Dorel 5278296COMUK User manual

B345278296COMUK01
Do Not Return This Product!
Contact our customer service team for help first
Call: 01942 524100
email: [email protected]
–Unit can p over causing severe injury or death.
–Anchor unit to stud in wall (if instructed to)
–Do not allow children climb on unit
–Put heavy items on lower shelves or drawers
5278296COMUK
STORAGE CABINET
Date of Purchase: ____/____/_____
Lot Number:
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.
WARNING
Easy Tough
Assembly Diculty Meter

Contact Us!
Helpful Hints
Do NOT return this product!
Contact our friendly customer service team rst for help
Call us!
01942 524100
PEOPLE NEEDED FOR ASSEMBLY: 1-2
ESTIMATED ASSEMBLY TIME: 1 HOUR
[email protected]
2
- Open your item in the area you plan to keep it for less heavy liing
- Idenfy, sort and count the parts before aempng assembly
- Compression dowels are tapped in with a hammer
- Slides are labeled with a R (right) and L (le) for proper placement
- Make sure to always face the point on the top of the Cam Lock towards the
outer edge
- Use all the nails provided for the back panel and spread them out equally
- Back Panel must be used to make sure your unit is sturdy
- Do NOT use harsh chemicals or abrasive cleaners on this item
- Never push, pull, or drag your furniture

Before You Start
Cam Lock Fastening System
3
P
P
P
P
P
This Cam Lock Fastening System will be usedthroughoutthe assembly process.
Read through each step carefully and follow the proper order
Separate and count all your parts and hardware
Give yourself enough room for the assembly process
Have the following tools: Flat Head Screwdriver, #2 Phillips Head
Screwdriver and Hammer
Cauon: If using a power drill or power screwdriver for screwing,
please be aware to slow down and stop when screw is ght.
Failure to do so may result in stripping the screw.
Quick
Tip
Asse
m
b
ly
1
3
2
4

Board Identfcaton
Notactual size
4
x1
T5278196011UD
TOP PANEL
x1
T5278196021UD
LEFT SIDE PANEL
x1
T5278196031UD
RIGHT SIDE PANEL
x1
T5278196040UD
BOTTOM PANEL
x1
T5278196051UD
FIXED SHELF
1
5
2 3
4
x1
T5278196061UD
FIXED SHELF
6
x1
T5278196070UD
MIDDLE PARTITION
7
x1
T5278196080UD
TOP APRON
8
x2
T5278196090UD
LONG LOWER RAIL
9

Board Identfcaton
Notactual size
5
x2
T5278196100UD
SHORT LOWER RAIL
10
x4
T5278196110UD
FOOT
11
x2
T5278196120UD
DRAWER FRONT
12
x2
T5278196130UD
LEFT DRAWER SIDE
13
x2
T5278196160UD
DRAWER BOTTOM
16
x2
T5278196170UD
ADJUSTABLE SHELF
17
x1
T5278196181UD
UPPER BACK PANEL
x1
T5278196200UD
LEFT DOOR
x1
T5278196210UD
RIGHT DOOR
18 20 21
x2
T5278196150UD
DRAWER BACK
15
x2
T5278196140UD
RIGHT DRAWER SIDE
14
x1
T5278196191UD
LOWER BACK PANEL
19

Part List
Actual Size
6
x38
TUD0001
Cam Bolt
M6 X 23
x38
TUD0002
Cam Lock
15-12
x40
TUD0004
DOWEL
M8 X 25
Hardware Bag Reference Number:
25278196COM0
x14
TUD0009
CBS 4 x 38
x24
TUD0011
PH SCREW
M4 X 12
x4
TUD0010
PH SCREW
M4 X 18
x32
TUD0008
CBS SCREW
M3.5 X 16
x20
TUD0034
PH SCREW
M3.5 X 12
x2
TUD0020
L-BRACKET

Part List
NotActual Size
7
x1 set
TUD0021
ANTI TIPPING KIT
x8
TUD0035
SHELF SUPPORT
x6
TUD0046
HINGES
x2 SETS
TUD0017
DRAWER SLIDE 14”
x2
TUD0012
HANDLE
x4 SETS
TUD0031
MAGNETIC
CATCH
M3 x 12mm
Hardware Bag Reference Number:
25278196COM0

8
* raw edges are shaded
Step 1
x14
TUD0001 x8 TUD0004
12 x2
10 x2
9x2
11 x4
1

9
Proper orientation of CAM LOCK
Tip
Assembly
Quick
* raw edges are shaded
Step 2
x8
TUD0002 x4
TUD0009
x4
TUD0001
9
9
10
11
11
11
11
10
4
x4
TUD0008 x2
TUD0020

10
* raw edges are shaded
Step 3
x16
TUD0001 x4 PCS TUD0017
x16
TUD0008
77
2
3

11
Proper orientation of CAM LOCK
Tip
Assembly
Quick
* raw edges are shaded
x4
TUD0001
x4
TUD0031
18
Step 4
5
4
6
6
7
x10
TUD0002 x6
TUD0004
6
(Top)
(Boom)
(Boom)

12
Proper orientation of CAM LOCK
Tip
Assembly
Quick
* raw edges are shaded
Step 5
1
6
18
7

13
Proper orientation of CAM LOCK
Tip
Assembly
Quick
* raw edges are shaded
Step 6
x6
TUD0002 x8 TUD0004
8
1
5
6
7
2
18

14
Proper orientation of CAM LOCK
Tip
Assembly
Quick
* raw edges are shaded
Step 7
x6
TUD0002 x8 TUD0004
1
5
6
7
2
3

15
Proper orientation of CAM LOCK
Tip
Assembly
Quick
* raw edges are shaded
Step 8
x4
TUD0002 x6 TUD0004
x2
TUD0009
1
5
3
4

16
* raw edges are shaded
Step 9
x20
TUD0034
19 18
3
4

17
Proper orientation of CAM LOCK
Tip
Assembly
Quick
* raw edges are shaded
Step 10
x4
TUD0004 x4 PCS TUD0017
x12
TUD0008
x8
TUD0009
x4
TUD0002
14
14
14
16
13
13
13
12 12
16
14
15
x2 SET
x2 SET x2 SET
x2 SET

18
* raw edges are shaded
Step 11
x8
TUD0035
17
17
17
17
17

19
* raw edges are shaded
Step 12
x4 SETS
TUD0031 x2 TUD0012 x4
TUD0010
x24
TUD0011
x6
TUD0046
20
21

20
* raw edges are shaded
Step 13
