Dorel Home Products 2115029N User manual

B342115029N00-120201
Date of Purchase
J.L. –2020/12/14
Lot Number (TAKEN FROM CARTON)
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY
INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.
1
© 2020 Dorel Home Products All Rights Reserved
Weight Limit: 600 Lb / 272 Kg
2115029N (Dark Grey Linen), 2115329N (Green Linen), 2115429N (Grey Linen), 2115529N (Orange Linen), 2115629N (Blue Linen),
2115729N (Pink Linen), 2115829N (Light Blue Linen), 2115929N (Mustard Linen), 2115309N (Camel Faux Leather),
2115009N (Black Faux Leather), 2458109N (White Faux Leather)2458409N (Gray Faux Leather),
Thank you for purchasing from DHP!
Futon
Questions, concerns, missing parts?
CONTACT OUR CUSTOMER SERVICE DEPARTMENT
BEFORE RETURNING PRODUCT TO THE RETAILER.
If parts are missing or damaged, we will gladly shipyour
replacement parts free ofcharge.
Visit www.dhpfurniture.com/eng/replacement-parts
or call Toll-Free 1-800-267-1739

Contact Us!
For help with assembly, identifying parts, product information or to order parts,
please contact us:
Read Before Beginning Assembly
●Work in a spacious area and near where the unit will be used, preferably on a
carpet, or use apiece of the cardboard packaging to protect your floor and product.
●Make sure all parts are included. Most parts are labeled or stampedon the raw
edge.
●Read each step carefully. It is very important that each step of the instructions is
performed in the correct order. If these steps are not followed in sequence, assembly
difficulties will occur.
●This product may contain small components. Please ensure that they are kept
away from small children.
●This product is designed for home use and is not intended for commercial use.
Limited 1 year Warranty
DHP warrants this product to be free from defects in material and workmanship
and agrees to remedy any such defect. This warranty covers one year from the
date of original purchase from authorized retailers. This is solely limited to the
repair or replacement of defective parts and assembly labor isnot included.
This warranty does not apply to any product which has been improperly assembled,
subjected to misuse or abuse or which has been altered or repaired in any way.The
warranty does not cover wearing, tearing, fading or splitting of the fabric (where
applicable). Liability for consequential damages is excluded to the extent exclusion is
permitted by law. This warranty gives you specific legal rights and you may also
have other rights which vary from state to state or province to province.
To obtain warranty service, purchaser must present original bill of sale.
Components repaired or replaced are warranted through the remainder of the
original warranty period only. The defective components will be repaired or
replaced without charge, subject to the termsand conditions described above.
Visit www.dhpfurniture.com to view the limited warranty valid in the U.S. and
Canada.
DO NOTuse
powertools
2
1hour
This product is shipped in
1carton
DHP Consumer Services
12345 Albert Hudon, Suite 100,
Montreal, Quebec H1G 3L1
[e-mail]
1-800-267-1739
Monday to Friday
Saturday
Sunday
9am to 9 pm (Eastern Time)
10 am to 6:30 pm (Eastern Time)
11 am to 7 pm (Eastern Time)
Chat
with us! www.dhpfurniture.com

PARTS
B
C
A
3

Each part has aunique part number. Please reference the appropriate part number when contacting customer service for replacement parts.
Before throwing any packaging, please verify all contents and make sure you have received all the parts listed above!
A
Armrest Band Armrest Care packed inside Seat A.
PARTS LIST
A B C
Seat
1PC Armrest
1PC
Armrest
1PC
D E F
Leg
2PCS
Leg
2PCS Middle Leg
2PCS
4
PART
LABELS
2115029N 2115329N 2115429N 2115529N 2115629N 2115729N 2115829N 2115929N 2115309N 2115009N 2458109N 2458409N
(Dark Grey
Linen)
(Green
Linen) (Grey Linen) (Orange Linen) (Blue Linen) (Pink Linen) (Light Blue Linen)
(Mustard
Linen)
(Camel Faux
Leather)
(Black Faux
Leather)
(White Faux
Leather)
(Gray Faux
Leather)
AT632440 T632490 T632540 T632590 T632640 T632690 T632740 T632790 T632840 T632890 T639310 T639340
BT632450 T632500 T632550 T632600 T632650 T632700 T632750 T632800 T632850 T632900 T639320 T639350
CT632460 T632510 T632560 T632610 T632660 T632710 T632760 T632810 T632860 T632910 T639330 T639360
DT632470 T632520 T632570 T632620 T632670 T632720 T632770 T632820 T632870 T632920 T632470 T632470
ET632480 T632530 T632580 T632630 T632680 T632730 T632780 T632830 T632880 T632930 T632480 T632480
FT632940 T632940 T632940 T632940 T632940 T632940 T632940 T632940 T632940 T632940 T632940 T632940

Please do not completely tighten all the hardware,
until the entire assembly is complete, unless
otherwise indicated in the step-by-step instructions.
The screw(s), bolt(s) to be used at each step are
shown in actual size in the lower right corner ofthe
page.
Hardware Pack
Hardware Pack #: T2115309N-00
HARDWARE LIST
123
5/16" X 3 15/16"
X 8
5/16" X 2 1/3"
X 4
M6 X 10mm
X 8
456
Washer
X12
Spring Washer
X12 Nut
X8
78 9
Allen Key 5mm
X 1
Allen Key 4mm
X 1
Wrench
X 1
5

13/64"
75mm
5mm
20mm
Note:Only screw in the
shortest threaded part of
the Bolts.
Step1
Hand tighten into B & C, asshown.
6
X 8
C
B
1
25/32"
261/64"
1

Step2
Attach B & C to Awith
as shown. , , and ,
X 8 X 8 X 8
A
C
B
C
B
7
4
5
6
A
9
65
4

Step3
Make sure legs D and legs E are assembled outwardly.
X 4 X 4 X 8 X 4
3.1 Attach Dx 2 & EX 2 to Awith , , .
3.2 Attach F x 2 to Awith , as shown.
E
75
4
2
E
D
D
F
A
F
8
3
8
5
4
3
2

Step4
Attach the sofa backrests together
with the Velcro, as shown.
9

CAUTION: This unit is intended for use only with the products and/or maximum
weights indicated. Use with other products and/or products heavier than the
maximum weights indicated may result in instability or cause possible injury. •Your futon can transform between a Sofa
and a Bed.
•Move your new furniture carefully, with
two people lifting and carrying the unit to
its new location.
•Your furniture can be disassembled and
reassembled to move.
•Clean the product with a sofa damp cloth.
DO NOT use harsh chemicals or abrasive
cleaners.
•Some parts have been pre-assembled for
this item. They are illustrated on this page
and available for replacement.
Helpful Hints
Weight Limit:
600 Lb / 272 Kg
That's it ! You've finished assembling yourFuton!
SupportLeg
T616300
X 2
10
