Donner Golden Tremolo User manual

The Golden Tremolo is inspired by the
iconic optical tremolo sound coming
from legendary US style combo amps,
giving you a deep, natural, pulsing
tremolo sound. Additional bias control is
for detailed sound character control.
Introduction
Overview
Owner’s Manual
Precautions
Power Supply
Always use a DC 9V center negative AC
adapter. Use of an adapter other than
that specified could damage the unit or
cause malfunction and pose a safety
hazard.
Always connect the AC adapter to an
AC outlet that supplies the rated voltage
required by the adapter.
Disconnect the AC adapter from the AC
outlet when during lightning storms or
not using the unit for an extended
period.
Connections
Always turn off the power before
connecting or disconnecting. Make sure
to disconnect all cables and AC adapter
before moving the unit. This will help
prevent malfunction and damages.
Environment Considerations
Avoid using the unit in any of the
following conditions that could cause
malfunction:
●Extremely hot or cold places
●Under direct sunlight
●Magnetic fields
●Near heaters and other heat sources
●Sandy or dusty places
●Places that are extremely humid or
exposed to splashing water
●Places with lots of vibrations
Electrical Interference
Devices that are very susceptible to
interference or that emits powerful
electromagnetic waves (e.g. radios and
TVs) should not be placed near this unit,
as interference could occur.
Electromagnetic interference could
cause malfunction and could corrupt or
destroy data.
Always operate this unit at a suitable
distance from these devices.
Handling
Do not apply excessive force to the
switches and other controls, exposing
the unit to strong impacts, which could
cause it to break.
Do not put foreign objects or liquids into
the unit.
Never open the case or attempt to
modify the product in any way since this
can result in damage to the unit.
Clean only with a soft, dry cloth.
●Inspired By Classics
Inspired by the iconic tremolo sound
coming from legendary US style combo
amps, the Golden Tremolo gives you a
real optical tremolo sound that is deep
and natural.
●Easy Controls, Wide Flexibilities
The Golden Tremolo features an easy-
to-use three-knob tone control: DEPTH
(effect depth), RATE (effect speed) and
BIAS (waveform bias) for using in
different scenarios. Each knob gives you
a wide control range.
●Unique Bias Control
The Golden Tremolo provides a bias
READ CAREFULLY BEFORE
PROCEEDING
Please keep this manual in a convenient
place for future reference.

Connections & Controls
knob for controlling the bias of the
pedal's optical unit, giving you access to
adjust the overall sound character. Turn
the knob up for a tighter, harder sound,
turn the knob down for a loosened,
softer sound.
● Carefully Selected Components
The Golden Tremolo is designed and
built with carefully selected components
to ensure best sound quality and road
performance. The solid Aluminum-alloy
chassis ensures touring reliability, and
True Bypass design gives you a
transparent tone.
Features
●Compact optical tremolo pedal
●100% analog circuit
●Wide range tone controls suitable for
both vintage and modern players
●True bypass provides transparent
tone
●LED indicator shows the working
state
●Enduring, light-weighted Aluminum-
alloy chassis
a
b
c
d
e
Specifications
Power Requirement: 9V DC center
negative
Current Consumption: 10mA
Dimensions: 42x93.5x52mm
Weight: 225g
a
c
d
b
www.donnerdeal.com
f
e
f
DC 9V Jack:
For power supply, use a 9-Volt DC
regulated by AC adapter, 500mA (plug
polarity is positive on the barrel and
negative in the center).
Input Jack:
1/4” mono audio jack, for connecting
guitar.
Output Jack:
1/4” mono audio jack, for connecting to
an amplifier.
DEPTH Knob:
Controls the tremolo depth.
BIAS Knob:
Controls the waveform bias for fine
tuning tremolo tone character.
SPEED Knob:
Controls the tremolo speed.
Footswitch and LED:
Tap to switch the unit on/off. The LED
will lit up when the effect is on.
g
g
g
