DoorHan DH1500 User manual

RAPID ROLLING
DOOR OPERATOR
USER’S MANUAL
© DoorHan, 2015
SAFETY INSTRUCTIONS 3
GENERAL DESCRIPTION 3
INSTALLATION 4
WIRING 5
PACKING LIST 6
WARNING!
ONLY QUALIFIED AND EXPERIENCED TECHNICIANS SHOULD ATTEMPT
INSTALLATION OR SERVICE TO THIS UNIT, OTHERWISE, SERIOUS PER-
SONAL INJURY, DEATH, OR PROPERTY DAMAGE MAY OCCUR.
PLEASE KEEP THESE INSTRUCTIONS FOR FURTHER REFERENCE.
DH1500 DH1500 DH1500 DH1500 DH1500 DH1500 DH1500 DH1500 DH1500

2
1. SAFETY INSTRUCTIONS
It is important that you read all the following instruction:
• Read carefully this manual.
• The door operator should be installed and put into operation by qualified personnel. Otherwise, serious personal
injury or property damage may occur.
• It is necessary to install the mechanical stops on guides, in order to avoid the exit of the door from the guides.
• The operator motor may only be disengaged with the door closed. This must be carried out by specialist personnel
for maintenance purpose only.
•
Keep remote controls or button switch away from children, to prevent the door operator from being activated
involuntarily.
• Locate any fixed control: within sight of door but away from all moving parts of the door and at a height of more
than 1.4m above the ground to avoid children reaching it.
•
The operator should be switched off before repairing it or opening its cover.
•
When opening or closing the door, do not attempt to walk or drive through the door.
•
The door should only be operated when it can be observed to avoid accidents.
•
It is forbidden to use the crank, when the electric operator runs, that can cause damage of the motor. Withdraw
the crank before running the operator.
2. GENERAL DESCRIPTION
• The rapid rolling door can isolate, open quickly, provide an emergency exit, protects your environment from humidity, dust
or other external factors and saves energy.
• Main technical parameters:
Main function:
• Use soft curtain door.
• Because of operating speed, they reduce energy costs and create more comfortable working condition.
• Uses newly encoder to replace the limit switch to ensure high precision, safe and reliable.
• The control unit regulates all the necessary functions such as soft start & soft stop, open priority, automatic close.
• Wiring terminals for infrared photocell, loop detector and radar etc.
Model DH1500(DELTA Connection) （ （ DH1500S(STAR Connection)
Power supply 220V/60Hz 380V/50Hz
Motor rotation speed 2880rpm
Reduce ratio 1:30 (1:15)
Motor power 1.5kw
Rated output torque 60N.m
Electromagnetic DC99V
Output shaft aperture ￠25mm
Work duty S2-15min/ S3-50%
Environment temperature -200~+450
Dimensions 462*230*165 mm
Main unit weight 20 kg
DH1500 Rapid Rolling Door Operator
Main function:Main function:Main function:

3
3. INSTALLATION
• Check the door is in good working condition, manually open and close the door to make sure the door operates smoothly
and freely.
• Use PVC curtain door only.
• The door must be well balanced, install balance spring if necessary.
Fig.1
Fig.2
DH1500 Rapid Rolling Door Operator

4
• Make sure the door shaft which out of the door operator about 160mm.
• To install the bracket on the fix board, determine the location, mark and drill the 2 holes ( ∅11).
• Fix the bracket on the operator with 4 screws M8x16. Make sure that the bracket is plumb and lever. See Fig.2
• The bracket installation should meet the specifications as shown in figure 3
• Slot the door operator with bracket onto the door shaft (ensure correct position of the key) and screw onto the fix board with
2 bolts M10x25 and 2 nuts M10.
• Slot the encoder onto the door shaft and push it close to the door operator and screw onto the door operator with screw
M8x16.
• Tight the screw on the encoder, make sure the encoder rotates with the shaft simultaneously.
4. WIRING
Before carry out any wiring work, it is essential to disconnect the control unit from the mains supply.
Motor
Open the wiring terminal block cover, connect motor as shown in Fig.4.
Factory preset: △ Wiring (PLC Input single-phase 220V, Output three-phase 220V)
Y Wiring (PLC Input three-phase 380V, Output three-phase 380V)
Fig. 3
Fig. 4
DH1500 Rapid Rolling Door Operator

5
Electromagnet brake
Connect power wires 220V (terminal block D, N1 of control box) to yellow wires of rectifier. Connect two wires of electromagnet
to black wires. The non-excitation brake is adjust be
Manual operation
Crank
The operator is equipped with a crank, which is used for emergency lifting/lowing of the door in case of power cut. Clock wise
to open, anticlockwise to close.
Warning
• Use the crank only in emergency.
• It is forbidden to use the crank, when the electric operator runs.
Fig. 5
Fig. 6
DH1500 Rapid Rolling Door Operator

6
5. PACKING LIST
After receiving the product, you should make an unpack-inspection, in which you should check whether the product was
damaged. If you have any problem please contact our sales agent. You should find the following items in our standard packing:
No. Item Quantity
1 Door motor 1
2 Reducer 1
3 Bracket 1
4Screw and washer M8X16 4
5 Bolt M10X25 2
6 Nut M10 2
7 Key 8X80 1
8 Crank 1
9 Current rectifier 1
10 Screw and washer M5X12 1
11 User’s manual 1
DH1500 Rapid Rolling Door Operator

7
DH1500 Rapid Rolling Door Operator
