ENGLISH

2
1.0 Summery of Models 3
2.0 Electronics 3
2.1 Fuzzy Lo ic 3
2.2 Fuzzy Lo ic with 2 Sensors 3
3.0 Automatic Defrost Function 4
4.0 Coolin Unit 5
5.0 Heatin Shell 5
5.1 Resistances at Heatin Elements 5
6.0 Li htin 6
7.0 Installation 8
8.0 Securin 9
9.0 Chan in the Slidin Hin e 10
10.0 Chan in the Decorative Panel 11
11.0 Automatic Door Control (ADC) 11
11.1 Mechanical ADC 11
11.2 Automatic Door Control (electrical) 13
12.0 Mountin a miniSafe 18
13.0 Storin Goods 19
14.0 Troubleshootin 20
15.0 Ener y Savin Tips 20
16.0 Technical Data 21
17.0 Wirin Dia rams 24
17.1 Refri erators without Li htin 24
17.2 Refri erators with Li htin 25
17.3 Refri erators with 55l/56l Capacity 26
18.0 HiPro Generation 27
19.0 HiPro Electronic 27
19.1 Temperature in the HiPro 27
compartment
19.2 Self-test of the electronics 28
19.3 Automatic fault analysis 28
19.4 Automatic Defrost Function 29
19.5 Coolin unit check 29
19.6 Heatin Shell 29
20.0 Li htin 30
21.0 Automatic Door Control 30
22.0 Operation intervention 30
23.0 Installation 31
24.0 Securin 31
25.0 Chan in the Slidin Hin e 31
26.0 Ener y Savin Tips 31
27.0 Manual fault analysis 32
28.0 Technical Data 32
29.0 Wirin Dia ram/ Occupancy electronics 33
TABLE OF CONTENTS

Summery of Models
Face lifting models and Greenline models are the latest generation of
miniBars/miniCools and consumes approximately 40% less energy than its
predecessors.
H 430LD H 330LD H 236LD
H 440LD H 340LD H 237LD
H 441LD H 341LD H 238LD
H 460LD H 360LD H 252LD
H 461LD H 361LD H 255LD
H 456LD/LDE H 356LD/LDE H 300LD
H 455LD H 355LD H 226LD
H 436D H 136D -
H 447D H 137D -
- EA 330/L -
- EA 355/L -
- EAW 3220 -
Changes Face-liftin models to Greenline models:
Automatic defrost -cycle and design
Changes Greenline models to Previous models: cooling unit, the heating
cartridge, lighting, insulation and electronic controls (Fuzzy Logic).
Electronics
Fuzzy Lo ic
All Greenline models and Facelifting models maintain a con-
stant temperature level which has been set at the beginning
of operation. This temperature level is controlled by
electronic intelligence in an energy-saving way.
Unlike conventional appliances, the electronic control
component does not switch on and off but controls (clocks)
the cooling units heating power in a way which does not
require system circulation to be interrupted.
The electronic controls sensor (A) is an air sensor. This means that the
sensor can react directly to the temperature inside the cooling appliance.
Fuzzy Lo ic with 2 sensors
By means of the second sensor the electronics carries out a leak detection
test. If leaks or blockages in the cooling unit are recognised the miniBar is
shut off by the electronics. The test is done after every defrost cycle
(every 24 hours).
After a Power-On- eset, the controllers software runs a self test routine to
check the function of the sensors. The result of the test is shown with the
length of the first duty-cycle of the heating element (jumper X4).
There are four different states which are shown in the following table:
3
2.0
1.0
Face lifting Greenline Models Previous Models
A
2.1
2.2

Status Duty-Cycle
both sensors o.k. 7 sec. ON
air-sensor missing/defective 9 sec. ON
evaporator-sensor missing/defective 12 sec. ON
both sensors missing/defective 15 sec. ON
If the air-sensor fails during normal operation, the software shuts down the
cooling unit in steps to 0.
In refrigerators without evaporator-sensor or if the evaporator-sensor is
defective the leakage test is not carried out.Then the new electronics works
like the previous one without leakage detection.
Automatic Defrost Function
The electronic also regulates the automatic defrosting of the refrigerator.
When the plug has been stuck to the socket the running time of the
refrigerator up to the first defrostin is 15 hours for reenline models
and 39 hours for the new face lift models (RH4XX). For all models the
defrostin takes 2 hours.Then the refri erator works 22 hours and
afterwards defrosts 2 hours. Therfore the starting of the refrigerators
determines the time of defrosting.
For example: Starting at 7.00h = first defrosting 22.00h - 24.00h (for facelift
models 22.00h next day)
4
3.0
S
TT
TTTT
S
(39h)
X4, connection heatin element
Connections evaporator-sensor = Y3, Y4
Connections air-sensor = Y1, Y2
Do not chan e the
connections of the
evaporator-sensor and
the air-sensor !
Air-sensor
Evaporator-sensor
N
X1,X2,X3 = N
X5,X6 = L
In service case please pull sensor off
electrics and check by means of
measurement.
(ch. 15.0 Troubleshooting)
Ambient temperature°C esistance (kW)
0° 32,51 +/-2%
10° 19,86 +/-2%
15° 15,68 +/-2%
20° 12,48 +/-2%

5
Coolin Unit
The cooling unit has been optimised for the Greenline models and Face-
Lifting models. Unlike the cooling units of its predecessors, the Greenline
models and Face Lifting models cooling units can be replaced.
When replacin the coolin unit, however, the heatin element
(heatin shell) must be replaced as well.
Ammonia is used as a coolant. This is a natural compound also used in house
hold cleaning agents (1 litre of Salmiak cleaner contains up to 200g of
ammonia - about twice as much as is used in the refrigerator). For the safety of
hotel guests and personnel, it has been established by inspectors that the
coolant poses no threat to health.
Heatin Shell
The conventional heating element (previous models) is replaced by a hea-
ting shell. The heating shell is situated directly to the cooker tube. An optimal
efficiency ratio is achieved by means of a direct and enlarged contact area.
Measurin of resistances at heatin elements
4.0
In case service is required:
5.0
Attention please! The heating bowls upper
edge must be placed at the shown position
(142 mm).
Install the mounting clip at the centre of
the heating shell.
142 mm
esistances :
ch. 15.0 Troubleshooting
5.1
Connections N
and X4
Measure resistance...
...replace heating shell if required.
230V / 65 W heatin shell ~ 800WW
230V / 80 W heatin shell ~ 650WW
110V / 65 W heatin shell ~ 186WW
110V / 80 W heatin shell ~ 150WW

Li htin (except for RH 356LD/E, RH 456LD/E)
All Greenline and face lifting cooling appliances are equipped with sensor-
controlled lighting. The lightings sensor (proximity switch, A) is activated by
means of a magnet (B) which has been foam-installed into the door.
The lighting mechanism consists of two lamps for 180-250V operation
switched in series. For voltages of 100-140V, the lamps are switched in
parallel by means of a bridge.
A = Proximity switch
Take care when
replacin - pay
attention to correct
polarity
B = Magnet
Chan in bulbs:
6
6.0
AB
180-250V 100-140V
The proximity switch (A) is mark with a N
on the left side in front (correct polarity) .
If you chance the proximity switch please
eighth of the polarity.
A
1. Pull out the
mains plug.
2. emove the
reflector disk.
3. emove defective
bulb.
4. Insert new bulb. 5. Clip reflector disk
back in.

Li htin for RH 356LD/LDE and RH 456LD/LDE
The above models are equipped with
separate warm shelf and cooling section
lighting. This lighting mechanism consists
of:
- sensor - switch
- 1 light bulb for warm shelf
- 2 light bulb for cooling section
- Transformer (output voltage 6V)
Pay attention to country-specific vol-
tages for the transformer!
Chan in bulbs:
7
1. Pull out the
mains plug.
2. emove the
reflector disk.
3. emove the
defective bulb.
4. Insert new bulb. 5.Clip reflector disk back in.
90°
1.
2.

Installation
8
7.0
1. The refri erator must be level both directions
2. There sould be 20mm clearance to the wall
3. Ventilation must be provided as shown in
alternatives A,B,C or D
4. The ventilation duct must at least measure
105mm x the wtdth of the refri erator
5. Only the entire coolin unit must project into
the duct as shown
6 Air passin throu h the duct must not be
preheated by any source of heat
7. Ventilation rills, if used, must have openin s
of at least 200cm² each
Please follow the installation details below
carefully. Guarantee is valid for products
installed as described only.
IMPORTANT:
20mm20mm
20mm
20mm
200cm²
200cm²
200cm²
200cm²
200cm²
200cm²
200cm²
200cm²

Securin
RH 356LD/E, RH 456LD/E
RH136, RH137, RH330, EA330, RH340, RH341, RH360,
RH361, RH437, RH447, RH430, RH440, RH41, RH460,
RH461, EAW 3220
The miniBar must be screwed onto the cupboard using the lower hinges.
9
Recess dimensions in mm:
Model Hi ht Width Depth
H 430LD, H 330LD 526 388 432
H 436D, H 136D 526 388 432
EA 330L 526 388 432
H 440LD, H 340LD 558 405 466
H 447D, H 137D 558 405 466
H 441LD, H 341LD 558 405 469
H 456LD/E, H 356LD/E 662 454 523
H 460LD, H 360LD 567 490 494
H 461LD, H 361LD 567 490 494
EAW 3220 567 490 494
1. Tighten screw. 2. Put on cap.
8.0
1. Tighten screw. 2. Put on cap.
on level with furniture

Chan in the Slidin Hin e
10
9.0
1. 2.
3. 4.
Distance to cupboard door (A)
A
1. When closed, the cupboard door (A)
must not lie against the rest of the
surrounding cupboard area
(distance 1-2mm).
1.
2.
1. 2.
mm
mm
2. There must be a distance of
6-8mm between the cupboard
door and the miniBar.

Chan in the Decorative Panel
Automatic Door Control (ADC)
Mechanical ADC
Reset of automatic door control:
11
10.0
- Unscrew the 2 screws of the upper door hinge.
- Pull the door and the hinge off, away from the housing and in an upward
direction from the lower hinge pin (2-3).
- Unscrew the screws (4) and pull off the frame section (5).
- Pull the decorative panel (6) out of the door frame and push in the new
decorative panel (7) in such a way that the upper edge runs exactly
parallel to the upper section of the frame.
Put on upper section of frame (5) and re-fasten with screws (4).
- Set the door on the lower hinge, put the upper hinge in the door, guide
the door with the hinge into the hinge hole opening and screw together.
11.0
1.
The red dot has disappeared now.
Using a red dot in the display window (A, point 3), the ADC shows that
the miniBar´s door has been opened.
1.
2.
RH456LD/E All other models
A
A
2.
3. Insert ADC key and turn to the
right.
3. Insert ADC key and turn to the
left.
11.1

Chan e of the Mechanical ADC
( for RH356 / RH456 LD E)
12
11.1.1
Pin
(triggers a weight when ope-
ning the door )
ADC - component, complete
The complete component is not screwed in the doorframe but inserted. So without
removal of the door or loosing of screwings the ADC-component can be exchan-
ged.
Press in the mounting
pins and pull out the
component a little bit.
Press in the mounting pins on
the other side as well by
means of a screw driver.....
......and pull out the complete ADC.

Automatic Door Control (electrical)
(for RH356 / RH456 LD E)
When the miniBar is opened, a magnetically operated approximation switch
located underneath on the fridge is activated (FIG 1.)
Depending on the connection (opening/closing mechanism), an electric
circuit is closed or opened. Accordingly, this is registered and processed at
the hotel reception. Note: Electrical rating!
The miniBar´s wiring connection is situa-
ted at the rear of the appliance and con-
sists of a 3-pin terminal strip (1).
Installation of the Electrical Door Control
The followin miniBars could be retrofitted with an electrical
door control :
RH 330, RH 340, RH 341, RH 360, RH 361, RH 430, RH 440,
RH 441, RH 460, RH 461 with the
Service-Kit
Spare part number: 210 6821-20
Instruction 599 4722-46/9
RH355, RH356 with the
Service-Kit
Spare part number: 210 6821-30
Instruction 599 4722-59/2
The instructions are on the following pages.
13
11.2
11.2.1
1= Terminal strip
2= Approximination switch
A= blue (opening mechanism)
B= black (closing mechanism)
C= white
FIG. 1

INSTRUCTION
Retrofit Electrical Automatic Door Control
RH 330, RH340, RH 341, RH 360, RH 361
In order to retrofit the electrical automatic door control, the following service-kit with spare
part number 210 6821-20 will be required.
You can order the service-kit at:
Dometic GmbH
Export Department
In der Steinwiese 16
D-57074 Sie en
Tel.: [phone]
Fax.: [phone]
Mountin the Electrical Automatic Door Control
14
Service-kit
Spare part number: 210 6821-20
BCDE
F
A
three pieces
1. Pull out the mains
plug.
2. Unscrew the door
hinge.
3. emove the door. 4. Unscrew the middle screw
from the lower doorstrip.
5. Mount the magnet
(B) at the lower door-
strip.The magnet
should be directed
towards the inside of
the miniBar.
6. Unscrew the two
lower hinges.
7. Take the distance-
plates (A) and put
the plates under the
hinges .
8. Mount the hinges
with the distance-
plates back on place.
AA
599 4722-38/6 S 04.03.1999

15
9. Unscrew the two
feet.
10. Take two plain
washers (F) und put
the washers under
the feet.
Mount the feet
back on place.
11. Drill a hole for the
sensor, ø3mm,
depth 5mm.
12. Fix the sensor (E) with
clip (C), leveled with the
housing.
13. Mount the terminal strip (D) on the rear side
of the miniBar (Prick two holes in the rear wall
for mounting the terminal strip).
FC
E
Dcentred
10 mm
Ø 3 mm
13,5 mm
14. Lead the sensor-cable to the terminal strip and
fix the cable with scotch tape.
1= terminal strip
2= approximation switch
A= blue (opening mechanism)
B= black (closing mechanism)
C= white
15. Connect the Sensor-cable to the terminal strip.
16. Take the last plain-
washer and put it
on the lower hinge
pin.
17. Mount the door
back on place
(follow point 2 and
3 backwards).

INSTRUCTION
Retrofit Elelectrical Door Control
RH 355, RH 356
In order to retrofit the electrical door control for the above model, the following service-kit
with spare part number 210 6821-30 will be required.
You can order the service-kit at:
Electrolux GmbH
Export department
In der Steinwiese 16
D- 57074 Sie en
Tel.: [phone]
Fax.: [phone]
Mountin the Electrical Door Control
16
Service-Kit
Spare part number:
210 6821-30
ABCD
If the minibar is wellappointed with 4 feet (8mm high), replace the 4 feet with new
feet (11mm high). Spare part number 295 1182-02.
Attention! The feet are not contain in the service-kit. Order the 4 feet separately.
If the miniBar is wellappointed with feet 11mm or higher, the high for the door
control is ok.
1. Pull out the mains plug.
599 4722-62/6 S 31.03.1999
2. Mount the sensor and the magnet.
miniBar-underside
The magnet should be
directed towards the
inside of the miniBar.
Scotch tape
Position for mouning the sen-
sor (D) with the clamp (B).
Position for mounting the magnet.

17
6. Dismantle the 8 mm high feed and mount the
feet 11 mm high.
5. Connect the sensor-cables to the terminal strip.
C
4. Mount the
terminal strip (C).
miniBar - sidewall (inside)
2 x Ø2,2 drillings for mounting the terminal strip.
Only for miniBar with feed 8 mm hi h!
1= Terminal strip
2= Approximination switch
A= blue (opening mechanism)
B= black (closing mechanism)
C= white

Mountin a miniSafe in RH355LD/ RH455LD
SKE160
SKE 180
18
Drawing picture for right
hand hinge (1).
By left hand hinge, 10mm
drilling on the opposite
(2).
3 cap nuts M8
3 mushroom head square neck bolt
12.0
Fixing underside
Fixing rear side

Storin Goods
19
13.0
The statics of the miniBars is aligned
with the original condition of the
appliance. Changes, e.g. bigger door
étagères lead to static changes .
The door could be overloaded.
Any damage due to improper use is not covered by the warranty. The
warranty does not cover any modifications to the appliance or the use of
non-original Dometic parts; the warranty does not apply if the installation
and operating instructions are not adhered to and no liability shall be
entertained.
No original door étagère
used. The overloaded door
hangs crookedly and doesn't
close.
Example :

Troubleshootin
Ener y Savin Tips
At an average room temperature of approx. 22°C, it is sufficient to
operate the miniBar with an average thermostat setting.
If possible, always store pre-cooled goods.
Do not expose the miniBar to direct sunlight and do not place it close
to a source of heat.
An unobstructed air circulation in the fridge aggregate must be
ensured (ref. chapter 7.0 Installation).
When removing goods, only open the miniBar briefly.
Switch on the miniBar approx. 12 hours prior to stocking.
20
14.0
Failure : No coolin (the coolin unit at the back of the appliance is cold)
Possible Cause Fault Elimination (authorised service provider)
a.) Defective heating shell ?
b.) Defective Air and / or
Evaporator-Sensor?
c.) Defective electronic ?
d.) The appliance is in defrost
mode.
a.) Measure resistance, replace heating shell if
required.
230V / 65 W ~ 800W
230V / 80 W ~ 650W
110V / 65 W ~ 186W
110V / 80 W ~ 150W
b.) Pull sensor off electrics and check by means
of measurement.
Ambient Temperature (°C) esistance (kOhm)
0° 32,51 +/-2%
10° 19,86 +/-2%
15° 15,68 +/-2%
20° 12,48 +/-2%
c.) Plug in and measure voltage applied at
heating shell output!
After a maximum of 15 seconds, the heating
shell will be driven by mains voltage.
d.) Pull out plug and put back in again.
Failure : No coolin (the coolin unit is warm)
a.) Is the appliance level?
b.) Has sufficient ventilation been
provided ?
c.) unning time to short ?
d.) Defective cooling unit ?
e.) Light permanently on when
door closed.
a.) Level the appliance using a spirit level.
b.) See section "Installation 7.0".
c.) Leave system running for a few hours.
d.) eplace cooling unit and - if required-
refrigerator.
e.) eplace lighting sensor. Install new door, if
required.
Possible Cause Fault Elimination (authorised service provider)
15.0
