Dorel Home Products DA2023579 User manual

B34DA202316900-100083
Thank you for purchasing from Dorel!
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY
INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.
1
Weight Limit: 400 lb / 181 kg
DA2023169 (Black Velvet), DA2023269 (Gray Velvet),
DA2023579 (Blue Velvet), DA2023779 (Green Velvet),
DA2023279 (Camel Faux Leather)
2 Seater sofa
Questions, concerns, missing parts?
CONTACT OUR CUSTOMER SERVICE DEPARTMENT
BEFORE RETURNING PRODUCT TO THE RETAILER.
If parts are missing or damaged, we will gladly shipyour
replacement parts free ofcharge.
Visit www.dhpfurniture.com/eng/replacement-parts
or call Toll-Free 1-800-267-1739
Date of Purchase Lot Number (TAKEN FROM CARTON)
J.L.. -2021/06/01
© 2021 Dorel Home Products All Rights Reserved

Read Before Beginning Assembly
●Work in a spacious area and near where the unit will be used, preferably on a
carpet, or use apiece of the cardboard packaging to protect your floor and product.
●Make sure all parts are included. Most parts are labeled or stampedon the raw
edge.
●Read each step carefully. It is very important that each step of the instructions is
performed in the correct order. If these steps are not followed in sequence, assembly
difficulties will occur.
●This product may contain small components. Please ensure that they are kept
away from small children.
●This product is designed for home use and is not intended for commercial use.
DO NOTuse
powertools
2
1hour
This product is shippedin
1carton
1-800-267-1739
Monday to Friday
Saturday
Sunday
DHP Consumer Services
12345 Albert Hudon, Suite 100,
Montreal, Quebec H1G 3L1
[e-mail]
Contact Us!
For help with assembly, identifying parts, product information or to order parts,
please contact us:
Limited 1year Warranty
Dorel warrants this product to be free from defects in material and workmanship
and agrees to remedy any such defect. This warranty covers one year from the
date of original purchase from authorized retailers. This is solely limited to the
repair or replacement of defective parts and assembly labor is not included.
This warranty does not apply to any product which has been improperly
assembled, subjected to misuse or abuse or which has been altered or repaired in
any way.The warranty does not cover wearing, tearing, fading or splitting of the
fabric (where applicable). Liability for consequential damages is excluded to the
extent exclusion is permitted by law. This warranty gives you specific legal rights
and you may also have other rights which vary from state to state or province to
province.
To obtain warranty service, purchaser must present original bill of sale.
Components repaired or replaced are warranted through the remainder of the
original warranty period only. The defective components will be repaired or
replaced without charge, subject to the terms and conditions described above.
Visit www.dhpfurniture.com to view the limited warranty valid in the U.S. and
Canada.
9 am to 9pm (Eastern Time)
10 am to 6:30 pm (Eastern Time)
11 am to 7pm (Eastern Time)
Chat
withus! www.dhpfurniture.com

PARTS
3
A
B
C
D
E
G

Armrest Band
Armrest Care
packed inside
Seat A.
PARTS LIST
Seat
1PC
Armrest
1PC
Armrest
1 PC
Back
1 PC
Wing
1 PC
Wing
1 PC
Leg
4 PCS
4
A B C
DEFG
A
PART
LABELS
DA2023169
(Black
Velvet)
DA2023269
(Gray
Velvet)
DA2023579
(Blue
Velvet)
DA2023779
(Green
Velvet)
DA2023279
(Camel Faux
Leather)
AT628750 T628820 T636500 T636570 T636640
BT628760 T628830 T636510 T636580 T636650
CT628770 T628840 T636520 T636590 T636660
DT628780 T628850 T636530 T636600 T636670
ET628790 T628860 T636540 T636610 T636680
FT628800 T628870 T636550 T636620 T636690
GT628810 T628880 T636560 T636630 T636700
Each part has aunique part number. Please reference the appropriate part number when contacting customer service for replacement parts.
Before throwing any packaging, please verify all contents and make sure you have received all the parts listed above!

Please do not completely tighten all the hardware,
until the entire assembly is complete, unless
otherwise indicated in the step-by-step instructions.
The screw(s), bolt(s) to be used at each step are
shown in actual size in the lower right corner ofthe
page.
Hardware Pack
Hardware Pack: TDA2023169-00
HARDWARE LIST
Plastic Washer M10
X 4
5
1

Step1
6
A
Carefully unpack parts/hardware from
storage of seat Aand place on a clean flat
surface.

Step2
7
Place both arms B, Cas shown below,
secure two legs Gand plastic washers
❶into pre-drilled holes on the bottom of
arms. Please avoid overtightening the
legs.
G
G
BC
7
X 2
1
1
1

Step3
8
Carefully lift and turn assembled arms B,
Conto its legs.
Attach seat Ato right arm Band left arm
Cby inserting the metal brackets on seat
Einto the metal glides on right arm Band
left arm Cas shown below. Ensure it
placed correctly.
B
C
A

Step4
9
E
F
D
Insert both metal plates of backrest wings
E, Fto both sides of back D.
Ensure they are placed correctly.

Step5
10
C
B
E
D
F
A
G
Insert metal plates of backrest D
preassembled with the wings Eand F to
metal glides of both arms Band Cas
show. Ensure they are placed correctly.
