12-2020 dormakaba Canada Inc. RAC5 MFC Installation Guide – PK3738 | 1
Table of Contents
1 Introduction and Disclaimers.................................................................. 3
1.1 Safety Procedures.........................................................................................................................4
2 Product Description................................................................................. 5
2.1 Features .........................................................................................................................................5
2.2 Components..................................................................................................................................6
2.2.1 Controller Box ............................................................................................................................................. 6
2.2.2 Contactless Card Reader......................................................................................................................... 7
3 Checklist and Exploded Views ............................................................... 7
3.1 Parts and Tools List......................................................................................................................7
3.1.1 RAC5 MFC Enclosure ................................................................................................................................. 7
3.1.2 Relay Expansion Board.............................................................................................................................. 7
3.1.3 Cables (not shown).................................................................................................................................... 7
3.1.4 Card Reader(s) ........................................................................................................................................... 7
3.1.5 Power Adapter............................................................................................................................................ 8
3.1.6 Installation Hard Bag ................................................................................................................................ 8
3.1.7 Tools Required (not supplied) .................................................................................................................. 8
3.2 Exploded View ..............................................................................................................................9
4 System Installation Overview................................................................ 9
4.1 Pre-installation Procedures.......................................................................................................10
4.2 Installation and Wiring Procedures .........................................................................................10
5 Annex A: Quick Troubleshooting Guide................................................15
5.1 Power Troubleshooting .............................................................................................................. 15
5.2 Card Reading Troubleshooting................................................................................................. 15
5.3 External Inputs Troubleshooting.............................................................................................. 16
5.4 Relay Expansion Board Troubleshooting ................................................................................ 16
6 Annex B: Multi-Floor Controller RAC5 MFC........................................17
7 Annex C: Electromagnetic Interference.............................................. 18
8 Annex D: RAC5 MFC Components .......................................................19
9 Annex E: Single Reader Wiring.............................................................20
10 Annex F: Dual Reader Wiring..............................................................20

12-2020 dormakaba Canada Inc. RAC5 MFC Installation Guide – PK3738 | 2
11 Annex G: Fire Alarm Panel Wiring .......................................................21
12 Annex H: Reader Drilling Template .................................................... 22

12-2020 dormakaba Canada Inc. RAC5 MFC Installation Guide – PK3738 | 3
1 Introduction and Disclaimers
Please read and follow all directions carefully.
These instructions are designed for use by qualified installers or individuals with knowledge of common safety
practices and the competence to perform the steps described herein.
dormakaba Canada Inc. is not responsible for damage or malfunction due to incorrect installation.
Carefully inspect windows, doorframes, doors, etc. to ensure that the installation
procedures will not cause any damage. dormakaba Canada Inc.’s standard warranty does
not cover damages caused by installation.
Installation of card readers or other peripherals within elevators must only be done with
prior consultation of the elevator manufacturer. A technician from the elevator
manufacturer should always be present for installation. Do not connect to a receptacle
controlled by a switch.
If installing the RAC5 MFC in an elevator cage environment, or in proximity to any other equipment that may
generate high levels of electromagnetic interference, follow the installation requirements as indicated in Annex
C to prevent any operational instability.
The Table below outlines Access Control Levels as they pertain to certain Features.
Feature Level
Destructive Attack Level I
Line Security I
Endurance Level IV
Standby Power I
Single Point Locking Device with Key Locks I
RAC5 MFC Model #: T53-XXXXX
Firmware #: FW-516334-V 10.07.20.4
CAUTION
WARNING

12-2020 dormakaba Canada Inc. RAC5 MFC Installation Guide – PK3738 | 4
1.1 Safety Procedures
Installation is to be done following standard safety procedures and using adequate equipment and protection
as prescribed. Power is to be off during the installation process as well as for any maintenance procedures.
Wear safety glasses when using any tools.
NOTE: This equipment has been tested and found to comply with Part 15 of the FCC Rules. These limits are
designed to provide reasonable
protection against harmful interference in a residential installation. This
equipment generates,
uses, and can radiate radio frequency energy and, if not installed and used in accordance
with
the instructions, may cause harmful interference to radio communications. However, there is no guarantee
that interference will not occur in a particular installation. If this equipment does
cause harmful interference to
radio or television
reception, which can be determined by turning the equipment off and on, the user is
encouraged to
try to correct the interference by one or more of the following measures:
Adhere to UL STD 294
Adhere to the National Electrical Code ANSI/NFPA 70
Statement according to FCC part 15
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may cause undesired operation.
CAUTION

12-2020 dormakaba Canada Inc. RAC5 MFC Installation Guide – PK3738 | 5
2 Product Description
2.1 Features
The RAC5 MFC is designed to operate either online or stand-alone elevator control units (ECUs). It provides
access control and secure stops for multiple floors and functions with RAC5 NFC wall readers and AMBIANCE
features. The system can control any RFID ECU up to 1,000 feet (300m) away when using the RAC5 MFC
system.
NOTE: For installation of the contactless reader of distances greater than 1,000 feet (300m) please contact
dormakaba Canada Inc. Technical Support.
The Contactless Card Reader can be mounted directly on the inside of the elevator car, typically on the elevator
call button panel. For surface mount, the surface area required for the contactless reader is 5"W x 5"H x 2"D
(12.7 x 12.7 x 5cm, 2" depth behind panel required). The RAC5 MFC is an access control solution that can operate
2 individual card readers, provides multiple relays, and much more as per the feature list below. See Figure 1 for
a typical configuration.
Figure 1 – RAC5 MFC System
Features
•Variable access delay
•Control up to two card
readers
•Tamper Alarm Input
•Power failure 3-way auto-
recovery; real time clock (RTC)
•Unlock delay
programmable via an
M-Unit
•Power Status LEDs
feedback
•Relay bypassing (passing
function)
•Fire Alarm Input
•Relay Expansion Board
(up to 8) with 8 relays
each

12-2020 dormakaba Canada Inc. RAC5 MFC Installation Guide – PK3738 | 6
2.2 Components
Refer to Annex E for RAC5 MFC component breakdown.
2.2.1 Controller Box
Figure 2 – RAC5 MFC Controller Box
(A) RAC5 MFC Enclosure & Access Door: Holds the controller board (PCB), power supply and relay expansion
board. Knockouts are available on 3 sides for routing of peripheral cables
(B) Power Supply: Provides the DC power required for operation of the controller PCB and all peripherals
(C) Controller Board: Controls all the features of the RAC5 MFC system
(D) Tamper Switch: Attached to the RAC5 MFC enclosure to generate an alarm if the box is opened during
operation
(E) Power & Battery Status LEDs: Provides visual indication of the operational status of the RAC5 MFC
system. Battery status LED is only used on battery back-up equipped systems
(F) Cam-lock with Key: To provide secure locking and to control access to the RAC5 MFC enclosure
Optional Components:
(G) Relay Expansion Board: Interface board providing 8 relay outputs that can be used to control relay-
equipped equipment. For example, it can be used with an elevator to call the elevator or to provide access
only to specific floors for certain guests and staff. Up to 8 expansion boards of 8 relays each giving up to
64 individual control relays can be added
Not Shown:
(H) Cables: Cables required for connections of the LEDs, power supply and controller PCB. If equipped, will
also include cable for connection of relay expansion board
G

12-2020 dormakaba Canada Inc. RAC5 MFC Installation Guide – PK3738 | 7
2.2.2 Contactless Card Reader
The Contactless Card Reader is a small mounted unit that protrudes from the wall and is used with RFID-based
keycards.
Figure 3 – Contactless Card Reader
3 Checklist and Exploded Views
3.1 Parts and Tools List
NOTE: Some items are dependent on the options or configuration purchased. Please ensure all parts ordered
and required for installation are available before starting. Parts are subject to change without notice. For letter
designations, refer to Figure 4.
3.1.1 RAC5 MFC Enclosure
NOTE: All items below come factory installed.
(A) RAC5 MFC enclosure with access door
(B) Power Supply: 24 VAC / 24 VDC input, 12 VDC output
(C) Controller PCB
(D) Tamper switch
(E) 2-panel mounted LEDs (green) for power and battery status
(F) Cam-lock
3.1.2 Relay Expansion Board
(G) 8 Relay expansion PCB boards, including 4 x 6-32 x 3/8” SS screw with washer and controller PCB
connection cable (not shown)
3.1.3 Cables (not shown)
NOTE: All items come factory installed.
(H) System cables: Power supply to LEDs, controller PCB and controller PCB jumpers
3.1.4 Card Reader(s)
(I) Contactless reader (see Figure 3)

12-2020 dormakaba Canada Inc. RAC5 MFC Installation Guide – PK3738 | 8
3.1.5 Power Adapter
NOTE: Dependent on the countries’ electrical power requirements.
(J) 1x International 24 VDC output Adapter with integrated 6-foot (1.8m) power cable and interchangeable
AC outlet prongs. Input power requirements of 100-240 VAC, 50 – 60 Hz, 1.0A
Or
(K) 1x North America 24 VAC output power adapter with 2 separate 10-foot (3m) power cable assembly (2x 18
AWG cables terminated on one end with fork terminals). Input power requirements of 110-120 VAC, 60
Hz.
3.1.6 Installation Hard Bag
(L) 4x Philips wood screw, #8 x 1-1/4”
(M) 4x Nylon anchor, #6-10
(N) 4x Concrete anchor, #7-9
(O) 2x Strain relief connector with locking nut
(P) Ring terminal connector
(Q) 5x Steel flat washer, #8
(R) 2x Crimp fork terminals, 18-22 AWG
3.1.7 Tools Required (not supplied)
Additional tools may be required dependent on the peripherals being installed. The list below covers the
installation of the RAC5 MFC enclosure only.
•Safety glasses
•Ink marker
•Electric drill
•9/64” (3.5 mm) drill bit
•7/32” (5.5 mm) drill bit
•1/4” (6.5 mm) drill bit
•3/8” (9.5 mm) drill bit
•Philips screwdriver - #2
•Slotted screwdriver – 3/32” tip width
•Adjustable wrenches
•Crimp tool – 18-22 AWG
•Pliers
•Wire cutter/stripper
•Hammer or rubber mallet
•Awl or centre punch

12-2020 dormakaba Canada Inc. RAC5 MFC Installation Guide – PK3738 | 9
3.2 Exploded View
Figure 4 – Exploded View
4 System Installation Overview
Before starting installation:
•Ensure all components ordered and materials/tools required are available
•Ensure all cabling is available for the peripherals/components being installed
All installations and wiring of RAC5 MFC enclosure & peripherals must comply with all
applicable local building codes and regulations and National Electric Code, ANSI/NFPA 70.
Do not connect power to the enclosure until the end of the installation.
IMPORTANT
CAUTION

12-2020 dormakaba Canada Inc. RAC5 MFC Installation Guide – PK3738 | 10
4.1 Pre-installation Procedures
1. Identify a secure location for the RAC5 MFC enclosure.
•Access to the RAC5 MFC enclosure must be restricted to authorized personnel
•AC power must be available within 6 feet (1.8 m) of the RAC5 MFC enclosure
•The location temperature must be from 0 to 49 °C (32 to 120 °F) and sheltered against weather
hazards and dripping water with relative humidity conditions less than 85% at 32 °C (90 °F)
•The enclosure must be installed using the hardware supplied
•The enclosure should be mounted at a workable height with clearance to completely open the
access door
•The enclosure can be places either horizontally in the ceiling or vertically on a concrete, wood or
plaster wall
2. Identify location(s) for contactless readers.
•Card readers must be placed within 1,000 feet (300 m) from the RAC5 MFC enclosure
•Readers should be installed in an obvious location at an ergonomic height near the access door or
elevator being controlled
•The space to use the contactless reader must be large enough to allow for adequate clearance
for the card being presented to the reader
3. Install strain relief.
•Strain reliefs are provided in the hardware bag to secure the wires leading into the enclosure and
to help prevent the possibility of wire tampering
a) Determine the routing needed for all wiring of the RAC5 MFC card readers and
peripherals and select the enclosure knock-out(s) to be removed for installation of the
strain relief(s)
b) Remove the selected knock-out(s) using a hammer and screwdriver / awl, and from the
inner side of the enclosure, tap out the small metal disc
c) Based on the amount of wires to be routed, attach the appropriate strain relief to the
enclosure as shown in Figure 5. Do not attempt to route an excessive amount of wires.
If extra strain reliefs are required, please contact dormakaba Canada Inc
Figure 5 – Strain Relief
4. Ensure that Dip Switch SW2 has Test Mode switch setting (SW4) is set to OFF.
IMPORTANT

12-2020 dormakaba Canada Inc. RAC5 MFC Installation Guide – PK3738 | 11
4.2 Installation and Wiring Procedures
1. Mount the RAC5 MFC enclosure
a) Install the enclosure in the desired location using the appropriate items from the hardware bag
NOTE: For easier access, we recommend removing the access door prior to installation.
Figure 6 – Enclosure
2. Mount the contactless card reader.
NOTE: All readers are rated IP 54.
a) Remove the back plate and use it to mark the holes for the cables and screws
NOTE: Refer to Annex H of this manual for elevator panel preparation for mounting readers.
b) Drill the holes in the wall according to the diameters indicated on the drilling template in Annex
H, based on the type of surface the reader is being installed on.
3. Connect peripheral wiring.
Do not exceed the maximum cable length indicated by the manufacturer of the
products being connected. In addition, the wire used to connect the peripherals to
the controller PCB must be of the proper gauge and type as specified by the
manufacturer.
Every wire must pass through a strain relief as connected in the pre-installation
procedures. dormakaba Canada Inc. does not provide technical or field support
for third party locking devices. Please consult the device manufacturer for
support.
NOTE: The maximum recommended wire length is the approximate wire length that causes a 5%
voltage loss in the wire, using a 12-volt locking device at the rated current included.
a) Fire Alarm Panel: Refer to Annex G, Figure 14 for detailed wiring
i. Remove the jumper wire connected between pins 3 and 4 of connector J18 on the
controller PCB and complete the fire panel installation as per manufacturer’s
indications
b) Tamper Switch to Premise Alarm System
i. To wire the tamper switch to the premise alarm system, disconnect the wires on
controller PCB connected J7 pins 1 & 2 and run a 2-connector cable from the
switch to the premise alarm system
N
OR
L
M
A
M
CAUTION
IMPORTANT

12-2020 dormakaba Canada Inc. RAC5 MFC Installation Guide – PK3738 | 12
The tamper alarm switch’s polarity is such that when the door is
closed, the switch itself is also in a closed state. Ensure that the
wiring to the premise alarm system is done accordingly to
prevent false alarms.
4. Wire relay expansion board outputs. Refer to Annex B for sample wiring diagram.
The relay expansion board provides 8 relay contacts for wiring and control of relay-enabled elevator. The
board only provides normally open or normally closed dry contacts, so no power is provided by the board.
As wiring of relay-controller equipment may vary between products, please refer to the product
manufacturer’s instruction booklet.
NOTE: Refer to Annex B, Figure 8 for specific relay expansion board bypass switches.
•If bypass switches are ON, the relays are bypassed and the green LED associated with that relay
is turned ON
•If bypass switches are OFF, the controller PCB can activate the relays. The associated LEDs turn
ON during relay activation
•When the power of the RAC5 MFC is too low (power failure), the controller PCB stops
functioning and the relays on the controller PCB or the expansion board will return to their
normal state. The normal state is defined as relays OFF. Any peripheral connected to the relays
will then be either in a normally open (NO) or normally closed (NC) state, depending on the
wiring
5. Install elevator controller.
Each Expansion board contains 8 dry relay contacts. Up to 8 expansion boards can be used for total
control of 64 common areas. The relay outputs are at the wiring input of each three-terminal connector
(NO, COM, NC) on the expansion PCB as well as being indicated on the label on the inside of the door.
Several floors can be controlled by one relay (one common area).
The relays in the RAC5 MFC are UL rated and are capable of a maximum switching of 30 VDC @ 1A. For
time duration of relay state change, please refer to Annex B, Figure 8.
6. Connect the power adapter.
NOTE: Dependent on the countries’ electrical power requirements, follow the directions below for the
power adapter required. Refer to Annex B, Figure 8 for detailed wiring.
a) International Power Adapter
i. Attach the appropriate AC outlet prong to the power adapter
ii. Route the power adaptor wires into the enclosure and secure the wire (recommended
with tie wraps)
iii. From the inside of the enclosure, crimp the fork terminals supplied in the hardware bad
to the end of each wire
iv. Connect the fork-terminated wires to the power supply input as shown in Annex B,
Figure 8
b) North America Power Adapter
i. From the inside of the enclosure, connect one end of the fork-terminated wires to the
power supply inputs as shown in Annex B, Figure 8
IMPORTANT

12-2020 dormakaba Canada Inc. RAC5 MFC Installation Guide – PK3738 | 13
ii. Route the wires out of the enclosure to the AC power source and secure the wires
(recommended with tie wraps)
iii. Crimp the fork terminals supplied in the hardware bag to the end of the wires and
connect them to the power adapter screw terminals

12-2020 dormakaba Canada Inc. RAC5 MFC Installation Guide – PK3738 | 14
7. Complete the installation.
a) If the access door was removed, reinstall the door to the RAC5 MFC enclosure
b) Bend the two tabs on the door to a maximum of 30 degrees as shown in Figure 7
Figure 7 – Door Tabs
c) Connect the LED wire harness from the power supply to the access door LEDs as indicated
below and in Annex B, Figure 8
NOTE: The wires must be connected with the proper polarity. Once the terminals are installed,
they are designed to have a tight fit so removal may damage the LEDs.
LED Description Location on Door ‘+’ Terminal Connection ‘-’ Terminal Connection
Power Status Top Red Orange
Battery Status Bottom Red Yellow
Ensure that the proper connections are made (e.g. red to red, black to black).
d) Plug the power adapter into the AC power source and/or turn on the main AC power to the
system
IMPORTANT

12-2020 dormakaba Canada Inc. RAC5 MFC Installation Guide – PK3738 | 15
5 Annex A: Quick Troubleshooting Guide
The following sections show basic troubleshooting for some common problems that may occur during
installation. Each section related to a specific type of problem. For detailed assistance, please contact Technical
Support.
5.1 Power Troubleshooting
Symptom Action
Power adapter LED is OFF •Verify that the AC supply is not turned off
•Verify that the Adapter output is not shorted
Power supply AC ON green LED
is OFF
•Verify that the wiring to the power wall-mount adapter is correct
•If using the 24 VDC International Adapter, verify that the polarity is
correct
Power supply DC ON red LED is
OFF
•Verify the wiring between the power supply and the RAC5 MFC
controller
•Verify that the power supply output is not shorted
RAC5 MFC enclosure’s panel
door ‘Power Status’ LED is OFF
•Verify that the power supply is powered (both AC ON and DC ON
LEDs are on)
•Verify the LED wiring to the power supply
All RAC5 MFC LEDs are OFF
•Verify that the DC ON LED on the power supply is on
•Verify that the AC power is active for the wall-mount adapter
•Verify that the RAC5 MFC controller is connected properly to the
power supply as per Annex B, Figure 8
•If qualified, with a multi-meter, verify that 24 VAC (North American
Power Adapter) or 24 VDC (International Power Adapter) is present
across the power supply terminal block XFMR_1 and XFMR_2 as per
Annex B, Figure 8
5.2 Card Reading Troubleshooting
Symptom Action
No feedback on Reader when
using a card
•Verify that the RAC5 MFC controller is active. If not, restart the RAC5
MFC controller: Press the Reset Switch (SW1) or disconnect and
reconnect the power
•Check that the Reader LED (D48 for Reader 1 or D37 for Reader 2) is
steady ON. If not, verify the reading wiring
•Verify that the card is encoded properly

12-2020 dormakaba Canada Inc. RAC5 MFC Installation Guide – PK3738 | 16
5.3 External Inputs Troubleshooting
Symptom Action
Tamper Alarm is not activating
the premise alarm
•Verify that the Tamper Alarm LED (D53) on the RAC5 MFC controller
turns on when the button is pressed. If not, verify the wiring on the
Tamper Switch
5.4 Relay Expansion Board Troubleshooting
The power for the RAC5 MFC must be turned off before connecting or disconnecting the
Relay Expansion Board.
LEDs on Relay Expansion board are normally OFF, meaning no trouble.
Symptom Action
LEDs on the Relay Expansion
Board are ON
•Verify that the ribbon cable between the RAC5 MFC controller and the
Relay Expansion Board is connected properly. If it is not connected, turn
the power off, connect the cable, and turn the power back on
•Verify that the relays are not bypassed (the bypass switches SW1 and
SW3 on the Relay Expansion Board should be off
•Verify that the RAC5 MFC is not in Passage Mode
Relay Expansion Board relays
do not activate
•Activate the manual bypass switches SW1 and SW3 on the Relay
Expansion Board and verify that the relays are activated and the
corresponding LEDs turn on. De-activate the manual bypass
•Verify that the RAC5 MFC controller is active: Heartbeat LED D46
should be blinking and the Reader LEDs (D48 and D37) are respectively
ON. If not, reset the RAC5 MFC Controller by pressing the reset switch
(SW1) or disconnect and reconnect the power.
•Verify that the RAC5 MFC controller is programmed properly
•Verify that the card is encoded properly
Firm Alarm does not unlock
door
•Verify that the Fire Alarm input is connected to a Normally Closed
contact
•Verify that the Fire Alarm LED (D47) is normally on and turns off when
the Fire Alarm is present
RAC5 MFC Controller PCB
resets when relay is activated
•Verify that there is no short-circuit on the locking device wiring
•If a diode is installed on the locking device, verify the polarity
CAUTION

12-2020 dormakaba Canada Inc. RAC5 MFC Installation Guide – PK3738 | 17
6 Annex B: Multi-Floor Controller RAC5 MFC
Figure 8 – RAC5 MFC
Number of Devices (SW3) OFF - One locking device ON - Two locking devices
Test Mode (SW4) OFF - Normal operation ON - Test mode
DIP SW2 Configuration
Type Wire Color Signal ID
Black XFMR- 1 1
Black/White XFMR-2 2
-XFMR-1 1
-XFMR-2 2
Adaptor
Power Supply to Power Adapter
International
North America
Power Supply
Wire / Conn. Descritpion Item* Signal PCB Conn.
-Relay Exp. Board (H)
Black Fire Alarm J18 pin 3
Black GND J18 pin 4
-Server - - J10
MFC PCB Peripherals Connections
Fire Alarm
-
Peripheral
Controller Board
Signal ID Wire Color Signal
AC Fail-1 NC Orange ( - )
- - Red* ( + )
Low Bat-1 NC Yellow ( - )
DC Out-2 ( + ) Red ( + )
- - Red* ( + )
Battery Status
Power Supply to MFC LEDs
Power Supply
LEDs
Description
Power Status
Terminal State Bypass Terminal State Bypass
1-1 NC 5-1 NC
1-2 COMM 5-2 COMM
1-3 NO 5-3 NO
2-1 NC 6-1 NC
2-2 COMM 6-2 COMM
2-3 NO 6-3 NO
3-1 NC 7-1 NC
3-2 COMM 7-2 COMM
3-3 NO 7-3 NO
4-1 NC 8-1 NC
4-2 COMM 8-2 COMM
4-3 NO 8-3 NO
Caution:
If bypass switches are "ON"
- Relays are bypassed & GREEN LEDs are "ON".
If bypass switches are "OFF"
- GREEN LEDs are "OFF" & Controller Board can activate
relays.
Relay Expansion Board
SW1-1
SW1-2
SW1-3
SW1-4
SW3-1
SW3-2
SW3-3
SW3-4
LED Description
D37 Reader 2 Online
D46 Heartbeat
D48 Reader 1 Online
PCB Status LEDs
Signal Reader Config Wire Color Term Block
12V Batt J1 pin 1 RED J4 - TB-2
GND J1 pin 2 BLACK J4 - TB-1
GND J1 pin 3 BLACK J4 - TB-1
12V Batt J1 pin 4 RED J4 - TB-2
RD2 Data + J12 pi n 1 WHITE J5 - TB-3
RD2 Data - J12 pin 2 GREEN J5 - TB-4
RD1 Data + J12 pi n 3 WHITE J5 - TB-3
RD1 Data - J12 pin 4 GREEN J5 - TB-4
Controller Board RAC5 Reader Connections
Controller Board
Contactless Reader
Wire connection to back of contactless card reader
TB-1 (BLACK), TB-2 (RED), TB-3 (WHITE), TB-4 (GREEN)
12 V G ND
Power Supply
NO C NC NO C NC
LOW BATT AC FAIL
D C O UT
+ -
BAT
+ -
INPUT
XF RM
1 2 3 4 1 2 3 4 1 2 3 4
J17
J3
J7
J8
J12
J1
J15
J16
J6
J18
J19
RAC5 MFC PCB
N O NC CO M GND F IRE GND 12V_LCK#1 GND 12V N O NC CO M
RE_UNL#2
GND
RE_UNL#1
1 (+ ) 2 (-) 3 (+) 4 (-)
1
2
3
4
1
2
3
2
1
1
2
3
12_LCK#2 GND
1 2 3 4
PWR GND GND PWR
RD#1 RD#2
READER2 READER 1
1 2 3 4
J11
REX2 GN D
TA MP ER
GND
DOOR
STAT#2 GND GND
REX# 1
GN D
DOOR
STAT#1
GND
GND LOW_BATAC_FAIL
4 3 2 1
Fire Alarm Panel
Connection or jumper
Power Adaptor
O N
1 2 3 4
1
0
5
23
4
85
67
1234
5678
1 4
O N
1 2 3 4
5 8
NO C NC NO C NC NO C NC NO C NC
NC C NONC C NONC C NONC C NO
Relay
Override
Switch SW1
and SW3
O N
1 2 3 4
1
0
5
23
4
85
67
1234
5678
1 4
O N
1 2 3 4
5 8
NO C NC NO C NC NO C NC NO C NC
NC C NONC C NONC C NONC C NO
O N
1 2 3 4
1
0
5
23
4
85
67
1234
5678
1 4
O N
1 2 3 4
5 8
NO C NC NO C NC NO C NC NO C NC
NC C NONC C NONC C NONC C NO
O N
1 2 3 4
1
0
5
23
4
85
67
1234
5678
1 4
O N
1 2 3 4
5 8
NO C NC NO C NC NO C NC NO C NC
NC C NONC C NONC C NONC C NO
REB2
Sw it c h
Selection
SW2
O N
1 2 3 4
DE LA Y0
DE LA Y1
DEVIC ES
TES T MODE
SW2
D46D37D48
SW1
Res et
Power
Status
Battery
Status
B
Wire Color Connector ID Signal ID
Red J16 pin 1 12V DC OUT +
Black J16 pin 2 GND DC OUT -
White J17 pi n 1 AC_FAIL AC FAIL NO
Brown J17 pi n 2 LOW_BAT LOW BAT NO
-J17 pi n 3 GND - -
AC Fail
RAC5 MFC PCB to Power Supply
Controller Board
Power Supply
Description
DC Power

12-2020 dormakaba Canada Inc. RAC5 MFC Installation Guide – PK3738 | 18
7 Annex C: Electromagnetic Interference
As per any other electronic equipment, the RAC5 MFC can be affected by electromagnetic interference cause
by industrial electrical equipment such as elevator motors. To prevent the unit from operational instability, such
as ‘freezing’ or losing programming, shielded cables should be used and connections made as per the diagram
below.
Figure 9 – Shielded Cable
Wall-Pluggable
Transformer
RAC5
Enclosure
RAC5 Main
PCB
Mounting
Screw
Ingress
Read er
Egress
Read er
Power Supply
Electrical
Connector
Shield Wire
of Cable
Ground Wire
Shield Wire
of Cable
To Ground
1- Use shielded cables for the readers
2- Connect the shield wire of the reader cables to the Ground wire
3- Connect the wires to the Mounting screw of the RAC5.
(Remove the paint under the mounting screw for good electrical contact.)
Shielded
Cables

12-2020 dormakaba Canada Inc. RAC5 MFC Installation Guide – PK3738 | 19
8 Annex D: RAC5 MFC Components
Figure 10 – RAC5 MFC Components
