dosatron D25RE2 User manual

1
DOSATRON INTERNATIONAL, INC. •800-523-8499
Press Ctrl + L for full screen
MAINTENANCE MANUAL
MAINTENANCE MANUAL
D25RE2
0.2 to 2%
1:500 to 1:50

«click »for next step
DOSATRON INTERNATIONAL, INC. •800-523-8499
2
200 mesh /80
micron filter
Union ball
check/check
valve or
water
hammer
arrestor
Concentrate
Inlet Outlet
Optional accessories:
•Pressure regulator
•Solenoid valves
•Water meter
•Flow restrictor
STANDARD INSTALLATION
STANDARD INSTALLATION
Optional
accessories

«click »for next step
DOSATRON INTERNATIONAL, INC. •800-523-8499
3
MAIN MENU
MAIN MENU
Click on a specific chapter
or
Click for next slide
•CHAPTER 1 REMOVING THE DISPENSER FROM INSTALLATION
•CHAPTER 2 DISASSEMBLING THE DISPENSER
•CHAPTER 3 REASSEMBLING THE DISPENSER
•CHAPTER 4 PISTON MAINTENANCE
•CHAPTER 5 AIR BLEED MAINTENANCE
•CHAPTER 6 BY-PASS MAINTENANCE
•CHAPTER 7 TROUBLESHOOTING GUIDE

«click »for next step
DOSATRON INTERNATIONAL, INC. •800-523-8499
4
SPECIFICATIONS
SPECIFICATIONS
D25RE2
D25RE2
Injection Range:
•1:500 to 1:50 1:500 to 1:50 - -0.2 to 2% 0.2 to 2%
Water Flow Range:
•0.05 to 11 GPM 0.05 to 11 GPM
Operating Water Pressure:
•4.3 to 85 PSI 4.3 to 85 PSI
Maximum Water Temperature:
•104 104° °F F – –40 40° °C C
Note:
Note: Normal safety precautions should be practiced when Normal safety precautions should be practiced when
working with chemicals and equipment.
working with chemicals and equipment.

5
DOSATRON INTERNATIONAL, INC. •800-523-8499
« click » for next slide
REMOVING THE DISPENSER FROM INSTALLATION
REMOVING THE DISPENSER FROM INSTALLATION
Return to Main Menu
CHAPTER 1
CHAPTER 1
D25RE2
0.2 to 2%
1:500 to 1:50

«click »for next step
DOSATRON INTERNATIONAL, INC. •800-523-8499
6
REMOVING THE DISPENSER FROM INSTALLATION
REMOVING THE DISPENSER FROM INSTALLATION
Unscrew the suction tube nut
and remove the hose.
After turning off the water and
relieving the pressure on the unit,
unscrew the dispenser inlet/outlet
couplings and allow it to drain.

7
DOSATRON INTERNATIONAL, INC. •800-523-8499
Return to Main Menu
« click » for next slide
D25RE2
0.2 to 2%
1:500 to 1:50
DISASSEMBLING THE DISPENSER
DISASSEMBLING THE DISPENSER
CHAPTER 2
CHAPTER 2

«click »for next step
DOSATRON INTERNATIONAL, INC. •800-523-8499
8
DISASSEMBLING THE DISPENSER
DISASSEMBLING THE DISPENSER
Unscrew and remove the lid.

«click »for next step
DOSATRON INTERNATIONAL, INC. •800-523-8499
9
Place the dispenser upside-down on a
table and remove the 4 dosing assembly
retaining screws.
Use a #2 Phillips screwdriver.
DISASSEMBLING THE DISPENSER
DISASSEMBLING THE DISPENSER

«click »for next step
DOSATRON INTERNATIONAL, INC. •800-523-8499
10
Pull the injection stem
assembly out of the body, and
let the solution drain out of it.
Caution
Caution: Stem may be full of
undiluted chemical. Be aware of
hazardous materials and take
the necessary precautions for
protection.
WATCH OUT FOR SPLASHING!
WATCH OUT FOR SPLASHING!
DISASSEMBLING THE DISPENSER
DISASSEMBLING THE DISPENSER

«click »for next step
DOSATRON INTERNATIONAL, INC. •800-523-8499
11
Grab the valve support and pull the piston out of the body, at
the same time, push the plunger up.
DISASSEMBLING THE DISPENSER
DISASSEMBLING THE DISPENSER

«click »for next step
DOSATRON INTERNATIONAL, INC. •800-523-8499
12
Unscrew and
remove the barbed
fitting.
Unscrew and
remove the conical
nut.
DISASSEMBLING THE DISPENSER
DISASSEMBLING THE DISPENSER
Dosing assembly
Dosing assembly - -disassembly disassembly

«click »for next step
DOSATRON INTERNATIONAL, INC. •800-523-8499
13
Remove the
anti-friction ring.
Dosing assembly
Dosing assembly - -disassembly disassembly
Unscrew and
remove the
adjusting nut
from the
sleeve.
DISASSEMBLING THE DISPENSER
DISASSEMBLING THE DISPENSER

«click »for next step
DOSATRON INTERNATIONAL, INC. •800-523-8499
14
Remove the injection stem from the top
of the sleeve.
Gently remove the sleeve O-ring.
DISASSEMBLING THE DISPENSER
DISASSEMBLING THE DISPENSER
Dosing assembly
Dosing assembly - -disassembly disassembly

«click »for next step
DOSATRON INTERNATIONAL, INC. •800-523-8499
15
Gently push the check valve out of the
injection stem with a pencil or similar
object. Do not scratch the inside of the
injection stem.
Gently remove the injection stem O-ring.
DISASSEMBLING THE DISPENSER
DISASSEMBLING THE DISPENSER
Dosing assembly
Dosing assembly - -disassembly disassembly

«click »for next step
DOSATRON INTERNATIONAL, INC. •800-523-8499
16
When disassembly of the Dosatron unit is complete, soak it in lukewarm soapy
water. A soft bristled brush may be used to break up residue.
Change seal kit every 12 months.
Seal kit part # ED252 includes:
J009 - Plunger seal
PJ121 - Injection stem assembly
J024 - Injection sleeve O-ring
MPDI122 - Check valve assembly
J051 - Check valve seal
CLEANING & MAINTENANCE PROCEDURE
CLEANING & MAINTENANCE PROCEDURE
DISASSEMBLING THE DISPENSER
DISASSEMBLING THE DISPENSER
J009

17
DOSATRON INTERNATIONAL, INC. •800-523-8499
« click » for next slide
Return to Main Menu
D25RE2
0.2 to 2%
1:500 to 1:50
REASSEMBLING THE DISPENSER
REASSEMBLING THE DISPENSER
CHAPTER 3
CHAPTER 3

«click »for next step
DOSATRON INTERNATIONAL, INC. •800-523-8499
18
REASSEMBLING THE DISPENSER
REASSEMBLING THE DISPENSER
Dosing assembly
Dosing assembly
Replace the O-ring on the dosing stem.

«click »for next step
DOSATRON INTERNATIONAL, INC. •800-523-8499
19
Dosing assembly
Dosing assembly
Reinsert the injection stem into the injection sleeve. Make sure that the long groove
in the injection stem aligns with the tooth inside the injection sleeve.
REASSEMBLING THE DISPENSER
REASSEMBLING THE DISPENSER

«click »for next step
DOSATRON INTERNATIONAL, INC. •800-523-8499
20
Replace the sleeve O-ring.
Dosing assembly
Dosing assembly
REASSEMBLING THE DISPENSER
REASSEMBLING THE DISPENSER
