Dometic REFRIGERATION 10-Series User manual

RMDT10.5(X)T
Absorber-refrigerator with oven
Installation Manual. . . . . . . . . . . . . . . . . . . . 15
Absorber-Kühlschrank mit Ofen
Montageanleitung. . . . . . . . . . . . . . . . . . . .32
Réfrigérateur à absorption avec
four
Instructions de montage . . . . . . . . . . . . . . .50
Absorberkoelkast met oven
Montagehandleiding . . . . . . . . . . . . . . . . .69
EN
DE
FR
NL
REFRIGERATION
10-SERIES
RMDT10_INM_WEST.book Seite 1 Montag, 1. Juni 2020 1:35 13

© 2020 Dometic Group. The visual appearance of the contents of this manual is
protected by copyright and design law. The underlying technical design and the
products contained herein may be protected by design, patent or be patent
pending. The trademarks mentioned in this manual belong to Dometic Sweden AB.
All rights are reserved.
RMDT10_INM_WEST.book Seite 2 Montag, 1. Juni 2020 1:35 13

RMDT10.5(X)T
3
NOTICE
NOTICE
d90°
RMDT10_INM_WEST.book Seite 3 Montag, 1. Juni 2020 1:35 13

RMDT10.5(X)T
4
523 mm
1566 mm
550 mm
1534 mm
523 mm
1566 mm
605 mm
1534 mm
RMDT 10.5XTRMDT 10.5T
1534 mm
605 mm
523 mm
1590 mm
1534 mm
550 mm
523 mm
1590 mm
RMDT 10.5T RMDT 10.5XT
A
B
1
RMDT10_INM_WEST.book Seite 4 Montag, 1. Juni 2020 1:35 13

RMDT10.5(X)T
5
6
2
3
4
5
1
≥55 mm
min.15 mm –
max. 25 mm
2
≥ 55 mm
≥ 90 mm
≥90 mm
≥ 55 mm
AB
3
RMDT10_INM_WEST.book Seite 5 Montag, 1. Juni 2020 1:35 13

RMDT10.5(X)T
6
≥1250 mm ≥250 mm
< 1250 mm < 250 mm
4
15 – 25 mm
> 25 mm > 25 mm
5
RMDT10_INM_WEST.book Seite 6 Montag, 1. Juni 2020 1:35 13

RMDT10.5(X)T
7
≥ 1800 mm
15 – 25 mm
1
2
6
≥ 300 mm
1 2
7
RMDT10_INM_WEST.book Seite 7 Montag, 1. Juni 2020 1:35 13

RMDT10.5(X)T
8
1
min.15 mm –
max. 25 mm
≥55 mm
8
RMDT10_INM_WEST.book Seite 8 Montag, 1. Juni 2020 1:35 13

RMDT10.5(X)T
9
A
3
1
2
B< 5 mm
5 mm – 10 mm
C
1
4
9
RMDT10_INM_WEST.book Seite 9 Montag, 1. Juni 2020 1:35 13

RMDT10.5(X)T
10
t40 mm
1
2
0
2
3
1
5
3
4
1
2
≥170 mm
≤ 1300 mm
Ø65
Ø55
≥10°
Ø3,5
a
RMDT10_INM_WEST.book Seite 10 Montag, 1. Juni 2020 1:35 13

RMDT10.5(X)T
11
1
b
3
2
1
4
c
d
e
RMDT10_INM_WEST.book Seite 11 Montag, 1. Juni 2020 1:35 13

RMDT10.5(X)T
12
1.
2.
3.
f
1
2
g
h
i
j
RMDT10_INM_WEST.book Seite 12 Montag, 1. Juni 2020 1:35 13

RMDT10.5(X)T
13
bk bn bu rd pk vt wh
EN Black Brown Blue Red Pink Violet White
DE Schwarz Braun Blau Rot Pink Violett Weiß
FR Noir Marron Bleu Rouge Rosa Violeta Blanc
NL Zwart Bruin Blauw Rood Roze Paars Wit
k
1
2
2
31
l
RMDT10_INM_WEST.book Seite 13 Montag, 1. Juni 2020 1:35 13

RMDT10.5(X)T
14
X32
X12 X13
X07
X15
X1X2
X22
X20 X17
X16
X15
X09
X30
X3
X6
2A Fuse
X4 X2
X32
wh
(
+
)
bn
(–)
vt (bu)
S+ Optional
L
L
N
N
Interface RS232
gy (gn)
86
bn(–)
bn
bn
rd (+) rd (+)
12V DC Internal
rd (+)
rd (+)
bk (-)
bk (-)
bk
bk
NTC2
ye (wh) (+)
wh
rd (+) rd (+)
NTC1
20A rd
30 87
85
D+ (wh)
rd (+)
pk (bu) (+) bk (–)
bn (–) bn (–)
wh (ye) (+)
BAD C F
E
BA
D
C
F
1
2
5
4
7
6
8
3
9
10
11
13
14
15
16
17 21
12
18
19
20
22
23 24 25
L PE N
WAGO
m
RMDT10_INM_WEST.book Seite 14 Montag, 1. Juni 2020 1:35 13

EN
RMDT10.5(X)T Explanation of symbols
15
Please read this instruction manual carefully before installation and first
use, and store it in a safe place. If you pass on the product to another
person, hand over this instruction manual along with it.
I
Table of contents
1 Explanation of symbols. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
2 Safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
3 Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
4 Installing the refrigerator-oven combination . . . . . . . . . . . . . . . . . . . . . . . . .18
5 Connecting the refrigerator-oven combination . . . . . . . . . . . . . . . . . . . . . 27
6 Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31
1 Explanation of symbols
!
!
A
I
NOTE
You can find details on the operation in the operation manual.
WARNING!
Safety instruction: Indicates a hazardous situation that, if not avoided,
could result in death or serious injury.
CAUTION!
Safety instruction: Indicates a hazardous situation that, if not avoided,
could result in minor or moderate injury.
NOTICE!
Indicates a situation that, if not avoided, can result in property damage.
NOTE
Supplementary information for operating the product.
RMDT10_INM_WEST.book Seite 15 Montag, 1. Juni 2020 1:35 13

EN
Safety instructions RMDT10.5(X)T
16
2 Safety instructions
The manufacturer accepts no liability for damage in the following cases:
• Faulty assembly or connection
• Damage to the product resulting from mechanical influences and incorrect
connection voltage
• Alterations to the product without express permission from the manufacturer
• Use for purposes other than those described in the operating manual
!WARNING! Failure to obey these warnings could result in death
or serious injury.
Explosion hazard
• Never open the absorber unit. It is under high pressure and can cause
injury if it is opened.
•Only operate the device at the pressure shown on the type plate.
Only use pressure controllers with a fixed setting which comply with
the national regulations (in Europe EN 12864).
Fire hazard
• Ensure clean and residue-free handling if silicon sealant or similar is
used. There is a risk of fire if silicone filaments come into contact with
hot parts or naked flames.
• Never use a naked flame to check the device for leaks.
• Only use propane or butane gas (not natural gas).
Health hazard
• Do not operate the device if it is visibly damaged.
• If the AC power cable for this device is damaged, it must be replaced
by the manufacturer, customer service or a similarly qualified person in
order to prevent safety hazards.
• This device may only be repaired by qualified personnel. Inadequate
repairs may cause serious hazards.
Risk of asphyxiation
• Dismantle all device doors for the disposal of the old device and leave
the shelves in the device to prevent accidental enclosure and suffoca-
tion.
RMDT10_INM_WEST.book Seite 16 Montag, 1. Juni 2020 1:35 13

EN
RMDT10.5(X)T Safety instructions
17
!CAUTION! Failure to obey these cautions could result in minor or
moderate injury.
Electrical shock
• Before starting the device, ensure that the power supply line and the
plug are dry.
Risk of crushing
• Do not put your fingers into the hinge.
ANOTICE! Damage hazard
• Only hold the device at the body of the device during transport. Never
hold the device at the absorber unit, the cooling fins, the gas pipes,
the door or the control panel.
• Make sure that the device circuit is not damaged during
transportation. The refrigerant in the device circuit is highly
flammable.
In the event of any damage to the device circuit (smell of ammonia):
– Switch off the device if applicable.
– Avoid naked flames and sparks.
– Air the room well.
• Do not install the device near naked flames or other heat sources (heat-
ers, direct sunlight, gas ovens etc.).
•Danger of overheating!
Always ensure sufficient ventilation so that the heat generated during
operation can dissipate. Make sure that the device is sufficiently far
away from walls and other objects so that the air can circulate.
• Check that the voltage specification on the type plate is the same as
that of the power supply.
• Do not open the refrigerant circuit under any circumstances.
• Only use the AC connection cable supplied to connect the device to
the AC mains.
• Only use cables with a suitable size.
• Never pull the plug out of the socket by the connection cable.
• The device may not be exposed to rain.
RMDT10_INM_WEST.book Seite 17 Montag, 1. Juni 2020 1:35 13

EN
Accessories RMDT10.5(X)T
18
3Accessories
4 Installing the refrigerator-oven
combination
I
You find the instructions manual for changing the door stop and the decorative
plate online at:
“dometic.com/manuals”.
The device is suitable for installation in:
• caravans
• motor homes
Description
Flexible gas piping
Seal for draft-proof installation for gaps of 1 – 5 mm (fig. 9B, page 9)
Seal for draft-proof installation for gaps of 5 – 10 mm (fig. 9C, page 9)
Winter cover LS300 for the ventilation grill
Adapter cable
•WAGO to CEE
•WAGO to UK
•WAGO to JST
•WAGO to MATE-N-LOK
Optional Fan Kit REF-FANKIT
Optional Battery pack Pack R10-BP for stand-alone gas operation
Frame Kit for installing the refrigerator-oven combination flush with the furniture
Optional Ø2,5/5,5 mm connector for stand-alone gas operation with a 9 Vg powerbank
NOTE
If you want to mount the refrigerator-oven combination flush with the furni-
ture (see fig. 3B, page 5), you need the optional frame kit (accesso-
ries). Consider the additional height (see fig. 1B, page 4) when
planning the installation.
RMDT10_INM_WEST.book Seite 18 Montag, 1. Juni 2020 1:35 13

EN
RMDT10.5(X)T Installing the refrigerator-oven combination
19
4.1 Preparing the installation
A
When installing the refrigerator, note the following:
• To enable the refrigerant to circulate properly, the refrigerator may not exceed an
angle of 3°.
Park the vehicle horizontally for this purpose.
• The refrigerator must be installed so that
– it is easily accessible for service work
– easy to de-install and install
– can be easily removed from the vehicle
• The refrigerator-oven combination must be installed in a recess so that it stands
firm when the vehicle is in motion. Note the dimensions in fig. 1, page 4 for this
purpose.
• The outer wall must be fitted with an air inlet vent (fig. 21, page 5) and an outlet
vent (fig. 22, page 5) with ventilation grills so that the heat generated can be
easily released to the outside:
– Air inlet vent: Fit ventilation grill as flush as possible with the base of the instal-
lation niche with a minimum cross-section of 400 cm².
– Outlet vent: fit as far above the refrigerator as possible.
– The distance between the air inlet and outlet vents must be at least 1250 mm
(fig. 4, page 6).
• If the ventilation grille of the air inlet vent cannot be installed flush to the ground,
an additional inlet vent (fig. 26, page 5) must be provided in the floor for
releasing leaked gas.
• Fit a nonflammable heat conduction plate (fig. 23, page 5) above the refriger-
ator so that the heat does not accumulate in the vehicle.
• The distance between the refrigerator and the rear wall must be at least 15 mm
but no more than 25 mm.
• A distance of more than 25 mm between the refrigerator and rear wall leads to
poor performance and increases the power consumption of the refrigerator.
Reduce the space behind the refrigerator to create adequate air inlet and outlet
ventilation (fig. 5, page 6). Use a ventilation plate, for example, to do this.
NOTICE!
• The refrigerator may not be installed in the rear of mobile homes with
the door pointing in the direction of travel without the manufac-
turer’s approval.
• Use exclusively original Dometic ventilation grills to ensure safe
operation.
RMDT10_INM_WEST.book Seite 19 Montag, 1. Juni 2020 1:35 13

EN
Installing the refrigerator-oven combination RMDT10.5(X)T
20
• If the minimum distance between the air inlet and outlet vents cannot be met, a
roof vent must be installed instead of the air outlet vent.
– The roof vent should be installed directly above the back of the refrigerator as
far as this is possible. Use an air duct (fig. 61, page 7) if you need to install
the roof vent offset; otherwise, heat will accumulate there.
– Fit a nonflammable heat conduction plate (fig. 62, page 7) above the
refrigerator so that the refrigerator does not heat up the oven.
– The distance between the air inlet vent and the roof vent must be at least
1800 mm (fig. 6, page 7).
– If a roof air conditioner is provided, the distance between the roof vent
(fig. 71, page 7) and the air outlet of the roof air conditioner (fig. 72,
page 7) must be at least 300 mm.
• The distance between the top of the oven and the ceiling must be at least 55 mm
(fig. 2, page 5).
• The distance in front of the oven between the top of the oven to the ceiling must
be at least 90 mm (fig. 3, page 5).
• The distance between the top of the oven and the flue outlet of the roof flue must
be between 250 mm and 1500 mm (fig. 4, page 6).
• If a roof flue (fig. 24, page 5) is being used: Fit a detachable panel (fig. 25,
page 5) above the oven so that you can always reach the flue pipe.
• If you do not have a roof flue: Fit a panel with a ventilation grille (fig. 81, page 8)
above the oven.
• The refrigerator-oven combination must not be installed at the side of the air inlet
and outlet vents as this leads to poor performance and increases the power con-
sumption of the refrigerator.
• The air inlet and outlet vents must not be covered by vehicle parts (such as an
open door or by installing accessories such as bicycle racks) while operating.
• Install the refrigerator-oven combination so that it is protected from excessive
heat, as this leads to poor performance and increases the power consumption of
the refrigerator.
• The refrigerator-oven combination must be installed in a draft-proof location, see
chapter “Installing the refrigerator-oven combination in a draft-proof location” on
page 21.
• The electrical installation must comply with national and local regulations.
European standards: EN 60335-1, EN 60335-2-24, EN 1648-1 and EN 1648-2.
• The gas installation must comply with national and local regulations.
European standard: EN 1949.
RMDT10_INM_WEST.book Seite 20 Montag, 1. Juni 2020 1:35 13
