Dometic CDF-11 User manual

CDF11
Compressor Cooler
Operating manual . . . . . . . . . . . . . . . . . . . . .5
Glacière à compression
Notice d’utilisation . . . . . . . . . . . . . . . . . . .20
Nevera por compresor
Instrucciones de uso . . . . . . . . . . . . . . . . . .36
Geleira com compressor
Manual de instruções . . . . . . . . . . . . . . . . .52
EN
FR
ES
PT
COOLING BOXES
COOLFREEZE
CDF11-O-US.book Seite 1 Freitag, 21. April 2017 11:46 11

CDF11-O-US.book Seite 2 Freitag, 21. April 2017 11:46 11

CoolFreeze CDF11
3
EMERGENCY OVERRIDE
NORMAL USE
1
11
10 9
23 4567
8
12
1
POWER
FRIDGE FREEZER
ERROR
SET
12 34 5 6 7
2
CDF11-O-US.book Seite 3 Freitag, 21. April 2017 11:46 11

CoolFreeze CDF11
4
3
1 2 3
4
5
6
CDF11-O-US.book Seite 4 Freitag, 21. April 2017 11:46 11

EN
CoolFreeze CDF11
5
Please read this operating manual carefully before starting the device.
Keep it in a safe place for future reference. If the device is passed on to
another person, this operating manual must be handed over to the user
along with it.
The manufacturer cannot be held liable for damage resulting from improper usage
or incorrect operation.
Contents
1 Explanation of symbols. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
2 Safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
3 Intended use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
4 Scope of delivery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
5 Technical description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
6 Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
7 Cleaning and maintenance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
8 Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
9 Disposal. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
10 Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
CDF11-O-US.book Seite 5 Freitag, 21. April 2017 11:46 11

EN
Explanation of symbols CoolFreeze CDF11
6
1 Explanation of symbols
!
!
A
I
2 Safety instructions
2.1 General safety
!WARNING!
•Do not operate the device if it is visibly damaged.
•If this device's power cable is damaged, it must be replaced by the
manufacturer, customer service or a similarly qualified person in order
to prevent safety hazards.
•This device may only be repaired by qualified personnel. Improper
repairs can lead to considerable hazards.
•This device can be used by children aged 8 years or over, as well as by
persons with diminished physical, sensory or mental capacities or a
lack of experience and/or knowledge, providing they are supervised
or have been taught how to use the device safely and are aware of the
resulting risks.
•Cleaning and user maintenance must not be carried out by children
without supervision.
•Children must not play with the device.
WARNING!
Safety instruction: Failure to observe this instruction can cause fatal or
serious injury.
CAUTION!
Safety instruction: Failure to observe this instruction can lead to injury.
NOTICE!
Failure to observe this instruction can cause material damage and impair
the function of the product.
NOTE
Supplementary information for operating the product.
CDF11-O-US.book Seite 6 Freitag, 21. April 2017 11:46 11

EN
CoolFreeze CDF11 Safety instructions
7
•Children must be supervised to ensure that they do not play with the
device.
•Always keep and use the device out of the reach of children under the
age of 8 years.
•Do not store any explosive substances such as spray cans with a
flammable propellant in the device.
!CAUTION!
•Disconnect the device from the power supply
– before each cleaning and maintenance
– after every use
•Food may only be stored in its original packaging or in suitable
containers.
ANOTICE!
•Check that the voltage specification on the type plate corresponds to
that of the energy supply.
•Only connect the device to a DC plug socket in the vehicle (e. g.
cigarette lighter) with the DC cable.
•Only connect the device as follows:
– With the DC cable to a DC plug socket in the vehicle (e. g.
cigarette lighter)
– Or with the AC connection cable to the AC mains supply
•Connect the device with the AC connection cable to the AC mains
supply.
•Never pull the plug out of the socket by the cable.
•If the cooler is connected to the DC socket: Disconnect the cooler and
other power consuming devices from the battery before connecting
the quick charging device.
•If the cooler is connected to the DC socket: Disconnect the cooler or
switch it off when you turn off the engine. Otherwise you may dis-
charge the battery.
•The cooling device is not suitable for transporting caustic materials or
materials containing solvents.
•The cooling device contains inflammable cyclopentane in the
insulation. The gases in the insulation material require special disposal
procedures. Deliver the device at the end of its life-cycle to an appro-
priate recycling.
CDF11-O-US.book Seite 7 Freitag, 21. April 2017 11:46 11

EN
Safety instructions CoolFreeze CDF11
8
2.2 Operating the device safely
!CAUTION!
•Before starting the device, ensure that the power supply line and the
plug are dry.
ANOTICE!
•Do not use electrical devices inside the cooler unless they are
recommended by the manufacturer for the purpose.
•Do not place the device near naked flames or other heat sources
(heaters, direct sunlight, gas ovens etc.).
•Danger of overheating!
Ensure at all timesthat there is sufficient ventilation so that the heat that
arises during operation does not build up. Make sure that the device
is sufficiently far away from walls and other objects so that the air can
circulate.
•Ensure that the ventilation openings are not covered.
•Do not fill the inner container with ice or fluid.
•Never immerse the device in water.
•Protect the device and the cable against heat and moisture.
CDF11-O-US.book Seite 8 Freitag, 21. April 2017 11:46 11

EN
CoolFreeze CDF11 Intended use
9
3 Intended use
The cooler CDF11 (ref. no. 9600001417) is suitable for cooling and freezing
foodstuffs.
The device has been designed for use with a 12/24 Vgon-board power supply
socket of a car (cigarette lighter) or caravan.
The appliance may also be used for camping use. The appliance shall not be
exposed to rain.
I
!
4Scopeofdelivery
•Cooling device
•Connection cable for 12/24 Vgconnection
•Carry strap
5 Technical description
The cooler can chill products, keep them cool as well as freeze them. A
maintenance-free refrigerant circuit with compressor provides the cooling.
The cooler is suitable for mobile use.
When used in vehicles the cooler can be secured with the seat belt.
An integrated battery monitor can be set to protect your vehicle battery from
discharging to dangerously low levels (see chapter “Using the battery monitor” on
page 14).
If an error occurs within the interior electronics, the cooling can be kept by using an
emergency switch.
NOTE
To operate the device using a 220 – 240 Vwmains supply, we
recommend using a rectifier (accessory).
CAUTION! Health hazard!
Please check if the cooling capacity of the device is suitable for storing
the food or medicine you wish to cool.
CDF11-O-US.book Seite 9 Freitag, 21. April 2017 11:46 11

EN
Technical description CoolFreeze CDF11
10
5.1 Description of the device
Position in fig. 1, page 3
Item Description
1 Control panel
2Cupholder
3 Fixing position for seat belt
4 Interior LED light
5 Cooling compartment
6 Freezer compartment
7 Lock
8 Skid proof pad
9Handles
10 Carry strap
11 Connection socket
12 Emergency switch
CDF11-O-US.book Seite 10 Freitag, 21. April 2017 11:46 11

EN
CoolFreeze CDF11 Technical description
11
5.2 Operating and display elements
Control panel (fig. 2, page 3)
Item Description Explanation
1 On/Off button Switches the cooler on or off when the button is pressed for
between one and two seconds
2 POWER Status indication
LED lights up green Compressor is on; preset
temperature isn’t reached
yet
LED lights up orange Preset temperature is
reached
LED flashes orange Insufficient voltage
3 ERROR LED flashes red Device is switched on but
not ready for operation
4 SET Selects the input mode
•Set Temperature
•Set temperature unit (Celsius or Fahrenheit)
•Set battery monitor
5 Display Shows the temperature inside the cooling compartment
The first three digits of the four-digit display show the
temperature, the fourth digit shows the temperature unit
(°C or °F).
In case of an error the display shows the error message
“Err1” or “Err2”.
6 + Press once to increase the value
7 – Press once to decrease the value
CDF11-O-US.book Seite 11 Freitag, 21. April 2017 11:46 11

EN
Operation CoolFreeze CDF11
12
6Operation
The device is equipped with an interior LED light which remains on whenever power
is connected. The power consumption of this LED light is extremely low and
insignificant compared to the overall power consumption of the device.
6.1 Before initial use
I
6.2 Energy saving tips
•Choose a well ventilated installation location which is protected against direct
sunlight.
•Allow warm food to cool down first before placing it in the device to keep cool.
•Do not open the cooling device more often than necessary.
•Do not leave the lid open for longer than necessary.
•Defrost the cooler once a layer of ice forms.
•Avoid unnecessary low temperatures.
6.3 Locking the cooler
➤Close the lid.
➤Press the lock (fig. 17, page 3) down until it snaps in audibly.
6.4 Connecting to a cigarette lighter
I
NOTE
Before starting your new cooling device for the first time, you should
clean it inside and outside with a damp cloth for hygienic reasons
(please also refer to the chapter “Cleaning and maintenance” on
page 17).
NOTE
If you connect the device to the cigarette lighter of your vehicle,
remember that the ignition must be turned on to supply the device with
power.
CDF11-O-US.book Seite 12 Freitag, 21. April 2017 11:46 11

EN
CoolFreeze CDF11 Operation
13
6.5 Securing the cooler in the vehicle
➤Open the lid of the cooler.
➤Place the seat belt into the fixing position (fig. 13, page 3) of the cooler.
➤Close the lid.
➤Fasten the seat belt and tighten it.
6.6 Switching-on the cooler
A
The cooler can be operated with 12 V or 24 Vg.
For safety reasons the cooler is equipped with an electronic system to prevent
polarity reversal. This protects the cooler againstshort-circuiting when connecting to
a battery.
➤Place the cooler on a firm foundation.
Make sure that the ventilation slots are not covered and that the heated air can
dissipate.
➤Connect the 12/24 V connection cable to the cigarette lighter or an 12/24 V
socket in your vehicle.
I
➤Press the “ON/OFF” button (fig. 21, page 3) for three seconds.
✓The “POWER” LED (fig. 22, page 3) lights up green.
When the cooler reaches the preset temperature, the LED lights up orange.
NOTICE! Danger of damaging the device!
•Ensure at all times that there is sufficient ventilation so that the
heat that generated during operation can dissipate. Ensure that
the ventilation slots are not covered. Make sure that the device
is sufficiently far away from walls and other objects so that the air can
circulate.
•Ensure that the only those objects are placed in the cooler that are
intended to be cooled at the selected temperature.
•Disconnect the cooler and other consumer units from the battery
before you connect the battery to a quick charging device.
Overvoltage can damage the electronics of the device.
NOTE
During normal operation the emergency switch (fig. 112, page 3) has
to be set to the “Normal” position.
CDF11-O-US.book Seite 13 Freitag, 21. April 2017 11:46 11

EN
Operation CoolFreeze CDF11
14
✓The display (fig. 25, page 3) switches on and shows the current cooling
temperature.
✓The cooler starts cooling the interior.
6.7 Setting the temperature
➤Press the “SET” button (fig. 24, page 3) once.
➤Use the “+” (fig. 26, page 3) and “–” (fig. 27, page 3) buttons to select the
cooling temperature.
✓The cooling temperature appears in the display for a few seconds. The display
flashes several times and then the current temperature is displayed again.
6.8 Selecting the temperature units
You can switch the temperature display between Celsius and Fahrenheit. This is how
to do it:
➤Switch on the cooler.
➤Press the “SET” button (fig. 24, page 3) twice.
➤Use the “+” (fig. 26, page 3) and “–” (fig. 27, page 3) buttons to select
Celsius or Fahrenheit.
✓The selected temperature units then appear in the display for a few seconds. The
display flashes several times before it returns to the current temperature.
6.9 Using the battery monitor
A
The device is equipped with a multi-level battery monitor that protects your vehicle
battery against excessive discharging when the device is connected to the on-board
12/24 V supply.
If the cooler is operated when the vehicle ignition is switched off, the cooler switches
off automatically as soon as the supply voltage falls below a set level. The cooler will
switch back on once the battery has been recharged to the restart voltage level.
NOTICE! Danger of damage!
When switched off by the battery monitor, the battery will no longer be
fully charged. Avoid starting repeatedly or operating current consumers
without longer charging phases. Ensure that the battery is recharged.
CDF11-O-US.book Seite 14 Freitag, 21. April 2017 11:46 11

EN
CoolFreeze CDF11 Operation
15
I
In “HIGH” mode, the battery monitor responds faster than at the levels “LOW” and
“MED” (see the following table).
This is how to select the battery monitor mode:
➤Switch on the cooler.
➤Press the “SET” button (fig. 24, page 3) three times.
➤Use the “+” (fig. 26, page 3) and “–” (fig. 27, page 3) buttons to select the
battery monitor mode.
✓The selected mode then appears in the display for a few seconds. The display
flashes several times before it returns to the current temperature.
I
NOTE
When switched off by thebattery monitor due to low voltage the display
(fig. 25, page 3) goes blankand the “POWER”LED (fig. 22,page 3)
flashes orange.
Battery monitor mode LOW MED HIGH
Switch-off voltage at 12 V 10.1 V 11.4 V 11.8 V
Restart voltage at 12 V 11.1 V 12.2 V 12.6 V
Switch-off voltage at 24 V 21.5 V 24.1 V 24.6 V
Restart voltage at 24 V 23.0 V 25.3 V 26.2 V
NOTE
When the cooler is supplied by the starter battery, select the battery
monitor mode “HIGH”. If the cooler is connected to a supply battery,
the battery monitor mode “LOW” will suffice.
If you wish to operate the cooler from the AC mains, set the battery
monitor to the “LOW” position.
CDF11-O-US.book Seite 15 Freitag, 21. April 2017 11:46 11

EN
Operation CoolFreeze CDF11
16
6.10 Using the emergency switch
The device is equipped with an emergency switch. Thus you can keep cooling if an
error occurs within the interior electronics.
I
➤If the interior electronics fail: Slide the emergency switch to the “Emergency”
position.
6.11 Switching off the cooler
➤Empty the cooler.
➤Switch the cooler off: Press the “ON/OFF” button (fig. 21, page 3) for three
seconds.
➤Pull out the connection cable.
If you do not want to use the cooler for a longer period of time:
➤Leave the cover slightly open. This prevents odour build-up.
6.12 Defrosting the cooler
Humidity can form frost in the interior of the cooling device or on the vaporiser. This
reduces the cooling capacity.
Defrost the device in good time to avoid this.
A
To defrost the cooler, proceed as follows:
➤Take out the contents of the cooling device.
➤If necessary, place them in another cooling device to keep them cool.
➤Switch off the device.
➤Leave the cover open.
➤Wipe off the defrosted water.
NOTE
During normal operation the emergency switch (fig. 112, page 3) has
to be set to the “Normal” position.
NOTICE! Danger of damaging the device!
Never use hard or pointed tools to remove ice or to loosen objects
which have frozen in place.
CDF11-O-US.book Seite 16 Freitag, 21. April 2017 11:46 11

EN
CoolFreeze CDF11 Cleaning and maintenance
17
6.13 Replacing the plug fuse (12/24 V)
➤Pull the adapter sleeve (fig. 34, page 4) off of the plug.
➤Unscrew the screw (fig. 35, page 4) out of the upper half of the housing
(fig. 36, page 4).
➤Carefully raise the upper half of the housing from the lower (fig. 31, page 4)
half.
➤Take out the contact pin (fig. 33, page 4).
➤Replace the defective fuse (fig. 32, page 4) with a new one that has the same
rating (T8A 32V).
➤Re-assemble the plug in the reverse order.
7 Cleaning and maintenance
!
A
➤Occasionally clean the device interior and exterior with a damp cloth.
➤Make sure that the air inlet and outlet vents on the device are free of any dust and
dirt, so that heat can be released and the device is not damaged.
WARNING!
Always disconnect the device from the power supply before you clean
and service it.
NOTICE! Risk of damage
•Never clean the cooler under running water or in dish water.
•Do not use abrasive cleaning agents or hard objects during cleaning
as these can damage the cooler.
CDF11-O-US.book Seite 17 Freitag, 21. April 2017 11:46 11

EN
Troubleshooting CoolFreeze CDF11
18
8 Troubleshooting
9Disposal
➤Place the packaging material in the appropriate recycling waste bins wherever
possible.
MIf you wish to finally dispose of the product, ask your local recycling centre
or specialist dealer for details about how to do this in accordance with the
applicable disposal regulations.
Fault Possible cause Suggested remedy
Device does not function,
“POWER” LED does not
glow.
There is no voltage
present in the
12/24 V socket
(cigarette lighter) in
your vehicle.
The ignition must be switched on in
most vehicles to apply current to the
cigarette lighter.
The device does not cool
(plug is inserted, “POWER”
LED is lit).
Defective
compressor.
This can only be repaired by an
authorised customer repair agent.
The device does not cool
(plug is inserted, “POWER”
LED flashes, the display is
blank).
The voltage present
in the 12/24 V socket
is too low.
Check the battery and charge if
necessary.
Check the wiring and connections.
When operating from the
12/24 V socket (cigarette
lighter):
The ignition is on and the
device is not working and
the “POWER” LED is not lit.
Pull the plug out of the
socket and make the
following checks.
The cigarette lighter
socket is dirty. This
results in a poor
electrical contact.
If the plug of your cooler becomes
very warm in the cigarette lighter
socket, either the lighter socket must
be cleaned or the plug has not been
assembled correctly.
The fuse of the
12/24 V plug has
blown.
Replace the fuse (5 A) in the cigarette
lighter plug, see chapter “Replacing
the plug fuse (12/24 V)” on page 17.
The vehicle fuse has
blown.
Replace the vehicle’s 12/24 V socket
fuse (usually 15 A). Please refer to your
vehicle’s operating manual.
“ERROR” LED flashes and
the display shows “ERR1”
or “ERR2”.
Device is defective. This can only be repaired by an
authorised customer repair agent.
CDF11-O-US.book Seite 18 Freitag, 21. April 2017 11:46 11

EN
CoolFreeze CDF11 Technical data
19
10 Technical data
I
The refrigerant circuit contains R134a.
Contains fluorinated greenhouse gases
Hermetically sealed equipment
CDF11
Ref. no.: 9600001417
Gross capacity: 10.5 litres
Connection voltage: 12/24 Vg
Power consumption: max. 30 W
Climate class: N
Cooling capacity: +10 °C to –18 °C (+50 °F to – 0.4 °F)
Refrigerant quantity: 28 g (0.06 lbs)
CO2equivalent: 0.040 t (88.18 lbs)
Global warming potential (GWP): 1430
Dimensions: 540 x 235 x 358 mm
(21.26 in x 9.25 in x 14.09 in)
Weight: 8.2 kg (18.08 lbs)
Operating temperature range: 18 °C to 43 °C (+64.4 °F to 109.4 °F)
Testing/certification:
NOTE
At ambient temperatures above 32 °C (90 °F) the minimum temperature
cannot be achieved.
4
CDF11-O-US.book Seite 19 Freitag, 21. April 2017 11:46 11

FR
CoolFreeze CDF11
20
Veuillez lire ce manuel avec attention avant de mettre l’appareil en
service. Conservez ensuite ce manuel. En cas de passer de l’appareil,
veuillez le transmettre au nouvel acquéreur.
Le fabricant décline toute responsabilité en cas de dommages provoqués par une
utilisation non-conforme de l'appareil ou par des erreurs de manipulation.
Sommaire
1 Explication des symboles . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
2 Consignes de sécurité . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
3 Usage conforme . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
4 Contenu de la livraison . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
5 Description technique . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
6 Utilisation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
7 Entretien et nettoyage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
8 Dépannage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
9 Recyclage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
10 Caractéristiques techniques . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
CDF11-O-US.book Seite 20 Freitag, 21. April 2017 11:46 11
