dosatron D3WL Operator's manual

D3WL
Congratulations on your new Dosatron.
Please read the following important information.
QUICK START UP
D3WL
3m3/h 14 US GPM
IMPORTANT NOTES
For complete information on the features and operations,
refer to your Manual on www.dosatron.com
or download our DOSATRON app
or
NEED HELP ?
Contact your DOSATRON distributor for service or parts
This document does not form a contractual engagement on the part of Dosatron International
and is for information only. Dosatron International reserves the right to alter product
specification or appearance without prior notice.
© DOSATRON INTERNATIONAL S.A.S 2018
DOSATRON INTERNATIONAL S.A.S. Certified QEH&S System
Rue Pascal - B.P. 6 - 33370 TRESSES (BORDEAUX) - FRANCE
Tel. [phone]
Fax. [phone]
[email protected] - www.dosatron.com
CUSTOMER SERVICE - SERVICE CLIENTÈLE (WORLDWIDE - EUROPE)
MANUFACTURED BY - FABRIQUÉ PAR :
WATER LINE
- When connecting a DOSATRON either to the public water
supply or to its own water source, you must respect the
regulations in force concerning protection of the source i.e.
backflow prevention, etc.
- Contact local authorities for requirements of backflow
prevention.
- When installing, operating, and maintaining the DOSATRON
water powered metering pump, keep safety considerations
foremost. Use proper tools, protective clothings, and eye
protection when working on the equipment and install the
equipment with a view toward ensuring safe operation.
- Follow the instructions in the manual and take additional
safety measures appropriate to the liquid being pumped and
the temperature of the water that powers the DOSATRON. Be
extremely careful in the presence of hazardous substances (e.g.
corrosives, toxins, solvents, acids, caustic, flammables, etc.).
- Before applying any aggressive chemicals, please consult your
distributor to confirm compatibility with the dosing pump.
- Dosatron Water Line pumps which REF contains index «N»
are certified under NSF/ANSI Standard 61 & 372 (Drinking
Water Treatment Equipment). They are certified for use with
calcium hypochlorite (max concentration 65% ) and with sodium
hypochlorite (max concentration 15 %). The temperature of the
treated water should not exceed 23°C.
Hand tighten. No tools needed.
CAUTION
ET346/QSUCED3WL-05-18
CLICK CHART
Clicks l/h Clicks l/h
2 130 16 1020
4 260 32 2040
8 510 46 3000
DO NOT USE THIS UNIT WITHOUT A 60 MICRON
[300 MESH] WATER FILTER*
OR YOUR WARRANTY WILL BE VOID.
*The 60 micron [300 mesh] water lter (sold separately)
protects your unit from debris in the water that causes
scoring to the piston and housing.
KNOW YOUR WATER FLOW!
GRADUALLY TURN ON THE WATER.
COUNT THE NUMBER OF CLICKS IN 15 SECONDS.
DO NOT EXCEED 46 CLICKS.
MAXIMUM PRESSURE 6 bar [87 PSI]
RECOMMANDATIONS

5
%
5
%
Maximum: 46 clicks/15 sec.
5
%
5
%NO !
5
%
Max.Torque 20 Nm thus 2 kg (1 N.m = 0,1 DaN.m)
Valve Check
valve
Filter
Filter :
60 microns [300 mesh]
Depending on your
water quality
5
%
5
%
BY PASS Option
Air-Bleed
Button
Ø 4 Ø 8
w
a
t
e
r
f
o
w
When possible,
DO NOT PLACE
the container directly
under
the DOSATRON
INSTALLATION
HINTS
Scan the QR-
code on the
dosing pump.
SPECIAL
D3WL3000IE
1
3
5
8 9
2
4
7
6
