Dometic REFRIGERATION 10-Series User manual

RMDT10.5(X)T
Absorber refrigerator
Operating manual . . . . . . . . . . . . . . . . . . . . 14
Absorber-Kühlschrank
Bedienungsanleitung . . . . . . . . . . . . . . . . .42
Réfrigérateur à absorption
Notice d’utilisation . . . . . . . . . . . . . . . . . . .73
Absorptiekoelkast
Gebruiksaanwijzing. . . . . . . . . . . . . . . . . .103
EN
DE
FR
NL
REFRIGERATION
10-SERIES
RMDT10_OPM_WEST.book Seite 1 Montag, 1. Juni 2020 2:53 14

© 2020 Dometic Group. The visual appearance of the contents of this manual is
protected by copyright and design law. The underlying technical design and the
products contained herein may be protected by design, patent or be patent
pending. The trademarks mentioned in this manual belong to Dometic Sweden AB.
All rights are reserved.
RMDT10_OPM_WEST.book Seite 2 Montag, 1. Juni 2020 2:53 14

RMDT10
3
NOTICENOTICE
d90°
RMDT10_OPM_WEST.book Seite 3 Montag, 1. Juni 2020 2:53 14

RMDT10
4
1
A
2
RMDT10_OPM_WEST.book Seite 4 Montag, 1. Juni 2020 2:53 14

RMDT10
5
2 3
1
4*
3
4
1
2
RMDT10_OPM_WEST.book Seite 5 Montag, 1. Juni 2020 2:53 14

RMDT10
6
5
RMDT10_OPM_WEST.book Seite 6 Montag, 1. Juni 2020 2:53 14

RMDT10
7
5.
4.
2.
3.
1.
6
1.
2.
3.
7
RMDT10_OPM_WEST.book Seite 7 Montag, 1. Juni 2020 2:53 14

RMDT10
8
1. 2.
1. 2.
8
RMDT10_OPM_WEST.book Seite 8 Montag, 1. Juni 2020 2:53 14

RMDT10
9
>3 mm
4 sec
1.
2.
1.
2.
4 – 8 h
8
RMDT10_OPM_WEST.book Seite 9 Montag, 1. Juni 2020 2:53 14

RMDT10
10
1.
2.
9
1.
BA
4x
4x
4x
4x
1.
2.
4x
2.
0
RMDT10_OPM_WEST.book Seite 10 Montag, 1. Juni 2020 2:53 14

RMDT10
11
BA
C
2.
2.
1.
1.
4x
4x
2.
4x
4x
4x
1.
a
RMDT10_OPM_WEST.book Seite 11 Montag, 1. Juni 2020 2:53 14

RMDT10
12
b
1. 2.
3.
2.
1.
AB
C
D
E
230 V
12 V
1.
2.
3.
F
G
CLICK
RMDT10_OPM_WEST.book Seite 12 Montag, 1. Juni 2020 2:53 14

RMDT10
13
523 mm
1566 mm
550 mm
1534 mm
523 mm
1566 mm
605 mm
1534 mm
RMDT 10.5XTRMDT 10.5T
1534 mm
605 mm
523 mm
1590 mm
1534 mm
550 mm
523 mm
1590 mm
RMDT 10.5T RMDT 10.5XT
A
B
c
RMDT10_OPM_WEST.book Seite 13 Montag, 1. Juni 2020 2:53 14

EN
Explanation of symbols RMDT10
14
Please read this instruction manual carefully before first use, and store it in
a safe place. If you pass on the product to another person, hand over this
instruction manual along with it.
Table of contents
1 Explanation of symbols. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
2 Safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
3 Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
4 Intended use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
5 Technical description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
6 Using the refrigerator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
7 Using the oven . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
8 Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
9 Cleaning and maintenance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
10 Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
11 Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
12 Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .41
1 Explanation of symbols
!
!
A
WARNING!
Safety instruction: Indicates a hazardous situation that, if not avoided,
could result in death or serious injury.
CAUTION!
Safety instruction: Indicates a hazardous situation that, if not avoided,
could result in minor or moderate injury.
NOTICE!
Indicates a situation that, if not avoided, can result in property damage.
RMDT10_OPM_WEST.book Seite 14 Montag, 1. Juni 2020 2:53 14

EN
RMDT10 Safety instructions
15
I
2 Safety instructions
The manufacturer accepts no liability for damage in the following cases:
• Damage to the product resulting from mechanical influences and incorrect
connection voltage
• Alterations to the product without express permission from the manufacturer
• Use for purposes other than those described in the operating manual
2.1 General safety
!WARNING! Failure to obey these warnings could result in death
or serious injury.
Electrocution hazard
• Installation and removal of the device may only be carried out by
qualified personnel.
• Do not operate the device if it is visibly damaged.
• This device may only be repaired by qualified personnel. Improper
repairs can result in considerable danger or damage to the device.
Fire hazard
• The refrigerant in the refrigerant circuit is highly flammable.
In the event of any damage to the refrigerant circuit (smell of
ammonia):
– Switch off the device.
– Avoid naked flames and sparks.
– Air the room well.
Explosion hazard
• Do not store any explosive substances, such as spray cans with
propellants, in the device.
Health hazard
• This device is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience
and knowledge, unless they have been given supervision or instruc-
tion concerning use of the device by a person responsible for their
safety.
NOTE
Supplementary information for operating the product.
RMDT10_OPM_WEST.book Seite 15 Montag, 1. Juni 2020 2:53 14

EN
Safety instructions RMDT10
16
• Cleaning and user maintenance may not be carried out by unsuper-
vised children.
• Children must be supervised to ensure that they do not play with the
device.
ANOTICE! Damage hazard
• Keep the condensation opening clean at all times.
• The device lighting may only be replaced by customer service.
• Do not use a high-pressure cleaner near the ventilation grill when
cleaning the vehicle.
• Attach the winter covers of the ventilation grille (accessories) when the
vehicle is cleaned from the outside or not used for a prolonged period
of time.
2.2 Safe operation
!CAUTION! Failure to obey these cautions could result in minor or
moderate injury.
Risk of injury
• Close and lock the device door before beginning a journey.
• The cooling aggregate at the back of the device becomes very hot
during operation. Protect yourself from coming into contact with hot
parts when removing ventilation grills.
ANOTICE! Damage hazard
• Do not use electrical devices inside the device.
• Ensure that the ventilation openings are not covered.
2.3 Safety when operating with gas
!WARNING! Failure to obey these warnings could result in death
or serious injury.
Explosion hazard
•Only operate the device at the pressure shown on the type plate.
Only use pressure controllers with a fixed setting which comply with
the national regulations.
• While driving only operate the device with gas if the vehicle manufac-
turer allows the operation of the gas system while driving (see vehi-
cle‘s manual).
RMDT10_OPM_WEST.book Seite 16 Montag, 1. Juni 2020 2:53 14

EN
RMDT10 Safety instructions
17
• Check the national requirements for operating the device with gas
during driving.
• Never operate the device with gas:
– At petrol stations
– In parking garages
– On ferries
– While transporting the caravan or mobile home with a transport
vehicle or tow truck
• Never use a naked flame to check the device for leaks.
• In case of gas odor:
– Close the gas supply cock and the valve on the cylinder.
– Open all windows and leave the room.
– Do not press an electric switch.
– Put out any naked flames.
– Have the gas system checked by a specialist.
ANOTICE! Damage hazard
• Only use propane or butane gas, not natural gas (see rating plate).
INOTE
• Ignition problems may occur at altitudes above 1000 m. Switch to a
different energy source.
2.4 Safety when operating
!CAUTION! Failure to obey these cautions could result in minor or
moderate injury.
Health hazard
• Make sure that you only put items in the device which may be chilled
at the selected temperature.
• Opening the door for long periods can cause significant increase of
the temperature in the compartments of the device.
• Food may only be stored in its original packaging or in suitable
containers.
• Store raw meat and fish in suitable containers in the device, so that it is
not in contact with or drip onto other food.
RMDT10_OPM_WEST.book Seite 17 Montag, 1. Juni 2020 2:53 14

EN
Accessories RMDT10
18
• If the device is left empty for long periods:
– Switch off the device.
– Defrost the device.
– Clean and dry the device.
– Leave the door open to prevent mould developing within the
device.
Risk of injury
• The device door or the freezer door can completely detach from the
device if used incorrectly. Push the doors closed until you hear a clear
click at the top and bottom.
• Do not lean on the open device door.
ANOTICE! Damage hazard
• If the door is not locked correctly on the opposite side, push on that
side at the top and the bottom until it locks in place.
• Only store heavy objects such as bottles or cans in the device door, in
the vegetable compartment or on the bottom shelf.
INOTE
• Ask your vehicle manufacturer if the battery management of your
vehicle shuts down the devices to protect the battery.
• Put the device door and the freezer door into the winter position if you
are not going to use the device for a longer period of time. This pre-
vents mold from forming.
• For ambient temperatures of +15 °C to +25 °C, select the average
temperature setting.
3Accessories
Description
Winter cover LS300 for the ventilation grill
Optional Fan Kit REF-FANKIT
Note: The Fan Kit can only be installed in refrigerators with software version 37 or higher
(fig. 2, page 4).
Optional Battery pack Pack R10-BP for stand-alone gas operation
Optional Ø2,5/5,5 mm connector for stand-alone gas operation with a 9 Vg powerbank
RMDT10_OPM_WEST.book Seite 18 Montag, 1. Juni 2020 2:53 14

EN
RMDT10 Intended use
19
4 Intended use
The refrigerator-oven combination is suitable for:
• Installation in caravans and motor homes
The refrigerator is suitable exclusively for:
• Cooling, deep-freezing and storing food
The refrigerator is not suitable for:
• Storing medications
• Storing corrosive substances or substances that contain solvents
• Quick-freezing food
The oven is suitable exclusively for:
• Cooking, baking and grilling food
The oven is particularly not suitable for:
•Heating
5 Technical description
The device is a combination of refrigerator and oven which are firmly screwed
together. The refrigerator and the oven can be operated independently of one
another. The oven uses the power and gas supply of the refrigerator and does not
need to be separately connected.
The refrigerator
The device is an absorption refrigerator.
The refrigerator is designed for use:
• on a DC power supply (12 V)
• on an AC power supply
• with liquefied gas (propane or butane)
The refrigerator has an automatic operating mode that selects the most economical
connected type of energy. The cooling unit operates silently.
RMDT10_OPM_WEST.book Seite 19 Montag, 1. Juni 2020 2:53 14

EN
Technical description RMDT10
20
The oven
The device is a gas-operated oven with grill function made of stainless steel.
I
Food can be cooked or baked in the oven at 130 – 230 °C. The grill function can be
switched on to warm up food evenly. The grill and the oven cannot be used at the
same time.
The gas can be ignited electronically.
5.1 Refrigerator control and display elements
The TFT display has the following operating and display elements (fig. 1A,
page 4):
NOTE
The oven uses the gas connection of the refrigerator and does not need
to be separately connected.
Symbol Description
Cooling capacity indicator
Operating with AC power
Operating with DC power
Operating with gas
Automatic mode:
In automatic mode the refrigerator automatically selects the most
economical operating mode according to the following priority:
•AC power
•DC power
•Gas
Battery:
Symbol lights up when the battery packs (optional) are inserted and
the device is in stand-alone gas mode.
Fan (optional):
Symbol lights up when die fan function is activated.
Frame heater:
Symbol lights up when the frame heater is on. The frame heater of the
ice compartment reduces condensation.
RMDT10_OPM_WEST.book Seite 20 Montag, 1. Juni 2020 2:53 14
