DongGuan Hiper Song Electronic Technology HS-BT183 User manual

Bluetooth Speaker
HS-BT183
Instruction manual
Key Specifications/Special Features:
Product name Bluetooth Speaker
Bluetooth V4.2
Transmisiion Distance 10m
Power Output 5w*2
Frequency Range 2.40-2.48GHz
Mic Sensitivity -32dB
SNR Better than +82db
Battery Capacity 1200mAh
Play-time 3-4 hours
Charging Time 3 hours
Data Transmission Up to 3Mbps
Uart Data Transmission Rate 115200bps
Function Bluetooth,USB,TF,Aux-In,Hands-free
Size 150*85*75mm;200*80*98mm
Color Brown,Red,Customized
Get the superior sound quality of the Hiper Song Wireless portable Bluetooth Speaker for
your smartphone. It looks sleek in light wood colour and will attract envious glances from
everyone who sees it. Feel the stunning bass without distortion even at high volume. The
wide range of 33 feet allows you to roam around without disturbance to the music.
FCC ID: 2ATAT-HS-BT183
DongGuan Hiper Song Electronic Technology Co., Ltd.

Retro Design - The retro design will be the envy of everyone. The classic wooden design
will look gorgeous on your desktop or home.
Dual 5W Powerful Speakers - Get superior quality sound with dual high-performance
drivers with enhanced bass in the speakers. The special bass harmonic distortion is less
than 1% to give you throbbing music at high volume.
Bluetooth v4.2 Connection - The latest Bluetooth technology gives you high-speed pairing
with a lot of devices. It connects automatically to the last device used for hassle-free
linking from even 33 ft. (10M) away so you don’t have to worry when you are extra busy.
Hands free Call - The best wire-free Bluetooth speaker for calling and receiving calls. It
has in-built microphone. Keep your hands-free and answer calls without stopping what
you are doing.
Long Battery Life - The 1200 mAh rechargeable battery will give you hours of connectivity
before needing a recharge. Get the powerful beat of music of 3-4 hours of uninterrupted
play.

1.The power switich
2.mode switch, can switch among BTS, USB, TF, Card, Line in, FM.
3.Short press for play or pause song under BT mode. USB, TF card, AUX mode and
manual search under Fm mode. Answer and end a call
Long press for full frequency automatic searching under FM mode, refuse to answer the
call
4.short press for play the previous song under BTS, TF card, and USB mode, Line in
mode, play the previous radio station under FM mode. Long press for reduces the volume
5.Short press for play the next song under BTS, TF card, and USB mode, Line in mode,
play the next radio station under FM mode. Long press for increase the volume
6.Connect 3.5mm audio playback device (PC, MP3, Phone, or CD walkman); when the
audio signal line is inserted, it does not switch automatically, press (M) key switch to AUX
mode.
7.Insert TF card to play MP3 format music. (TF card supports a maximum capacity of
32GB)
8.Insert U disk to play MP3 format music. (U disk supports a maximum capacity of 32GB)
9.Talk to the microphone can enhance the call effect
10.Red indicating lamp: charging lamp. Blue indicating lamp: Flash means that the BTS
device is not connected; slow Flash means the BTS device connects successfully
11.Charge jack, it is charging for built-in battery, when charging cable insert into USB
adaptor (5V/500mah) or computer USB port, the red LED lights will light up. When full.
The indicator does not light.
Multifunctional Dual Channel Wooden Bluetooth Speaker
Features:
* Outdoor Wirelss Speaker,built-in BT 4.2 + EDR wireless
transmission, working distance up to 10 meters.
* Support Hand-free when answer calling (with MIC)

* Compatible with most mobile
phones,computers,tablets,notebook,mp3,mp4 etc
* BT chip, clear sound and perfect quality, powerful bass and can
enjoy unfettered stereo music anytime, anywhere when you are out.
* Stereo audio transmission protocol (A2DP
V1.2/A2DP/AVRCP/HFP/HSP)
* Support playing MP3 songs stored in the TF card
* Support external 3.5mm audio input terminals of all.
* Supports rechargeable.
* High quality subwoofer super deep bass speakers,dual
loudspeakers 3D surround sound.
* Support APP output function,after being paired to the PC BT
DONGLE, you can play the computer's various audio and you can
also use the voice chat, to achieve wireless QQ, MSN, SKYPE, etc..

Bluetooth Pairing
1. Power the headphones ON. A tone will be heard, and
theheadphone LED indicator will flash RED and BLUE.
2. Set your mobile device to search for Bluetooth devices.
When it appears, select HS-BT183 from the list of found devices.
3. After a successful pairing, a tone will be heard and the head-
phone LED indicator will slowly flash BLUE.
In Bluetooth mode, playback and volume can be adjusted withthe
on-ear controls, or the controls on your paired device..
. Press the [ b ] button to pause and resume playback.,
. Press the [+ ] and [- ] buttons to skip tracks.
. Press and hold the [+ ] and [- ] buttons to adjust volume.
Connecting with a 3.5 mm Aux Cable
Plug one connector of a 3.5 mm auxiliary cable (not included)into the
3.5 mm aux input port on the bottom of the left earcup.Plug the other
connector into the audio output port on urmedia-playing device.
. ln auxiliary mode, playback and volume will be adjusted withthe
controls on your connected device.
. The headphones will automatically power OFF when a 3.5 mmaux
cable is unplugged.
FCCWarningStatement
Changesormodificationsnotexpresslyapprovedbythepartyresponsibleforcompliancecould
voidtheuser’sauthoritytooperatetheequipment.Thisequipmenthasbeentestedandfoundto
complywiththelimitsforaClassBdigitaldevice,pursuanttoPart15oftheFCCRules.These
limitsaredesignedtoprovidereasonableprotectionagainstharmfulinterferenceinaresidential
installation.Thisequipmentgeneratesusesandcanradiateradiofrequencyenergyand,ifnot
installedandusedinaccordancewiththeinstructions,maycauseharmfulinterferencetoradio
communications.However,thereisnoguaranteethatinterferencewillnotoccurinaparticular
installation.Ifthisequipmentdoescauseharmfulinterferencetoradioortelevisionreception,
whichcanbedeterminedbyturningtheequipmentoffandon,theuserisencouragedtotryto
correcttheinterferencebyoneormoreofthefollowingmeasures:
‐‐ Reorientorrelocatethereceivingantenna.
‐‐ Increasetheseparationbetweentheequipmentandreceiver.
‐‐Connecttheequipmentintoanoutletonacircuitdifferentfromthattowhichthereceiveris
connected.
‐‐ Consultthedealeroranexperiencedradio/TVtechnicianforhelp.
Thisdevicecomplieswithpart15oftheFCCRules.Operationissubjecttothefollowing
twoconditions:(1)Thisdevicemaynotcauseharmfulinterference,and
(2)thisdevicemustacceptanyinterferencereceived,includinginterferencethatmaycause
undesiredoperation.
