). The number of flashes will equal the training level you have chosen.
■Signal Field Indicator When testing the receiver in the signal field the status light will
flash green when the receiver is in the warning zone and will flash green and red when
the receiver is in the correction zone.
■Correction Alert (TattleTale™) You will be able to tell if your pet has entered the
correction area by looking at the status light. The status light will double flash green
every 40 seconds for 24-hours after the dog enters the boundary area.
■Battery Indicator This feature monitors the voltage level of the battery. When the
receiver detects that the battery has reached a low voltage level, the status light will
change from the normal blinking “green” every 30 seconds to blinking “red” every 10
seconds. This indicates that your battery is close to the end of its useful life and you
should change the battery within the next 3-4 days
AutoMemory™ When the receiver is set to Level 4, 5, or 6, our AutoMemory feature
automatically adjusts the correction level of the receiver if your pet enters the avoidance
zone. If the dog does not enter the signal field again in the next 24-hour period, the
receiver defaults to the original setting.
SETTING THE RECEIVER
Receiver Training Levels Your receiver provides eight training levels that allow you to
customize the training setting to your dog’s individual needs: Audible (or Vibration) Only,
Level 1 (extra low), Level 2 (low), Level 3 (low medium), Level 4 (medium), Level 5 (medium
high), Level 6 (high), and Level 7 (extra high).
When the receiver is shipped from the
manufacturer, it is set to Training Level 2 (low).
Changing the Receiver Settings If you need to change the Training Level on the receiver,
hold your test light magnet to the marked area on the side of the receiver. Hold the magnet
steady and you will hear a series of beeps that indicate the current training level. The
“Audible (or Vibration) Only” level is one long beep, Level 1 is one short beep, Level 2 is
two short beeps, Level 3 is three short beeps, etc. Vibration receivers will vibrate instead
of beep. The Training Level will continue to advance while the magnet is held in position.
When you reach the desired setting, pull the magnet away from the receiver. The receiver
is now set.
Magnet
Battery Cap Tool
Contact Post Wrench
Test Light
Adjustable
Collar Contact
Posts
Metal Lock Washer
Collar Bone
Training Level Adjustment Location
Status Light
3.6 Volt Battery (R9/R9
V )
Battery Cap
GentleFit
™
Contact Posts
(optional)
Insert R9/R9Vbattery POSITIVE end down.
Insert R7 battery NEGATIVE end down.
Using the magnet to set the
training level on the R7 Receiver
Using the magnet to set the
training level on the R9/R9VReceiver

10 Michigan Drive - Natick MA 01760 - 800-793-3436 - www.dogwatch.com
©2017 DogWatch Inc. All rights reserved. 295050 Rev. F.3 07-17
Note: Any time the magnet activates the receiver, the number of beeps (or vibrations)
will indicate the current receiver level. As long as the magnet is held in place, it will
advance the receiver to the next training level and continue to cycle through the
settings in the order shown on the chart below.
PROGRAMMABLE FEATURES
Using the RATE and TRAINING MODE settings on your DogWatch transmitter in
conjunction with the TRAINING LEVELS on your receiver, you can customize the receiver
to one of 20 training settings, as outlined in the chart below.
For example: If the receiver is on Level 1 and the transmitter is on Rate 1, your dog will receive
the lowest level of correction and the least number of pulses per second.
Please remember that if your Receiver Level is set to 1, 2 or 3 and you switch the Training
Mode to QuickAlert (Mode B), the Rate (pulses per second) may change. For example, if the
receiver is set to Level 3 / Rate 1, your dog will receive a slow correction. If you switch your
Transmitter to QuickAlert, your dog will now receive a fast correction.
AutoMemory™
self activates
and advances
to the next level.
}
RECEIVER
TRAINING
LEVELS
TRANSMITTER MODE AND RATE SETTINGS
Mode A
Rate 1
Mode A
Rate 2
Mode A
Rate 3
Mode B
QuickAlert™
Audible Only* Transmitter Rate Fixed at Medium
(extra low) 1 Slow Medium Fast Slow
(low) 2 Slow Medium Fast Medium
(low medium) 3 Slow Medium Fast Fast
(medium) 4 Fast Fast
(medium high) 5 X - Fast X - Fast
(high) 6 XX - Fast XX - Fast
(extra high) 7 Audible and XXX Fast Correction are Simultaneous
TRANSMITTER SETTINGS
Rates There are three Transmitter Rate settings: (1 = slow, 2 = medium, 3 = fast).
Rate refers to the number of pulses per second. A slow rate means there are fewer
pulses per second. A fast rate means there are more pulses per second.
Training Modes The Training Mode switch allows you to choose between two training
options: Basic (Mode A) and QuickAlert™(Mode B).
• In Mode A, there is an audible beep (or a vibration) before a correction.
• For harder to train dogs, Mode B delivers a very quick “alert” correction before the
normal audible (or vibration) warning and correction.
*** IMPORTANT ***
Never change the receiver Training Levels when your dog is wearing the collar.
