Donner TUTTI LOVE User manual

Tutti Love is a compact chorus pedal
perfect for guitar and bass. This all-
analog stompbox reproduces the classic
warm jazz chorus tone with a natural
wave curve.
Introduction
Overview
Owner’s Manual
Precautions
READ CAREFULLY BEFORE
PROCEEDING
Please keep this manual in a convenient
place for future reference.
Power Supply
Always use a DC 9V center negative AC
adapter. Use of an adapter other than
that specified could damage the unit or
cause malfunction and pose a safety
hazard.
Always connect the AC adapter to an
AC outlet that supplies the rated voltage
required by the adapter.
Disconnect the AC adapter from the AC
outlet when during lightning storms or
not using the unit for an extended
period.
Connections
Always turn off the power before
connecting or disconnecting. Make sure
to disconnect all cables and AC adapter
before moving the unit. This will help
prevent malfunction and damages.
Environment Considerations
Avoid using the unit in any of the
following conditions that could cause
malfunction:
●Extremely hot or cold places
●Under direct sunlight
●Magnetic fields
●Near heaters and other heat sources
●Sandy or dusty places
●Places that are extremely humid or
exposed to splashing water
●Places with lots of vibrations
Electrical Interference
Devices that are very susceptible to
interference or that emits powerful
electromagnetic waves (e.g. radios and
TVs) should not be placed near this unit,
as interference could occur.
Electromagnetic interference could
cause malfunction and could corrupt or
destroy data.
Always operate this unit at a suitable
distance from these devices.
Handling
Do not apply excessive force to the
switches and other controls, exposing
the unit to strong impacts, which could
cause it to break.
Do not put foreign objects or liquids into
the unit.
Never open the case or attempt to
modify the product in any way since this
can result in damage to the unit.
Clean only with a soft, dry cloth.
●Classic chorus sound
Featuring a pure analog design, the
Tutti Love pedal delivers the smooth,
natural chorus tones embraced by jazz,
rock, and pop artists for decades.
●Easy, flexible controls
Tutti Love offers easy in/out and an
extra LEVEL knob in addition to the
traditional DEPTH and RATE
parameters.

Connections & Controls
●Carefully selected components
The Tutti Love pedal was designed and
manufactured with quality components
to ensure exceptional sound and sturdy
performance. The aluminum alloy
casing ensures touring reliability, and
the True Bypass circuitry gives you a
transparent tone.
Features
●Convenient compact size
●True Bypass
●Rich, natural analog chorus
●True bypass provides transparent tone
●Three knob configuration for flexible
sound character
●Reliable aluminum alloy casing
a
b
c
d
e
Specifications
Power Requirement: 9V DC center
negative
Current Consumption: 11mA
Dimensions: 42x93.5x52mm
Weight: 230g
a
c
d
b
www.donnerdeal.com
f
DC 9V Jack:
For power supply, use a 9-volt DC
regulated by AC adapter, 500mA (plug
polarity is positive on the barrel and
negative in the center).
LEVEL Knob:
Adjusts the chorus volume.
DEPTH Knob:
Adjusts the chorus sound depth.
RATE Knob:
Adjusts the chorus speed.
INPUT Jack:
1/4” mono audio jack, for connecting
instrument.
OUTPUT Jack:
1/4” mono audio jack, for connecting
to an amplifier.
Footswitch and LED:
Tap to switch the unit on/off. The LED
will lit up when the effect is on.
fg
e
g
g
