Instruction Manual
Original Instruction Manual
Important:
Read this instruction manual carefully before putting the chain saw into operation and strictly observe the
safety regulations!
Keep this instruction manual!
PS-4605
PS-4605 H
PS-5105
PS-5105 H
PS-5105 C
PS-5105 CH

2
RE Y
Table of contents Page
Packing ................................................................................ 2
Delivery inventory .............................................................. 3
Symbols ............................................................................... 3
SAFETY PRECAUTIONS
Intended use ................................................................... 4
General precautions ....................................................... 4
Protective equipment ...................................................... 4
Fuels / Refuelling ............................................................ 5
Putting into operation ...................................................... 5
Kickback ......................................................................... 6
Working behavior/Method of working ...........................6-7
Transport and storage ..................................................... 8
Maintenance ................................................................... 8
First aid ........................................................................... 8
Technical data ..................................................................... 9
Denomination of components ........................................... 9
PUTTING INTO OPERATION
Mounting the guide bar and saw chain .................... 10-11
Tightening the saw chain .............................................. 11
Checking the chain tension ........................................... 12
Retightening the saw chain ........................................... 12
Chain brake .................................................................. 12
Fuels ........................................................................13-14
Refuelling ...................................................................... 14
Checking the chain lubrication ...................................... 15
Adjusting the chain lubrication ...................................... 15
Starting the engine ........................................................ 16
Cold start ....................................................................... 16
Warm start .................................................................... 16
Stopping the engine ...................................................... 16
Checking the chain brake ............................................. 16
Working in winter ............................................................ 17
Grip heating .................................................................. 17
Adjusting the carburetor .................................................. 18
MAINTENANCE
Sharpening the saw chain .......................................19-20
Cleaning the brake band and sprocket interior ............. 21
Cleaning the guide bar ................................................. 21
Replacing the saw chain ............................................... 22
 Cleaningtheairlter.................................................... 23
Replacing the spark plug .............................................. 24
Checking the ignition spark ........................................... 24
 Checkingthemuferscrews......................................... 24
Replacing/cleaning the spark arrester screen ............... 24
Replacing the starter cable / Replacing the return
spring / Replacing the Featherlight -Start spring .......... 25
Mounting the fan housing ............................................. 25
Cleaning the cylinder area ............................................ 26
Replacing the suction head .......................................... 26
Instructions for periodic maintenance ........................... 27
Service, spare parts and guarantee ................................ 28
Trouble shooting .............................................................. 29
EU conformity declaration ............................................... 29
Extract from spare parts list ......................................30-31
Accessories .............................................................30-31
Packing
Your DOLMAR chain saw comes delivered in a protective card-
board box to protect against shipping damage.
Cardboard is a basic raw material and is consequently reuseable
or suitable for recycling (waste paper recycling).
Thank you for purchasing a DOLMAR product!
Congratulations on choosing a DOLMAR chain saw! We are
condentthatyouwillbesatisedwiththismodernpieceof
equipment.Astheworld’soldestmanufacturerofchainsaws
- we got our start in 1927 - we have the longest experience in
the industry. This experience shows in every detail of every
DOLMAR chain saw.
The PS-4605, PS-5105 are very handy and robust chain saws
with a new Design.
The automatic chain lubrication with variable‑ow oil pump
and maintenance-free electronic ignition ensure trouble-free
operation, while the hand-saving anti-vibration system and
ergonomic grips and controls make work easier, safer, and
less tiring for the user.
The Featherlight-Start system lets you start the saw effortlessly
with a spring-loaded starting assist.
DOLMAR chain saws PS-4605, PS-5105 are equipped with the
latest safety features and meet all national and international
standards. These features include: hand guards on both handles,
grip throttle lever lock, chain catch, safety saw chain, and chain
brake. The chain brake can be actuated manually, and is also
inertia-actuated automatically in case of kickback.
The following industrial property rights apply: DE 10191359,
WO 01/77572, DE 20006638, US 7033149, DE 20219246,
US 7204025, EP 1428637, DE 20013210, US 6648161, DE
10132973, DE 10202360, DE 20102076, US 6814192, DE
20314982, US 7191751, DE 10157589, DE 20021316, US
6578543.
In order to ensure the proper functioning and performance
of your new chain saw, and to safeguard your own per-
sonal safety, it is imperative that you read this instruction
manual thoroughly before operation. Be especially careful
to observe all safety precautions! Failure to observe these
precautions can lead to severe injury or death!
WARNING
The ignition system of this equipment produces an electro-
magnetic eld. This eld may interfere with some medical
devices such as a pacemaker. To reduce the risk of serious
or fatal injury, persons with a medical device should consult
with their physician and the manufacturer of the device before
operating this equipment.

3
18
4
5 6 7
32
Delivery inventory
Model codes
H= Saw with grip heating
C= Saw with catalytic converter
1. Chain saw
2. Guide bar
3. Saw chain
4. Chain protection cover
5. Universal wrench
6. Offset screwdriver
7. Screwdriver for carburetor adjustment
8. Cylinderncleaner
9. Instruction manual (not shown)
In case one of the parts listed should not be included in the
delivery inventory, please consult your sales agent.
Symbols
You will notice the following symbols on the saw and in the Instruction Manual:
Caution, kickback!
Chain brake
Fuel and oil mixture
Normal / Winter operation
Grip heating
Carburetor adjustment
Chainoilll/oilpump
Saw chain oil adjustment
screw
First aid
Recycling
CE - Marking
Read instruction manual and
follow the warning- and safety
precautions!
Particular care
and caution!
Forbidden!
Wear protective helmet,
eye and ear protection!
Wear protective
gloves!
No smoking!
Noopenre!
Stop engine!
Push decompression valve
Start engine
Combination switch
Start/Stop (I/O), Choke
Safety position

4
4
56
7
1
2
3
1
4
3
2
SAFETY PRECAUTIONS
Intended use
Power chain saws
This power chain saw may be used only for sawing wood out of
doors. It is intended for the followung uses depending on its class:
- Professional and mid-class: Use on small, medium and large
trees: felling, limb removal, cutting to length, thinning.
- Hobbyklasse: Occasional use on small trees, fruit-tree care,
felling, limb removal, cutting to length.
Unauthorised users:
Persons who are not familiar with the Instruction Manual, children,
youngpeople,andpersonsundertheinuenceofdrugs,alcohol
or medication must not use this saw.
National regulations may restrict the use of the unit!
General precautions
- To ensure correct operation the user has to read this instruc-
tion manual to make himself familiar with the characteristics
ofthechainsaw.Usersinsufcientlyinformedwillendanger
themselves as well as others due to improper handling.
- It is recommended to lend the chain saw only to people who
are experienced in working with chain saws. Always hand over
the instruction manual.
- First users should ask the dealer for basic instructions to be-
come familiarized with the characteristics of engine powered
sawing or even attend a recognized course of instruction.
- Children and young persons aged under 18 years must not
be allowed to operate the chain saw. Persons over the age of
16 years may, however, use the chain saw for the purpose of
being trained as long as they are under the supervision of a
qualiedtrainer.
- Use chain saws always with the utmost care and attention.
- Operate the chain saw only if you are in good physical condition.
If you are tired, your attention will be reduced. Be especially
careful at the end of a working day. Perform all work calmly
and carefully. The user has to accept liability for others.
- Never use the chain saw after having consumed alcohol, drugs
or medication.
‑ Areextinguishermustbeavailableintheimmediatevicinity
whenworkingineasilyinammablevegetationorwhenithas
notrainedforalongtime(dangerofre).
Protective equipment
- In order to avoid head, eye, hand or foot injuries as well as
to protect your hearing the following protective equipment
must be used during operation of the chain saw:
- The kind of clothing should be appropriate, i. e. it should be
tight‑tting but not be a hindrance. Do not wear jewellery
or clothing which could become entangled with bushes or
shrubs. If you have long hair, always wear a hairnet!
- It is necessary to wear a protective helmet whenever working
with the chain saw. The protective helmet (1) is to be checked
in regular intervals for damage and is to be replaced after 5
years at the latest. Use only approved protective helmets.
- The face shield (2) of the protective helmet (or the goggles)
protects against sawdust and wood chips. During operation of
the chain saw always wear a goggle or a face shield to prevent
eye injuries.
- Wear adequate noise protection equipment (ear muffs (3),
ear plugs, etc.). Octave brand analysis upon request.
- The safety jacket (4) is provided with special signal-coloured
shoulder straps and is comfortable and easy to care for.
- The protective brace and bib overall (5) is made of a nylon
fabric with multiple layers and protects against cuts. We strongly
recommend its use.
- Protective gloves (6) made of thick leather are part of the
prescribed equipment and must always be worn during
operation of the chain saw.
- During operation of the chain saw safety shoes or safety
boots(7)ttedwithantiskidsole,steeltoecapsandpro-
tection for the leg must always to be worn. Safety shoes
equipped with a protective layer provide protection against
cuts and ensure a secure footing.
- Sawing dry wood can create dust. Use a suitable dust mask.

5
6
5
7
8
3 Meter
9
● Maintenance ● Stopping work
● Refuelling ● Transport
● Sharpening the chain ● Putting out of function
Fuels / Refuelling
- Stop the engine before refuelling the chain saw.
‑ Donotsmokeorworknearopenres(5).
- Let the engine cool down before refuelling.
- Fuels can contain substances similar to solvents. Eyes and skin
should not come in contact with mineral oil products.Always wear
protective gloves when refuelling. Frequently clean and change
protective clothes. Do not breathe in fuel vapors. Inhalation of
fuel vapours can be hazardous to your health.
- Do not spill fuel or chain oil. When you have spilt fuel or oil imme-
diately clean the chain saw. Fuel should not come in contact with
clothes. If your clothes have come in contact with fuel, change
them ot once.
- Ensure that no fuel or chain oil oozes into the soil (environmental
protection). Use an appropriate base.
- Refuelling is not allowed in closed rooms. Fuel vapors will ac-
cumulateneartheoor(explosionhazard).
‑ Ensuretormlytightenthescrewplugsofthefuelandoiltanks.
- Change the place before starting the engine (at least 3 m from
the place of refuelling) (6).
- Fuel cannot be stored for an unlimited period of time. Buy only
as much as will be consumed in the near future.
- Use only approved and marked containers for the transport and
storage of fuel and chain oil. Ensure children have no access to
fuel or chain oil.
Putting into operation
- Do not work on your own. Another person must be nearby
in case of emergencies (within shouting distance).
- Ensure that there are no children or other people within the
working area. Pay attention to any animals in the working area,
as well (7).
- Before starting work the chain saw must be checked for
perfect function and operating safety according to the pre-
scriptions.
Check especially the function of the chain brake, the correct
mounting of the guide bar, the correct sharpening and tightening
ofthechain,thermmountingofthesprocketguard,theeasy
motion of the throttle lever and the function of the throttle lever
lock, the cleanliness and dryness of the handles, and the function
of the ON/OFF switch.
- Put the chain saw only into operation if it is completely assembled.
Never use the chain saw when it is not completely assembled.
- Before starting the chain saw ensure that you have a safe footing.
- Put the chain saw into operation only as described in this in-
struction manual (8). Other starting methods are not allowed.
- When starting the chain saw it must be well supported and
securely held. The guide bar and chain must not be in contact
with any object.
- When working with the chain saw always hold it with both
hands. Take the back handle with the right hand and the tubu-
lar handle with the left hand. Hold the handles tightly with your
thumbsfacingyourngers.
- CAUTION: When releasing the throttle lever the chain will
keep on running for a short period of time (free-wheeling).
- Continuously ensure that you have a safe footing.
- Hold the chain saw such that you will not breathe in the exhaust
gas. Do not work in closed rooms (danger of poisoning).
- Switch off the chain saw immediately if you observe any
changes in its operating behavior.
- The engine must be switched off before checking the chain
tension, tightening the chain, replacing it or clearing mal-
functions (9).
- When the sawing device is hit by stones, nails or other hard
objects, switch off the engine immediately and check the
sawing device. If the chain saw is exposed to force, such as
through impact or falling, inspect the entire chain saw for proper
functioning.
- When stopping work or leaving the working place switch off the
chain saw (9) and put it down such that nobody is endangered.
CAUTION:Do not put the overheated power chain
sawindrygrassoronanyinammableobjects.
Themuferisveryhot(dangerofre).
- CAUTION: Oil dropping from the chain or guide bar after hav-
ing stopped the saw chain will pollute the soil. Always use an
appropriate base.

6
Z
10
12
13
14
11
Kickback
- When working with the chain saw dangerous kickbacks may
occur.
- Kickback occurs when the upper part of the end of the guide
bar inadvertently touches wood or other hard objects (10).
- This causes the saw to be thrown back toward the user with
great force and out of control. Risk of injury!
In order to prevent kickback, follow these rules:
- Only specially-trained persons should perform plunge cuts, i.e.,
piercing timber or wood with the tip of the saw!
- Never apply the end of the bar when starting to make a cut.
- Always observe the end of the guide bar. Be careful when
continuing an already started cut.
- When starting to cut the chain must be running.
- Ensure that the chain is always sharpened correctly. Pay special
attention to the height of the depth limiter.
- Never cut several branches at the same time. When cutting a
branch ensure that no other branch is touched.
- When crosscutting a trunk be aware of the trunks next to it.
Working behavior/Method of working
- Only use the chain saw during good light and visibility periods.
Be aware of slippery or wet areas, and of ice and snow (risk of
slipping). The risk of slipping is extremely high when working
on recently peeled wood (bark).
- Never work on unstable surfaces. Make sure that there are no
obstacles in the working area, risk of stumbling. Always ensure
that you have a safe footing.
- Never saw above your shoulder height (11).
- Never saw while standing on a ladder (11).
- Never climb up into trees to perform sawing with the chain saw.
- Do not work leaning too far over.
- Guide the chain saw in such a way that no part of your body is
within the elongated swivelling range of the saw (12).
- Use the chain saw for sawing wood only.
- Avoid touching the ground with the chain saw while it is still
running.
- Never use the chain saw for lifting up or removing pieces of
wood or other objects.
- Remove foreign objects such as sand, stones and nails found
within the working area. Foreign objects may damage the sawing
device and can cause dangerous kickback.
- When sawing precut timber use a safe support (sawing jack,
13). Do not steady the workpiece with your foot, and do not
allow anyone else to hold or steady it.
- Secure round pieces against rotation.
-For cutting down trees or performing crosscuts the spike
bar (13, Z) must be applied to the wood to be cut.
- Before performing a crosscutrmlyapplythespikebartothe
timber, only then can the timber be cut with the chain running.
For this the chain saw is lifted at the back handle and guided
with the tubular handle. The spike bar serves as a centre of
rotation. Continue by slightly pressing down the tubular handle
and simultaneously pulling back the chain saw. Apply the spike
bar a little bit deeper and once again lift the back handle.
- When the timber must be pierced for cutting or longitudi-
nal cuts are to be performed it is urgently recommended
to have this carried out by specially trained persons only
(high risk of kickback).
- When starting a cut, the blade can slip to the side or jump slight-
ly. This depends on the wood and the condition of the chain.
Therefore, always hold the chain saw with both hands.
- Do longitudinal - lengthwise - cuts at the lowest possible
angle (14). Be very careful when doing this type of cut, as the
spike bar cannot grip.
- The saw must be running whenever you remove the chain saw
from the wood.
- When performing several cuts the throttle lever must be released
in between.

7
B
A
B
15
16
17
18
19
2 1/2
45°
45°
= cutting down area
- Be careful when cutting splintery wood. Cut pieces of wood
may be pulled along (risk of injuries).
- When cutting with the upper edge of the guide bar, the chain
saw may be pushed in the direction of the user if the chain
gets clamped. For this reason use the lower edge of the bar
whenever possible. The chain saw will then be pushed away
from you (15).
‑ Ifthetimberisundertension(16),rstcutthepressureside
(A). Then the crosscut can be performed on the tension side
(B). Thus clamping of the guide bar can be avoided.
- At the end of the cut the weight of the chain saw will cause it
to swing through, since it is no longer held by the cut. Hold it
rmlytocontrolthis.
CAUTION:
People felling trees or cutting of branches must be specially
trained. High risk of injuries!
- When cutting of branches, the chain saw should be supported
on the trunk. Do not use the end of the bar for cutting (risk of
kickback).
- Be aware of branches under tension. Do not cut free branches
from below.
- Never perform detensioning cuts while standing on the trunk.
- Before cutting down a tree ensure that
a) only those people are within the working area which are
actually involved in cutting down the tree.
b) every worker involved can withdraw without stumbling (the
people should withdraw backwards in a diagonal line, i. e.
at a degree of 45°).
c) the bottom part of the trunk is free from foreign objects,
underbrush and branches. Make sure to have a safe footing
(risk of stumbling).
d) the next working place is at least 2 1/2 tree lengths away
(17). Before cutting down the tree check the direction of fall
and make sure that there are neither people nor objects
within a distance of 2 1/2 tree lengths.
- Judging the tree:
Direction of hanging - loose or dry branches - height of the
tree - natural overhang - is the tree rotten?
- Take into account the direction and speed of the wind. If strong
gusts are occurring, do not do any felling.
- Cutting the roots:
Start with the strongest root. First do the vertical and then the
horizontal cut.
- Notching the trunk (18, A):
The notch determines the direction of fall and guides the tree.
The trunk is notched perpendicular to the direction of fall and
penetrates 1/3 -1/5 of the trunk diameter. Perform the cut near
the ground.
- When correcting the cut, always do so over the whole width of
the notch.
- Cut down the tree (19, B) above the bottom edge of the notch
(D). The cut must be exactly horizontal. The distance between
both cuts must be approx. 1/10 of the trunk diameter.
- The material between both cuts (C) serves as a hinge. Never
cut it through, otherwise the tree will fall without any control.
Insert felling wedges in time.
- Secure the cut only with wedges made of plastic or aluminium.
Do not use iron wedges. If the saw hits an iron wedge the chain
can be seriously damaged or torn.
- When cutting down a tree always stay sidewards of the falling
tree.
- When withdrawing after having performed the cut, be alert for
falling branches.
- When working on sloping ground the user of the chain saw
must stay above or sidewards of the trunk to be cut or the tree
already cut down.
- Be alert for trunks which may roll towards you.

8
20
21
22
23
SERVICE
Transport and storage
- When changing your location during work switch off the
chain saw and actuate the chain brake in order to prevent
an inadvertent start of the chain.
- Never carry or transport the chain saw with the chain
running.
-When the saw is hot, do not cover it (with a tarp, blanket,
newspaper or the like).
Let the saw cool down before putting it in a storage case
or vehicle. Saws with catalytic converter take longer to
cool down!
- When transporting the chain saw over long distances the chain
protection cover (delivered with the chain saw) must be applied.
- Carry the chain saw with the tubular handle. The guide bar
pointsbackwards(20).Avoidcomingincontactwiththemufer
(danger of burns).
- Ensure safe positioning of the chain saw during car trans-
portation to avoid fuel or chain oil leakage.
- Store the chain saw safely in a dry place. It must not be stored
outdoors. Keep the chain saw away from children. The chain
protection cover should always be put on.
- Before storing the chain saw over a long period of time or
shipping it the fuel and oil tanks must be completely emptied.
Maintenance
- Before performing maintenance work switch off the chain
saw (21) and pull out the plug cap.
- Before starting work always check the operating safety of
the chain saw, in particular the function of the chain brake.
Make sure that the chain is always sharpened and tightened
correctly (22).
- Operate the chain saw only at a low noise and emission level.
For this ensure the carburetor is adjusted correctly.
- Regularly clean the chain saw.
- Regularly check the tank cap for tightness.
Observe the accident prevention instructions issued by
trade associations and insurance companies. Do not
performanymodicationsonthechainsaw.Youwillput
your safety at risk.
Perform only the maintenance and repair works described in
the instruction manual. All other work must be carried out by
DOLMAR Service.
Use only original DOLMAR spare parts and accessories.
Using spare parts other than original DOLMAR parts or
accesories and guide bar/chain combinations or lengths which
are not approved bring a high risk of accidents. We cannot
accept any responsibility for accidents and damage resulting
from using sawing devices or accesories which have not been
approved.
First aid
For the event of a possible accident, please make sure that a
rstaidkitisalwaysimmediatelyavailablecloseby.Immediately
replaceanyitemsusedfromtherstaidbox.
When calling for help, give the following information:
- Place of the accident
- What happened
- Number of injured people
- Kind of injuries
- Your name!
NOTE
Individuals with poor circulation who are exposed to excessive
vibration may experience injury to blood vessels or the nervous
system.
Vibration may cause the following symptoms to occur in the
ngers,handsorwrists:”Fallingasleep”(numbness),tingling,
pain, stabbing sensation, alteration of skin colour or of the skin.
If any of these symptoms occur, see a physician!
To reduce the risk of vibration white nger, keep your
hands warm, wear gloves, and make sure the saw chain
is sharp.

9
Stroke volume cm3 45.6 50.0
Bore mm 43 45
Stroke mm 31.4 31.44
Max. power at speed kW / 1/min 2.6 / 10,000 2.8 / 10,000
Max. torque at speed Nm / 1/min 2.8 / 7,000 3.1 / 7,000
Idling speed / max. engine speed with bar and chain 1/min 2,500 / 13,800 2,500 / 13,800
Clutch engagement speed 1/min 3,900 3,900
Sound pressure level at the workplace LpA, av per ISO 22868 1) 3) dB(A) 102.1 / KpA = 2.5 102.4 / KpA = 2.5
Sound power level LWA, Fl + Ra per ISO 22868 2) 3) dB(A) 110.8 / KWA = 2.5 111.3 / KWA = 2.5
Vibration acceleration ah,w eq per ISO 22867 1) 3)
- Tubular handle m/s2 4.1 / K = 2 5.2 / K = 2
- Rear handle m/s2 3.6 / K = 2 3.7 / K = 2
Carburetor Carburetor (membrane, choke valve carburetor) Type ZAMA
Ignition system Type electronic
Spark plug Type NGK BPMR 7A
Electrode gap mm 0.5
or spark plug Type BOSCH WSR 6F
Fuel consumption at max. load per ISO 7293 kg/h 1.2 1.3
Specicconsumptionatmax.loadperISO7293 g/kWh 450 450
Fuel tank capacity cm3470
Chain oil tank capacity cm3270
Mixture ratio (fuel/two-stroke oil)
- when using DOLMAR oil 50 : 1
- when using Aspen Alkylat (two-stroke fuel) 50 : 1 (2%)
- when using other oils 50 : 1 (quality grade: JASO FC or ISO EGD)
Chain brake engages manually or in case of kickback
Chain speed (at top-speed) m/s .325“= 25,6 3/8“= 29,6
Sprocket pitch inch .325 or 3/8
Number of teeth Z 7
Chain type see the Extract from the spare-parts list
Pitch / gauge inch .325 / 0.050, 0.058 or 3/8 / 0.058
Guide bar, length of a cut cm 33 / 38 / 45 / 53
Guide-bar type see the Extract from the spare-parts list
Weight (fuel tank empty, without chain, guide bar and accessories) kg 4) 4)
1) Figures derived in equal part from idling, full-load and top-speed. 2) Figures derived in equal part from full-load and top-speed. 3) Uncertainty (K=).
4) PS-4605 = 5,3, PS-4605 H = 5,5, PS-5105 = 5,3, PS-5105 C = 5,4, PS-5105 H = 5,5, PS-5105 CH = 5,6.
Technical data PS-4605 PS-5105
2
24 25
16
17
18 19
3
4
1
6
7
15
5
8
9
111213
20212223
1014
Denomination of components
1 Handle
2 Cover
3Cover clasp
4 Tubular handle
5 Hand guard (release for chain brake)
6 Mufer
7Spike bar
8Chain tensioning screw
9Retaining nuts
10 Chain catch
11 Sprocket guard
12 Adjusting screw for oil pump (bottom side)
13 Adjusting screws for carburetor
14 Switchforgripheating(onlyon“H”modelsaws)
15 Identicationplate
16 Starter grip
17 Combination switch (Choke / Start / Stop)
18 Throttle lever
19 Safety locking button
20 Rear hand guard
21 Fuel tank cap
22 Fan housing with starting assembly
23 Oil tank cap
24 Guide bar
25 Chain (Blade)
Identicationplate(15)
Indicate when ordering spare parts
Serial number
Year of
manufacture

10
6 5 4
5 7
1
2
3
C
D
B
A
Put on the guide bar (7). Make sure that the pin (5) of the chain
tensioner engages in the hole in the guide bar.
Remove the plastic transport cover (*) and dispose of prop-
erly.
Turn chain tensioning screw (4) to the left (counter-clockwise)
until the pin (5) of the chain tensioner is underneath the threaded
pin (6).
Mounting the guide bar and saw chain
Use the universal wrench delivered with the chain saw for the
following work.
Put the chain saw on a stable surface and carry out the following
steps for mounting the guide bar and saw chain:
Release the chain brake by pulling the hand guard (1) in direc-
tion of arrow.
Unscrew retaining nuts (2).
Pull off the sprocket guard (3).
PUTTING INTO OPERATION
CAUTION:
Before doing any work on the guide bar or chain, always
switch off the engine and pull the plug cap off the spark
plug (see„Replacingthesparkplug“). Always wear protec-
tive gloves!
CAUTION:
Start the chain saw only after having assembled it com-
pletely and inspected.

11
9 12
2
4
8
1011
9
F
H
E
23
G
Replace the sprocket guard (3).
Tighten the nuts (2) only hand-tight to begin with.
Lift the chain (9) over the sprocket (8).
CAUTION:
Do not insert the chain between the chain sprocket and the
disc.
Guide the chain from above about halfway into the groove (10)
on the guide bar.
Place the chain over the chain catch (11) on the bottom.
CAUTION:
Note that the cutting edges along the top of the chain must
point in the direction of the arrow!
Tightening the saw chain
Turn the chain tensioning screw (4) to the right (clockwise) until
the saw chain catches in the groove on the lower side of the
guide bar (see circle).
Slightly lift the end of the guide bar and turn the chain adjusting
screw (4) to the right (clockwise) until the chain rests against
the bottom side of the guide bar.
While still holding up the tip of the guide bar, tighten the retaining
nuts (2) with the universal wrench.
Pull the chain (9) around the sprocket nose (12) of the guide
bar in the direction of the arrow.

12
2
4
12
1
C
B
A
Engaging the chain brake (braking)
If the kickback is strong enough the sudden acceleration of the
guide bar combined with the inertia of the hand guard (1) will
automatically actuate the chain brake.
To engage the chain brake manually, simply push the hand
guard (1) forward (towards the tip of the saw) with your left
hand (arrow 1).
Releasing the chain brake
Pull the hand guard (1) towards you (arrow 2) until you feel it
catch. The brake is now released.
Chain brake
The PS-4605 / PS-5105 comes with an inertia chain brake as
standard equipment. If kickback occurs due to contact of the
guide-bar tip with wood (see SAFETY PRECAUTIONS, page 6),
the chain brake will stop the chain through inertia if the kickback
issufcientlystrong.
The chain will stop within a fraction of a second.
The chain brake is installed to block the saw chain before
starting it and to stop it immediately in case of an emer-
gency.
IMPORTANT: NEVER run the saw with the chain brake acti-
vated(exceptfortesting,see“Testingchainbrake”)!Doing so
can very quickly cause extensive engine damage!
ALWAYS release the chain brake
before starting the work!
Checking the chain tension
The tension of the chain is correct if the chain rests against
the bottom side of the guide bar and can still be easily turned
by hand.
While doing so the chain brake must be released.
Check the chain tension frequently - new chains tend to get
longer during use!
When checking the chain tension the engine must be switched
off.
NOTE:
It is recommended to use 2-3 chains alternatively.
In order to guarantee uniform wear of the guide bar the bar
should be turned over whenever replacing the chain.
Retightening the saw chain
Loosen the nuts (2) about one turn with the universal wrench.
Raise the tip of the guide bar a little and turn the chain tensioning
screw (4) to the right (clockwise) until the saw chain is again up
against the bottom edge of the guide bar (see circle).
While keeping the tip of the guide bar raised, tighten the nuts
(2) again with the universal wrench.

13
E
Chain oil
Use an oil with adhesive additive for lubricating the chain and
guide bar. The adhesive additive prevents the oil from being
ungoffthechaintooquickly.
We recommend the use of chain oil which is bio-degradable in
order to protect the environment. The use of bio-degradable oil
may even be required by local regulations.
The chain oil BIOTOP sold by DOLMAR is made of special
vegetable oils and is 100% bio-degradable. BIOTOP has been
grantedthe„blueangel“(BlauerUmweltschutz‑Engel)forbeing
particularly environment-friendly (RAL UZ 48).
BIOTOP chain oil is available in the following sizes:
1 l order number 980 008 210
5 l order number 980 008 211
20 l order number 980 008 213
Bio-degradable oil is stable only for a limited period of
time. It should be used within 2 years from the date of
manufacture (printed on the container).
D
50:1
+
Gasoline 50:1 50:1
Fuel
CAUTION:
This saw is powered by mineral-oil products (gasoline and oil).
Be especially careful when handling gasoline.
Avoidallameorre.Donotsmoke(explosionhazard).
Fuel mixture
This tool is powered by a high-performance air-cooled two-
stroke engine. It runs on a mixture of gasoline and two-stroke
engine oil.
The engine is designed for unleaded regular gasoline with a min.
octane value of 91 ROZ. In case no such fuel is available, you can
use fuel with a higher octane value. This will not affect the engine.
In order to obtain an optimum engine output and to protect
your health and the environment use unleaded fuel only.
To lubricate the engine, use a synthetic oil for two-stroke air-coo-
led engines (quality grade JASO FC or ISO EGD), which has
to be added to the fuel. The engine has been designed for use
of DOLMAR EXTRA high-performance two-stroke engine oil and
a mixture ratio of only 50:1 to protect the environment. In addition,
a long service life and reliable operation with a minimum emission
of exhaust gases are ensured.
DOLMAR EXTRAhigh-performance two-stroke engine oil is avail-
able in the following sizes:
1 l order number 980 008 103
100 ml order number 980 008 104
DOLMAR high-performance two-stroke engine oil is available in
the following sizes to suit your individual requirements:
1 l order number 980 008 112
100 ml order number 980 008 106
In case DOLMAR high-performance two-stroke engine oil is not
available, it is urgently recommended to use a mixture ratio of 50:1
with other two-stroke engine oils, as otherwise optimum operation
of the engine cannot be guaranteed.
Caution: Do not use ready-mixed fuel from petrol
stations.
The correct mixture ratio:
50:1 when usingDOLMAR high-performancetwo-stroke engine
oil, i. e. mix 50 parts gasoline with 1 part oil.
50:1 when using DOLMAR EXTRA high-performance two-
stroke engine oil, i. e. mix 50 parts gasoline with 1 part oil.
50:1 when using other synthetic two-stroke engine oils
(quality grade JASO FC or ISO EGD), i. e. mix 50 parts
gasoline with 1 part oil.
NOTE: For preparing the fuel‑oil mixture rst mix the entire oil
quantity with half of the fuel required, then add the remaining fuel.
Thoroughlyshakethemixturebeforellingitintothechainsawtank.
Itisnotwisetoaddmoreengineoilthanspecied
to ensure safe operation. This will only result in a
higher production of combustion residues which will
pollute theenvironmentand clogthe exhaustchannel
inthecylinderaswellasthemufer.Inaddition,fuel
consumptionwill rise and performancewill decrease.
The Storage of Fuel
Fuels have a limited storage life. Fuel and fuel mixtures
age through evaporation, especially at high tempera-
tures. Aged fuel and fuel mixtures can cause starting
problems and damage the engine.Purchase only that
amount of fuel, which will be consumed over the next
few months. At high temperatures, once fuel has been
mixed it should be used up in 6-8 weeks.
Store fuel only in proper containers, in dry, cool,
secure locations!
AVOID SKIN AND EYE CONTACT
Mineral oil products degrease your skin. If your skin
comes in contact with these substances repeatedly and
for an extended period of time, it will desiccate. Various
skin deseases may result. In addition, allergic reactions
are known to occur.
Eyes can be irritated by contact with oil. If oil comes into
your eyes, immediately wash them with clear water. If
your eyes are still irritated, see a doctor immediately!
1000 ml (1 litre) 20 ml 20 ml 20 ml
5000 ml (5 litres) 100 ml 100 ml 100 ml
10000 ml (10 litres) 200 ml 200 ml 200 ml

14
STOP
A
B
NEVER USE WASTE OIL
Waste oil is very dangerous for the environment.
Waste oil contains high amounts of carcinogenic substances.
Residues in waste oil result in a high degree of wear and tear
at the oil pump and the sawing device.
In case of damage caused by using waste oil or unappropriate
chain oil the product guarantee will be null and void.
Your salesman will inform you about the use of chain oil.
AVOID SKIN AND EYE CONTACT
Mineral oil products degrease your skin. If your skin comes in
contact with these substances repeatedly and for an extended
period of time, it will desiccate. Various skin deseases may result.
In addition, allergic reactions are known to occur.
Eyes can be irritated by contact with oil. If oil comes into your
eyes, immediately wash them with clear water.
If your eyes are still irritated, see a doctor immediately!
Important note on bio-degradable chain oils
If you are not planning to use the saw again for an ex-
tended period of time, empty the oil tank and put in a
small amount of regular engine oil (SAE 30), and then
runthesawforatime.Thisisnecessarytoushoutall
remaining bio-degradable oil from the oil tank, oil-feed
system, chain and guide bar, as many such oils tend to
leave sticky residues over time, which can cause damage
to the oil pump or other parts.
Thenexttime youuse thesaw,ll thetankwith BIOTOP
chain oil again. In case of damage caused by using waste
oil or unappropriate chain oil the product guarantee will be
null and void.
Your salesman will inform you about the use of chain oil.
chain oil
fuel/oil mixture
Refuelling
FOLLOW THE SAFETY PRECAUTIONS!
Be careful and cautious when handling fuels.
The engine must be switched off!
Thoroughly clean the area around the caps, to prevent dirt from
getting into the fuel or oil tank.
Unscrew the tank cap (use the universal wrench if necessary,
seeillustration)andlltankwithfuelmixtureorsawchainoil
uptothebottomedgeofthellingneck.Becarefulnottospill
fuel or chain oil! Be careful not to spill fuel or chain oil!
Screw on the tank cap by hand all the way.
Lubricating the chain
Duringoperationtheremustalwaysbesufcientchainoilinthe
chain‑oiltanktoprovidegoodchainlubrication.Onellingis
sufcientforaboutonehalf‑hourofcontinuousoperation.During
this procedure check whether there is enough the chain oil in
thetankandrellifnecessary.Do this only with the engine
turned off! Screw on the tank cap by hand all the way.
waste oil

15
1
2 3
C
E
D
Checking the chain lubrication
Neverworkwiththechainsawwithoutesufcientchainlubri‑
cation. Otherwise the service life of the chain and guide bar
will be reduced. Before starting work check the oil level in the
tank and the oil feed.
Check the oil feed rate as described below:
Startthechainsaw(see„Startingtheengine”).
Hold the running chain saw approx. 15 cm above a trunk or the
ground (use an appropriate base).
Ifthelubricationissufcient,youwillseealightoiltracebe-
causeoilwillbeungoffthesawingdevice.Payattentiontothe
direction the wind is blowing and avoid unnecessary exposure
to the oil spray!
Note:
After the saw has been turned off it is normal for residual chain
oil to drip from the oil feed system, the guide bar and the chain
for a time. This does not constitute a defect!
Place the saw on a suitable surface.
To ensure troublefree operation of the oil pump the oil guide
groove at the crank case (2) and the oil inlet bore in the guide
bar (3) must be cleaned regularly.
Note:
After the saw has been turned off it is normal for residual chain
oil to drip from the oil feed system, the guide bar and the chain
for a time. This does not constitute a defect!
Place the saw on a suitable surface.
Adjusting the chain lubrication
The engine must be switched off.
You can adjust the oil pump feed rate with the adjusting screw
(1). The adjusting screw is on the bottom side of the housing.
The oil pump comes factory-set to a medium feed rate.
To adjust the supply rate, use a small screwdriver to turn the
adjusting screw:
• to the right for a faster
• to the left for a slower
oil feed rate.
Pick one of the three settings depending on the length of the
guide bar.
While working make sure there is enough chain oil in the tank.
If necessary, add oil.
Adjustment range about 90°

16
A
B
Cold starting:
Move the combination switch (1) up (choke position). This also
actuates the half-throttle lock.
Pull the starter cable (2) out slowly until you feel resistance (the
piston is now just before top dead centre).
Nowpullitquicklyandpowerfullyuntilyouheartherst
audible ignition.
CAUTION: Do not pull the starter cable more than about 50
cm/20”out,andletitbackinslowlybyhand.
Move the combination switch (1) to the central “ON”position.
Pullthestartercableagain,quicklyandrmly.Assoonasthe
engine is running, grasp the rear handle (the safety lock button
(3) is actuated by the palm of the hand) and press the throttle
trigger (4).
The half-throttle lock will disengage and the engine will now
idle.
CAUTION: The engine must be put in idle immediately after
starting. If this is not done, the clutch can be damaged.
Now disengage the chain brake.
Warm starting:
As described above for cold starting, but before starting push
the combination switch (1) up (Choke position) and
then right away back to the middle “ON”position.Thisisonly
toengagethehalf‑throttlelock.Iftheenginedoesn’tstartafter
2 or 3 pulls, repeat the entire starting procedure as described
for cold starting.
Stopping the engine
Depress the combination switch (1).
NOTE: After being pressed down, the combination switch will
revert to the ON position again. The engine is switched off, but can
be turned on again without moving the combination switch.
IMPORTANT: To cut off the ignition current, push the combi-
nation switch all the way down past the resistance point to the
safety position ( ).
Cold start (Choke)
Warm start (ON)
Engine off
Combination switch
in safety position
(ignition current cut off,
necessary for all mainte-
nance, repair, and instal-
lation work)
1
4 3
2
Starting the engine
Do not start the chain saw until after it is completely as-
sembled and checked!
Move at least 3 meters / 10 feet away from the place where the
chain saw was fuelled.
Make sure you have a secure footing, and place the saw on
the ground in such a way that the guide bar and chain are not
near anything.
Actuate the chain brake (block it).
Holdthefronthandlermlywithonehandandpressthesaw
against the ground.
Hold the down rear handguard with your right foot as shown.

17
9
6
C
OFF
ON
Grip heating
(onlyon“H”modelsaws)
The electric grip heating is switched on and off with switch
(9).
On: Move switch down
Off: Move switch up
E
7
8
Working in winter
In order to prevent carburetor icing in conditions of low tempe-
rature combined with high humidity, and below + 5°C in order
to get up to operating temperature faster, heated air can be
taken from the cylinder.
Removethecover(see“Cleaningtheairlter”).
Remove the insert (7) and insert it as shown for winter opera-
tion.
If the temperature is above + 5°C (40°F) the engine needs to
induct cold air. If this is not done, the cylinder and piston
can be damaged!
For temperatures above + 5°C (40°F) turn the insert 180° so
that after it is inserted the induction opening (8) is closed.
Put the cover back on.
Note: When working in snow, the insert (7) can be replaced by
a specal insert with nylon screen, which prevents snow from
getting in. It is available as an accessory, part no. 957 173 250.
Symbol on top when inserted – Normal operation
Symbol on top when inserted – Winter operation
D
Checking the chain brake
The chain brake must be checked before every use of the
saw!
Start the engine as described above (have a secure footing,
place the chain saw on the ground so that the chain and guide
bar are not near anything).
Holdthefronthandlermly,withyourotherhandontherear
grip.
Let the engine run at medium speed and push the handguard
(6) in the direction of the arrow using the back of your hand,
until the chain brake engages. The chain should now stop im-
mediately.
Bring the engine back to idle and release the chain brake.
Caution: If the chain does not stop immediately in this test,
turn off the engine immediately. Do NOT use the chain saw
in this condition! Contact a DOLMAR service centre.

18
A
Adjusting the carburetor
CAUTION: Carburetor adjustment may only be done by a
specialist DOLMAR service centre!
Only adjusting screw (S) can be manipulated by the user.
If the saw chain moves in idle (i.e. without the throttle being
pressed), it is imperative to correct the idle speed!
Do not adjust the idle speed until after complete assembly
and testing of the saw!
Idle speed adjustment must only be undertaken when
theengineiswarm,withacleanairlterandproperlyin-
stalled guide bar and chain.
Use a screwdriver (4 mm blade) for idle adjustments.
Adjusting the idle speed
Turn adjusting screw (S) counter-clockwise (unscrew): Idle
speed decreases.
Turn adjusting screw (S) clockwise (screw in): Idle speed
increases.
Important: If the saw chain still moves during idle even
after you have adjusted the idle speed, do NOT use the
saw. Take it to a DOLMAR service centre!
SERVICE
S

19
min.
3 mm (0.11”)
α
α
ββ
A
B
C
Thesharpeningangle(α)mustbeidenticalforallcutters!
25° for chain type 686, 099
30° for chain type 086, 484
35° for chain type 093
The teeth will have the proper angle (b) automatically if the
properroundleisused.
60° for chain type 686, 099
85° for chain type 086, 093, 484
Different angles result in a roughly, irregularly running chain,
increase wear and tear and cause chain beakage.
MAINTENANCE
Sharpening the saw chain
CAUTION: Before doing any work on the guide bar or chain,
always switch off the engine and pull the plug cap off the
spark plug (see „Replacing the spark plug“). Always wear
protective gloves!
The chain needs sharpening when:
The sawdust produced when sawing damp wood looks like
woodour.
The chain penetrates the wood only under great pressure.
The cutting edge is visibly damaged.
The saw is pulled to the left or right when sawing. This is caused
by uneven sharpening of the chain.
Important: Sharpen frequently, but without removing too
much metal!
Generally,2or3strokesofthelewillbeenough.
Have the chain resharpened at a service centre when you have
already sharpened it yourself several times.
Proper sharpening:
CAUTION: Use only chains and guide bars designed for
this saw (see the Extract from the spare-parts list)!
All cutters must be of the same length (dimension a). Cutters
with different lengths result in rough running of the chain and
can cause cracks in the chain.
The minimum cutter length: 3 mm. Do not resharpen the chain
when the minimum cutter length has been reached; at this point,
the chain must be replaced (see the Extract from the spare-parts
listand„Replacingthesawchain“).
The depth of the cut is determined by the difference in height
between the depth limiter (round nose) and the cutting edge.
The best results are obtained with a depth-limiter depth of 0.64
mm (.025“).
CAUTION: Excessive depth
increases the risk of kickback!
0,64 mm
(.025“)
0,64 mm
(.025“)

20
1 2
D
4/5
E
F
Chain typ
086, 686, 484, 099
Chain typ
093
Files and how to work with them
Useaspecialsawchainroundleforsharpening.Standardround
lesareunsuitable.Fortheordernumber,see“Accessories”.
Type 086, 484, 686:Filetherstcutterhalfwitha4,8mmdia.
roundsaw‑chainle,thenswitchtoa4.5mmdia.le.
Type 093, 099:Filetherstcutterhalfwitha5,5mmdia.round
saw‑chainle,thenswitchtoa4.5mmdia.le.
Theleshouldcutonlywhenpushedforwards(arrow).Liftthe
lewhenleadingitbackwards.
First sharpen the shortest cutter. The length of this cutter is then
the standerd for all other cutters of the chain.
Newsawteethmustbeledtotheexactsameshapeasthe
used teeth, including on their running surfaces.
File depending on chain type (90° or 10° to the guide bar).
Aleholder makesleguidance easier.It ismarkedfor the
correct sharpening angle of:
 α=25°(686,099)
 α=30°(086,484)
 α=35°(093)
(keepthemarksparallelwiththechainwhenling,seeillustration)
andlimitsthecutdepthtothecorrect4/5ofthelediameter.
See "Accessories" for the order number.
After having sharpened the chain, the height of the depth limiter
mustbecheckedbymeansofachaingauge.See„Accessories“
for the order number.
Correct even the smallest excess height with a special at
le(1).See„Accessories“fortheordernumber.
Round off the front of the depth limiter (2).
α
