Dorani Limited DORVT User manual

DORANI TOUCH
VIDEO INTERCOM SYSTEM
USER MANUAL
MODEL: DORVT
2 WIRE SYSTEM
WWW.DORANI.COM.AU
Dorani (PJM Sale ) – 03 9357 0942
4/1 Merri Concour e, Campbellfield, Victoria 3061

2
FEATURES
- True Touch Screen functionality
- 2 x Door station connectivity
- 4 x Internal Monitors connectivity (SEE N TE)
- Picture Memory Recording (with addition of Micro SD Card)
- 2 Door Releases from the 1 Door Station (with D RV15)
- Auto Divert to Mobile when not at home (with D RVT05/06 Installed)
- 2 Camera - CCTV Viewing from monitors
- Internal monitor paging and broadcasting
- Access Control Keypad on Surface Door station
- DIN Rail Modular design
- Multiple cabling methods - star or looped (please see diagrams)
Note: The system is designed to have 2 monitors alight and display images on initial call,
all monitors in the system will ring. Pressing of non-imaged monitors will enable
communication with the door station
n smaller cable runs, additional monitors may be able to be programmed to alight on
call
- Dorani places no Guarantee on this feature
C MP NENTRY
D RVT01 7” LCD Touch Kit with Surface Door Station
D RVT02 7” LCD Touch Kit with Flush Door Station
D RVT03 7” LCD Touch Screen Monitor
D RVT04 4 Way Monitor R Door Station Branch Controller
D RVT06 PSTN Phone Line Interface
D RVT07 CCTV 2 Wire Camera
D RVT08 CCTV Module
D RVT09 Power Supply Module
D RVT10 Audio Door
D RVT11 Surface Mount Door Station
D RVT12 Flush Mount Door Station
D RVT13 Surface Mount Access Control Door Station
D RVT14 Flush Mount Access Control Door Station
D RVT15 Additional Lock Relay Module

3
BASIC USER GUIDE
nce your installer has set all the installation programming and parameters, only the
General Programming and Main Menu page should be required.
GENERAL PR GRAMMING
The General Programming Page is designed for user end programming of such settings
as Time/Date, Ring Tones, Naming Door Stations, etc.
Access the General Programming section by Pressing the monitor on (anywhere on the
screen) and the Pressing the gear symbol
The menu list comes up and all settings can be changed using the onscreen adjustments.
Press on the setting that you wish to change and use the up and down buttons to
ammend
PERATI N
Press Front doorbell button on utdoor station to create intercom call.
The screen will appear with the image of the door station pressed (on monitors
programmed to alight on call). At this time a snapshot of the caller will be taken.
Answer by pressing NCE the Speech Symbol R Speaker Symbol – The
communication can now occur between Door and Monitor.
If a Door locking device is connected Pressing the Door release Buttons
Padlock 1 will trigger the lock to release.
Padlock 2 is reserved for Second locking devices connected to the same door station
– Additional Relay Module is required for this.
Ending the call is by pressing the Return Symbol
FISH EYE LENS/Z M FEATURE
Keypad Door stations are fitted with Fish Eye lenses with a wider angle, taping on the
image will zoom to that location for the period of the call.

4
M NIT R
The monitor function is used to bring the Door station or Camera connected to the
system for remote viewing.
Pressing on the station desired will show the station on the screen, door stations can
then be activated (door locks), etc. as you would when in an intercom call.
Door stations programmed into the system will only show an image.
Cameras will only show an image if a CCTV Module is installed and Cameras connected.
Pressing the arrow symbol on top of the page enables you to access meu features
for adjusting brightness, colour and contrast. nce set they remain at this until adjusting
again.
INTERC M
Pressing Intercom will give 2 options:
Inner Broadcast – Press this button to enable instant talking to the other monitors
connected in the system.
Inner Call -will ring ALL montitors connedted in the system, communication can
only be established once another monitor is answered.
Answering and Ending the call is done in the same manner as normal intercom.
MEDIA
Pressing Media will enable you to access all images taken upon pressing of the intercom
door bell and format SD Cards, etc.
To view images press Graphics Playback and scroll using the left and right buttons
These can be deleted one by one by pressing the Bin button and then the Bin button to
confirm.
The system holds 100 Still Images on internal storage. Deletion is done by pressing the
bin icon and confirming deletion.

5
The addition of a Micro SD Card in the top of the monitor (Max 32GB) will override the
orginal Still Images and will enable call recording direct to the SD Card.
The SD Card MUST be formatted for this to work. To Format the SD Card, insert the SD
card properly into the SD Card Slot.
Press Then Choose to Format the SD Card
CALL REC RD
If the Camera Symbol is pressed during a conversation, the video call will be recorded.
This can be viewed in date order with the call record feature .
PH NE
If a Telephone interface has been installed, diversion can be set for the system.
Press and then Divert - Pressing the phone number location will activate the
keyboard - input your phone number and press K, once completed you MUST press the
save button to store all phone numbers.
Diversion can then be set in Call Scenario.
CALL SCENARI
Pressing Call Scenario allows you to choose between:
Normal– Intercom Rings normally, times out if no answer
Do Not Disturb – This Turns off the ringing of the intercom
Divert, Simultaneously – If a diversion module is installed, both the monitor and the
phone will ring at the same time
Divert, If No Answer – The monitor will ring for approximately 30 Seconds before
diverting to the telephone module.
CL SE
Close turns of the screen and put the system into standy mode waiting a call.
USING KEYPAD D R STATI N
If the Keypad is not alight – tap any key to activate the keypad - Enter your user code
followed by the # Key to trigger the lock.

6
PR GRAMMING C DES INT KEYPAD D R STATI NS
Program New Master Code
3 Beeps = Incorrect setting, code or location
Long Beep = Correct
This is the main programming code Keep this new code in a safe place)
Step 1: Press 1234 + # Key– Door station should go white
Step 2: Enter 01 followed by # - Door Station should go Yellow
Step 3: Enter 4 digit code followed by # - Door station should go Green then White
This is now the new Installer Code
Program new User Codes 20 29 for Door Release 1
Step 1: Press Master Code + # Key (e.g. 1234#) – Door station should go white
Step 2: Enter User Location to Program (20 – 29) followed by # - Door Station should go
Yellow
Step 3: Enter 4 digit code followed by # - Door station should go Green then White
Repeat steps 2 & 3 to program more users – Press * to exit programming at any time
TO DELETE OR CHANGE A CODE – THE USER CODE MUST BE CHANGED TO “0” FIRST,
THEN REPROGRAMMED.
Note: If RLC adapter is installed for a seconday release of the same door station separate
users and codes need to be programmed for these. This is done the same as above using
User numbers 60 - 69
The following is a record of codes stored into the system. Keep this up to date and
in a safe location for future reference for reprogramming.
Your Installer Code Is _________________
User 20 User 60
User 21 User 61
User 22 User 62
User 23 User 63
User 24 User 64
User 25 User 65
User 26 User 66
User 27 User 67
User 28 User 68
User 29 User 69
