Dometic MC Series User manual

MC302, MC502
Mother milk cooler
Installation and Operating Manual. . . . . . . . 9
Muttermilchkühler
Montage- und Bedienungsanleitung . . . . .30
Glacière pour lait maternel
Instructions de montage
et de service . . . . . . . . . . . . . . . . . . . . . . . . . 51
Koelkast voor moedermelk
Montagehandleiding en
gebruiksaanwijzing . . . . . . . . . . . . . . . . . . . 71
EN
DE
FR
NL
REFRIGERATION
MC SERIES
DometicMC302-MC502_IOM_4445103487_EMEA(en-de-fr-nl)_202x-xx-xx.book Seite 1 Freitag, 29. Oktober 2021 12:08 00

© 2021 Dometic Group. The visual appearance of the contents of this manual is
protected by copyright and design law. The underlying technical design and the
products contained herein may be protected by design, patent or be patent
pending. The trademarks mentioned in this manual belong to Dometic Sweden AB.
All rights are reserved.
DometicMC302-MC502_IOM_4445103487_EMEA(en-de-fr-nl)_202x-xx-xx.book Seite 2 Freitag, 29. Oktober 2021 12:08 00

MC302, MC502
3
2
1
5
7
8
6
MC302FS
MC502FS
MC302BIU
MC502BIU
3
3
4
1
5
6
7
8
431 2
2
DometicMC302-MC502_IOM_4445103487_EMEA(en-de-fr-nl)_202x-xx-xx.book Seite 3 Freitag, 29. Oktober 2021 12:08 00

MC302, MC502
4
1
2
1
1
1
2
2
2
ADCB
3
~ 50 mm
4
DometicMC302-MC502_IOM_4445103487_EMEA(en-de-fr-nl)_202x-xx-xx.book Seite 4 Freitag, 29. Oktober 2021 12:08 00

MC302, MC502
5
~ 50 mm
5
m
i
n
.
1
0
0
°
6
DometicMC302-MC502_IOM_4445103487_EMEA(en-de-fr-nl)_202x-xx-xx.book Seite 5 Freitag, 29. Oktober 2021 12:08 00

MC302, MC502
6
1.
2.
3.
7
4.
1.
1.
3.
2.
8
DometicMC302-MC502_IOM_4445103487_EMEA(en-de-fr-nl)_202x-xx-xx.book Seite 6 Freitag, 29. Oktober 2021 12:08 00

MC302, MC502
7
1
2
3
4
12
34
9
CD
AB
0
DometicMC302-MC502_IOM_4445103487_EMEA(en-de-fr-nl)_202x-xx-xx.book Seite 7 Freitag, 29. Oktober 2021 12:08 00

MC302, MC502
8
820
422 FS: 450; BIU: 440
540
580
MC302
a
MC502
948
486 FS: 494; BIU: 484
552
592
b
DometicMC302-MC502_IOM_4445103487_EMEA(en-de-fr-nl)_202x-xx-xx.book Seite 8 Freitag, 29. Oktober 2021 12:08 00

EN
MC302, MC502 Explanation of symbols
9
Please read these instructions carefully and follow all instructions,guidelines, and warnings included in this product manual in order to ensure
that you install, use, and maintain the product properly at all times. These instructions MUST stay with this product.
By using the product, you hereby confirm that you have read all instructions, guidelines, and warnings carefully and thatyou understand and
agree to abide by the terms and conditions as set forth herein. You agree to use this product only for the intended purpose and application
and in accordance with the instructions, guidelines, and warnings as set forth in this product manual as well as in accordance with all appli-
cable laws and regulations. A failure to read and follow the instructions and warnings set forth herein may result in an injury to yourself and
others, damage to your product or damage to other property in the vicinity. This product manual, including the instructions, guidelines, and
warnings, and related documentation, may be subject to changes and updates. For up-to-date product information, please visit
dometic.com.
Table of contents
1 Explanation of symbols. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
2 Safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
3 Scope of delivery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
4 Intended use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
5 Technical description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
6 Installing and connecting the refrigerator . . . . . . . . . . . . . . . . . . . . . . . . . . .16
7 Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
8 Cleaning and maintenance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
9 Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
10 Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
11 Disposal. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
12 Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
1 Explanation of symbols
D
!
DANGER!
Safety instruction: Indicates a hazardous situation that, if not avoided,
will result in death or serious injury.
WARNING!
Safety instruction: Indicates a hazardous situation that, if not avoided,
could result in death or serious injury.
DometicMC302-MC502_IOM_4445103487_EMEA(en-de-fr-nl)_202x-xx-xx.book Seite 9 Freitag, 29. Oktober 2021 12:08 00

EN
Safety instructions MC302, MC502
10
!
A
I
2 Safety instructions
2.1 General safety
!WARNING! Failure to obey these warnings could result in death
or serious injury.
Electrocution hazard
• Ensure that the refrigerator has been installed by a qualified technician
in accordance with the Dometic installation manual.
• Do not operate the refrigerator if it is visibly damaged.
• If this refrigerator's power cable is damaged, it must be replaced by
the manufacturer, service agent or a similarly qualified person in order
to prevent safety hazards.
• This refrigerator may only be repaired by qualified personnel.
Inadequate repairs may cause serious hazards.
• repairs may cause serious hazards.
• When positioning the refrigerator, ensure the supply cord is not
trapped or damaged.
• Do not locate multiple portable socket-outlets or portable power sup-
plies at the rear of the refrigerator.
Fire hazard
• The refrigerant in the refrigerant circuit is highly flammable.
In the event of any damage to the refrigerant circuit:
– Switch off the refrigerator.
– Avoid naked flames and sparks.
– Air the room well.
CAUTION!
Safety instruction: Indicates a hazardous situation that, if not avoided,
could result in minor or moderate injury.
NOTICE!
Indicates a situation that, if not avoided, can result in property damage.
NOTE
Supplementary information for operating the product.
DometicMC302-MC502_IOM_4445103487_EMEA(en-de-fr-nl)_202x-xx-xx.book Seite 10 Freitag, 29. Oktober 2021 12:08 00

EN
MC302, MC502 Safety instructions
11
• After installation, it must still be possible to disconnect the refrigerator
from the supply mains. This may be achieved by having the plug
accessible or by incorporating a switch in the fixed wiring according
to the wiring rules.
Explosion hazard
• Do not store any explosive substances, such as spray cans with
propellants, in the refrigerator.
Health hazard
• This refrigerator can be used by children aged from 8 years and above
and persons with reduced physical, sensory or mental capabilities or
lack of experience and knowledge if they have been given supervision
or instruction concerning use of the refrigerator in a safe way and
understand the hazards involved.
• Children shall not play with the refrigerator.
• Cleaning and user maintenance shall not be made by children without
supervision.
!CAUTION! Failure to obey these cautions could result in minor or
moderate injury.
Risk of crushing
• Do not put your fingers into the hinge.
ANOTICE! Damage hazard
• Check that the voltage specification on the type plate is the same as
that of the power supply.
• The refrigerator is not suitable for storing substances which are caustic
or contain solvents.
• Keep the drainage outlet clean at all times.
• Do not open the refrigerant circuit under any circumstances.
• Only carry the refrigerator upright.
2.2 Operating the refrigerator safely
DDANGER! Failure to obey these warnings will result in death or
serious injury.
Electrocution hazard
• Do not touch exposed cables with your bare hands.
DometicMC302-MC502_IOM_4445103487_EMEA(en-de-fr-nl)_202x-xx-xx.book Seite 11 Freitag, 29. Oktober 2021 12:08 00

EN
Safety instructions MC302, MC502
12
!WARNING! Failure to obey these warnings could result in death
or serious injury.
Fire hazard
• Keep the ventilation openings, in the appliance enclosure or in the
built-in structure, clear of obstruction.
• Do not use mechanical objects or other means to accelerate up the
defrosting process, other than those recommended by the manufac-
turer.
• Do not damage the refrigerant circuit.
• Do not use electrical devices in the compartments of the appliance
unless they are of the type recommended by the manufacturer.
!CAUTION! Failure to obey these cautions could result in minor or
moderate injury.
Electrocution hazard
• Before starting the refrigerator, ensure that the power supply line and
the plug are dry.
Health hazard
• Mother milk may only be stored in suitable containers.
• Opening the door for long periods can cause significant increase of
the temperature in the compartments of the refrigerator.
• Clean regularly surfaces that can come in contact with accessible
drainage systems.
• If the refrigerator is left empty for long periods:
– Switch off the refrigerator.
– Defrost the refrigerator.
– Clean and dry the refrigerator.
– Leave the door open to prevent mold developing within the
refrigerator.
ANOTICE! Damage hazard
• Do not place the refrigerator near naked flames or other heat sources
(heaters, direct sunlight, gas ovens etc.).
• Never immerse the refrigerator in water.
• Protect the refrigerator and the cable against heat and moisture.
DometicMC302-MC502_IOM_4445103487_EMEA(en-de-fr-nl)_202x-xx-xx.book Seite 12 Freitag, 29. Oktober 2021 12:08 00

EN
MC302, MC502 Scope of delivery
13
3Scopeofdelivery
4 Intended use
The mother milk cooler (also referred to as refrigerator) is designed to store mother
milk which should be stored between +1 °C and +4 °C in enclosed buildings, such
as:
• In hospitals, and health centers
•Innursinghomes
The refrigerator is not suitable for installation in caravans or mobile homes.
The refrigerator is intended to be used either as a built-in appliance or as freestand-
ing refrigeration appliance. Refer to the installation instructions.
The refrigerator is designed exclusively for cooling and storing mother milk.
• The refrigerator is not suitable for cooling and storing any foodstuff like bever-
ages, foods, and fresh foods, except of mother milk.
• The refrigerator is not suitable to freezing mother milk.
This product is only suitable for the intended purpose and application in accordance
with these instructions.
This manual provides information that is necessary for proper installation and/or
operation of the product. Poor installation and/or improper operating or mainte-
nance will result in unsatisfactory performance and a possible failure.
The manufacturer accepts no liability for any injury or damage to the product
resulting from:
• Incorrect assembly or connection, including excess voltage
• Incorrect maintenance or use of spare parts other than original spare parts
provided by the manufacturer
• Alterations to the product without express permission from the manufacturer
• Use for purposes other than those described in this manual
Quantity Description
1 Refrigerator
1 Handle
1 Installation and operating manual
DometicMC302-MC502_IOM_4445103487_EMEA(en-de-fr-nl)_202x-xx-xx.book Seite 13 Freitag, 29. Oktober 2021 12:08 00

EN
Technical description MC302, MC502
14
Dometic reserves the right to change product appearance and product
specifications.
5 Technical description
5.1 Function description
All materials used in the refrigerator are compatible for use with mother milk.
The refrigerant circuit is maintenance-free.
The refrigerator is available as freestanding version (FS) and as built-in version (BIU).
The freestanding version is intended for freestanding use. The cooling unit cover
protects the warm parts of the cooling units. The foot frame with ventilation openings
ensure sufficient ventilation. By removing the foot frame and cooling unit cover the
refrigerator can be used as a built-in version.
The built-in version is intended to be mounted into furniture. It doesn‘t have a foot
frame or cooling unit cover.
During operation at an ambient temperature of +10 °C to +35 °C, the refrigerator
can maintain an inner temperature of +1 °C to +4 °C.
The digital thermometer shows and stores the minimum and maximum inner
temperatures from the last reset so that you can check whether the mother milk has
been stored at the appropriate temperatures.
5.2 Control elements
No. in
fig. 1,
page 3
Explanation
1Doorlock
2Door
3 Digital thermometer (see fig. 2, page 3)
4 Cooling unit cover
5 Drawers
6 Interior light
DometicMC302-MC502_IOM_4445103487_EMEA(en-de-fr-nl)_202x-xx-xx.book Seite 14 Freitag, 29. Oktober 2021 12:08 00

EN
MC302, MC502 Technical description
15
Key to fig. 2, page 3
5.3 Safety thermostat
The refrigerator is fitted with a safety thermostat. This thermostat switches off the
compressor as soon as the inside temperature falls below +1 °C preventing the
mother milk from being harmed by freezing.
5.4 Rechargeable battery
In case the power supply is interrupted, the monitoring functions of the electronics
are maintained by an integrated rechargeable battery for at least 12 hours.
The battery is automatically charged if the refrigerator is connected to the mains and
switched on.
At the first starting up of the refrigerator the error message “E3” may appear. The
message will disappear as soon as the battery is charged.
If the capacity of the battery is no longer sufficient to take over the monitoring
functions the error message “E3” appears on the display.
7Fan
8 Foot frame
No. Explanation
1 Power button
2 Mute button
3 Current inner temperature
4 Minimum inner temperature
5 Reset button
6 Maximum inner temperature
7 LED (red) for alarms
8 LED (green) for power presence
No. in
fig. 1,
page 3
Explanation
DometicMC302-MC502_IOM_4445103487_EMEA(en-de-fr-nl)_202x-xx-xx.book Seite 15 Freitag, 29. Oktober 2021 12:08 00

EN
Installing and connecting the refrigerator MC302, MC502
16
A
5.5 Internal ventilation
The refrigerator is fitted with an internal ventilation.
The fan is operating when the door is closed.
A
To prevent warm outside air from being unnecessarily sucked in, the fan
automatically switches off when the door is opened.
5.6 External alarm function
There are two terminals with two floating contacts on the back of the refrigerator that
can be used to trigger an additional external alarm (acoustical or visual).
6 Installing and connecting the
refrigerator
6.1 Unpacking the refrigerator
1. Check that the packaging is not damaged.
2. Remove the cardboard packaging.
3. Check that the refrigerator is not damaged.
If you find damage on the packaging or at the refrigerator resulting from
transport, report it immediately to the transportation firm.
6.2 Installing freestanding version
Observe the following instructions when installing:
1. Install the refrigerator so that the warm air produced can easily flow away, either
upwards or to the sides.
2. Place the refrigerator at the chosen place.
NOTICE!
The battery should be precautionary replaced every 2 years. This
replacement must be carried out by qualified personnel.
NOTICE!
The airflow to the fan must never be impeded by blocking or covering
the ventilation slots.
DometicMC302-MC502_IOM_4445103487_EMEA(en-de-fr-nl)_202x-xx-xx.book Seite 16 Freitag, 29. Oktober 2021 12:08 00

EN
MC302, MC502 Installing and connecting the refrigerator
17
3. Leave the refrigerator to stand for at least four hours before you connect it to the
power supply so that the refrigerant can flow back into the compressor.
6.3 Installing built-in version
!
Observe the following instructions when installing:
• Install the refrigerator so that the warm air produced can easily flow away (either
upwards or to the front, see fig. 3, page 4).
Key to fig. 3, page 4
• Make sure that the refrigerator door is able to open at least 100°. Otherwise the
drawers cannot be used.
1. Check the dimensions of the refrigerator (fig. a, page 8 or fig. b, page 8).
2. Place the refrigerator according to fig. 4, page 4 or fig. 5, page 5.
3. Mount the refrigerator to the furniture by two screws through the fittings at the
bottom (fig. 6, page 5).
4. Leave the refrigerator to stand for at least four hours before you connect it to the
power supply so that the refrigerant can flow back into the compressor.
6.4 Connecting the refrigerator to the power supply
A
CAUTION!
Ensure the shelf is adequate to carry the total weight of the refrigerator
and the contents to be stored.
No. Explanation
1 Cold intake air
2 Hot waste air
NOTICE!
• Connect the refrigerator to a separate circuit to prevent
malfunctioning due to problems with other electrical equipment.
Never connect the refrigerator to a single socket with other electrical
equipment by means of a multi-socket.
•UK only: The refrigerator is supplied with a plug fitted with 3 A fuse.
In case this fuse has to be to changed, a 3 A ASTA approved
(BS 1362) fuse must be used.
DometicMC302-MC502_IOM_4445103487_EMEA(en-de-fr-nl)_202x-xx-xx.book Seite 17 Freitag, 29. Oktober 2021 12:08 00

EN
Operation MC302, MC502
18
1. Connect the plug of the connection cable into the AC mains.
✔The green power LED lights up (fig. 22, page 3).
2. Press the button.
✔The display turns on.
For the first two seconds the display will not show temperature values; it shows
“--.-”. Then the temperature read from the sensor is shown.
6.5 Mounting and removing the door handle
1. Mount the handle as shown (fig. 7, page 6).
2. Remove the handle as shown (fig. 8, page 6).
6.6 Installing an external alarm
Use the floating contacts at the back of the refrigerator as follows:
• The upper contacts correspond to the power fail alarm (fig. 91 and 2, page 7).
• The lower contacts correspond to the temperature alarm (fig. 93 and 4,
page 7).
A voltage between 12 V and 250 V can be connected at the contacts. The maximum
load must not exceed 8 A. The minimum power rating is 100 mA/5 V.
I
7Operation
7.1 Before first use
Before first use, clean the refrigerator inside and outside with a damp cloth for
hygienic reasons (see also chapter “Cleaning and maintenance” on page 22).
7.2 Saving energy
• Only open the mother milk cooler as often and for as long as necessary.
• For optimal energy consumption, position the shelves and drawers according to
their position on delivery.
NOTE
The external alarm signal can only be switched off by eliminating the
cause of the alarm.
DometicMC302-MC502_IOM_4445103487_EMEA(en-de-fr-nl)_202x-xx-xx.book Seite 18 Freitag, 29. Oktober 2021 12:08 00

EN
MC302, MC502 Operation
19
• On a regularly basis, make sure the door seal still fits properly.
• Clean dust and dirt from the condenser at regular intervals.
7.3 Switching on
!
• At the first starting up of the refrigerator or after switching it off for a long time the
display of the digital thermometer (fig. 2, page 3) shows the current ambient
temperature alternating with the error message „E6“.
• The alarm LED will light up but no audible alarm will sound.
• As soon as the inner temperature reaches the operating temperature range
(1 °C to 4 °C) the current temperature is shown.
1. Reset the thermometer to avoid a wrong maximum temperature value.
2. Press the button for 5 seconds.
7.4 Using the refrigerator
!
A
7.5 Display backlight in battery mode
The thermometer display has a blue backlightto make the temperature values easier
to read. The display backlight works continuously while the refrigerator is connected
to the mains.
In battery mode the display backlight will switch off after 2 minutes.
➤To activate the display backlight for 3 seconds, briefly press the button.
CAUTION!
Do not store mother milk before the E6 error code has disappeared and
the operating temperature range has been reached.
CAUTION!
Always leave some space between the refrigerated goods in the refrig-
erator to ensure efficient and even cooling. If the drawers are packed too
tightly there may be unacceptable temperature values.
NOTICE! Damage hazard
Only store heavy objects such as bottles or cans on the bottom of the
refrigerator.
DometicMC302-MC502_IOM_4445103487_EMEA(en-de-fr-nl)_202x-xx-xx.book Seite 19 Freitag, 29. Oktober 2021 12:08 00

EN
Operation MC302, MC502
20
7.6 Temperature values
I
The thermometer stores the values of the minimum and maximum inner temperature
since the last reset.
To reset these values:
➤Press the button for 5 seconds.
7.7 Setting the temperature
The refrigerator is equipped with an automatic temperature regulation function. The
temperature cannot be set.
7.8 Alarms
A
There are five special cases when alarms occur:
The alarm can be muted and unmuted:
➤Press the button.
NOTE
The temperature values are shown in °C. This cannot be changed.
NOTICE!
• If you are not able to eliminate the problem triggering the alarm,
store the refrigerated goods somewhere else as soon as possible.
• In case of power failure, the inner temperature will raise in 2 hours
(hold over time) from 2 °C to 10 °C at an ambient temperature
of 25 °C.
Alarm event Number of beeps Duration of the beeps
Temperature out of range 1 beep / 5 sec 1 sec
Power failure 1 beep / 3 sec 0.5 sec
Inner fan is blocked n.a. permanent beeping
Door open for > 20 sec
1 beep / 2 sec 1 sec
Connection problem between
display and controller
Door open for > 60 sec 2 beeps / 2 sec 0.5 sec
DometicMC302-MC502_IOM_4445103487_EMEA(en-de-fr-nl)_202x-xx-xx.book Seite 20 Freitag, 29. Oktober 2021 12:08 00
