Dorcy LT-033 Administrator Guide

LED Bluetooth Lantern
OPERATION INSTRUCTION MANUAL
READ ALL INSTRUCTIONS BEFORE FIRST USE
KEEP THIS MANUAL FOR REFERENCE.
Before rst and every use, charge the unit battery fully following the
instructions on “HOW TO CHARGE”. When the battery is not in use for a long
period, the runtime of the light will be shortened due to the self-discharge of
the battery.
Before First Use
Changes or modications not expressly approved by the party
responsible for compliance could void the user’s authority to
operate the equipment. This equipment has been tested and
found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference
in residential installation. This equipment generates, uses and
can radiate radio frequency energy and, if not installed and
used in accordance with the instructions may cause harmful
interference to radio communications. However, there is no
guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference
to radio or television reception, which can be determined by
turning the equipment o and on, the user is encouraged to
try to correct the interference by one or more of the following
measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and
receiver.
Connect the equipment into an outlet on a circuit
dierent from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician
for help.
1
2
3
Product Features
The lantern had a function of High, Low, Red lights and O
Integrated wireless Bluetooth speaker connection, Bluetooth 3.0 Audio
Bluetooth On / O power switch
Built in 3.7V 1600mAh Lithium Battery
DC5V USB output, suitable for battery charge on electronic devices with
USB input.
Connect audio cable (not included) directly to AUX audio plug to play
music without Bluetooth connection.
Intergraded handle with hook
Main Button
Battery Power Indicator (BPI)
USB cover
Micro-USB Charger Port
USB Output
Bluetooth“On / O” Switch
Speaker
AUX audio plug
Micro USB charging cable
1
2
3
4
5
6
7
8
9
10
8
CAUTION
RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE.
DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS.
Model : LT-033
5
6
7
9
4
10
Specication
Illumination
4 - 5 hrs
(High)
10 - 12 hrs
110 - 120 Lumens
40 - 50 hrs
(Low)
30 - 40 hrs
(Red)
Runtime
3.7V 1600mAh Lithium battery
Battery Type
-20˚c to 45˚c
Operating Temperature
≤ 90%
Operating Humidity
Bluetooth Speaker Runtime
Changes or modifications not expressly approved by the party responsible for compliance could void
the user’s authority to operate the equipment. This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference in residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different fromthat to which the receiver is
connected.
Consult the dealer or an experienced radio/TV technician for help.
IMPORTANT!
WARNING!
DO NOT immerse in water, drop into fire.
DO NOT disassembly the product.
Please charging the lantern at least once per 1 months in order to keep the battery in normal stage.
Please always handle the battery in safety way.
If the lantern has been destroyed or crashed, do not use it again or consult your product provider
The USB charging cable is for indoor use only.
Never short-circuit the terminal of the battery and the plug of the USB charging cable. It may cause
the battery to overheat, resulting in fire or damage of the components.
If the USB charging cable, USB plug, or lantern body is damaged. DO NOT use it.
Use only the Micro USB charging cable for charging.
Lithium batteries in the product can easily rupture, ignite, or explode when exposed to high
temperatures, or direct sunlight. The product should be stored and charged under well ventilated
environment. Short-circuiting a battery can also cause it to ignite or explode. Never open a battery's
casing. Batteries contain safety devices that, protect the cells inside from abuse. If damaged, these can
cause the battery to ignite or exploded
DO NOT charge the lantern and charge an electronic device at the same time. This will shorten the
lantern’s battery life.
Securely close the USB cover at the back of the lantern so that it will not be damage while water
splash/ rain, or the water resistance will be compromise.
Safely and properly dispose of the battery lantern according to your local regulations when it comes
to the end of its useful life.
This lantern is NOT a toy. Children should be supervised to ensure that they do not play with this
lantern.
A long period of non-use will lower the voltage of the battery due to natural self-discharge. If the light
is kept on until the power is completely gone (i.e. over discharge), it may shorten the battery life. Even
when you do not use the lantern. Charge the battery every month.
DO NOT charge the lantern for more than 8 hours.
If the lantern does not serve the proper running time even though the battery is fully charged, the
battery may have reached the end of its useful life.
06012015 V1

Fully charge the lantern use only the Micro USB charging cable.
1. Connect the micro USB with the USB charging cable into the lantern
charging port at the back of the lantern, and the other end of USB charging
cable into your home power outlet (DC5V power sources). Or use a comput
er other 5V/1A power source. Plug the USB charging cable into the USB port.
2. Standard charging time is around 3 hours. (Depending on the life of the
battery, the charging time will vary). Be careful not to charge it for more
than 8 hours. Over charge will damage the battery.
NOTE: The charging time and the operation time may vary depending on the use environment.
Status indicator:
The battery power indicator light indicates how much
battery life remains for the mode in use.
Light ashing = Charging
All lights on = Fully charged 100% battery life
Three light on = Around 75% battery life
Two light on = Around 50% battery life
One light on = Low battery > Around 25% battery life
How To Charge
Trouble Shooting
The lantern speaker doesn’t work or it won’t pair
• Try moving your device closer.
• Is the lantern turned on and charged?
• Turn the Bluetooth o and then on to wake it.
• Is Bluetooth enabled on your device or computer?
• Try repeating the setup procedure in this guide or pair with a dierent
Bluetooth device.
• The speaker plays music from one device at a time. Unpair the device not
being used. (Refer to your device documentation for help.) Pair a new
device using the setup procedure.
• If pairing with a computer, specify the lantern speaker as the audio out
device on the computer.
Operation with audio function
To play audio from a Bluetooth device, you need to pair the device with the
lantern speaker.
1. On your Bluetooth device, turn on Bluetooth and scan for devices in its
Bluetooth menu.
2. Turn on the Bluetooth when powering up for the rst time, the lantern
speaker is discoverable for 2 minutes and is ready for pairing. A short
sound will indicate the Bluetooth is on.
3. The model code of this lantern “DS-ML-903V1” will appear on the device
list of your Bluetooth device, select the lantern. The Bluetooth status will
show on your Bluetooth menu after pairing is established. The lantern
speaker is ready to play music.
Note: If the Bluetooth turns o after ve minutes, it has enters power saving mode. Slide the
power switch o and then turn on to wake the Bluetooth, and try pairing your device again.
Repeat step 3.
Note: The lantern speaker operates with a single pair devices mode. If you pair the speaker with
another device, the device least recently connected needed to be un-pair with the speaker rst.
Repeat steps 2 and 3 above
Remark: Connect audio cable (not included) directly to AUX audio plug to play music without
Bluetooth connection.
Operation with power bank function
1. Select the suitable USB charging charger (dierent devices require
dierent charging cables for charging).
2. Put the USB cable into lantern USB output port, then put the other
side of the cable into the charging device (mobile, tablet, etc.) The device
will then start charging.
3. When the lantern is out of battery, it will stop charging.
Operation with light function
To turn the lantern ON, press the main button.
Adjust the light settings (High / Low / Red) by pressing the main button.
To turn the lantern OFF, press the main button till to o the light.
Operation Instruction
Status indicator :
2
3
Turn on Bluetooth
>
>
Bluetooth devices
SEARCHING
(Dierent devices require
dierent charging cables
for charging)
Charging 100% battery life 75% battery life 50% battery life 25% battery life
100% battery life
75% battery life
50% battery life
25% battery life
Status
indicator
“Low, High, Red” light switch
1
Bluetooth devices
ON
Bluetooth devices
Model No.:
CONNECT
DS-ML-903V1
Bluetooth devices
PAIRED
