Domestia DMR-001-016 User manual

www.domestia.be
MANUAL
DMR-001-016

2
1
1. INSTALLATION 1
The single pole relay is compatible with the base of the DMC-012-002 card.
To install it, please follow the following procedure:
• Switch o the circuit breaker assigned to the relay to be modified.
• Remove the caliper.
• Remove the relay currently in the base.
• Position the unipolar relay, taking care not to bend the legs of the latter.
• Modify the wiring to work in "Unipolar".
• Reset the circuit breaker assigned to the relay to be modified.
2. TECHNICAL CHARACTERISTICS 1
• Electrical insulation between coil and contact: 5000Vrms.
• Insulation between open contacts: 1000Vrms.
• Working current: 16A.
• Instantaneous breaking current: 80A.
• Upper isolation space: 10mm.
DMC-012-002
A
B
C
D
E
*(1)
1 2 3 4 5 6 7 8 9 10 11 12
8 A
8 A 8 A
8 A
8A 8A 8A 8A 8A 8A 8
A 8 A
Rechts
Boven
Onder
Center
Links
NPh
TL
FIGURE A
In the example given above, relay 1 is a single-pole relay of16A and
relays 2 to 12 are the original 8A bipolar relays.
Warning ! As shown in the diagram, the 2 studs are bridged
internally in the single-pole relay.
16A single pole relay

3
3. GUARANTEES 1
WARRANTY CONDITION
The basic warranty period for your product is 2 years from the date of receipt of your
order.
Whatever the problem with your item, keep your invoice, with the serial number, as this is
the only document that serves as a guarantee.
The warranty does not apply in the following cases:
• Damage caused by improper use, abuse, misuse maintenance or failure to comply
with the instructions given by the manufacturer in the instructions for use. Repair
attempts made by the customer or by a unauthorized third party. Damage caused
by accidents, force majeure or other causes for which Domestia cannot be held
responsible.
• Defect in no way aecting the proper functioning or proper use of the equipment.
4. STANDARDS 1
• EN 60730-1 (VDE 0631, part 1).
• EN 60335-1 (VDE 0700, part 1).
• UL, CUR file E44211.
• VDE file 40006031.
