DOM Tronic Plus User manual

Tronic Plus
Instructions

Tronic Plus
SAFETY
Keep the manual accessible
These instructions form an integral part of the furniture lock.
■ Keep these instructions with the
furniture lock.
■ Ensure that the instructions are
available for the assembly fitter
/ operator.
■ Please include these instructions
if you sell the furniture lock or
pass it on.
Important safety information
The furniture lock is built in
accordance with recognised safety
regulations. When working with and
on the furniture lock, however,
residual risks that can cause
danger to life and limb remain.
The following safety notices must
therefore be observed and followed.

Safety
Avoid risk of explosion
The furniture lock is not suitable for
use in areas where there is a risk of ex-
plosion. Assembling and operating the
furniture lock in an area where there is
a risk of explosion can lead to serious
injury or death.
■ Only assemble and operate the
locks in areas where there is no
explosive atmosphere.
Choking risk
Children can become injured aer
swallowing small parts.
■ Make sure that small parts e.g.
locking media or screws are kept
out of the reach of children.
Avoid property damage
and malfunction
Property damage can occur as a
result of incorrect storage for an
extended period of time.
■ Store the furniture lock and
its components in the original
packaging in a dry and
dust-free place.
Property damage can occur
as a result of the furniture lock
being assembled and operated
incorrectly.
■ Read these instructions carefully
before assembling the furniture
lock and putting it into operation.
■ Follow the instructions step by step.
■ Never touch the furniture lock’s
electronic components.
■ Protect the parts of the furniture
lock against moisture.
■ Handle the furniture lock carefully
to prevent scratches.
■ Secure the screws using the
specified torque.
Risk of property damage as a
result of incorrect cleaning
and maintenance.
■ Do not lubricate any parts of the
furniture lock.
■ Clean the housings and closing
devices with a so, damp cloth;
do not use any cleaning agents.
Appropriate user training
■People working on and with the
furniture lock must have basic
manual skills so that they can safely
make screw connections and drill
holes if necessary.
■ Installers of the furniture lock must
understand how it works and how
the individual components interact.

Tronic Plus
INSTRUCTIONS
TO CLOSE:
TO OPEN:
TO OPEN:
Open and close by 4-digit code. The
code is erased every time the lock is
opened, being available for a new use.
TO CLOSE:
The latch closes automatically aer
2 seconds. Note: the lock is provided
with a metal latch holder that allows
to close the door just by pushing it.
(slam door system)
Multiuser mode
Single User mode

PRESS FOR 3 SECONDS
TO OPEN:
1. Press Enter for 3 seconds.
2. Introduce Current code
and press enter.
INSPECTION MODE
Introduce the 5 digit Master code
and press enter. Close the lock
by pressing enter before 30s.
The User code is not deleted.
DELETE USER CODE
Introduce Master code and press enter.
Aer 30s the lock remains opened. The
User code has been deleted and a new
User code will be required to close the
lock again.
Current code New code
Master code
Change the User code
Open using Master code: Inspection mode/Delete User code
3. Introduce New code
and press enter.
-30S
INSPECTION
MODE
+30S
USER
ERASED

Tronic Plus
INSTRUCTIONS
1. Press Enter during 3 seconds.
2. Introduce Current master code
and press Enter.
Change the Master code
PRESS FOR 3 SECONDS
Current master code
New master code
3. Introduce New master code
and press Enter.

Tronic Plus
INSTRUCTIONS
1
2
Batteries replacement
Measurements
IMPORTANT:
2. The batteries replacement must
be done in less than 5 minutes.
The BATPACK must remain
connected during the release of
the batteries (otherwise the clock
will loose the programmed time).
1. Torx 20
IP (keypad / lock case ----/45
Working temperature -5ºC <> +70ºC
Latch force > 45Kgf
UV Rays > 10000h
Vibration 10 - 200 Hz 2g
Life test > 200000 cycles
Electrostatic discharge 8000 V
Battery life > 90000 cycles 0 three years

Warranty and liability
Copyright
Information available onlineDocumentation Oicer
Our General Terms and Conditions
apply as a matter of principle.
Warranty and liability claims that are
made if personal injury or property
damage occurs are always excluded if
they are attributable to one or more of
the following causes:
This documentation may not be
reproduced either in whole or in part,
stored or transmitted, disclosed or
translated in any form or by any means
without the prior written consent of
DOM Security.
You can download these instructions
and other information about the
Tronic family on the product details
page at the following web address:
www.dom-security.com
DOM Security
Product Management Department
20, rue de l’Arc de Triomphe
75017 Paris, France
■ Improper use of the furniture lock
■ Failure to observe the notices in
these instructions
■ Improperly performed assembly
■ Improperly performed repairs
■ Disasters caused by external
influences and force majeure.
This documentation is updated
at regular intervals. The publisher
is always grateful to receive
information about any errors
or suggestions regarding
this documentation.
© DOM Security, 20, rue de l’Arc de
Triomphe, 75017 Paris, France
Tronic Plus
WARRENTY AND WARNINGS
