Dometic Coolfreeze CF SERIES User manual

CF11
Compressor cooler
Operating manual
EN
PORTABLE REFRIGERATION
CF SERIES
CF11-O-AUS.book Seite 1 Donnerstag, 14. Juni 2018 1:41 13

EN
CoolFreeze
3
Please read this manual carefully before starting the device. Keep it in a
safe place for future reference. If the device is passed on to another
person, this manual must be handed over to the user along with it.
The manufacturer cannot be held liable for damage resulting from improper usage
or incorrect operation.
Table of contents
1 Explanation of symbols. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
2 Safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
3 Scope of delivery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
4 Intended use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
5 Technical description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
6 Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
7 Cleaning and maintenance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
8 Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
9 Guarantee . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
10 Disposal. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
11 Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
CF11-O-AUS.book Seite 3 Donnerstag, 14. Juni 2018 1:41 13

EN
Explanation of symbols CoolFreeze
4
1 Explanation of symbols
!
!
A
I
2 Safety instructions
2.1 General safety
!WARNING!
•Do not operate the cooling device if it is visibly damaged.
•If this cooling device's power cable is damaged, it must be replaced
by the manufacturer, customer service or a similarly qualified person in
order to prevent safety hazards.
•This cooling device may only be repaired by qualified personnel.
Improper repairs can lead to considerable hazards.
•This cooling device can be used by children aged 8 years or over, as
well as by persons with diminished physical, sensory or mental capac-
ities or a lack of experience and/or knowledge, providing they are
supervised or have been taught how to use the cooling device safely
and are aware of the resulting risks.
•Cleaning and user maintenance must not be carried out by children
without supervision.
•Children must not play with the cooling device.
•Children must be supervised to ensure that they do not play with the
cooling device.
WARNING!
Safety instruction: Failure to observe this instruction can cause fatal or
serious injury.
CAUTION!
Safety instruction: Failure to observe this instruction can lead to injury.
NOTICE!
Failure to observe this instruction can cause material damage and impair
the function of the product.
NOTE
Supplementary information for operating the product.
CF11-O-AUS.book Seite 4 Donnerstag, 14. Juni 2018 1:41 13

EN
CoolFreeze Safety instructions
5
•Always keep and use the cooling device out of the reach of children
under the age of 8 years.
•Do not store any explosive substances such as spray cans with a
flammable propellant in the cooling device.
!CAUTION!
•Disconnect the cooling device from the power supply
– before each cleaning and maintenance
– after every use
•Food may only be stored in its original packaging or in suitable
containers.
ANOTICE!
•Check that the voltage specification on the type plate corresponds to
that of the energy supply.
•Only connect the cooling device as follows:
– With the DC connection cable to a DC power supply in the vehicle
– Or with the AC connection cable to the AC power supply
•Never pull the plug out of the socket by the cable.
•If the cooling device is connected to the DC outlet: Disconnect the
cooling device and other power consuming devices from the battery
before connecting a quick charging device.
•If the cooling device is connected to the DC outlet: Disconnect the
cooling device or switch it off when you turn off the engine. Otherwise
you may discharge the battery.
•The cooling device is not suitable for transporting caustic materials or
materials containing solvents.
•The insulation of the cooling device contains flammable cyclopentane
and requires special disposal procedures. Deliver the cooling device
at the end of its life-cycle to an appropriate recycling.
2.2 Operating the cooling device safely
!CAUTION!
•Before starting the cooling device, ensure that the power supply line
and the plug are dry.
ANOTICE!
•Do not use electrical devices inside the cooling device unless they are
recommended by the manufacturer for the purpose.
CF11-O-AUS.book Seite 5 Donnerstag, 14. Juni 2018 1:41 13

EN
Scope of delivery CoolFreeze
6
•Do not place the cooling device near naked flames or other heat
sources (heaters, direct sunlight, gas ovens etc.).
•Danger of overheating!
Ensure at all times that there is a minimum of 50 mm ventilation on all
four sides of the cooling device. Keep the ventilation area free of any
objects that could restrict the air flow to the cooling components.
Do not place the cooling device in closed compartments or areas with
none or minimal air flow.
•Ensure that the ventilation openings are not covered.
•Do not fill the inner compartment with ice or fluids.
•Never immerse the cooling device in water.
•Protect the cooling device and the cable against heat and moisture.
3Scopeofdelivery
•Compressor cooler
•Connection cable for DC connection
•Connection cable for AC connection
•Operating manual
•Shoulder strap
4 Intended use
The compressor cooler is suitable for refrigerating and freezing foodstuffs.
The compressor cooler has been designed for operation using a DC socket of a car
or caravan as well as an AC mains supply.
The compressor cooler can also be used for camping. The compressor cooler may
not be exposed to rain.
!CAUTION! Health hazard!
Please check if the cooling capacity of the compressor cooler is suitable
for storing the food or medicine you wish to cool.
CF11-O-AUS.book Seite 6 Donnerstag, 14. Juni 2018 1:41 13

EN
CoolFreeze Technical description
7
5 Technical description
The cooler can chill products, keep them cool as well as freeze them. A low
maintenance refrigerant circuit with compressor provides the cooling.
The cooler is portable.
For use in vehicles, the cooling device can be secured with a safety belt.
The cooler can withstand a short term inclination of 30°, for example on boats.
An integrated battery monitor can be switched on to protect your vehicle battery
from discharging to dangerously low levels (see chapter “Using the battery monitor”
on page 13).
5.1 Operating and display elements
Control panel
Item Description Explanation
1 ON/OFF button Switches the cooling device on or off when the button is
pressed for between one and two seconds
2 POWER Operating display
LED lights up green Compressor is on; set
temperature not yet reached
LED lights up orange Set temperature has been
reached
LED flashes orange Voltage is too low
3 ERROR LED flashes red Device is switched on but
not ready for operation
POWER
FRIDGE FREEZER
ERROR
12 34 5 6 7
1
CF11-O-AUS.book Seite 7 Donnerstag, 14. Juni 2018 1:41 13

EN
Technical description CoolFreeze
8
Connection sockets
4 SET Selects the input mode
•Setting the temperature
•Set temperature unit (°Celsius or °Fahrenheit)
•Set the battery monitor
5 Display Displays the temperature in the refrigerator compartment
The first three digits of the four-digit display show the tem-
perature, the fourth digit indicates the temperature unit
(°C or °F).
When an error occurs, the display shows “Err1” or “Err2”.
6 + Press once to increase the selected value
7 – Press once to decrease the selected value
Item Description
1 AC voltage supply inlet
2 AC fuse holder
3 DC voltage supply inlet
Item Description Explanation
2
100-240V~AC
FUSE
12/24V DC
12 3
CF11-O-AUS.book Seite 8 Donnerstag, 14. Juni 2018 1:41 13

EN
CoolFreeze Operation
9
6Operation
The cooling device is equipped with an LED interior light that remains on when the
voltage is applied. The energy consumption of the LED interior light is extremely low
and is negligible compared to the total energy consumption of the device.
6.1 Before initial use
I
6.2 Energy saving tips
•Choose a well ventilated location which is protected from direct sunlight.
•Allow warm food to cool down first before placing it in the device to keep cool.
•Do not open the cooling device more often than necessary.
•Do not leave the lid open for longer than necessary.
•Defrost the cooling device as soon as a layer of ice forms.
•Avoid unnecessarily low temperature settings.
6.3 Latching the lid
➤Close the lid.
➤Press the latch (fig. 31,page 9) down, until it latches in place audibly.
NOTE
Before starting your new cooler for the first time, you should clean it
inside and outside with a damp cloth for hygienic reasons (see also
chapter “Cleaning and maintenance” on page 16).
3
1
CF11-O-AUS.book Seite 9 Donnerstag, 14. Juni 2018 1:41 13

EN
Operation CoolFreeze
10
6.4 Connecting the cooling device
The cooler can be operated with 12 Vgor 24 Vgor 100 – 240 Vw.
A
➤Place the cooler on a firm base.
Make sure that the ventilation slots are not covered and that the heated air can be
dissipated.
Using the fused DC plug
A
I
NOTICE! Danger of Damage!
•Disconnect the cooler and other consumer units from the battery
before you connect the battery to a quick charging device.
•Overvoltage can damage the electronics of the device.
NOTICE! Danger of damage!
For protection ofthe device the DC cable supplied includes a fuse inside
the plug. Do not remove the fused DC plug.
Only use the DC cable supplied.
NOTE
If you connect the cooler to the DC socket, remember that the ignition
must be turned on to supply it with power.
1
3
2
4
CF11-O-AUS.book Seite 10 Donnerstag, 14. Juni 2018 1:41 13

EN
CoolFreeze Operation
11
➤Plug the DC connection cable (fig. 42, page 10) into the DC power supply inlet
of the cooler (fig. 23, page 8).
➤Connect the DC connection cable to a DC power outlet.
Connecting to an AC power supply (e.g. at home or in the office)
D
The cooling device has a built-in multi-voltage mains adapter with a priority circuit for
connecting to an AC voltage source. The priority circuit automatically switches to
mains operation if the appliance is connected to an AC power suply, even if the DC
connection cable is still connected.
➤Plug the AC connection cable (fig. 43, page 10) into the AC power supply inlet
of the cooler (fig. 21, page 8).
➤Connect the AC connection cable to the AC power outlet.
6.5 Secure the cooling device in the vehicle
➤Open the lid of the cooling device.
➤Place the safety strap into the guide (fig. 41, page 10) of the cooling device.
➤Close the lid.
➤Engage the safety strap and tighten it.
DANGER! Danger of electrocution
•Never handle plugs and switches with wet hands or if you are
standing on a wet surface.
•If you are operating your cooler on board a boat with an AC power
supply, you must install a residual current circuit breaker between the
power supply and the cooler.
Seek advice from a trained technician.
