OWNER'S MANUAL
MANUALE DI
ISTRUZIONI
VHF FM HANDHELD
MARINE TRANSCEIVER
156-162 MHz 5W
DOLPHIN MR-8060

- 1 -
Index
Contents .................................................................................................................. 1
Introduction ......................................................................................................... 2-3
Contents of Package ............................................................................................. 3
Battery Operation ................................................................................................... 4
Controls and Indicators .................................................................................... 5-10
Operation.......................................................................................................... 11-18
User Information ................................................................................................... 18
Specifications ....................................................................................................... 19
Optional Accessories ........................................................................................... 19
Important Informations ........................................................................................ 20
Declaration of Conformity.................................................................................... 21
Table of restrictions on the use of VHF marine transceivers ........................... 22
English
0678
RoHS
2002/95/EC
NOTICE !
The use of VHF marine transceivers is subject to the regulations applied in the country
where the product has to be used. As regulations are subject to possible modifications,
please check the current regulations in your country with your dealer or local supplier,
before using the radio. INTEK does not take any responsibility for illegal use and
operation of this product not in accordance with the regulation of the country where the
product is used (please check the frequency bands table at page 22).

Introduction
- 2 -
Congratulations !
Congratulations on your selection and purchase of this high quality product. With proper care
and adherence to the set-up and user instructions in this Owner’s Manual, this unit will let you
enjoy years of trouble-free service.
We are committed to providing quality products that fit your needs, however we would like to
receive any comments or suggestions that you might have on this product, which will help us in
continuous improvement of the quality.
Applications
Thank you for choosing INTEK for your marine mobile application. We believe that this user
friendly transceiver will provide you with clear and reliable communications and to keep your
professional and sport activities at peak efficiency. This transceiver incorporates the latest and
most advanced technology, so you will be pleased with its quality and its technical features.
The marine transceiver INTEK DOLPHIN has been designed to be used in marine environment
and his functions make it very attractive, specially thanks to the VOX (handsfree use) function,
adjustable Digital Squelch and Digital S/RF Meter.
DOLPHIN-EX (INTERNATIONAL VERSION)
Items in this manual that are marked (DOLPHIN-EX) refer only to model INTEK DOLPHIN-EX.
Functions marked (DOLPHIN-EX) are not available in model DOLPHIN (EUROPEAN
VERSION).
Model DOLPHIN-EX is not available in the European market.
English
IMPORTANT !
This radio can only be used with a valid ship' s radio station licence, issued by the national
authorities in the home country of the ship.
This radio can be used on non-solas (non GMDSS) ships only.

Introduction - Contents of Package
- 3 -
Features and Benefits
The radio includes a number of advanced features, nevertheless its operation is user firendly
and you may get familiar with it, after few minutes of use.
Please refer to the following list of the main feautres in this two-way radio :
Fastpath to the rescue channel 16
50 Private Channels (DOLPHIN-EX)
Selection from International channels, USA channels and Canadian channels
Meteo weather channels
Roger Beep Tone
Keypad Program Tone
8 Memory Channels
Keypad Lock
Adjustable Digital Squelch
Monitor
Auto Power Save Circuit
VOX / Handsfree Use
Dual Watch function
Adjustable Hi-LO Transmitter Power
Channel / Memory Scan
3 Selectable Call Tone Melodies
Large Size Back Lighted LCD Display
Battery Status
Digital S/RF Meter
Scrambler Function (DOLPHIN-EX)
38 CTCSS Codes (DOLPHIN-EX)
External Earset-Microphone Jack
Wall Charger Jack
Contents of Package
Please carefully check that the package contains the following items :
1 x Main Unit (Radio with Antenna)
5 x 1.2V 1500mAh Ni-MH Battery
1 x 230VAC Wall Charger
1 x Belt Clip
1 x User Manual (this one)
English

Battery Operation
- 4 -
English
Installing and Checking Batteries
Slide down and remove the battery door (17) and to access the battery room. Set the battery
type switch (18) according to the type of used batteries (Ni for rechargeable batteries and AL
for alkaline batteries). Install 5 x AA size alkaline batteries or rechargeable batteries and pay
attention to install it with the correct polarity as indicated in the battery room. Switch ON radio
by turning the OFF/VOL (2) control and check the battery level on the battery level indicator
(G), 4 bars mean full charge, 3 bars mean normal charge, 2 bars mean half charge and 1 bar
means low battery condition. When the battery capacity is low, the Battery Indicator (G) and bt
Lo (P) indication will flash on the LCD display. Recharge or replace the batteries at this time.
Please refer to the following item BATTERY CHARGING.
Battery Charging
When the battery capacity is low, switch OFF the radio and connect the supplied battery travel to
the CHARGE jack (4), then plug it into the 230VAC outlet. To obtain the maximum performance
from the batteries, recharge them only when they are fully discharged. The charging time
depends on the capacity of the used batteries, it is approximately 12 hours for one set of Ni-MH
batteries (1200-1500mAh). When the charging time has expired, unplug the charger from the AC
outlet and then disconnect it from the radio.
WARNING !
1. Only the Ni-MH (or Ni-CD) batteries may be recharged.
2. Do never try to recharge alkaline batteries, as this might cause damage to the radio
or explosion of the batteries.
3. Set the battery type selector (18) to Ni.
4. Always switch OFF radio before starting the battery charging process.
5. Do not recharge batteries for more than 13-14 hours, in order to avoid overcharge or
overheating, which could cause damage to the radio.
6. Use only the enclosed battery charger or original INTEK battery chargers.

Controls and Indicators
Front Panel
- 5 -
BUSY
SC DW
HI LO
SCR
PS
VOX
WUIC
TX
1
10
14
13
12
11
15
2
6
8
9
4
7
5
3
16
VHF MARINE TRANSCEIVER
DOLPHIN
S
1 2 3 4 5 6
English

Controls and Indicators
- 6 -
1. Antenna
High efficency rubber antenna.
2. OFF/VOL (OFF/Volume) Control
This knob switches the radio ON and OFF and it adjusts the volume control. If no signals are
being received on the operating channel, it is suggested to open the SQUELCH and adjust the
volume to the desired level while listening to the background noise.
3. LCD Display
Large size LCD display with green color backlight function for best readability in darkness. The
large 6-line LCD indicates simultaneously all the programmed settings and all the enabled
functions. Digital 6-bar S/RF Meter and 4-bar battery level indicator.
LCD Display
A. Keypad Program Tone Icon
The Keypad Program Tone Icon (A) is lighted when the keyboard tone function is enabled.
B. Roger Beep Icon
The Roger Beep Icon (A) is lighted when the Roger Beep function is enabled.
BUSY
SC DW
HI LO
SCR
PS
VOX
WUIC
TX
S
123456
E F GCB
Q P OR
H
A D
I
U
T
S
V
L
M
N
English

English
Controls and Indicators
- 7 -
C. TX Icon
The TX (C) icon is ligthed when radio is in the transmit mode.
D. LOCK Icon
The LOCK icon is lighted when the keypad lock function has been enabled.
E. W Icon
The W (E) icon is lighted when the Meteo weather channels are enabled.
F. U I C Icons
The indication U I C (F) is alternatively displayed in accordance with the selected band
(U = USA, I = International, C = Canada).
G. Battery Level Indicator
It shows the current battery level condition.
H. SCR Icon (DOLPHIN-EX)
The SCR Icon (H) is lighted when the SCRAMBLER function is enabled.
I. HI Icon
The HI icon (I) is lighted when the trasmitter is in the HIGH POWER mode.
L. LO Icon
The LO icon (L) is lighted when the trasmitter is in the LOW POWER mode.
M. DW Icon
The DW icon is lighted when the DW (DUAL WATCH) function has been enabled, in order to
automatically monitor two different channels.
N. CTCSS Code Number (DOLPHIN-EX)
It shows the selected CTCSS Code Number.
O. SC Icon
The SC icon (O) is lighted when the SCAN function has been enabled, in order to automatically
search busy channels or busy memory channels.
P. Channel Number
It indicates the number of the current operating channel.
Q. S/RF Digital Bar Meter
The 6-bar digital meter indicates the received signal strength (S0 to S6) in the receive mode.
It indicates the transmitter RF output power in the transmit mode.

English
Controls and Indicators
- 8 -
R. Memory Channel Number (1-8)
It indicates the selected memory channel number, total 8 memory channels are available (1-8).
S. M Icon
The M Icon (S) is lighted when the radio is in MEMORY MODE.
T. PS Icon
The PS Icon (T) is lighted when the Automatic Power Save Circuit has been enabled.
U. VOX Icon
The VOX Icon (U) is lighted when the VOX (handsfree use) is enabled.
V. BUSY Icon
The BUSY Icon (V) appears when radio is receiving a signal or when Squelch is open.
4. Earset-Microphone-Charge Jack
Connect an external earset-microphone to this jack. Connect the supplied 230VAC battery travel
charger to this jack.
WARNING !
Use only original accessories. Connecting and using accessories other than the original
ones, may cause serious damage to the radio and will void the warranty.
Always set the volume to minimum before connecting an external earset, in order to avoid
damaging the earset or the user’s ear.
5. UP Key
The UP (5) key is used to change channel and toggle setting in Menu mode.
6. 16 Key (Emergency Rescue Channel 16)
Press this key to immediately access and enable the emergency rescue channel 16 (156.800 MHz).
7. DOWN Key
The DOWN (7) key is used to change channel and toggle setting in Menu mode.
8. MENU / MEMORY key
Use the MENU (8) key to enable and program the various functions of the radio. Pressing the
MENU (8) key will scroll the various functions. Press and hold the MENU (8) key for about 3
seconds to enter in the MEMORY MODE (refer to MEMORY CHANNEL OPERATION at page 15
and 16).

English
Controls and Indicators
- 9 -
9. Built-in Speaker
Built-in front speaker.
10. Desk Charger Contacts
Contacs for Desk Charger mod. INTEK DDC-500.
11. Built-in Microphone
Built-in microphone.
12. LIGHT / SCRAMBLER Key
LIGHT
Shortly press the LIGHT (12) key to backlight the LCD display. The LCD backlight will be turned
OFF automatically after 5 seconds.
SCRAMBLER (DOLPHIN-EX)
Press and hold the LIGHT (12) key to enable the SCRAMBLER function (refer to SCRAMBLER
FUNCTION at page 17).
13. MON Key
Press the MON key (13) to activate the Monitor function. This function opens Squelch in order to
listen to the background noise and weak signals.
14. SCAN / LOCK Key
SCAN
Shortly press the SCAN (14) key to start the channels/memory scanning (refer to AUTOMATIC
SCAN at page 16 and 17).
KEYPAD LOCK
Press and hold the SCAN (14) key for about 3 seconds to enable the keypad LOCK function.
Press and hold this key again to disable the keypad LOCK function.
15. PTT (Push-To-Talk) Key
Press the PTT (15) key to transmit and hold it during transmission. The TX (C) icon will be lighted
during transmission. Release the PTT (15) key at the end of your transmission to return to the
receive mode.
WARNING ! Do not touch the antenna during transmission.

English
Controls and Indicators
- 10 -
16
17
18
16. Belt Clip
1. To install the belt clip, slide it down into the special slot situated in the rear side of the
unit, until the block system make a click.
2. To remove the clip, pull the block tab toward exterior and slide the clip toward the up
side of the unit.
17. Battery Door
Open this cover (17) to install or remove batteries.
18. Battery Type Selector
The battery type selector (18) is located inside the battery room. Set the switch (18) to Ni if
rechargeable batteries are used. Set the switch (18) to AL if alkaline batteries are used.
Rear Panel

English
Operation
- 11 -
Menu Operation
Channel Selection
The pre-set frequency band is the International band. To choose the desired channel, please
proceed as follows :
1. Press the MENU (8) key until the channel number (P) blinks on the LCD display.
2. Press the UP (5) or DOWN (7) keys to select the desired channel. Pressing and holding
the UP (5) or DOWN (7) keys, the channel selection will move quicker.
3. To confirm the selection and exit the Menu Mode, press the PTT key (15) or press the
MENU (8) key to move to the next function.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
156.050
156.100
156.150
156.200
156.250
156.300
156.350
156.400
156.450
156.500
156.550
156.600
156.650
156.700
156.750
156.800
156.850
156.900
156.950
157.000
157.050
157.100
157.150
157.200
157.250
157.300
157.350
157.400
160.650
160.700
160.750
160.800
160.850
156.300
160.950
156.400
156.450
156.500
156.550
156.600
156.650
156.700
156.750
156.800
156.850
161.500
161.550
161.600
161.650
161.700
161.750
161.800
161.850
161.900
161.950
162.000
60
61
62
63
64
65
66
67
68
69
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
156.025
156.075
156.125
156.175
156.225
156.275
156.325
156.375
156.425
156.475
156.575
156.625
156.675
156.725
156.775
156.825
156.875
156.925
156.975
157.025
157.075
157.125
157.175
157.225
157.275
157.325
157.375
157.425
160.625
160.675
160.725
160.775
160.825
160.875
160.925
156.375
156.425
156.475
156.575
156.625
156.675
156.725
156.775
156.825
156.875
161.525
161.575
161.625
161.675
161.725
161.775
161.825
161.875
161.925
157.375
157.425
CHANNEL FREQ. (TX) FREQ. (RX) CHANNEL FREQ. (TX) FREQ. (RX)
International Channels Frequency Table

English
Operation
- 12 -
VOX (Handsfree use) Function
Your radio is equipped with a user selectable Voice Operated Transmitter function (VOX), that
is used for automatic voice transmission (handsfree use or baby room monitor use). In this
mode, transmission is automatically initiated by speaking into the microphone (11) and there is
no need to push the PTT (15). To enable the VOX function, please proceed as follows :
1. Press the MENU (8) key several times, until the Vo indication (P) appears on the LCD
display and the VOX icon (U) will blink.
2. Press the UP (5) or DOWN (7) keys to select the level of sensitivity (from 01 to 04) or to
disactivate the VOX (OF). The VOX level 01 indicates the highest VOX sensitivity.When
VOX feature is on, the VOX icon (U) will appear on the LCD display.
3. To confirm the selection and exit the Menu Mode, press the PTT key (15) or press the
MENU (8) key to move to the next function.
Transmitter RF Power Setting
Your radio has a HI/LOW Power selection function to set the TX Output Power. This function is
very convenient to reduce the current drain and extend battery life when communicating within
short distance. To select the output power, please proceed as follows :
1. Press the MENU (8) key several times, until the Pr (P) indication appears on the LCD
display and the HI (I) or LO (L) icons will blink.
2. Press the UP (5) or DOWN (7) keys to select the desired power level HI (high power) or
LO (low power).
3. To confirm the selection and exit the Menu Mode, press the PTT key (15) or press the
MENU (8) key to move to the next function.
Squelch Level Selection
This function allows to silent the receiver by cutting the background noise, when no signals are
received. The SQUELCH threshold level is adjustable in 7 steps, from level 0 (Squelch open) to
level 6 (lowest Squelch sensitivity). To select the desired Squelch level, please proceed as
follows :
1. Press the MENU (8) key several times, until the SL (P) and the selected Squelch level (N)
indications will blink on the LCD display.
2. Press the UP (5) or DOWN (7) keys to select the desired Squelch level from 0 (squelch open)
to 6. If level 0 is selected, Squelch will be open and you will hear the background noise.
3. To confirm the selection and exit the Menu Mode, press the PTT key (15) or press the
MENU (8) key to move to the next function.

English
Operation
- 13 -
Keypad Program Tone Setting
When a key is pressed, a beep tone is heard to confirm your command. The user may enable or
disable this keypad program tone.
1. Press the MENU (8) key several times, until the Bp (P) indication appears and the keypad
tone icon (A) will blink on the LCD display.
2. Press the UP (5) or DOWN (7) keys to set the desired selection on (keypad tone enabled)
or oF (keypad tone disabled).
3. To confirm the selection and exit the Menu Mode, press the PTT key (15) or press the
MENU (8) key to move to the next function.
4. When the Keypad tone is enabled, the tone icon (A) appears on the LCD display.
Roger Beep Tone Setting
The radio is equipped with a user selectable Roger Beep Tone feature, which enables you to
send a Beep Tone at the end of each transmission after every release of the PTT (15) key. This
will prompt any receiving unit that your transmission has ended. To enable or disable this
function, please proceed as follows :
1. Press the MENU (8) key several times, until the rb (P) indication appears and the tone
icon (B) will blink on the LCD display.
2. Press the UP (5) or DOWN (7) keys to set the desired selection on (Roger Beep tone
enabled) or oF (Roger Beep tone disabled).
3. To confirm the selection and exit the Menu Mode, press the PTT key (15) or press the
MENU (8) key to move to the next function.
4. When the Roger Beep tone is enabled, the tone icon (B) appears on the LCD display.
Call Tone Setting
The radio is equipped with 3 user selectable Call tone melodies. To set the desired Call tone
melody, please proceed as follows :
1. Press the MENU (8) key several times, until the CA (P) indication and melody number (N)
will blink on the LCD display.
2. Press the UP (5) or DOWN (7) keys to set the desired melody (01-02-03).
3. To confirm the selection and exit the Menu Mode, press the PTT key (15) or press the
MENU (8) key to move to the next function.
4. To transmit the CALL tone, quickly press the PTT key (15) twice.

English
Operation
- 14 -
Dual Watch Setting
The radio is equipped with a Dual Watch function that allows to monitor 2 differents channels.
To set the Dual Watch function, please proceed as follows :
1. Select the first channel to be monitored.
2. Press the MENU (8) key several time until the oF (P) icon (function disabled) and the DW
(M) icon will blink on the LCD display.
3. Press the UP (5) or DOWN (7) keys to select the second channel to be monitored.
4. To confirm the selection and exit the Menu Mode, press the PTT key (15) or press the
MENU (8) key to move to the next function.
5. When the Dual watch function is enabled, the DW icon (M) appears on the LCD display
and the radio will start monitoring and will stop when a signal is received on one of the two
stored channels, scan will re-start at the end of transmission.
6. To disable the Dual Watch function, press the SCAN (14) key.
Automatic Power Save Setting
The radio has a unique Automatic Power Save circuit designed to dramatically extend battery
life. If it senses no transmission within 5 seconds, it automatically switches to the Power Save
mode. The Radio can still receive transmissions in this mode. To enable or disable this
function, please proceed as follows :
1. Press the MENU (8) key several times, until the PS (P) indication appears and the PS icon
(T) will blink on the LCD display.
2. Press the UP (5) or DOWN (7) keys to set the desired selection on (function enabled) or
oF (function disabled).
3. To confirm the selection and exit the Menu Mode, press the PTT key (15) or press the
MENU (8) key to move to the next function.
4. When the Power Save function is enabled, the PS icon (T) appears on the LCD display.
Frequency Band Selection
The user must select the frequency channels in accordance with the country where the radio is
used from International channels (International channels are allowed frequencies in Europe) to
USA channels or Canadian channels (USA and Canadian frequencies are to be used only in
the American market). To select the desired Frequency Band, please proceed as follows :
1. Press the MENU (8) key several times, until the Co (P) indication appears and the U (USA

English
Operation
- 15 -
channels), I (International channels) or C (Canadian channels) will flash on the LCD display.
2. Press the UP (5) or DOWN (7) keys to select the desired frequency band.
3. To confirm the selection and exit the Menu Mode, press the PTT key (15) or press the
MENU (8) key to move to the next function.
Meteo Weather Channel Selection
The 10 Weather Channels (WX Band) may be enabled and may be selected after the normal
operating channels, in the selected band. To select the Meteo weather channels, please
procees as follows :
1. Press the MENU (8) key several times, until the 01 (P) indication appears and the W (E)
icon will blink on the LCD display.
2. Press the UP (5) or DOWN (7) keys to set the desired selection on (function enabled) or
oF (function disabled).
3. To confirm the selection and exit the Menu Mode, press the PTT key (15) or the MENU (8) key.
4. If the Meteo channels are enabled, the icon W (E) appears on the LCD display.
MEMORY CHANNEL OPERATION
Programming Memory Channels (1-8)
La radio is equipped with 8 programmable memory channels. To store a channel in one of the 8
memory channels, please proceed as follows :
1. Select the desired channel number as indicated at page 11.
2. Press and hold the MENU (8) key for about 3 seconds to enter the MEMORY MODE. The
M icon (S) will blink on the LCD display.
3. Press the UP (5) or DOWN (7) keys to select one of the 8 memory channels (1-8). If the
memory channel 0 is selected, no channels can be stored as a memory channel. If a
memory channel has been already programmed and stored, a new programming will
replace the previous on (overwriting).
4. Shortly press the PTT (15) key to confirm the selection and store the memory channel.
The radio will enter in Stand-by mode.
Memory Channels Recall
1. Press and hold the MENU (8) key for about 3 seconds to enter the MEMORY MODE. The
M icon (S) will blink on the LCD display.
2. Shortly press the PTT (15) key to enter the MEMORY RECALL MODE. The radio will

English
Operation
- 16 -
show the last programmed memory channel. If no memory channels have been
programmed, radio will return automatically to Stand-by mode.
3. Shortly press the MENU (8) key and the UP (5) or DOWN (7) keys to select the desired
memory channel e press the PTT (15) key to confirm the selection.
4. To exit the MEMORY MODE switch OFF and ON the radio.
Memory Channels Delete
1. Recall the desired memory channel as indicated above.
2. Press and hold the MENU (8) key for about 3 seconds until the M (S) icon will blink on the
LCD display.
3. Press the UP (5) or DOWN (7) keys to select the memory channel 0 and press the PTT
(15) key to confirm the deletion. The radio will enter in Stand-by mode.
AUTOMATIC SCAN
This function allows automatic scanning of all channels and programmed memories. To start
the automatic scan function proceed as follows :
Automatic Channel Scanning
1. Shortly press the SCAN (14) key; the unit will automatically start the automatic channels
scanning and the SC (O) icon will appear on the LCD display.
SCAN will automatically stop when a signal is detected on one channel, in order to listen to
the communication and SCAN will re-start when no more signal is detected on that channel
after about 4 seconds. If you press the PTT key (15) during the SCAN operation, SCAN will
stop automatically and radio will set the last used channel. SCAN will then restart after
about 14 seconds if no signals are received on that channel. If a signal with a CTCSS code
is received, the radio shows that channel with the corresponding code. If the receiving code
is different from the pre-programmed, the radio won’t correspond with that correspondent.
2. Press the SCAN (14) key to exit the SCAN mode.
Automatic Memory Channels Scanning
1. Press and hold the MENU (8) key for about 3 seconds to enter the MEMORY MODE. The
M icon (S) will blink on the LCD display.
2. Shortly press the PTT (15) key to enter the MEMORY RECALL MODE. The radio will
show the last programmed memory channel.
3. Shortly press the SCAN (14) key; the unit will automatically start the automatic memory
channels scanning and the SC (O) icon will appear on the LCD display.

Operation
- 17 -
SCAN will automatically stop when a signal is detected on one channel, in order to listen
to the communication and SCAN will re-start when no more signal is detected on that
channel after about 4 seconds. If you press the PTT key (15) during the SCAN operation,
SCAN will stop automatically and radio will set the last programmed channel. SCAN will
then restart after about 14 seconds if no signals are received on that channel.
4. Press the SCAN (14) key to exit the SCAN mode.
5. To exit the MEMORY MODE switch OFF and ON the radio.
SCRAMBLER FUNCTION (DOLPHIN-EX)
You can enjoy privacy of communication within your group, by enabling the SCRAMBLER
function and selecting the same scrambler formula as your group members do. Two different
scrambler formulas are available and selectable (01-02). To enable the SCRAMBLER function
please proceed as follows :
1. Press and hold the LIGHT (12) key for about 3 seconds until the Sc (P) indication appears
and the SCR (H) icon will blink on the LCD display.
2. Press the UP (5) or DOWN (7) keys to select the desired formula (01-02). Selecting OF
will disable the SCRAMBLER function.
2. Press the PTT (15) key to confirm the selection and exit to Stand-by mode.
4. When the SCRAMBLER function is enabled, the SCR icon (H) appears on the LCD display.
5. Please make sure that other group members have enabled SCRAMBLER function and
select the same formula.
6. To disable the SCRAMBLER function repeat the items 1-2 and select OF.
CTCSS FUNCTION (DOLPHIN-EX)
The radio has 38 CTCSS private codes available. Different CTCSS tones may be associated to
different channels. To choose the desired CTCSS code, please proceed as follows :
1. Press the MENU (8) key several times, until the CTCSS code number (N) blinks on the
LCD display. The CTCSS code OF (N) indicates that no CTCSS tone is programmed on
that channel.
2. Press the UP (5) or DOWN (7) keys to select the desired CTCSS code number. Pressing
and holding the UP (5) or DOWN (7) keys, the selection will move quicker.
3. To confirm the selection and exit the Menu Mode, press PTT key (15) or press the MENU
(8) key to move to the next function.
English

Operation - User Information
- 18 -
Selecting a CTCSS code of OF will disable the CTCSS feature. To communicate between two
or more radios, both the channel and CTCSS code selections must be the same. To
communicate with other models and brands of radios, the actual radio frequency and CTCSS
frequency must be matched. The frequency chart and CTCSS Code chart are included to help
with this selection.
User Information
in accordance with art. 13 of the Legislative Decree of 25th July 2005, no. 15 ”Implementation of
Directives 2002/95/EC, 2002/96/EC and 2003/108/EC, relative to reduction of the use of
hazardous substances in electrical and electronic equipment, in addition to waste disposal”.
The crossed bin symbol shown on the equipment indicates that at the end of its
working life the product must be collected separately from other waste.
The user must therefore take the above equipment to the appropriate differentiated
collection centres for electronic and electro technical waste, or return it to the dealer
when purchasing a new appliance of equivalent type, in a ratio of one to one.
Appropriate differentiated waste collection for subsequent recycling, treatment and environment-
friendly disposal of the discarded equipment helps to prevent possible negative environmental
and health effects and encourages recycling of the component materials of the equipment.
Illegal disposal of the product by the user will be punished by application of the administrative
fines provided for by the legislative decree no. 22/1997 (article 50 and following of the legislative
decree no. 22/1997).
No Freq. (Hz)
OF
CTCSS OFF
01 67,0
02 71,9
03 74,4
04 77,0
05 79,7
06 82,5
07 85,4
No Freq. (Hz)
08 88,5
09 91,5
10 94,8
11 97,4
12 100,0
13 103,5
14 107,2
15 110,9
No Freq. (Hz)
16 114,8
17 118,8
18 123,0
19 127,3
20 131,8
21 136,5
22 141,3
23 146,2
No Freq. (Hz)
24 151,4
25 156,7
26 162,2
27 167,9
28 173,8
29 179,9
30 186,2
31 192,8
No Freq. (Hz)
32 203,5
33 210,7
34 218,1
35 225,7
36 233,6
37 241,8
38 250,3
--
CTCSS - TONE FREQUENCY CHART
English

Specifications - Optional Accessories
- 19 -
SPECIFICATIONS
General
Channels INT / USA / CANADA / METEO
Operating Frequency 156.025 - 157.425 MHz (TX) / 156.300 - 162.000 MHz (RX)
Power Source 7.5V (5 x AA 1.5V alkaline battery)
6.0V (5 x AA 1.2V rechargeable battery)
Dimensions H195 x L60 X D40 mm (including antenna)
Weight gr. 250 (including battery)
Receiver
Sensitivity 0.3µV for 12dB SINAD
Squelch Sensitivity Adjustable in 7 levels
Audio output 300mW at 10% THD
Transmitter
Output Power 5W-1W selectable
Modulation FM
Damaged Antenna
Do not use any radio that has a damaged Antenna. If a damaged antenna comes in contact
with the skin, a minor burn may occur.
Battery Operation - Important Information
Dispose of battery in the proper manner, according to federal, state and local regulations that
apply in your area. A battery may leak electrolyte if it is mixed in a set with different battery
types, if inserted incorrectly, if disposed of in fire, or if an attempt is made to charge a battery
not intended to be charged. Discard leaky batteries immediately. Leaking batteries can cause
skin burns or other personal injury.
Optional Accessories :
MT-SM100 External Earset-Microphone with Tie Clip
MT-SM200 External Earset- Flexible Boom Microphone with Tie Clip
DDC-500 230VAC Electronic Quick Desk Charger
English
