Dover OPW Fluid Transfer civacon 8800E User manual

Operation Manual
OPW Fluid Transfer Group Europe B.V.
Rack Monitor 8800E/8801E
Version A.7
Date 16 June 2011

Rack Monitor 8800E/8801E
Document: Operation Manual
Date: 16-Jun-2011
Version: A.6
Page 2 of 35 H71343
<< This page is left blank intentionally >>

Rack Monitor 8800E/8801E
Document: Operation Manual
Date: 16-Jun-2011
Version: A.6
Page 3 of 35 H71343
Disclaimer
In this document an operation manual is presented of the OPW Rack Monitor 8800E/8801E. It is important that the
end user (in many cases the operator) of the OPW Rack Monitor 8800E/8801E has an adult age, is skilled, reads
and understands this manual, otherwise it is not recommended to use the OPW Rack Monitor 8800E/8801E.
OPW Fluid Transfer Group Europe BV guarantees that this product is adequate for the stated use and is in
accordance with the Directive(s) stated in the declaration of conformity in this manual.
OPW Fluid Transfer Group Europe BV can not be held responsible for incorrect use of the RACK MONITOR
8800E/8801E. The Rack Monitor 8800E/8801E is for the use of monitoring of loading of tank trucks with the
application and parameters stated in this manual.
In case this OPW Rack Monitor 8800E/8801E is used in another location than mentioned in the initial
quotation or is abused, all guarantees will be declined.
This operation manual is a part of the supplied product and must at all times accompany the Rack Monitor
8800E/8801E, when it is relocated or sold to a third party. All pages of this manual should be present, in
accordance to the table of contents. If not, please contact the OPW Fluid Transfer Group Europe BV.
© COPYRIGHT 2007. The design, drawings and documentation are the exclusive property of OPW Fluid Transfer
Group Europe BV. It is submitted on the condition that the designs contained therein are held confidential and is
subject to return on demand.
Apart from exceptions provided by the law, nothing from this publication may be duplicated and/or published by
means of photography, microfilm, storage in computer files or otherwise, which also applies to full or partial
processing, without the written consent of OPW Fluid Transfer Group Europe BV.
Although the utmost care has been taken with this publication, errors and omissions cannot be entirely excluded.
The OPW Fluid Transfer Group Europe BV therefore accepts no liability, not even for direct or indirect damage,
occurring due to or in relation with the application of publications issued by OPW Fluid Transfer Group Europe
BV.
This is an OPW Fluid Transfer Group Europe BV product, for technical assistance, information and/or complaints
contact:
OPW Fluid Transfer Group Europe BV
Visiting adress:
Roggestraat 38
2153 GC Nieuw Vennep
Netherlands
Postal adress:
P.O.Box 32
2150 AA Nieuw Vennep
Netherlands
T: [phone]
F: [phone]
E: [e-mail]
W: http://www.opw-ftg.nl
Mr. Harry Gilde
Managing Director

Rack Monitor 8800E/8801E
Document: Operation Manual
Date: 16-Jun-2011
Version: A.6
Page 4 of 35 H71343
Warranty
All parts and products are thoroughly inspected and tested from the time raw material is received at
our plant, until the product is completed. We guarantee that all products are free from defects in
materials and workmanship for a period of one year from the date of shipment. Any product that may
prove defective within said one year period will, at our option, be promptly repaired, or replaced, or
credit given for future orders. This warranty shall not apply to any product which has been altered in
any way, which has been repaired by any party other than an authorized service representative, or
when such a failure is due to misuse or conditions of use. We shall have no liability for labor costs,
freight costs, or any other cost or charges in excess of the amount of invoice for the products.
THIS WARRANTY IS IN LIEU OF ALL OTHER WARRANTIES, EXPRESS OR IMPLIED, AND
SPECIFICALLY THE WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.
Approvals
The 8800E/8801E CIVACON Loading Rack Monitor is suitable for
Equipment group II, category 2(1)
Class I, Division 1, Groups C & D
hazardous locations with intrinsically safe outputs, and housed in an Explosion Proof
Enclosure. All monitors are ATEX / FM / CSA approved. Please consult the factory for the availability of
special models.
Technical assistance in the U.S.A.
If at any time during the installation a question arises that is not covered in this Installation
Instruction, or with any other applicable documents referenced, feel free to call the
CIVACON ELECTRONICS TECHNICAL ASSISTANCE LINE :
In the U.S.A., Call 1-800-5 CIVACON . (800-524-8226)
For the CUSTOMER SERVICE DEPARTMENT :
In the U.S.A., Call 1-888-526-5657
In other countries, call your local agent.
4304 MATTOX RD. * KANSAS CITY, MO 64150
PH: [phone] * FAX: [phone]
[phone] [phone]

Rack Monitor 8800E/8801E
Document: Operation Manual
Date: 16-Jun-2011
Version: A.6
Page 5 of 35 H71343
EC Declaration of Conformity
In accordance with ISO/IEC 17050:2004
No. DOC07001
We OPW Fluid Transfer Group Europe BV
of Roggestraat 38
2153 GC Nieuw Vennep
The Netherlands
T: [phone]
declare that:
Product description : Rack Monitor 8800E/8801E
Item number : 8800E/8801E
Serial no./ Lot no. : see Installation manual
Brand name : Civacon
Protection Type : EEx d IIB T4
Certificate number : Zelm 07 ATEX 0332 X
Product category : II 2 G
is/are in accordance with the following Directives:
94/9/EC ATEX 95 – Explosion Safety Directive
and its amending directives
2004/108/EC EMC – Electro Magnetic Compatibility Directive
and its amending directives
has been designed and manufactured to the following specifications:
EN 60079-0 Electrical apparatus for explosive gas atmospheres – Part 0: General requirements
EN 60079-11 Electrical apparatus for explosive gas atmospheres – Part 11: Intrinsic safety ”i”
EN 60079-1 Electrical apparatus for explosive gas atmospheres – Part 1: Flameproof enclosures ”d”
EN 61000-6-2 Generic standards, Immunity for industrial environments
EN 61000-6-4 Generic standards, Emission for industrial environments
I hereby declare that the equipment named above has been designed to comply with the relevant
sections of the above referenced specifications. The unit complies with all essential requirements of the
Directives.
The commitments are fulfilled towards: Zelm Ex
Siekgraben 56, 38124 Braunschweig, Deutschland
Identification number: CE 0820
Place : Nieuw Vennep Date :
There is a signed declaration of conformity in the installation manual.
Mr. Harry Gilde
Managing Director
(Authorized signatory on behalf of OPW Fluid Transfer Group Europe B.V.)

Rack Monitor 8800E/8801E
Document: Operation Manual
Date: 16-Jun-2011
Version: A.6
Page 6 of 35 H71343
Table of Contents
Disclaimer 3
Warranty 4
Approvals 4
Technical assistance in the U.S.A. 4
EC Declaration of Conformity 5
Specifications 8
Electrical Specifications 8
Inputs. 9
Outputs. 9
External environment reminder (see installation manual for details) 10
Product Description. 11
Front layout. 12
LED (electronic light indicator) Display info at power up. 13
LED Display info. 14
Sensors Types. 15
Sensors and Grounding. 15
System operation. 16
Normal operation. 17
Liquid Crystal Display. 17
Sensor detection. 20
Bypass operation. 22
8800E Interior. 23
Firmware upgrade. 24
Event log. 24
Dipswitch setting. 24
Languages settings. 24
Communication settings. 25

Rack Monitor 8800E/8801E
Document: Operation Manual
Date: 16-Jun-2011
Version: A.6
Page 7 of 35 H71343
Data communications. 26
Table 4 27
Table 5 27
Table 6 28
Table 7 28
Products. 29
Supplied accessories. 29
Optional system accessories. 29
Maintenance. 30
Check Points. 30
Troubleshooting. 31
Annex A – Additional Electrical Drawings 33
Annex B – Recommended Spare Parts 33
Annex C – Certificates 34

Rack Monitor 8800E/8801E
Document: Operation Manual
Date: 16-Jun-2011
Version: A.6
Page 8 of 35 H71343
Specifications
The Rack Monitor 8800E/8801E is a loading rack monitoring system, detects and communicates an overfill
condition to the loading rack control automation equipment by means of a normally open relay contact. In addition
this non-permissive condition as well as diagnostic information is displayed. A typical system contains loading rack
control monitor (88xxE Rack Monitor) and a API 10 wire screened coiled cable with a black 10 pins 4 J-slot plug
(Model 7400E).
Thermistor and optic signal inputs allow compatibility with the NEN-EN13922 and two other API standard signalling
conventions commonly used in the industry. Either of these signals comes from the truck/trailer mounted onboard
control monitor or sensors. The 88xxE rack monitor supersedes the 84xx and 85xx type rack monitors and are
suitable for hazardous locations with intrinsically safe outputs.
There are two versions available. The Rack Monitor 8800E is a complete version with liquid crystal display. And the
Rack Monitor 8801E version without a liquid crystal display.
The installation of both versions is the same.
Electrical Specifications
Mains:
Nominal min. input voltage : 90 Vac.
Nominal max. input voltage : 250 Vac.
Nominal input current : 0,4 ARMS @ 110 Vac
Nominal input current : 0,2 ARMS @ 230 Vac
Frequency : 50 / 60 Hz
The nominal power consumption depends on ambient temperature.
Above -10ºC (14ºF) no internal heating is needed
Nominal power consumption : 20VA.
Below -10ºC (14ºF) a certain amount of power is used to keep the liquid display within operating temperature.
Version 8800E
Nominal power consumption : 30VA.
Version 8801E
Nominal power consumption : 20VA.
Mains current limitation
internal fuses : 2AT

Rack Monitor 8800E/8801E
Document: Operation Manual
Date: 16-Jun-2011
Version: A.6
Page 9 of 35 H71343
Inputs.
Sensor Terminal CN2 Pin 1~ 8
: all EN13922 compliant sensors.
: all industry standard format overfill detection sensors
. Two-Wire sensor (maximum eight)
. Two-Wire Thermistor sensors (maximum eight)
. Five-Wire sensors (maximum twelve)
. ROM 3204E Onboard monitor.
: Dry sensor emulator (dummy)
Ground verification Terminal CN2 Pin 9
: verification according EN13922
: Positive and negative sensing
Truck comms Terminal CN2 Pin 11
:Tank truck data communication prepared
Emergency switch : an intrinsically safe normally closed input.
(latched or un-latched.)
Outputs.
Permit Relay output
Voltage : 250V ac/dc
Current limitations : 5AT Internal Fuses
Functional specs : Form-A, Normally open safety relay contacts
energized when rack monitor overfill circuit is permissive
Ground verification Relay output
Voltage : 250V ac/dc
Current limitations : 5AT Internal Fuses
Functional specs : Form-A, Normally open relay contacts
energized when Ground connection is verified
Auxiliary 1 Relay output
Voltage : 250V ac/dc
Current limitations : 5AT Internal Fuses
Functional specs : Form-C (SPCO) Auxiliary relay
See label inside box for functionality
Auxiliary 2 Relay output
Voltage : 250V ac/dc
Current limitations : 5AT Internal Fuses
Functional specs : Form-C (SPCO) Auxiliary relay
See label inside box for functionality

Rack Monitor 8800E/8801E
Document: Operation Manual
Date: 16-Jun-2011
Version: A.6
Page 10 of 35 H71343
Communications.
RS485/422 : galvanic isolated data communication port (non IS)
: Half duplex (RS485)
: Full duplex (RS422)
: multi-drop
: standard 9600Bps ,8 Bits 1Stopb No parity
: selectable 120Ωterminator.
: rotary switch selectable Monitor address 00~99
See label inside box for addition dipswitch setting.
Ethernet interface :Industry standard 4 wire RJ45 connector
Contact OPW FTG for availability.
Miscellaneous.
Optional socket : expansion slot for additional functionality.
Real Time Clock : precise trimmed Quartz real time clock.
: clock is set to Greenwich Mean Time (GMT)
SD Ram socket : Primary used for Update Firmware
: Secondary used for Time stamped data / event logging.
External environment reminder (see installation manual for details)
Operating Temperature Range (Ta) : -45°C (-42.8°F) to +70°C (158°F)
Storage Temperature 8800E (Ts) : -20°C (-4°F) to +70°C (158°F)
Storage Temperature 8801E (Ts) : -45°C (-42.8°F) to +70°C (158°F)
The storage and transport ambient temperature of the 8800E may never exceed the above mentioned temperature
range to prevent damage to the liquid crystal display.
The 8801E Rack monitor can be stored at Operating Temperature
Read installation chapter for recommended precautions when the 8800E/8801E is used in the maximum ambient
operating temperature range.
The Liquid crystal display must be shielded from direct sunlight.
View angle display : ~25°
Visibility display : ~0.5 m
View angle LED’s : 120°
Visibility LED’s : 20 m (no direct sunlight)
Main Seal : certified Silicon label. Use only OPW part H71197 as replacement.
•The gasket(s) is attached or secured to bottom part to prevent loss, damage or incorrect assembly. The
gasket material shall not itself adhere to the other joint face and has to be slightly greased.

Rack Monitor 8800E/8801E
Document: Operation Manual
Date: 16-Jun-2011
Version: A.6
Page 11 of 35 H71343
Product Description.
This manual describes the operation, and troubleshooting of the Civacon 8800E/8801E Loading Rack Monitoring
System.
Read separate installation manual for wiring the rack monitor
It is intended to help operators, maintenance persons, and equipment specifiers understand the operation and
standard features of the 8800E/8801E Rack monitor
It is recommended reading this manual before installation of the equipment.
The 8800E/8801E monitor is a loading rack monitoring system designed to offer a reliable and safe assistance
when loading a tank truck.
It can detect and work with a wide variety of overfill sensors but can also be set to accept only sensors conform.
EN13922 Tanks for transport of dangerous goods
Service equipment for tanks
Overfill prevention systems for liquid fuels
The 8800E monitor is designed to interface with the user by means of a large multi languages Liquid Crystal
Display and Light Emitting Diodes indicators (LED)
A clear and short message will be shown on the Liquid Crystal Display to explain the status of the overfill sensors,
cabling and Rack monitor.
The 8801E monitor is designed to be used where environment does not meet the necessary temperature
specifications when the monitor is switched off.
Note: For simplicity the manual will refer to the standard 8800E Rack monitor with
Liquid Crystal Display. and therefore all information mentioned as shown on the
LC-Display must be ignored when a 8801E is used.
Both 8800E and 8801E are standard equipped with a high quality blue cord set and a black 10 pins plug. An
junction box (Model 7500 Series) can be ordered as an option. Passive (and active) storage plug hangers are also
available.
Please consult the factory for the current availability of all optional products. Thermistor and Optic signal inputs
allow compatibility with the European standard EN13922 as well as the two API standard signalling conventions
commonly used in the industry. Either of these signals comes from the truck/trailer mounted onboard control
monitor or sensors.

Rack Monitor 8800E/8801E
Document: Operation Manual
Date: 16-Jun-2011
Version: A.6
Page 12 of 35 H71343
Front layout.
Figure 1
Besides the large multi languages Liquid Crystal Display five Indicator bars are used to interface with the user.
– The upper bar is indicating the status of the ground verification.
– Second bar is indicating the internal communication of the electronics.
– The Yellow indicators on the third bar are flashing if a bypass is activated.
The Red indicator will flash if a internal system error is detected.
– The remaining Red bar and Green bar are indicating the status of the sensors.

Rack Monitor 8800E/8801E
Document: Operation Manual
Date: 16-Jun-2011
Version: A.6
Page 13 of 35 H71343
LED (electronic light indicator) Display info at power up.
LED Test sequence.
During power up the Red Error indicator in the middle small bar will start flashing every ½ second to indicate no
communication is present.
When the main processor starts sending messages to the LED and LC-Display board the two Blue indicators will
start flashing inversely and the Red indicator will be switched off.
1. Middle Red Communication error indicator
2. Two Blue Communication indicator (flashing)
The LED test sequence will continue with:
3. Left White Grounding indicator
4. Right White Grounding indicator
5. Middle Red Grounding error indicator
6. Left Yellow Bypass indicator
7. Right Yellow Bypass indicator
8. Middle Red System error indicator
9. Red bar Compartment 1 till 12 indicators
10. Green bar Compartment 1 till 12 indicators
All indicators have been switched on and off and the LED display is ready to receive sensor data from the main
controller.
When no truck is connected all Red compartment indicators shall be on and a message will appear on the LC-
Display. The two blue communication indicators will flash inversely to indicate proper internal communication.
As soon as the plug is connected to a truck an extensive short and open circuitry test will be preformed and valid
ground verification will be shown by two inversely flashing white indicators ( see Figure 1 ).
After the auto switching mechanism has detected type and amount of sensors the indication of the Red and Green
LED indicator compartment bar will lit up accordingly.

Rack Monitor 8800E/8801E
Document: Operation Manual
Date: 16-Jun-2011
Version: A.6
Page 14 of 35 H71343
LED Display info.
Two-Wire sensors
Getting permissive,
(connect Plug)
Red compartment indicators are continuous on.
White earth indicators inversely flashing (if ok).
Green indicators flashing : getting permissive (e.g. heating).
Green indicators continuous on : compartment dry
If all (8) green indicators are continuous on (DRY) the red indicators will be switched off and truck is permissive to
load.
Getting wet during loading.
Green indicators : of all dry compartments are continuous on and wet compartment is off
Red indicator : of all dry compartment are flashing and wet compartment is continuous on.
If bypass key is used.
Green indicators : of all dry compartments are continuous on and wet compartment is off
Red indicator : of all dry compartments are off and wet compartment continuous on
Yellow indicators : inversely flashing
Continuous checking overfill detection on non-bypassed compartments.
Getting wet again during loading.
Green indicators : of all dry compartments are continuous on and wet compartments are off
Red indicator : of all dry compartment are flashing and wet compartments are continuous on.
Yellow indicators : inversely flashing
Five-Wire sensors
Getting permissive,
(Connect Plug)
Red compartment indicators are continuous on.
White earth indicators inversely flashing (if ok).
Green indicators : amount of dry detected compartments
the red indicators will be switched off and truck is permissive to load.
Getting wet during loading. ( e.g. 6 compartment truck. 4 becomes wet)
Green indicators : dry compartments 1,2,3 and 5 are continuous on and wet compartment 4 is off
Red indicators : dry compartments 1,2,3 and 5 till 12 are flashing and wet compartment 4 is continuous on.
If bypass key is used.
The Rack Monitor will switch to permissive but no compartments will be monitored due to sensor
characteristics.
Yellow indicators : inversely flashing
Getting wet again during loading.
No continuous overfill detection possible in Five-Wire mode.
Faulty detected sensors.
LED indication when a sensor fault (or more) is (are) detected
Green indicators : all off
Red indicator : all correct detected sensors are flashing and faulty sensor(s) is (are) continuous on
If the fault is bypassed the rack monitor will revert to the state mentioned above with the faulty channels bypassed.
Note: is some, cases most likely with Five-Wire sensors it is not possible to continue with an overfill detection
functionality.

Rack Monitor 8800E/8801E
Document: Operation Manual
Date: 16-Jun-2011
Version: A.6
Page 15 of 35 H71343
Sensors Types.
Two-Wire Thermistor Sensors. (NTC)
Two-Wire sensors.
Five-Wire sensors.
Sensors and Grounding.
Before continuing describing the functionality of the rack monitor a short explanation of the sensors and ground
verification.
As mentioned above there are three industrial standard sensor principals.
There are two industrial standards for the Two-Wire sensors.
A Thermistor sensor with a negative temperature coefficient (NTC) and a Two-Wire optic or compatible sensor. The
Thermistor sensor is basically a heating element in combination with a temperature sensor.
The Thermistor sensors are heated up to approximately 75°C (167°F) (Depending type).
Time to heat the sensor depends on ambient temperature and used Thermistor type.
( how the 8800E will handle the Thermistor is explained later in this document).
The sensing circuit of a 2 (and 5) wire sensor are not necessarily done with a optic detection circuit. To avoid
misunderstanding this manual will refer to Two-Wire sensors and Five-Wire Sensors. Two-Wire sensors can be
used on vehicles with no more then eight compartments. Standard Rack monitors are monitoring all 8 channels
(see Dipswitch setting for 6 channels US version). This means remaining channel(s) on vehicles equipped with
Two-Wire sensors with less then 8 compartments must be connected to a electronic Dummy (e.g. part number
1920). All sensors are individual Wired / connected to the Rack monitor and more than one wet compartment can
be detected at the same time.
The Five-Wire sensors are connected in series and therefore capable of handling more then 8 compartments.
Because of this, only one wet compartment can be detected at the same time. A special diagnostic wire is used to
determine the wet compartment. The 8800E can handle more then 12 compartments but only 12 will can be
indicated on the LED display.
(Maximum 12 compartments according EN13922)
The 8800E will try to determine which compartment is wet if more than 12 compartments are used and if a good
connection is made between plug and socket and wiring are done carefully, the 8800E shall indicate the correct
compartment on the Liquid Crystal Display.
Note: Displaying the correct wet compartment is only possible if there are no bad connections.
Ground verification is done via pin 9 on the terminal and plug-socket connection.
For NEN-EN13922 application pin 9 is also used for detecting if a Vapour recovery hose is properly connected to
the Tank-Truck when five-Wire sensors are used.
Note: The Vapour recovery hose is checked via pin 8 on a Tank-Truck equipped with Two-Wire sensors.
Note: Consult socket drawings for detailed information.
The 8800E Rack Monitor is capable of (auto-)detecting a resistive Ground connection as well as a Ground-Bolt
(EL00001-E) connection on a Tank-Truck. Make sure connection between pin 9 and pin 10 via the Tank-Truck
chassis is less then 1kΩ.
The two wire Thermistor sensors are simple component sensors with no active elements. This means the Rack
monitor has to control the Thermistor sensor where a two-wire optic or compatible sensor has active elements and
is self oscillating when dry.
As soon as the 8800E rack monitor has detected the Thermistor sensor it will supply power to heat the Thermistor
bead from ambient temperature to a predefined high temperature this will be indicated on the LC-Display with a “H”
and also the green indicators will flash from low intensity to high intensity. As soon as the thermistor bead reach the
predefined high temperature the 8800E will switch off the power. The Thermistor will cool down until the predefined
low temperature is reached. When a the Thermistor bead becomes wet the 8800E is not able to heat the Thermistor
bead within the specified time and switch to NON-permissive.

Rack Monitor 8800E/8801E
Document: Operation Manual
Date: 16-Jun-2011
Version: A.6
Page 16 of 35 H71343
System operation.
The purpose of the Civacon 8800E Rack Monitor liquid level sensing system is to detect a liquid point level signal
from a sensor mounted in compartments of a tank truck, or storage tanks. The system provides an automatic signal
to the rack automation equipment to shut-off the flow of liquid and warn of an impending overflow condition of a tank
truck or storage tank It can detect up to 8 Two-Wire Sensors or 12 Five-Wire Sensors
As soon as the power is supplied, the monitor will perform a extensive self test of its internal functions (see power
up test). If one of the test fails (except Led Test) a message will be shown on the Liquid Crystal Display. Also a red
Led indicator will blink. (see troubleshooting chapter for details).
Make sure no vehicle is attached at power-up.
Note: The cable and plug connections shall be tested if a active storage hanger is used.
If all tests are passed the rack monitor is ready for use.
The first task of the 8800E Rack Monitor is to ensure proper grounding is established via Pin 9 and pin 10 of the
plug socket connection to the tank-truck chassis. As soon as this has been ensured, two white Led indicators will
flash inversely. Secondly the 8800E will check for shorts between sensors and shorts to ground for every channel
and for open circuits. Then the 8800E Rack Monitor will determine sensor type and the amount of compartments. It
can detect up to eight thermistors or Two-Wire sensors, up to 12 Five-Wire sensors and is fully compatible with the
3204E Onboard Retain Overfill Monitor.
If possible, the amount of sensors will be shown on the Display and Led indicators. ( see sensor detection chapter
for details).
The 8800E Rack monitor provides an “Auto switching” capability between Two-Wire sensors, Two-Wire Thermistor
sensors and Five-Wire sensors.
If sensor type is selected, all sensors are dry and proper ground is verified the 8800E Rack monitor will
communicates a Permissive condition to the automation equipment. When Thermistor sensors are used a waiting
period has to be observed.
Of course the monitor can only be connected to one type of signal source at any one time. You cannot have Two &
Five-Wire sensors connected at the same time. Although the 8800E/8801E Rack Monitor can detect and operate
with a mix of Two-Wire sensors (Thermistor and self oscillating) it is not recommended.
The 8800E Rack Monitor systems uses self-checking principles to provide a continuous check on all system
components. It also checks short circuits between sensors and ground and open circuits when connected to a tank-
truck.
If at any time the 8800E Rack Monitor detects any kind of failure, a signal to the automation equipment will be send
to shut-off the flow
All sensor failures are indicated on the two displays.

Rack Monitor 8800E/8801E
Document: Operation Manual
Date: 16-Jun-2011
Version: A.6
Page 17 of 35 H71343
Normal operation.
The main task of the 8800E Rack Monitor is to provide a signal to the rack automation equipment to shut-off the
flow of liquid as soon as a sensors in a compartment tank detect a liquid point level
When the rack monitor is not used for 15 minutes it goes into sleep mode.
During sleep mode the Red Led indicators will be dimmed and occasionally flash with high intensity to indicate “
system ready in sleep mode”.
As soon as the Plug is connected to the truck socket or removed from the active storage hanger the system awakes
and is ready for use. If proper ground and dry sensors are detected the rack monitor will switch to permissive. When
the loading is finished and the plug is removed from the truck it will wait 15 minutes before it goes back to sleep.
Liquid Crystal Display.
Liquid Crystal Display info at power up.
After power up the following messages will sequential appear on the LC Display.
01
P
O
W
E
R
-
U
P
S
E
Q
U
E
N
C
E
S
T
A
R
T
E
D
02
03
D
i
s
p
l
a
y
B
o
a
r
d
04 H a r d w a r e V e r s i o n : 1 .
05
F
p
V
e
r
s
i
o
n
:
.
3
06
S
o
f
t
w
a
r
e
V
e
r
s
i
o
n
:
.
6
07
08 M
a i n B o a r d
09
H
a
r
d
w
a
r
e
V
e
r
s
i
o
n
:
.
2
10 F p V e r s i o n : . 3
11
S
o
f
t
w
a
r
e
V
e
r
s
i
o
n
:
.
7
12
13
C
o
n
f
i
g
:
n
o
f
i
l
e
14
15 T I M E S E T T O h h : m m : s s D D . M M . Y Y
16 T E M P E R A T U R E X X - º C
Note: Versions in the above shown figure are just an example.
Time hh means hours, mm means minutes, ss means seconds
Date DD means day, MM means month, YY means year.
The temperature is measured inside the box and NOT ambient temperature.
The real time clock is used for logging only and is factory set to Greenwich Mean Time.

Rack Monitor 8800E/8801E
Document: Operation Manual
Date: 16-Jun-2011
Version: A.6
Page 18 of 35 H71343
Liquid Crystal Display info during normal operation.
After the power up sequence the 8800E will enter the normal operation mode. The following messages will
sequential appear on the LC-Display.
01 S Y S T E M R E A D Y
02
P
L
E
A
S
E
C
O
N
N
E
C
T
P
L
U
G
As soon as the plug is connected to the truck the following message page will appear.
(e.g. truck with Ground bolt and Two-Wire Dry sensors)
In line 4 the type of ground verification: Ground Bolt
In line 5 the type of sensors: Two Wire Sensors
In line 6 the amount of sensors:
In line 7 the state of the detected sensors: Dry
If all sensors are dry and a proper ground is verified the indication “permit to load “will appear at line 10.
If less then 8 sensors are connected and the remaining sensors are emulated with a dummy the rack monitor will
indicate the remaining channels as dry Two-Wire sensors.
Note: only when special Dummy is mounted in the socket of the Tank-Truck. Else remaining channels will be
indicated as Dry
01 S Y S T E M R E A D Y
02 S O C K E T D E T E C T E D
03
04 G R O U N D V E R I F I C A T I O N : B O L T
05 S E N S O R T Y P E D E T E C T E D : 2 W I R E
06 S E N S O R D E T E C T E D : 1 2 3 4 5 6 7 8
07 S E N S O R S T A T E : D D D D D D D D
08
09
10
P
E
R
M
I
T
T
O
L
O
A
D
Note: If the plug is not connected to the truck socket it will go into sleep mode after 15 minutes.
The Red Led lamps will lit up every few seconds

Rack Monitor 8800E/8801E
Document: Operation Manual
Date: 16-Jun-2011
Version: A.6
Page 19 of 35 H71343
An other example can be
(e.g. 12 compartment truck with ground loop and Five-Wire Dry sensors)
01
S
Y
S
T
E
M
R
E
A
D
Y
(
E
N
1
3
9
2
2
)
02 S O C K E
T D E T E C T E D
03
04 G R O U N D V E R I F I C A T I O N : B O L T
05 S E N S O R T Y P E D E T E C T E D : 5 W
I R E
06 S E N S O R D E T E C T E D : 1 2
07 S E N S O R S T A T E : D R Y
08
09
10 P E R M I T T O L O A D
It can happen that during loading a sensor get wet. In this case the display will indicate the following.
(e.g. 12 compartment truck with ground loop and Five-Wire sensors and sensor in compartment 4 becomes wet)
01 S Y S T E
M R E A D Y ( E N 1 3 9 2 2 )
02 S O C K E
T D E T E C T E D
03
04 G R O U N D V E R I F I C A T I O N : B O L T
05 S E N S O R T Y P E D E T E C T E D : 5 W
I R E
06 S E N S O R D E T E C T E D : 1 2
07 S E N S O R S T A T E : W
E T 4
08
09
10 N O P E R M I T T O L O A D
Note: see appendix for more examples

Rack Monitor 8800E/8801E
Document: Operation Manual
Date: 16-Jun-2011
Version: A.6
Page 20 of 35 H71343
Sensor detection.
The 8800E and 8801E rack monitor is an auto switching rack monitor and will detect automatically the 3 types
commonly used overfill sensors. Before the rack monitor switch to permissive the following steps will be performed.
1. Individual short detection between sensors and ground.
2. Resistive ground detection via pin 9
3. Ground bolt detection via pin 9
4. Sensor type detection
5. Detected sensors complies to EN13922
6. Detected sensors complies to Rest Of the World specifications (ROW)
7. Detected sensors appears to work but not complies to the above specifications.
Note: Overfill sensors commonly used in industry are not necessary compatible with commonly used Rack
Monitors in industry.
The specification of the ROW overfill sensor are based on an extensive worldwide sensor collection. All
parameters of those sensors are collected and the boundaries are stored in a table inside the 8800E/8801
Rack monitor.
Note: The European Standard EN13922 describes the following points.
- Functions
- Major components
- Characteristics
- Test methods
Note: in some cases the rack monitor is still able to use the connected sensor as an overfill detection device. The
operator will be asked to accept the detected sensor by using the Blue bypass key.
Step 1.
In this step the rack monitor is checking if all wires are connected to a sensor and there are no shorts between
channels.
E.g. If on the tank truck one sensor is connected to two pins on the socket or one dummy channel is used to
emulate two dry sensors the Rack monitor will detect this as a short and show this on the LC-Display.
Step 2. & 3
Although ground verification is continues it is mention in this document as a step.
Since many Tank-Trucks are equipped with a ground bolt the 8800E/8801E Rack Monitor will accept this
automatically as a proper ground verification.
Be aware that conform the EN13922 in combination with Five-Wire sensor(s) the earth verification is
connected in series with the vapour recovery hose interlock switch
Step 4.
The Rack monitor will apply power to the sensor and analyze the measured signal.
In case of a Two-Wire Thermistor sensor, a special algorithm will be used to heat the sensor to his operating
temperature. This will be shown on the LC-Display with a H at Line 7
Also the Green LED indicator will change intensity until operating temperate is reached.
Note: Time to heat the sensor depends on ambient temperature and used Thermistor type.
07 S E N S O R S T A T E : H H H H H H H H
If no Two-Wire sensors are detected, power will be applied at channel 8 and a pulse will transmitted at pin 4
If a return pulse is detected the rack monitor will continue with Five-Wire senor(s).
