Doosan G20 SIIIA Manual

This manual contains
important safety information
and must be made available to
personnel who operate and
maintain this machine.
46674960_en_C_02/18
G20, 30, 40 SIIIA
OPERATION & MAINTENANCE MANUAL
Original Instruction
G20 SIIIA SERIAL No : G02030001 ->
G30 SIIIA SERIAL No : G03030001 ->
G40 SIIIA SERIAL No : G04030001 ->

3 G20, 30, 40 SIIIA Operation & Maintenance Manual
CONTENTS
FOREWORD ............................................................................................................................................ 5
GENERAL DATA .................................................................................................................................... 11
SAFETY ................................................................................................................................................. 13
OPERATING INSTRUCTIONS .............................................................................................................. 21
MAINTENANCE ..................................................................................................................................... 71
ALTERNATOR INSTALLATION & MAINTENANCE ............................................................................... 99
REFERENCE INFORMATION
Write the correct information for YOUR DIPP generator in the spaces below. Always use these numbers when
referring to your DIPP generator.
Generator Serial Number
Engine Serial Number
NOTES:
YOUR DIPP DEALER:
ADDRESS:
PHONE:

4 G20, 30, 40 SIIIA Operation & Maintenance Manual

5 G20, 30, 40 SIIIA Operation & Maintenance Manual
FOREWORD
CONTENTS
FOREWORD ........................................................................................................................................... 6
DECLARATION OF CONFORMITY ........................................................................................................ 7

6 G20, 30, 40 SIIIA Operation & Maintenance Manual
FOREWORD
The contents of this manual are considered to be
proprietary and confidential to and should not be
reproduced without the prior written permission of the
company.
Nothing contained in this document is intended to extend
any promise, warranty or representation, expressed or
implied, regarding the products described herein. Any
such warranties or other terms and conditions of sale of
products shall be in accordance with the standard terms
and conditions of sale for such products, which are
available upon request.
This manual contains instructions and technical data to
cover all routine operation and scheduled maintenance
tasks by operation & maintenance staff. Major overhauls
are outside the scope of this manual and should be
referred to an authorised service department.
The design specification of this machine has been
certified as complying with EC directives. As a result:
a) Any machine modifications are strictly prohibited, and
will invalidate EC certification.
The use of repair parts / lubricants / fluids other than
those included within the approved parts list may create
hazardous conditions over which the company has no
control. Therefore the company cannot be held
responsible for equipment in which non-approved repair
parts are installed.
The company reserves the right to make changes and
improvements to products without notice and without
incurring any obligation to make such changes or add
such improvements to products sold previously.
The intended uses of this machine are outlined below
and examples of unapproved usage are also given,
however the company cannot anticipate every application
or work situation that may arise.
IF IN DOUBT CONSULT SUPERVISION.
This machine has been designed and supplied for use
only in the following specified conditions and
applications:
•Operation within the ambient temperature range
specified in the GENERAL INFORMATION section of
this manual.
The use of the machine in any of the situation types
listed in table 1:
a) Is not approved,
b) May impair the safety of users and other persons,
and
c) May prejudice any claims made against the
company.
The company accepts no responsibility for errors in
translation of this manual from the original English
version.
© COPYRIGHT 2018
DOOSAN COMPANY
TABLE 1
Use of the machine outside the ambient temperature
range specified in the GENERAL INFORMATION
SECTION of this manual.
This machine is not intended and must not be used
in potentially explosive atmospheres, including
situations where flammable gases or vapours may
be present.
Use of the machine fitted with non approved
components / lubricants / fluids.
Use of the machine with safety or control
components missing or disabled.
Use of the machine for storage or transportation of
materials inside or on the enclosure except when
contained within the toolbox.
GENERATOR
Use of the generator to supply load(s) greater than
those specified.
Use of unsafe or unserviceable electrical equipment
connected to the generator.
Use of electrical equipment: (a) Having incorrect
voltage and / or frequency ratings. (b) Containing
computer equipment and / or similar electronics.

7 G20, 30, 40 SIIIA Operation & Maintenance Manual
DECLARATION OF CONFORMITY
1)
EC Declaration of Conformity
2)
3) We: 4) Represented in EC by:
Doosan International USA, Inc Doosan Trading Limited
1293 Glenway Drive Block B, Swords Business Campus
Statesville Swords
North Carolina 28625-9218 Co. Dublin
USA Ireland
5) Hereby declare that, under our sole responsibility the product(s)
6) Machine description: Portable Generator
7) Machine Model: G20-SIIIA, G30-SIIIA, G40-SIIIA, G60-SIIIA, G80-SIIIA, G100-SIIIA, G150-SIIIA, G200-SIIIA,
G250, G400-SIIIA, G500-SIIIA
8) Commercial name: G20-SIIIA, G30-SIIIA, G40-SIIIA, G60-SIIIA, G80-SIIIA, G100-SIIIA, G150-SIIIA, G200-SIIIA,
G250, G400-SIIIA, G500-SIIIA
9) Serial number:
10) is (are) in conformity with the relevant provisions of the following EC Directive(s)
11) 2006/42/EC The Machinery Directive
12) 2014/30/EU The Electromagnetic Compatibility Directive
13) 2000/14/EC The Noise Emission Directive
16) 97/68/EC The emission of engines for no-road mobile machinery
31) 2014/35/EU The Low Voltage Equipment Directive
17) and their amendments
18) Conformity with the Noise Emission Directive 2000/14/EC
19)
20)
22)
Type kW
22)
Type kW
G20-SIIIA
15 88,6L
WA
89L
WA
G100-SIIIA 80 94,3L
WA
95L
WA
G30-SIIIA
26 89,8L
WA
91L
WA
G150-SIIIA 120 95,6L
WA
96L
WA
G40-SIIIA 32
88,8L
WA
92L
WA
G200-SIIIA 160 95,8L
WA
97L
WA
G60-SIIIA 48 91,5L
WA
92L
WA
G250 205 96,5L
WA
97L
WA
G80-SIIIA 64 93,3L
WA
94L
WA
G400-SIIIA 320 97,2L
WA
98L
WA
Jan Moravec
27) Engineering Director
28) Issued at Dobris, Czech Republic 29) Date
30)
The technical documentation for the machinery is available from:
Doosan Bobcat EMEA s.r.o. (DBEM), U Kodetky 1810, 263 12 Dobris, Czech Republic
We declare that the G500-SIIIA has been assessed according to the Noise Emission Directive 2000/14/EC and, in accordance with
the terms of this Directive, has been excluded from the scope of this Directive. It may carry "CE" marking in compliance with
other applicable EC directives.
24)
Guaranteed
sound power
level
Original declaration
Directive 2000/14/EC, Annex VI, Part I
Notified body: AV Technology, Warrington, UK. Nr 1067
21)
Machine
23)
Measured
sound power
level
24)
Guaranteed
sound power
level
21)
Machine
23)
Measured
sound power
level
SAMPLE
