evertz 7707CVR-8 Series User manual

7700 MultiFrame Manual
7707CVR-8 Eight Analog Video Fiber Receiver
Revision 1.0
TABLE OF CONTENTS
1. OVERVIEW.......................................................................................................................................... 1
2. INSTALLATION................................................................................................................................... 3
2.1. CARE AND HANDLING OF OPTICAL FIBER............................................................................ 4
3. SPECIFICATIONS............................................................................................................................... 5
3.1. OPTICAL INPUT......................................................................................................................... 5
3.2. ANALOG VIDEO OUTPUTS ............................................................................................................. 5
3.3. ELECTRICAL................................................................................................................................. 5
3.4. COMPLIANCE................................................................................................................................5
3.5. PHYSICAL (NUMBER OF SLOTS)..................................................................................................... 6
3.6. ORDERING INFORMATION.............................................................................................................. 6
4. STATUS INDICATORS AND DISPLAYS ........................................................................................... 7
4.1. STATUS INDICATOR LEDS....................................................................................................... 7
4.2. DOT-MATRIX DISPLAY............................................................................................................. 8
4.2.1. Display of Warning Status Indications............................................................................. 9
4.2.2. Displaying the Video Standard........................................................................................ 9
4.2.3. Displaying the Optical Power.......................................................................................... 9
4.2.4. Displaying the Firmware Version................................................................................... 10
4.2.5. Setting the Video Pre-emphasis.................................................................................... 10
4.2.6. Setting the Video Gain.................................................................................................. 10
4.2.7. Setting the DC Offset....................................................................................................11
4.2.8. Setting the Password for Channel Blocking and Selecting Channels to be Blocked.... 11
4.2.9. Setting the Orientation of the Text on the Card Edge Display....................................... 12
4.2.10. Resetting Factory Defaults............................................................................................ 12
5. JUMPERS.......................................................................................................................................... 13
5.1. SELECTING WHETHER LOCAL FAULTS WILL BE MONITORED
BY THE GLOBAL FRAME STATUS ........................................................................................ 13
5.2. CONFIGURING THE MODULE FOR FIRMWARE UPGRADES.............................................. 13
6. VISTALINK®REMOTE MONITORING/CONTROL........................................................................... 14

7700 MultiFrame Manual
7707CVR-8 Eight Analog Video Fiber Receiver
Revision 1.0
6.1. WHAT IS VISTALINK®?............................................................................................................... 14
6.2. VISTALINK®MONITORED PARAMETERS .............................................................................. 15
6.3. VISTALINK®CONTROLLED PARAMETERS............................................................................ 15
6.4. VISTALINK®TRAPS.................................................................................................................... 16
Figures
Figure 1-1: 7707CVR-8 Block Diagram ................................................................................................................2
Figure 2-1: 7707CVR-8 Rear Panels....................................................................................................................3
Figure 4-1: Card Edge Menu Structure.................................................................................................................8
Figure 5-1: Location of Jumpers and Card Edge Controls .................................................................................13
Tables
Table 6–1: VistaLINK®Monitored Parameters....................................................................................................15
Table 6–2: VistaLINK®Controlled Parameters ...................................................................................................15
Table 6–3: VistaLINK®Traps ..............................................................................................................................16

7700 MultiFrame Manual
7707CVR-8 Eight Analog Video Fiber Receiver
Revision 1.0
REVISION HISTORY
REVISION DESCRIPTION DATE
1.0 Initial Release Sept 09
Information contained in this manual is believed to be accurate and reliable. However, Evertz assumes no responsibility for the use thereof nor for
the rights of third parties, which may be effected in any way by the use thereof. Any representations in this document concerning performance of
Evertz products are for informational use only and are not warranties of future performance, either express or implied. The only warranty offered by
Evertz in relation to this product is the Evertz standard limited warranty, stated in the sales contract or order confirmation form.
Although every attempt has been made to accurately describe the features, installation and operation of this product in this manual, no warranty is
granted nor liability assumed in relation to any errors or omissions unless specifically undertaken in the Evertz sales contract or order confirmation.
Information contained in this manual is periodically updated and changes will be incorporated into subsequent editions. If you encounter an error,
please notify Evertz Customer Service department. Evertz reserves the right, without notice or liability, to make changes in equipment design or
specifications.

7700 MultiFrame Manual
7707CVR-8 Eight Analog Video Fiber Receiver
Revision 1.0
WARNING
Never look directly into an optical fiber. Non-reversible damage to the eye can
occur in a matter of milliseconds.
"
Do not hook up the 7707CVT-8 series DWDM cards and any 7707CVR-8 series
cards directly with a short fiber optic cable. The 7707CVT-8 series DWDM card
produces +7dBm of power, which will damage the receiver if connected
directly.
"
Do not hook up the 7707CVT-8 series cards that output more than -7dBm of
power and 7707CVR-8 series high sensitivity (-H versions) receiver cards
directly with a short fiber optic cable. The 7707CVT-8 series cards that
produce more than -7dBm of power will damage the receiver if connected
directly.

7700 MultiFrame Manual
7707CVR-8 Eight Analog Video Fiber Receiver
Revision 1.0 7707CVR-8 - 1
1. OVERVIEW
The 7707CVR-8 is a VistaLINK®-capable, composite analog video fiber receiver for broadcast quality
video signals. This single card module accepts a fiber optic input from the companion 7707CVT-8
composite analog video fiber transmitter, demultiplexes the signals, performs D to A conversion and
outputs NTSC or PAL analog video.
The 7707CVR-8 occupies two card slots and can be housed in a 1RU frame which will hold up to 3
modules, a 3RU frame which will hold up to 7 modules, a 350FR portable frame which holds up to 3
modules, or a standalone enclosure which will hold 1 module.
Features:
Single card fiber optic receiver for up to eight analog video signals
Supports both NTSC and PAL video signals
Broadcast quality analog video performance
Meets or exceeds EIA/TIA RS250-C short haul specifications for analog video transport
Adjustable gain, DC offset and pre-emphasis for up to 250m of Belden 1694A coaxial cable
Comprehensive signal and card status monitoring via four digit card edge display or remotely
through SNMP and VistaLINK®
VistaLINK®capability is available when modules are used with the 3RU 7800FR or 350FR portable
frame and a 7700FC VistaLINK®Frame Controller module in slot 1 of the frame
Fully hot-swappable from front of frame with no fiber disconnect/reconnect required
Supports single-mode and multi-mode fiber optic cable
Accepts any wavelength in the 1270nm to 1610nm range

7700 MultiFrame Manual
7707CVR-8 Eight Analog Video Fiber Receiver
7707CVR-8 - 2 Revision 1.0
Figure 1-1: 7707CVR-8 Block Diagram

7700 MultiFrame Manual
7707CVR-8 Eight Analog Video Fiber Receiver
Revision 1.0 7707CVR-8 - 3
2. INSTALLATION
The 7707CVR-8 comes with a companion rear plate that has eight BNC connectors and one SC/PC,
ST/PC or FC/PC optical connector. For more information on mounting the rear plate and inserting the
module into the frame see section 3 of the frame chapter.
Figure 2-1: 7707CVR-8 Rear Panels
FIBER INPUT: SC/PC, ST/PC or FC/PC female connector. This wide range input accepts optical
wavelengths of 1270nm to 1610nm for standard, CWDM or DWDM transmission schemes.
"
Do not hook up the 7707CVT-8 series DWDM cards and any 7707CVR-8 series cards
directly with a short fiber optic cable. The 7707CVT-8 series DWDM card produces
+7dBm of power, which will damage the receiver if connected directly.
"
Do not hook up the 7707CVT-8 series cards that output more than -7dBm of power
(see 7707CVT-8 series specifications for output power of various laser types) and
7707CVR-8 series high sensitivity (-H versions) receiver cards directly with a short
fiber optic cable. The 7707CVT-8 series cards that produce more than -7dBm of
power will damage the receiver if connected directly.

7700 MultiFrame Manual
7707CVR-8 Eight Analog Video Fiber Receiver
7707CVR-8 - 4 Revision 1.0
ANALOG VIDEO OUTPUTS
1 to 8: On the 7707CVR-8 series card module, there are eight composite analog video outputs. Each
output can have cable pre-emphasis applied independently.
2.1. CARE AND HANDLING OF OPTICAL FIBER
"
Never touch the end face of an optical fiber. Always keep dust caps on optical fiber
connectors when not connected and always remember to properly clean the optical end
face of a connector before making a connection.
The transmission characteristics of the fiber are dependent on the shape of the optical core and therefore
care must be taken to prevent fiber damage due to heavy objects or abrupt fiber bending. Evertz
recommends that you maintain a minimum bending radius of 5 cm to avoid fiber-bending loss that will
decrease the maximum attainable distance of the fiber cable. The Evertz fiber optic modules come with
cable lockout devices, to prevent the user from damaging the fiber by installing a module into a slot in the
frame that does not have a suitable I/O module. For further information on the care and handling of fiber
optic cable see section 3 of the Fiber Optics System Design chapter in the front of the binder.

7700 MultiFrame Manual
7707CVR-8 Eight Analog Video Fiber Receiver
Revision 1.0 7707CVR-8 - 5
3. SPECIFICATIONS
3.1. OPTICAL INPUT
Number of Inputs: 1
Connector: Female SC/PC, ST/PC, FC/PC
Operating Wavelength: 1270nm to 1610nm
Maximum Input Power:
Standard: 0dBm
High Sensitivity: -7dBm
Optical Sensitivity:
Standard: -23dBm
High Sensitivity: -28dBm
3.2. ANALOG VIDEO OUTPUTS
Standards: NTSC, SMPTE 170M, PAL, ITU-R624-4
Number of Outputs: 8
Connector: BNC per IEC 61169-8 Annex A
System bandwidth: 5.5MHz
Output Level: 1V p-p (nominal), 2V p-p maximum
Gain: Unity gain nominal, adjustable 50% to 150%
Output Impedance: 75Ω
Return Loss: > 20dB
SNR: > 70dB
Differential Gain: < 1.0%
Differential Phase: < 0.7°
Pre-Emphasis: Cable loss compensation for up to 250m of Belden 1694A (each output
adjustable separately)
Passband Ripple:
NTSC: < ±0.1dB to 4.1MHz and < ±0.2dB to 5.5MHz
PAL: < ±0.1dB to 4.8MHz and < ±0.2dB to 5.8MHz
Chroma/Luma Gain: 98% - 103%
Chroma/Luma Delay:
NTSC: <5ns
PAL: <12ns Line Time Distortion:1.2%
3.3. ELECTRICAL
Voltage: +12V DC
Power: 13W
3.4. COMPLIANCE
Laser Safety: Class 1 laser product
Complies with 24 CFR 1040.10 and 1040.11 IEC 60825-1
EMI/RFI: Complies with FCC Part 15, Class A EU EMC directive

7700 MultiFrame Manual
7707CVR-8 Eight Analog Video Fiber Receiver
7707CVR-8 - 6 Revision 1.0
3.5. PHYSICAL (NUMBER OF SLOTS)
350FR: 2
7700FR-C: 2
7800FR: 2
3.6. ORDERING INFORMATION
7707CVR-8 Eight Analog Video Fiber Receiver, VistaLINK®
7707CVR-8-H Eight Analog Video Fiber Receiver, High Sensitivity, VistaLINK®
Ordering Options: Rear Plate must be specified at time of order
Eg: Model + 3RU
Rear Plate Suffix:
+3RU 3RU Rear Plate for use with 350FR, 7700FR-C or 7800FR Multiframe
+1RU 1RU Rear Plate for use with 7701FR Multiframe
+SA Standalone Enclosure Rear Plate
Connector Suffix:
+SC SC/PC
+ST ST/PC
+FC FC/PC
Enclosures:
350FR 3RU Portable Multiframe which holds up to 3 dual slot modules
7700FR-C 3RU Multiframe which holds up to 7 dual slot modules
7800FR 3RU Multiframe which holds up to 7 dual slot modules
7701FR 1RU Multiframe which holds up to 3 single or dual slot modules
S7701FR Standalone Enclosure

7700 MultiFrame Manual
7707CVR-8 Eight Analog Video Fiber Receiver
Revision 1.0 7707CVR-8 - 7
4. STATUS INDICATORS AND DISPLAYS
The 7707CVR-8 has 11 LED Status indicators and a 4 digit alphanumeric display on the front card edge to
show operational status of the card at a glance. The card edge pushbutton and toggle switch are used to
select various displays on the alphanumeric display. Figure 5-1 shows the location of the LEDs and card
edge controls.
4.1. STATUS INDICATOR LEDS
Two large LEDs on the front of the board indicate the general health of the module:
LOCAL FAULT: This Red LED indicates poor module health and will be On during the absence of a
valid optical link to a 7707CVT-8 module, or if a local input power fault exists (i.e.: a
blown fuse). The LOCAL FAULT indication can also be reported to the frame
through the FRAME STATUS jumper.
MODULE OK: This Green LED indicates good module health. It will be On when a valid optical link
to a 7707CVT-8 module is present, and board power is good.
There are nine small LEDs on the back side of the board that indicate the presence of video and optical
link.
OPTICAL LINK: This Green LED indicates that an optical link is established.
This Red LED indicates that optical link errors are present.
VIDEO 1 PRESENT: This Green LED indicates the presence of a valid signal on the Video 1 input.
This Amber LED indicates that Video 1 output is blocked.
VIDEO 2 PRESENT: This Green LED indicates the presence of a valid signal on the Video 2 input.
This Amber LED indicates that Video 2 output is blocked.
VIDEO 3 PRESENT: This Green LED indicates the presence of a valid signal on the Video 3 input.
This Amber LED indicates that Video 3 output is blocked.
VIDEO 4 PRESENT: This Green LED indicates the presence of a valid signal on the Video 4 input.
This Amber LED indicates that Video 4 output is blocked.
VIDEO 5 PRESENT: This Green LED indicates the presence of a valid signal on the Video 5 input.
This Amber LED indicates that Video 5 output is blocked.
VIDEO 6 PRESENT: This Green LED indicates the presence of a valid signal on the Video 6 input.
This Amber LED indicates that Video 6 output is blocked.
VIDEO 7 PRESENT: This Green LED indicates the presence of a valid signal on the Video 7 input.
This Amber LED indicates that Video 7 output is blocked.
VIDEO 8 PRESENT: This Green LED indicates the presence of a valid signal on the Video 8 input.
This Amber LED indicates that Video 8 output is blocked.

7700 MultiFrame Manual
7707CVR-8 Eight Analog Video Fiber Receiver
7707CVR-8 - 8 Revision 1.0
4.2. DOT-MATRIX DISPLAY
Additional signal and status monitoring and control over the card’s parameters is provided via the 4-digit
alphanumeric display located on the card edge (see Figure 5-1). The card edge toggle switch is used to
select whether you are displaying status from the card (monitoring mode) or setting control parameters for
the card (control mode).
LINK...LOS (Link Loss)
Supersedes
OK (Ay-Okay)
BACK (Abort)
Pushbutton Ö
Menu Level 1 Menu Level 2 Menu Level 3
Indications
CTRL (Control)
Selections
STAT (Status)
VER (Software Version) Software Version
Indications
Selections
FRST(Factory Reset)
BACK (Abort)
DISP (Display Orientation) VERT (Vertical)
HORZ (Horizontal)
Selections
YES (Accept)
NO (Abort)
Menu Level 4
×
Toggle
Switch
Ø
Selections
VID (Video)
Selections
VID (Video)
Selections
0to 100 (%)
Selections
PSWD (Password)
Selections SelectionsSelections
0-9999
(Select / Enter Password)
BLOK (Block Channel)
EN (Enable Channel)
Selections
PAL
NTSC
LOS (Signal Loss)
BLOK (Channel Blocked)
Indications
Menu Level 5
PWR (Optical Power) -1 to -40 (Standard)
Indications
LOW (Low Power)
-7 to -30 (High Sensitivity -H)
OVER (Over Power)
95 to 150 (%)
Selections
-100 to +100 (mV)
Selections
Selections
DC (DC Offset)
EQ (Equalization)
GAIN (Gain)
VID1 (Video 1)
VID2 (Video 2)
VID3 (Video 3)
VID4 (Video 4)
VID1 (Video 1)
Selections
VID2 (Video 2)
VID3 (Video 3)
VID4 (Video 4)
Selections
VID5 (Video 5)
VID6 (Video 6)
VID7 (Video 7)
VID8 (Video 8)
VID5 (Video 5)
VID6 (Video 6)
VID7 (Video 7)
VID8 (Video 8)
VID1 (Video 1)
VID2 (Video 2)
VID3 (Video 3)
VID4 (Video 4)
VID5 (Video 5)
VID6 (Video 6)
VID7 (Video 7)
VID8 (Video 8)
VCH1 (Video 1)
VCH2 (Video 2)
VCH3 (Video 3)
VCH4 (Video 4)
VCH5 (Video 5)
VCH6 (Video 6)
VCH7 (Video 7)
VCH8 (Video 8)
VID1 (Video 1)
VID2 (Video 2)
VID3 (Video 3)
VID4 (Video 4)
VID5 (Video 5)
VID6 (Video 6)
VID7 (Video 7)
VID8 (Video 8)
Figure 4-1: Card Edge Menu Structure
If a specific menu selection has a configuration value associated with it, then this may be changed using
the toggle switch. Pressing the pushbutton will apply the displayed value and return you to the previous
menu level.

7700 MultiFrame Manual
7707CVR-8 Eight Analog Video Fiber Receiver
Revision 1.0 7707CVR-8 - 9
The most recent user selection will be maintained in non-volatile memory in the event of power
loss to the module.
4.2.1. Display of Warning Status Indications
The top level, default display indicates overall card status and warnings:
OK Card is functioning properly
LINK…LOSS No valid optical link established between the 7707CVT-8 and the 7707CVR-8
Flashing alternates between LINK and LOSS
Pressing the pushbutton from this default display will allow the user to select from STAT (status) and
CTRL (control) menu items.
4.2.2. Displaying the Video Standard
The 7707CVR-8 detects the video standard of the signals present at its inputs. To display the video
standard, select the STAT menu item in menu level 1, select VID from menu level 2, then use the toggle
switch to display the desired video channel (from VID1 to VID8) and press the pushbutton to select it.
For the sake of simplicity, only the VID1 menu item will be described in the manual.
STAT
VID
VID1
NTSC
PAL
LOS
BLOK
The video standard will be displayed from the list below:
NTSC displays that NTSC is present.
PAL displays that PAL is present.
LOS displays that there is a Loss of Signal.
BLOK displays that there is a Channel Block.
4.2.3. Displaying the Optical Power
The 7707CVR-8 module can measure and display the input optical power over a range of -1dBm to –
40dBm at increments of 1dBm for the standard version and -7dBm to –30dBm in 1dBm increments for the
–H version. To display the input optical power, select the STAT menu item in menu level 1, then use the
toggle switch to display the PWR option and press the pushbutton to select it.
STAT
PWR
OVER
-1 to –40
-7 to –30
LOW
The display will show one of the following:
OVER Indicates optical input power exceeding –1dBm for standard
version and -7dBm for “–H” version
-1 to –40 Optical input power within this range (Standard Version).
-7 to –30 Optical input power within this range (-H Version).
LOW Input optical power low (< -40 dBm for Standard Version, < -30
dBm for –H Version)

7700 MultiFrame Manual
7707CVR-8 Eight Analog Video Fiber Receiver
7707CVR-8 - 10 Revision 1.0
4.2.4. Displaying the Firmware Version
The VER option displays the card’s current firmware version. To display the firmware version, select the
STAT menu item in menu level 1 then use the toggle switch to display the VER option and press the
pushbutton to select it.
STAT
VER
(software version)
The firmware version will scroll across the display.
For example: VER 1.0 BLD 067
4.2.5. Setting the Video Pre-emphasis
The EQ controls are used to set the amount of pre-emphasis being applied at the video output(s). It can
be adjusted to compensate for various output cable lengths to achieve a flat frequency curve. The display
shows a range of approximate cable length values expressed in meters for Belden 1694 cable or
equivalent. When set to 0 the video pre-emphasis is turned off.
To set cable pre-emphasis, select the CTRL menu item in menu level 1, select VID from menu level 2,
then select EQ. Use the toggle switch to select the desired video channel pre-emphasis (from VID1 to
VID8) and press the pushbutton to select it. Use the toggle switch to set the pre-emphasis value of VID1
to VID8. For the sake of simplicity, only the VID1 menu item will be described in the manual.
CTRL
VID
EQ
VID1
0 to 100
This control selects the amount of pre-emphasis that is applied at the video
output(s).
0 to 100% Pre-emphasis range, describing a % value
4.2.6. Setting the Video Gain
The Gain control is used to set the gain of the video output on the 7707CVR-8. The display shows a
range of gain values expressed as a percentage.
"Note: The values other than 100 are approximate only.
To set the Gain, select the CTRL menu item in menu level 1, select VID from menu level 2, then select
GAIN. Use the toggle switch to select the desired video channel gain (from VID1 to VID8) and press the
pushbutton to select it. Use the toggle switch to set the gain value of VID1 to VID8. For the sake of
simplicity, only the VID1 menu item will be described in the manual.
CTRL
VID
GAIN
VID1
95 to 150
This control enables the user to set the gain of the video output.
95 to 150% Video Gain range, describing a % value

7700 MultiFrame Manual
7707CVR-8 Eight Analog Video Fiber Receiver
Revision 1.0 7707CVR-8 - 11
4.2.7. Setting the DC Offset
The DC Offset control is used to set the DC offset level of the video output on the 7707CVR-8. The
display shows a range of offset values from 0 Volts, expressed in millivolts.
To set the DC Offset, select the CTRL menu item in menu level 1, select VID from menu level 2, then
select DC. Use the toggle switch to select the desired video channel DC offset (from VID1 to VID8) and
press the pushbutton to select it. Use the toggle switch to set the gain value of VID1 to VID8.
CTRL
VID
DC
VID1
-100 to +100
This control enables the user to set the DC offset level of the video output.
-100 to +100 DC Offset range, describing a mV (millivolt) value
4.2.8. Setting the Password for Channel Blocking and Selecting Channels to be Blocked
The 7707CVR-8 allows selective blocking of video channels 1 to 8 with a password. The default password
is 7154.
To view the menu for channel blocking, use the pushbutton to select the CTRL menu item in menu level 1,
then use the pushbutton to select PSWD from menu level 2. Use the toggle switch to cycle through
password 0…9999. Use the pushbutton to enter the password shown on the display in menu level 3.
CTRL
PSWD
0-9999
VCH1
VCH2
VCH3
VCH4
VCH5
VCH6
VCH7
VCH8
EN
DIS
In menu level 4 use the toggle switch and then pushbutton to select the
following:
PWSL Enter a new password 0…9999
VCH1 Select Video Input 1
VCH2 Select Video Input 2
VCH3 Select Video Input 3
VCH4 Select Video Input 4
VCH5 Select Video Input 5
VCH6 Select Video Input 6
VCH7 Select Video Input 7
VCH8 Select Video Input 8
To enable or disable blocking, select the video channel (VCH1 to VCH8)
menu item in menu level 4. Use the toggle switch to set the blocking
parameter in menu level 5 of VCH1 to VCH8 individually.
EN Enable Channel
BLOK Block Channel
"Without the correct password, the blocking or enable setting of each channel cannot
be changed. The current Block or Enable status can only be viewed in menu level 5.

7700 MultiFrame Manual
7707CVR-8 Eight Analog Video Fiber Receiver
7707CVR-8 - 12 Revision 1.0
4.2.9. Setting the Orientation of the Text on the Card Edge Display
The DISP display option allows the user to set a horizontal or vertical orientation for the card edge display
messages. To set the display orientation, select the CTRL menu item in menu level 1, then use the toggle
switch to display the DISP menu selection and use the pushbutton to select it. Use the toggle switch to
change between HOR and VERT. Press the pushbutton to make your selection.
CTRL
DISP
HORZ
VERT
This control enables the user to select the display orientation.
HOR Horizontal display used when the module is housed in the 1 rack
unit 7701FR frame or the stand-alone enclosure.
VERT Vertical display used when the module is housed in the 3-rack unit
7700FR frame.
4.2.10. Resetting Factory Defaults
The FRST menu option will return the 7707CVR-8 to factory defaults. To return all settings to factory
defaults, select the CTRL menu item in menu level 1, then use the toggle switch to display the FRST menu
selection and use the pushbutton to select it. Use the toggle switch to change between YES and NO.
Press the pushbutton to make your selection.
CTRL
DISP
YES
NO
This control enables the user to reset the setting to factory default.
YES Return all card settings to factory default.
NO Retain current settings. Abort the factory reset operation.

7700 MultiFrame Manual
7707CVR-8 Eight Analog Video Fiber Receiver
Revision 1.0 7707CVR-8 - 13
5. JUMPERS
FRAME STATUS
ON/OFF
LOCAL FAULT
DISPLAY
SELECT
PUSH BUTTON
TOGGLE SWITCH
UPGRADE
RUN/UPGD
J6
MODULE OK
VIDEO 2 PRESENT
VIDEO 3 PRESENT
VIDEO 1 PRESENT
VIDEO 4 PRESENT
J5
J7
OPTICAL LINK PRESENT
SERIAL PORT
VIDEO 5 PRESENT
VIDEO 6 PRESENT
VIDEO 7 PRESENT
VIDEO 8 PRESENT
Figure 5-1: Location of Jumpers and Card Edge Controls
5.1. SELECTING WHETHER LOCAL FAULTS WILL BE MONITORED
BY THE GLOBAL FRAME STATUS
The FRAME STATUS jumper J6 determines whether local faults (as shown by the Local Fault indicator)
will be connected to the 7700FR frame's global status bus.
FRAME STATUS: To monitor faults on this module with the frame status indicators (on the Power
Supply FRAME STATUS LED's and on the Frame's Fault Tally output) install this jumper in the
On position. (Default)
When this jumper is installed in the Off position local faults on this module will not be
monitored.
5.2. CONFIGURING THE MODULE FOR FIRMWARE UPGRADES
UPGRADE: The UPGRADE jumper J5 is used when firmware upgrades are being done to the module.
For normal operation it should be installed in the RUN position. See the Upgrading Firmware
chapter of this manual for more information.
To upgrade the firmware in the module unit pull it out of the frame. Move the UPGRADE
jumper into the UPGD position. Install the Upgrade cable provided (located in the vinyl pouch
in the front of this manual) onto the SERIAL header at the card edge. Re-install the module
into the frame. Run the upgrade as described in the Upgrading Firmware section of this
manual. Once the upgrade is complete, remove the module from the frame, move the
UPGRADE jumper into the RUN position, remove the upgrade cable and re-install the module.
The module is now ready for normal operation.

7700 MultiFrame Manual
7707CVR-8 Eight Analog Video Fiber Receiver
7707CVR-8 - 14 Revision 1.0
6. VISTALINK®REMOTE MONITORING/CONTROL
6.1. WHAT IS VISTALINK®?
VistaLINK®is Evertz’s remote monitoring and configuration platform which operates over an Ethernet
network using Simple Network Management Protocol (SNMP). SNMP is a standard computer network
protocol that enables different devices sharing the same network to communicate with each other.
VistaLINK®provides centralized alarm management, which monitors, reports, and logs all incoming alarm
events and dispatches alerts to all the VLPro Clients connected to the server. Card configuration through
VistaLINK®PRO can be performed on an individual or multi-card basis using simple copy and paste
routines, which reduces the time to configure each module separately. Finally, VistaLINK®enables the
user to configure devices in the network from a central station and receive feedback that the configuration
has been carried out.
There are 3 components of SNMP:
1. An SNMP manager also known as a Network Management System (NMS) is a computer running
special software that communicates with the devices in the network. Evertz VistaLINK®Pro Manager
graphical user interface (GUI), third party or custom manager software may be used to monitor and
control Evertz VistaLINK®enabled fiber optic products.
2. Managed devices (such as 7707CVT-8 and 7707CVR-8 cards), each with a unique address (OID),
communicate with the NMS through an SNMP Agent. Evertz VistaLINK®enabled 7700 series modules
reside in the 3RU 7700FR-C MultiFrame and communicate with the manager via the 7700FC
VistaLINK®frame controller module, which serves as the Agent.
3. A virtual database known as the Management Information Base (MIB) lists all the variables being
monitored and which both the Manager and Agent understand. Please contact Evertz for further
information about obtaining a copy of the MIB for interfacing to a third party Manager/NMS.
For more information on connecting and configuring the VistaLINK®network, see the 7700FC Frame
Controller chapter.

7700 MultiFrame Manual
7707CVR-8 Eight Analog Video Fiber Receiver
Revision 1.0 7707CVR-8 - 15
6.2. VISTALINK®MONITORED PARAMETERS
The following parameters can be remotely monitored through the VistaLINK®interface.
Parameter Description
Video 1 to 8 Standard A range of values describing the detected video signal
Video 1 to 8 Signal Valid Indicates the valid video signal
Optical Power and
Threshold A range of values describing optical power at the fiber input and if this value
is below user set threshold
Optical Link Indicates the presence of a valid optical link with a 7707CVT-8 module
Optical Link Error Indicates the presence of optical link errors if errors exists
Card Type Indicates either 7707CVR-8, 7707CVR-8-H card type.
Table 6–1: VistaLINK®Monitored Parameters
6.3. VISTALINK® CONTROLLED PARAMETERS
When the MASTER jumper is set to the REMOTE position, the following parameters can be remotely
controlled through the VistaLINK®interface. When the MASTER jumper is set to the LOCAL position the
local jumper settings will override the settings configured through the VistaLINK®interface.
Parameter Description
Video 1 to 8 DC Offset A range of values describing DC Offset at the Video output (1 to 8)
Video 1 to 8 Gain A range of values describing Gain of Video 1 to 8 output as a
percentage (100 % = unity gain)
Video 1 to 8 EQ A range of values describing the pre-emphasis being applied to the
Video 1 to 8 output
Video 1 to 8 Blocking Allows user to block channels 1 to 8
New Password Allows user to change current password
Optical Power Alarm
Threshold Controls the power alarm threshold. VLPro Control Parameter Only.
Table 6–2: VistaLINK®Controlled Parameters

7700 MultiFrame Manual
7707CVR-8 Eight Analog Video Fiber Receiver
7707CVR-8 - 16 Revision 1.0
6.4. VISTALINK®TRAPS
The following traps can be remotely monitored through the VistaLINK®interface.
Trap Description
Video Input 1 to 8 Invalid Indicates a valid video signal on Channel 1 to 8
NOTE: Always loss on blocked channel
Link Presence Shows if the optical link is established
Link Errors Indicates the presence of bit errors in the optical link
Optical Power Below Threshold Indicates whether or not received optical power is below the set
threshold
Table 6–3: VistaLINK®Traps
