Dorel DL7519E User manual

Model Number: UPC Code: Color:
DL7519E 0-65857-17348-2 Espresso
DL7519W 0-65857-17349-9 White
Date of Purchase: _____ / _____ / _____ Lot Number:
(taken from carton)
TWIN BUNK BED
Congratulations on your latest furniture purchase! Dorel Living furniture has been developed with
quality, convenience and style in mind. We trust it will provide you with many years of exceptional
comfort and service.
Before beginning assembly, we encourage you to familiarize yourself with your new furniture piece
by taking a few minutes to go through this booklet. It contains important information on our
warranty and care tips to keep your furniture looking as good as new.
Customer satisfaction is important to us at Dorel Asia. Our agents are available Monday to Friday
8am to 5pm (EST) to answer any question you may have. For faster service, always have the
model number ready when calling our toll free number 1-800-295-1980 or emailing us at
[email protected] .
For more great furniture ideas, check out our website at www.dorelliving.com
You can also keep up to date on all the latest trends by liking our Facebook page.
DO NOT RETURN PRODUCT TO THE STORE. If a part is missing or damaged, contact our
customer service department. We will replace the part FREE of charge.
NOTE: THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION.
PLEASE READ AND KEEP FOR FUTURE REFERENCE.

*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
PROHIBIT MORE THAN ONE PERSON ON UPPER BUNK.
KEEP THESE INSTRUCTIONS FOR FUTURE USE.
THE MATTRESS PLATFORM IS DESIGNED TO SUPPORT A MATTRESS WITHOUT THE NEED FOR A
POSTURE BOARD OR BOX SPRING.
USE ONLY COIL SPRING MATTRESSES ON BOTH THE UPPER AND LOWER BUNKS. FAILURE TO DO
SO CAN RESULT IN INJURY.
DO NOT ALLOW HORSEPLAY ON OR UNDER THE BED AND PROHIBIT JUMPING ON THE BED.
ALWAYS USE THE RECOMMENDED SIZE MATTRESS OR MATTRESS SUPPORT, OR BOTH, TO HELP
PREVENT THE LIKELIHOOD OF ENTRAPMENT OR FALLS.
USE ONLY MATTRESSES WHICH ARE 74"-75" LONG AND 37 1/2" - 38 1/2" WIDE ON UPPER AND ON
LOWER BUNKS. ENSURE THICKNESS OF MATTRESS DOES NOT EXCEED 6". SURFACE OF
MATTRESS MUST BE AT LEAST 5" (127MM) BELOW THE UPPER EDGE OF GUARDRAILS.
DO NOT ALLOW CHILDREN UNDER 6 YEARS OF AGE TO USE THE UPPER BUNK.
ALWAYS USE THE LADDER FOR ENTERING AND LEAVING THE UPPER BUNK.
DO NOT USE SUBSTITUTE PARTS. CONTACT CUSTOMER SERVICE FOR REPLACEMENT PARTS.
USE OF A NIGHT LIGHT MAY PROVIDE ADDED SAFETY PRECAUTION FOR A CHILD USING THE
UPPER BUNK.
E-MAIL: [email protected]
WARNING
STRANGULATION HAZARD - NEVER ATTACH OR HANG ITEMS TO ANY PART OF THE BUNK BED
THAT ARE NOT DESIGNED FOR USE WITH THE BED; FOR EXAMPLE, BUT NOT LIMITED TO HOOKS,
BELTS AND JUMP ROPES.
FOLLOW THE INFORMATION ON THE WARNINGS APPEARING ON THE UPPER BUNK END
STRUCTURE AND ON THE CARTON. DO NOT REMOVE WARNING LABEL FROM BED.
THE USE OF WATER OR SLEEP FLOTATION MATTRESSES IS PROHIBITED.
ALWAYS USE GUARDRAILS ON BOTH LONG SIDES OF THE UPPER BUNK. IF THE BUNK BED WILL
BE PLACED NEXT TO THE WALL, THE GUARDRAIL THAT RUNS THE FULL LENGTH OF THE BED
SHOULD BE PLACED AGAINST THE WALL TO PREVENT ENTRAPMENT BETWEEN THE BED AND
WALL (APPLICABLE FOR BUNK BEDS WITH FULL LENGTH GUARDRAILS ON ONE SIDE).
PERIODICALLY CHECK AND ENSURE THAT THE GUARDRAIL, LADDER AND OTHER COMPONENTS
ARE IN THEIR PROPER POSITION, FREE FROM DAMAGE, AND THAT ALL CONNECTORS ARE TIGHT.
Montreal, Quebec
Canada, H1G 3L1
CUSTOMER SERVICE
If you are missing parts or have any questions about this product, contact our customer service representative
first!
CALL 1-800-295-1980
You can also order parts by writing to the address listed below. Please include the product model number, color
and a detailed description of the part.
Customer Service Department No. 413
12345 Albert-Hudon Boulevard, Suite 100

*
*
*
*
*
*
*
*
Check bolts/screws periodically and tighten them if necessary.
WARNING: Should this product become
damaged, and/or components are broken or
missing, DO NOT USE.
BED IS DESIGNED FOR CHILDREN RANGING FROM 6 YEARS OF AGE TO YOUNG TEENAGERS.
Dust regularly with a soft, dry cloth. We do not recommend the use of chemical cleaners or wax on our
lacquered furniture as it may damage the finish. Keep solvents, alcohol, nail polish and polish removers
away from your hardwood furniture surfaces.
MAINTENANCE
LIMITED WARRANTY
Dorel warrants its product to be free from defects in material and workmanship and agrees to remedy any
such defect. This warranty covers 1 year from the date of original purchase. This warranty is valid only
upon presentation of proof of purchase. This is solely limited to the repair or replacement of defective
furniture components and no assembly labor is included. This warranty does not apply to any product
which has been improperly assembled, subjected to misuse or abuse or which has been altered or
repaired in any way. This warranty gives you specific legal rights and you may also have other rights which
vary from State to State.
CARE AND CLEANING
A RUBBER MALLET (NOT INCLUDED) IS RECOMMENDED TO FACILITATE ASSEMBLY.
READ EACH STEP CAREFULLY BEFORE STARTING. IT IS VERY IMPORTANT THAT EACH STEP OF
INSTRUCTION IS PERFORMED IN THE CORRECT ORDER. IF THESE STEPS ARE NOT FOLLOWED IN
SEQUENCE, ASSEMBLY DIFFICULTIES WILL OCCUR AND CAN RESULT IN INJURY.
CAUTION: ADULT ASSEMBLY REQUIRED
ASSEMBLY WILL REQUIRE TWO PEOPLE.
MOST BOARD PARTS ARE LABELED OR STAMPED ON THE RAW EDGE.
MAKE SURE ALL PARTS ARE INCLUDED. WORK IN SPACIOUS AREA, PREFERABLY ON A SMOOTH
SOFT SURFACE.
PHILLIPS SCREWDRIVER (NOT INCLUDED) IS REQUIRED.
NOTES

1
3
5 6
7
8
9
WOOD DOWEL
4 PCS
BARREL NUT
16 PCS
WOOD JOINT CONNECTOR (4mm HEX HEAD)
22 PCS
FLAT HEAD WOOD SCREW
24 PCS
WOOD DOWEL
34 PCS
10
TWIN BUNK BED
HARDWARE LIST
2
JOINT CONNECTOR (4mm HEX HEAD)
16 PCS
WOOD JOINT CONNECTOR (4mm HEX HEAD)
14 PCS
DL7519E / DL7519W
4
STOPPER
24 PCS
ALLEN KEY
1 PC
FLAT HEAD WOOD SCREW
6 PCS
∅11.8mm x
∅10mm x 50mm
∅19mm x 95mm
∅4mm x 30mm
∅4mm x 35mm
∅6.5mm x
∅1/4" x 100mm
∅6.5mm x 48mm

A B C
D E F
TWIN BUNK BED
DL7519E / DL7519W
PARTS LIST
TOP POST
2 PCS
TOP POST
1 PC
TOP POST
1 PC
BOTTOM POST
2 PCS
BOTTOM POST
2 PCS
TOP HEADBOARD TOP
CROSS -2 PCS

G H I
J K L
M N O
P Q R
TOP SIDE RAIL (WITH 1 HOLE)
1 PC
BOTTOM SIDE RAIL (WITH NO HOLE)
1 PC
SLAT
12 PCS
LONG LADDER END
1 PC
SHORT LADDER END
1 PC
LADDER STEP
4 PCS
GUARDRAIL LEG
2 PCS
TWIN BUNK BED
DL7519E / DL7519W
PARTS LIST
HEADBOARD BOTTOM CROSS
4 PCS
TOP SIDE RAIL (WITH 3 HOLES)
1 PC
BOTTOM SIDE RAIL (WITH 2 HOLES)
1 PC
LONG GUARDRAIL
2 PCS
SHORT GUARDRAIL
2 PCS

S T U
V W X
Y Z
TWIN BUNK BED
DL7519E / DL7519W
PARTS LIST
TOP HEADBOARD SLAT
8 PCS
SLAT
4 PCS
BOTTOM HEADBOARD SLAT
8 PCS
BOTTOM HEADBOARD SLAT
4 PCS
TOP HEADBOARD PANEL
2 PCS
TOP HEADBOARD SLAT
4 PCS
BOTTOM HEADBOARD PANEL
2 PCS
BOTTOM HEADBOARD TOP
CROSS- 2 PCS

NOTES: Headboard top cross (F) and headboard bottom cross (G) may require that they be pulled closer together
or further apart in order to allow wood dowels (7) to align with holes in top posts (A & B).
TWIN BUNK BED
DL7519E / DL7519W
One of the headboard top crosses (F) has a label on it. Do not use it in this step.
Insert stoppers (10) into headboard bottom cross (G) as shown above.
Insert top headboard slats (S & V) and top headboard panel (W) to top headboard bottom cross (G) and push down until firmly
in place.
Attach the headboard top cross (F) on the top headboard slats (S & V) and headboard panel (W).
Insert wood dowels (7) into each end of headboard top cross (F) and bottom cross (G). Attach top posts (A) & (B) with wood
joint connectors (3) and Allen key (9) as shown.
STEP 1

STEP 2
TWIN BUNK BED
DL7519E / DL7519W
NOTE: Be sure to use headboard top cross (F) with label attached to it between top posts (A) and (C).
See illustration for label orientation.
Repeat the previous step to assemble the remaining three sets of headboards. Be sure to pair the bottom
posts (D) and (E) for one pair; (E) and (D) for another; and the top posts (C) and (A) for the last pair.

TWIN BUNK BED
DL7519E / DL7519W
Attach the two headboards with bottom posts (D and E) to bottom side rails (I and K) using joint
connectors (1) and barrel nuts (8) as shown. Use Allen key (9) to tighten to joint connectors.
Note: This is the lower bunk.
STEP 3
I
K
Holes
1
1
9
8
8
8
8
I
K
Holes
1
1
9
8
8
8
8
