DoorKing 9411 Single Channel with Aux Relay Quick setup guide

Information Manual
Copyright 2016 DoorKing, Inc. All rights reserved.
Underground Loops and Loop Detectors
Underground Loops and Loop Detectors
DoorKing Plug-In Loop Detectors and Loop Accessories
9409 Dual Channel
9410 Single Channel
9411 Single Channel
with Aux Relay

Loop Info-Q-2-16 1
INTRODUCTION 2
SECTION 1 - HOW THE LOOP SYSTEM WORKS 4
SECTION 2 - LOOP INSTALLATION GUIDELINES 8
Underground Loop
Lead-In Wire or Cable
Loop Detector
Design Facts
2
2
2
2-3
4
4
5
5
6
6
7
8-9
10
Field of Sensitivity
Height of Detection
Field Cancellation Effect
Field Enhancement Effect
Loop Phasing
Electrically Reverse the Phase of a Loop
Loop Detection Field Interference and Loop Placement
Saw Cut Loop Guidelines
DoorKing Preformed Loop Guidelines
SECTION 3 - TYPICAL LOOP LAYOUT EXAMPLES 11
SECTION 5 - DOORKING LOOP DETECTORS AND ACCESSORIES 14
11
12
Slide Gates
Swing Gates
SECTION 4 - TROUBLESHOOTING LOOP SYSTEMS 13
13
13
13
13
Loop Diagnostics
Poor Connections
Shorted Loop Wire
Detector Adjustments

Loop Info-Q-2-16
2
INTRODUCTION
A loop detection system is a method of sensing vehicles and is typically used in automated gate applications to prevent a
gate from automatically closing on a vehicle or to automatically open the gate when a vehicle is exiting a property. Vehicle
loops can also be used to activate card readers, ticket spitters, etc. When properly installed, loops are an extremely
reliable form of vehicle detection. The loop detection system operates by creating an electrical field of sensitivity that
tunes to the surrounding environment. When a metallic object enters this electrical field, the loop detector senses a
change in the field and generates an output, usually activating a relay in a gate operator or other access control device that
controls the operation of the gate.
There are three basic components in a loop detection system:
• Underground loop
• Loop lead-in wire or cable
• Loop detector
Proper installation of the loops is essential for reliable functioning of the detector system. Most detector problems are caused
by improper loop installation! The geometry (size and shape) of the loop defines the detection zone characteristics.
• Loop size may vary and will depend on lane width, traffic patterns, and types of vehicles to be detected.
• The short leg of any loop used for vehicle detection should never be less than 18 in. The height of detection is directly
related to the length of the short leg of the loop. A general rule of thumb to follow is that the height of detection is
1/2 to 2/3 the length of the short leg of the loop.
• Normal loops (4 ft x 8 ft) are used to detect motorcycles and automobiles. Minimum size for loops to detect typical
vehicular traffic is 18 in x 48 in. It is always recommended to use a larger loop whenever possible.
• Maximum “detection height” of a loop is 3 to 4', which may be achieved with a loop measuring 6' on the short leg.
• Loops can be saw cut into concrete or asphalt. They can be placed under brick pavers and asphalt or be imbedded in a
poured concrete road surface.
Design Facts
Underground Loop
The loop is made from a continuous
piece of wire (NO SPLICES) that is
coiled around for a number of turns
in a square or rectangular pattern.
The wire is embedded into pavement
either as a preformed loop placed
prior to paving, or into a saw cut that
is cut into existing pavement. Both
ends of this wire are then extended
to the edge of the pavement.
Loop Lead-In Wire or Cable
The lead-in wire or cable extends the two
ends of the loop wire back to the loop
detector. On short runs (Loop is within ten
feet from the loop detector), the two wires
exiting the loop can be twisted together,
run in conduit to the operator and
connected directly to the loop detector.
The lead-in wire: DoorKing recommends
that lead-in wire be twisted a minimum of six turns per foot.
The lead-in cable: If additional lead-in wire is required, DoorKing recommends that you
use a shielded twisted pair (Insulated (floated) at one end and grounded at gate opera-
tor) with a direct burial rated jacket or be placed in PVC conduit. All splices must be
soldered and placed in a watertight J-box.
Loop Detector
The loop detector is the electronic
component that controls the loop
system. DoorKing offers loop detectors
(Models 9409, 9410 and 9411) that plug
directly into the gate operator control
board, eliminating the wire harness and
wiring connections other than the loop
lead-in wires. These detector boards have
a terminal strip where the loop lead-in
wire connects. There are also various
other types of standalone detectors
available on the market that can be hard
wired into the gate operator control
board.
Loop with
3 Wire Turns
Operator Chassis Ground
(See page 6 for
grounding restrictions).
Long Leg Length
Soldered Spliced Connections
in Watertight J-Box
PVC Conduit
Short Leg Length

Loop Info-Q-2-16 3
Loops that are physically adjacent to each other and operating on separate loop detectors may interfere (cross-talk) with each
other if they are operating on the same frequencies. Changing the operating frequency on one of the loop detectors can
eliminate this interference. (See page 7 for more information)
When connecting two loops to a single loop detector terminal, always connect the loops in series. If the loops are close
together, the direction of the windings should be considered. Loops physically near each other and wound in the same direction
electrically (i.e. both Clockwise or Counter-Clockwise) will cause field cancellation effects (a dead zone) between the loops. This
may be desirable when two loops (reverse loops) are placed on each side of a sliding gate. Wiring the loops in this manner will
allow the gate to slide between the two loops without causing the loops to detect the gate. If the loops are wound in electrically
opposite directions (i.e. one Clockwise and one Counter-Clockwise), field enhancement will occur between the loops, effectively
extending the field of sensitivity for the loop system. (See pages 5 and 6 for more information)
• During the construction of new installations (i.e. concrete or asphalt), a pre-formed loop may be used as an alternate to
the saw cut type. Pre-formed loops are typically encased in PVC or other durable materials to provide high reliability and
long life. Sizes may vary depending on the source of the pre-formed loop. DoorKing offers a variety of pre-formed loops
that come with 25 feet of lead-in wire. (See page 10 for more information)
• The loop will tune to its environment. Stationary or static metal objects, such as conduits, pipes, metal grates, etc., will
not affect the loop field. High voltage electrical power lines, either underground or overhead, can affect the loop field.
In addition, fluctuating electrical fields, such as heating coils, can cause loop lock-ups and false detection.
• A heavy grid of reinforcing bars (re-bar) may affect the loop field. To minimize this, DO NOT place a loop directly on the
rebar. Support the loop 1 - 2 inches above the rebar. If possible, make cuts or bends in the rebar grid directly below the
loop. Bars and electrical wires running at angles to the loop have less effect on the loop than those running parallel to the
loop wires. (See page 10 for more information)
• If a single loop is used with a long lead-in cable (500 feet or greater), it is advisable to add an additional turn in the loop.
This increases the ratio of the loop inductance to the total inductance, thereby improving loop sensitivity and overall loop
system stability.
• The inductance of the loop (in micro henries) must fall within the tuning range of the loop detector for the loop system to
operate properly. This is typically not a problem since most loop detectors have a very wide tuning range (20 - 2500
micro henries) and can accommodate most size loops.
To calculate the inductance of a loop use this formula:
Determine the Number of Wire Turns Required for Each Loop
Loop area (Sq. Ft.) - Multiply loop width by loop length.
Note: The number of turns should be increased by 1 turn if lead-in wire or cable length is 500 ft or greater.
Loop Area in Square Feet Number of Turns Required
6 - 12
12 - 60
60 - 240
6
4
3
2
( Side 1 + Side 2 + Side 3 + Side 4 )Number of Turns2 = Inductance
2
( 6 + 8 + 6 + 8 )42 = 224 Micro Henries
Example: To calculate the inductance of a typical 6 x 8 foot loop with four turns of wire:

Loop Info-Q-2-16
4
SECTION 1 - HOW THE LOOP SYSTEM WORKS
A loop sets up an inductive field, called a field of sensitivity. This field of sensitivity completely surrounds the loop wires
extending above, below, and on all sides of the loop. When a vehicle (or any metallic object) enters this field of sensitivity, the
inductance of the loop changes as more of the inductive field is disrupted by the vehicle. Once the disruption of the inductive
field is high enough, the loop detector senses this change and outputs a signal, usually in the form of a dry contact relay switch
activation.
The height of the field of sensitivity, and therefore the height of detection, is determined by the size of the loop. The height
of detection is especially important when you need to detect a high bed truck, which requires more height than a passenger car.
The height of detection above (and below) the loop is determined by the shortest leg of the loop. The height of detection is
equal to 1/2 to 2/3 the length of the SHORT LEG. For example, a four-foot by eight-foot loop will give you approximately 2-1/2
feet of detection height, whereas a six-foot by eight-foot loop will give you approximately 4-feet of detection height. The short
leg of a loop used for vehicle detection should never be shorter than 18 in. The maximum “detection height” of a loop is
6-feet on the short leg. If larger loops are used, the “detectable height” of the loop will NOT increase.
Field of Sensitivity
Height of Detection
Cutaway of Underground Loop Inductive Field of Sensitivity
Detection Height
Approx. 1 ft.
Detection Height
Approx. 3 ft.
Larger short leg needed to detect trailer height vs. car height.
Maximum Detection Height
Approx. 4 ft.
3 Turn
Saw Cut Loop
Sensitivity Field
Roadway
Short Leg
Short Leg
Long Leg
Short Leg
Long Leg
Long Leg
18” Min.
5’
6’

Loop Info-Q-2-16 5
Winding the loops in the same direction (Clockwise or Counter-Clockwise) electrically creates the effect of the electrical current
passing through the closest edges of the loops in opposite directions. Since the electrical currents are flowing in the opposite
directions, the inductive fields of sensitivity created have the same magnetic poles (North or South) toward each other. Since
“likes” repel, the fields of sensitivity are pushed up and away from each other, creating a “Dead Zone”.
• The detection field shown is a relative profile of the detection height and will vary with the size of the loops, spacing
between the loops, and the type of vehicle. The relative height over the two inside wires increases as the loops are moved
closer together and decreases as the loops are moved apart.
Field Cancellation Effect
Both loops wound counter-clockwise.
Counter-clockwise Loop Counter-clockwise Loop
Dead Zone
Inside
Wire Field Outside
Wire Field
Slide Gate
2 loops wound in the same direction repel the inside wire fields.
Slide Gate
Winding the loops in the opposite direction (Clockwise or Counter-Clockwise) electrically creates the effect of the electrical
current passing through the closest edges of the loops in the same direction. Since the electrical currents are flowing in the
same direction, the inductive fields of sensitivity created have opposite magnetic poles (North or South) toward each other.
Since “unlikes” attract, the fields of sensitivity pull towards each other, creating a larger zone of detection. Winding the loops in
electrically opposite directions could create an enhanced zone that would inhibit a slide gate from closing.
• The detection field shown is a relative profile of the detection height and will vary with the size of the loops, spacing
between the loops, and the type of vehicle. The relative height over the two inside wires decreases as the loops are
moved closer together and increases as the loops are moved apart.
Field Enhancement Effect
Loop wound
Clockwise.
Loop wound
Counter-Clockwise.
Clockwise Loop
Inside
Wire Field
Outside
Wire Field
Counter-clockwise Loop
2 loops wound in opposite directions attract the inside wire fields.
Inside Wires
Start
Finish
Start
Finish
Start
Finish
6
93
12
Inside Wires
6
93
12
Start
Finish
6
93
12
Inside Wires
Inside Wires
6
93
12

Loop Info-Q-2-16
6
Phasing loops refers to the direction that the electrical current flows through the loops, and not necessarily the physical
direction that the loop wire has been wound. For example, if two loops are installed and physically wound in a Clockwise
direction, you can reverse the electrical current through one of the loops by simply reversing the connection where the loops
are wired together. Doing this effectively changes the “electrical” direction that the loops are wound.
Electrically Reverse the Phase of a Loop
Loop 1 physically wound clockwise
Loop 2 physically wound clockwise
9410
Terminal
Reverse the loop 2
wires to reverse the
“electrical” direction
(Phase) of loop 2.
Loop 2 will then
function in a counter-
clockwise “electrical”
direction.
Note: If slide gate reverses direction during cycling without an obstruction
present (vehicle on loop), loop sensitivity fields might be attracted to each
other and sensing the gate’s movement. Electrically reversing one loop would
change the field of sensitivity allowing a “Dead Zone” for gate movement.
It was mentioned previously that when two loops are wired to the same detector terminal, they must be the same size, same
number of turns and the same distance from the gate. They must be connected in series and the direction in which each loop is
wound is important for proper door or gate operation. It is also advisable to have the loop connections accessible for mainte-
nance and repair. Route each of the loop lead-in wires all the way to the loop detector
before wiring the loops together in series for easier access to the loop connections in
future maintenance, rather than connecting them together in a water tight junction box
in the ground and running a single lead-in cable to the loop detector.
Loop Phasing
Loop lead-in wires running to loop detector.
(Must be twisted a minimum of six turns per foot)
9410
2 loops
wired in
series at
the loop
detector.
If using shielded twisted pair loop lead-in cable, ground shield at operator end ONLY.
Slide Gate
Terminal
PVC Conduit Loop 1 Wound Clockwise
Loop 2 Wound Clockwise
PVC Conduit
PVC Conduit
6
93
12
6
93
12
Operator Chassis Ground
Insulated (Floated) Shield
Loop Lead-In Cable
Watertight J-Box
Wire from Loop
Tape to keep
wires together
Tape to keep
wires together
Grounded
Shield
Connected to
Loop Detector Shielded twisted pair with a high-density polyethylene insulation.
All spliced connections must be soldered.
Do not use wire nuts or crimp connectors.
Soldered Connection

Loop Info-Q-2-16 7
Loop Detector Cross-Talk and False Calls
The actual loop operating frequency (in KHz) is a function of the frequency DIP-switches on the loop
detector. A common problem with loops are when they are positioned too close to each other and
their detection fields overlap. If the loops are on similar frequencies, this can cause “cross-talk”
between the loops and “false calls” can occur in the loop detector. Changing the frequency of one
loop (switching it’s frequency as far away from the other loop’s frequency as possible) will eliminate
the “false calls”. Switching the frequency of a loop WILL NOT affect the loop’s detection height.
Detection Field Around Loops
It is important that the loops are installed far enough away from all moving metal
objects (gate) to keep the loop’s detection fields clear. The 1/2 to 2/3 the length
of the short leg of the loop will determine a detection field limit. Do not install the
loop closer to the gate than the short leg of the loop otherwise the movement of
the gate will interfere with the loop’s detection field and the loop detector will
give a “false call” and reverse the gate’s direction in mid-cycle. A simplified
solution is to place loops AT LEAST 4 feet away from each other or the gate.
Frequency
DIP-switches
9410
L1
Reverse
Loop
Short Leg
Length
1/2 to 2/3rd Short Leg Length Detection Field
1/2 to 2/3rd Short Leg Length Detection Field
When loop detection fields do not overlap,
loop detectors can be on similar frequencies.
When loop detection fields overlap, loop detectors MUST be on
different frequencies or they will “cross-talk”. (See below)
Reverse
Loop
Slide Gate
Swing Gate
Loop Detection Field Interference and Loop Placement
Reverse
Loop
Short Leg
Length
Reverse
Loop
Shadow Loop
See page 12 for
more information.
Optional
Automatic
Exit Loop
Optional
Automatic
Exit Loop
Short Leg
Distance
Short Leg
Distance
Short Leg
Distance
or 4 ft Min.
from Gate
Drawings not to scale
or 4 ft Min.
from Gate
Loop Detection Field
Loop Detection Field Loop Detection Field
Loop Detection Field
or 4 ft Min.
from Gate

Loop Info-Q-2-16
8
SECTION 2 - LOOP INSTALLATION GUIDELINES
In order to have a loop detection system operate as a reliable, high performance system, it is necessary to pay careful attention
to the loop installation. The use of proper installation techniques and the proper type of wire can reduce frustration, aggravation,
and unnecessary service calls.
Depth of Saw Cut - The depth of the saw cut will vary depending on the number of wire turns, typically 1 1/2” for 1-3 turns and 2” for 4-6
turns. The backer rod should be at least 1 inch below the surface of the pavement. The saw cut must be free from loose debris which can
damage the wire insulation. If the saw cut is too deep, the roadway under the saw cut may crack over time, creating a possible path for water
into the road bed material. One guideline to consider would be to try not to exceed 50% of the overall pavement depth when cutting a slot for
the loop wire. Greater depth should be used in softer pavement materials to protect the loop wire against damage from surface erosion and
wear.
Shape of Loop - The loop is typically cut in a rectangle with 45° angled corners that eliminates the sharp edges that can eventually cut through
the wire insulation. DO NOT allow the rectangular saw cuts to connect in the corners or the triangular pieces that are created will eventually
break free from the roadway. Cut an exit slot with NO sharp angles for the wires where they leave the loop saw cut.
Types of Loop Wire - Moisture in the loop’s wire insulation can cause significant changes in the dielectric constant resulting in excessive loop
(frequency) drift. Choose a wire insulation that is impervious to moisture. Typically 18 AWG Cross Linked Polyethylene (XLPE) insulated
wire is used with COLD sealant because of the ease of installation. It is rated for direct underground burial which makes it very resistant
to moisture absorption and provides good abrasion resistance. 18 AWG Polyvinyl Chloride (PVC) insulation (TFFN, THHN, THWN) should
ONLY be used with HOT sealant that will encapsulate the wires and protect them from all moisture. This wire is not rated for direct under-
ground burial and will absorb moisture if not completely protected by the hot sealant. DO not use cold sealant with this type of wire because it
will not completely encapsulate the wires. Any voids in the sealant will allow moisture next to the wire insulation that can cause a loop failure
in time. Either type wire must be wound with one continuous length, No splices are allowed.
Backer Rod - The loop wires must be held securely in the bottom of the slot by means of a plastic foam type material called
“Backer Rod”. The recommended method of holding the loop wire in the slot is to use a series of one (1) inch long pieces of backer rod
spaced approximately one (1) foot apart along the entire length of the saw cut and exit slot. Make certain to press the backer rod tightly into
the slot. Use a wooden stick or other blunt instrument to avoid potential damage to the loop wire. If the backer rod is not pressed tightly into
the slot, the loop wires will be loose in the slot and can cause false calls due to vibration or sudden movement.
Cold or Hot Sealants - Cold sealant is typically preferred because it is easier to use than hot sealant. It is pliable and will “Give” with tempera-
ture changes in the type of roadway used (Typically asphalt or concrete). When properly applied, the cold sealant should completely cover the
loop wires and backer rod and level with the top of the roadway. Since the sealant forms a barrier between the wire and the environment, it is
essential that the wires are completely covered. There must be NO voids where water can collect and freeze within the slot. The freeze/thaw
cycling will eventually push the loop wires up and out of the slot where the voids exist resulting in a loop failure. Hot sealant must completely
surround the loop wires and backer rod to protect them from moisture. Very close attention must be paid with this type of installation because
any voids in the sealant can allow moisture next to the wire insulation causing a loop failure in time. Hard setting epoxies should not be used
in softer material like asphalt.
Lead-In Wire - The lead-in wire is a continuation of the loop wire (No splicing) and is typically used when the distance between the loop and
the detector is 100 ft or less. It must be tightly twisted together with a minimum of six turns per foot.
Lead-In Cable - If a lead-in cable is used (Typically for distances greater than 10 ft between the loop and the detector), it should be a shielded,
twisted pair with a high-density polyethylene insulation. The shield should be floated, left unconnected and insulated at the spliced end and
grounded to an earth ground (Operator’s ground) at the detector end. Any other grounding arrangements can cause erratic system operation.
(See page 6)
Splice Connections - 1. All splices must be soldered - do not use wire nuts or crimp connectors because the output from the loop detector to
the loop is at very low voltage. This means that there is not enough power to go through a weak connection. 2. Each splice point must be
protected with a moisture proof seal. No splices are allowed in the loop itself. Failure to observe these precautions are the two most
common causes of loop related problems.
Exit Slot - Where the loop wires leave the loop saw cut (NO sharp angles), they must be tightly twisted together with a minimum of six turns
per foot. Use tape on the twisted end to hold the wires together. This prevents false calls from movement between the wires.
After determining the size, placement and number of turns of the loop:
(See below text and illustrations on the next page)
Saw Cut Loop Guidelines

Loop Info-Q-2-16 9
Continuous length of wire (NO Splices).
Cutaway of Underground Loops
1” Foam backer rod
spaced every 1 ft in saw cut
holds wires in place.
Sealant
1/2” to 3/4” Min.
Roadway Sealant even with road surface. Sealant even with road surface.
4 Turn Loop or Greater 3 Turn Loop or Less
1” depth 1 1/2”
Typical
2”
Typical
3/16” to 1/4” Saw Cut
3/16” to 1/4” Saw Cut
Roadway
45° corner
saw cut.
45° corner
saw cut.
Straight saw cut.
Drill approx. 1/2” hole in expansion joint (If existing)
to give loop wires room to move during roadway
expansion and contraction.
Straight saw cut.
45° corner
saw cut.
Twist wire from this
point to loop detector.
Exit Slot
NO Sharp
Angles
Watertight J-Box
Sweep
Loop Lead-In Wire or Cable
to Operator in
PVC Conduit
Tape on end to hold
wires together.
Straight saw cut.
Straight saw cut.
DO NOT allow the straight saw cuts to connect in
the corners or the triangular roadway pieces that are
created will eventually break free from the roadway.
Depth will vary
depending on the
number of wire
turns.
Backer Rod
Sealant
Note: Use only sweeps for 90° conduit bends. Do not
use 90° elbows as this will make wire pulls very
difficult and can cause damage to wire insulation.
NO 90° Elbows
Sweep
Drawings not to scale
Expansion Joint (If existing)
1” foam backer rod
spaced every 1 ft. in saw cut.

Loop Info-Q-2-16
10
•The same careful attention to proper installation guidelines described for saw cut loops also apply to the installation of
DoorKing 4 ft x 8 ft preformed loops.
•Preformed loops should be imbedded 2 to 3 inches below the surface of the poured concrete pavement.
•If installed with asphalt pavement, cover the loop with 1-inch minimum of soil or sand to protect the loop from hot asphalt.
Sand and Gravel Base 1” Minimum Depth
Hold Down Stakes
Hold Down Stakes
Styrofoam Blocks
T connector
accepts 1/2”
PVC conduit.
Poured Concrete
Asphalt
2” to 3” Depth
Loop Lead-In
Wires
T connector
accepts 1/2”
PVC conduit.
Loop Lead-In
Wires
Sand and Gravel Base
Tape
• Wire mesh or reinforcement in concrete should be cut away a minimum of 6 inches from the perimeter of the loop.
DoorKing Preformed Loop Guidelines
Reinforcement wires, rebar and electrical wires
running at angles to the loop have less effect on the
loop than those running parallel to the loop wires.
1/2” PVC Conduit
6”
6”
6”
6”
Preformed Loop
Preformed Loop

Loop Info-Q-2-16 11
SECTION 3 - TYPICAL LOOP LAYOUT EXAMPLES
Slide Gates
Reverse
Loop
Gate Track
“Dead Zone”
Underground Loop Wire
Reverse
Loop
Optional
Automatic
Exit Loop
Loop Lead-In Cable Loop Lead-In Wire
Lead-In Wire
Reverse Loops
•Minimum loop size is 18 in. x 48 in. (Pages 3 and 4)
DoorKing preformed loops are 4 ft x 8 ft. (Page 10)
•Loops must be the same size, same number of turns and
same distance away from the gate. (Page 6)
•Loops must be wound in the same direction to create a
“Dead Zone”. (Page 5)
•Loops must be wired in series. (Page 6)
•Loops must be far enough away from gate to avoid gate
movement interference. (Page 7)
•Loops should to be far enough away from the exit loop to
avoid any “cross-talk” or on a different loop detector
frequency if detection fields overlap. (Page 7)
Automatic Exit Loop
•Install a separate loop detector.
•Minimum loop size is 18 in. x 48 in. (Pages 3 and 4)
DoorKing preformed loops are 4 ft x 8 ft. (Page 10)
•Normally located 20-100 feet away from the gate so
that the gate is open or opening as you drive up to it.
Typically a loop lead-in cable will need to be installed.
(Pages 2 and 6)
•Loop should to be far enough away from the reverse
loop to avoid any “cross-talk” or on a different loop
detector frequency if detection fields overlap.
(Page 7)
Loop Lead-Ins
•Wire loop lead-in should be twisted 6 turns per foot. (Pages 3 and 6)
•Use wire loop lead-ins up to 100 ft. away from operator. (Page 2)
•Use cable loop lead-in farther than 10 ft. away from operator if required. (Pages 2 and 6)
•All wire connections must be soldered between underground loop wire and
loop lead-ins. (Page 6)
•Series wired loop lead-ins should each be run to the operator before
connecting them together for easy maintenance. (Page 6)
Every slide loop installation is unique and may have specific problems that are not fully explained in this manual. DoorKing
highly recommends that the loop system is installed by a professional installer who understands loop systems and can foresee
any problems that might occur for your specific installation.
Slide gates require the use of two reversing loops wired in series to a single loop detector for maximum vehicular protection. Be
sure that the two reverse loops are properly phased so that the gate can slide through the “dead zone”. The optional automatic
exit loop requires a second loop detector.

Loop Info-Q-2-16
12
Every swing loop installation is unique and may have specific
problems that are not fully explained in this manual. DoorKing
highly recommends that the loop system is installed by a
professional installer who understands loop systems
and can foresee any problems that might occur for
your specific installation. Swing gates
typically use two reverse loops that are
installed outside the swing path of
the gate. This is necessary to avoid
the loops detecting the gate swinging
over them. This would be detected by the
loops and cause the gate to reverse.
However, this leaves a large unprotected
area.
To eliminate the unprotected area, a “shadow” loop is
installed under the swing path of the gate. The control circuit in the gate
operator will only accept inputs from the shadow loop detector when the
gate is in the full open position. Once the gate begins its closing cycle, the gate
operator ignores any input from the shadow loop detector, thereby allowing the gate to
pass over the shadow loop without reversing itself. The reverse loops and shadow loop require a two-channel loop detector.
The optional automatic exit loop requires a separate single loop detector.
Swing Gates
Unprotected
Unprotected
Area
Area
Swing Path
of Gate
Swing Path
of Gate
Reverse Loop
Reverse Loop
Shadow Loop
•Minimum loop size is 18 in. x 48 in. (Pages 3 and 4)
DoorKing preformed loops are 4 ft x 8 ft. (Page 10)
•Loop should stay inside swing path of gate.
•Loop should line up with open gate position.
•Loop should to be far enough away from the reverse loops to
avoid any “cross-talk” or on a different loop detector frequency
if detection fields overlap. (Page 7)
Reverse Loop
Optional
Automatic
Exit Loop
Reverse Loop Shadow
Loop
Loop Lead-In Wire
Primary Operator
Secondary Operator
Loop Lead-In Wires
Loop Lead-In Cable
Underground Loop Wire
Closed Gate
Position
Open Gate
Position
Primary
Operator
Secondary
Operator
Reverse Loops
•Minimum loop size is 18 in. x 48 in. (Pages 3 and 4) DoorKing preformed loops are 4 ft x 8 ft. (Page 10)
•Loops must be the same size, same number of turns and same distance away from the gate. (Page 6)
•Loops must be wired in series. (Page 6)
•Loops must be far enough away from gate to avoid gate movement interference. (Page 7)
•Loops should to be far enough away from the shadow loop and/or exit loop to avoid any “cross-talk”
or on a different loop detector frequency if detection fields overlap. (Page 7)
Automatic Exit Loop
•Install a separate loop detector.
•Minimum loop size is 18 in. x 48 in. (Pages 3 and 4)
DoorKing preformed loops are 4 ft x 8 ft. (Page 10)
•Normally located 20-100 feet away from the gate so that the gate is
open or opening as you drive up to it. Typically a loop lead-in cable
will need to be installed. (Pages 2 and 6)
•Loop should to be far enough away from the reverse loop and/or
shadow loop to avoid any “cross-talk” or on a different loop detector
frequency if detection fields overlap. (Page 7)
Loop Lead-Ins
•Wire loop lead-in should be twisted 6 turns per foot. (Pages 2 and 6)
•Use wire loop lead-ins up to 100 ft. away from operator. (Page 3)
•Use cable loop lead-in farther than 10 ft. away from operator if required. (Pages 2 and 6)
•All wire connections must be soldered between underground loop wire and loop lead-ins. (Page 6)
•Series wired loop lead-ins should each be run to the operator before
connecting them together for easy maintenance. (Page 6)

Loop Info-Q-2-16 13
SECTION 4 - TROUBLESHOOTING LOOP SYSTEM
Loop Diagnostics
Proper installation of the loops is essential for reliable functioning of the detector system. Loop detection systems, when
properly installed, will provide one of the most reliable forms of vehicle detection available. Many loop system problems are
caused by poor connections, splices, incorrect type of loop wire, or the loop wire shorting to ground all of which will cause
intermittent operation or complete failure.
DoorKing loop detectors have a provision that provides loop diagnostics, which identifies if a
problem has occurred in the detection system. The red surface mounted LED (L1) on the loop
detector will illuminate when the detector senses a vehicle presence, and will go out when the vehicle
leaves the field of sensitivity. If any problem occurs in the underground loop, lead-in cable, or in any
of the connections, this LED will go into a fault mode by flashing. If the problem is a short or an
intermittent poor connection, which corrects itself, the detector will return to normal operation,
however the LED will continue to blink until it is manually reset or until power is removed from the
system. If the LED is blinking, even if the detector is working properly, a problem exists and checks
should be made for poor connections or shorts to ground.
The loop wire shorting to ground is a very common problem. This is especially true when PVC wire
(THHN, TFFN, etc.) is used for the ground loop or a splice was made underground. These type of
problems will often cause problems when moisture is present. If there is a nick in the wire insulation, the
loop will work when the ground is dry, but when moisture is present (rain, sprinklers, morning dew, etc.),
the nick causes a short to ground. This can be checked by utilizing a megohm meter capable of testing up
to 500 megohms (500 million ohms), such as a DoorKing meter P/N 9401-045 (A typical ohms meter will
not read units as small as micro henries). Disconnect the loop wires from the loop detector. Place one of
the meter leads to the loop wire and the other to earth ground. Resistance should be greater than 100
megohms. If resistance is between 100 and 50 megohms, the wire insulation has been nicked and the
integrity of the loop is questionable. If the resistance is less than 50 megohms, the loop wire will have to
be replaced.
Poor Connections
A poor connection from the loop to the loop detector will generally cause an intermittent problem where the loop will “false call” or “lock on”.
Often a crimp connection, wire nut, or similar type connector will operate when they are originally installed, but after a period of time the wires
may corrode, or the connection will loosen. Vibrations from gate operators can cause these loose connections to be intermittent and generate
false calls, or lock up the detector. Remember, the power through the loop is very low and does not have enough power (like 110 volt
connection) to go through any type of corrosion or loose connection. Be sure that all connections are soldered.
Shorted Loop Wire
Loop Detector Adjustments
• Sensitivity sets how much moving metal must be present
for the detector to send an output.
• Sensitivity Boost increases sensitivity by a factor of ten
once a vehicle is detected. This locks in high bed trucks.
• Frequency sets the operating frequency of the loop. When
two loops are operating in close proximity to each other,
the frequency on each detector should be set differently.
The loop with the longest length of wire should be set at
the lowest frequency.
• Frequency Counter - Blinks out frequency on L1 LED when
the detector is powered up or reset button has been pressed.
9410
Manual
Reset
L1
Frequency
Sensitivity
9410
L1
20 BAD
CAUTION
MEGOHMS
40
60
100
150
200
300
400
700
ON
Megohmmeter
M500
M500
1000
ABOVE 1000
NO LIGHT
BELOW

Loop Info-Q-2-16
14
SECTION 5 - DOORKING LOOP DETECTORS AND ACCESSORIES
All loop detectors have the following features:
•Self-tuning circuitry. Automatically adjust for
different loops and changes in weather.
•Sensitivity boost automatically increases
sensitivity during detection. Prevents dropout
from high bed vehicles.
•Four frequencies available.
•Four sensitivity levels available.
•Surface mounted LED’s to indicate when
power is applied to the detector and when the
loop is triggered. 9410
L1 L1 L2
Single Channel Dual Channel
9409
Part Number Description
9410-010
9409-010
9411-010
9401-045
2600-771
2600-772
9401-060
9401-061
9401-062
Color Black Blue Red
18 AWG XLPE Loop Wire – Order by Part Number
500 Feet P/N 9402-076
P/N 9402-077
P/N 9402-078
P/N 9402-079
P/N 9402-080
P/N 9402-081
1000 Feet
Single channel plug-in detector board. Four different sensitivity and frequency settings. Sensitivity Boost
feature, frequency counter, and Fast Trak feature. Manufactured by DoorKing Inc.
Single channel with relay plug-in detector board. Four different sensitivity and frequency settings. Sensitivity
Boost feature, frequency counter, and Fast Trak feature. Connect a device to aux relay terminal (dry relay
contacts, normally open-NO or normally closed-NC) that will activate whenever the loop detector senses a
vehicle in the Loop’s detection field. Used with the 1600 barrier gate operators. Manufactured by DoorKing Inc.
Megohm meter. Checks integrity of ground loops. Reads up to 500 megohms.
Asphalt sealant, flat black, 10 oz. tube
Concrete sealant, gray, 10 oz. tube.
Two channel plug-in detector board. Four different sensitivity and frequency settings for each loop. Sensitiv-
ity Boost feature, frequency counter, and Fast Trak feature for each loop. Loop 1 output is feed directly into
control board; loop two output is via a dry contact relay. Manufactured by DoorKing Inc.
Pre-fabricated ground loop (BLUE), 24 foot circumference with 50-foot lead-in cable. Loop consist of three
turns of THHN insulated 18 AWG stranded wire enclosed in PLIOVIC tubing allowing it to be formed to the size
and shape required. A “T” connector allows the lead-in wire to be routed through a 1/2 inch PVC conduit.
Pre-fabricated ground loop (BLACK), 24 foot circumference with 50-foot lead-in cable. Loop consist of three
turns of THHN insulated 18 AWG stranded wire enclosed in PLIOVIC tubing allowing it to be formed to the size
and shape required. A “T” connector allows the lead-in wire to be routed through a 1/2 inch PVC conduit.
Pre-fabricated ground loop (RED), 24 foot circumference with 50-foot lead-in cable. Loop consist of three
turns of THHN insulated 18 AWG stranded wire enclosed in PLIOVIC tubing allowing it to be formed to the size
and shape required. A “T” connector allows the lead-in wire to be routed through a 1/2 inch PVC conduit.
Reset
Sensitivity
Frequency
9411
L1
Single Channel with Aux Relay
Reset
Aux
Relay
Sensitivity
Frequency
Reset
Sensitivity
Frequency

Information Manual
Underground Loops and Loop Detectors
Underground Loops and Loop Detectors
DoorKing Plug-In Loop Detectors and Loop Accessories
DoorKing, Inc.
120 S. Glasgow Avenue
Inglewood, California 90301
U.S.A.
Phone: [phone]
Fax: [phone]
www.doorking.com
Loop Info-P-3-10
