dr. Mercola Clear Air User manual

Owner’s Manual

2 3
WelcomeTable Of Contents
Thank you for purchasing Dr. Mercola’s ClearAir Vehicle Air Purifier.
This low-maintenance air purifier has been designed to provide you with a
cleaner vehicle air space by assisting with odor and particle removal.
Follow the instructions provided with your ClearAir Vehicle Air Purifier to assist
you with easy setup and maintenance.
Packaged Materials:
1 ClearAir Vehicle Air Purier
1 12V DC Power Cable
1 Owner’s Manual
Records:
Please record the serial number of your ClearAir Vehicle Air Purier.
Serial #
Welcome................................................................. 3
Packaged Materials........................................................ 3
Records.................................................................. 3
Uses & Features .......................................................... 4
Warnings................................................................. 4
Cautions ................................................................. 5
Diagrams & Control Panel Information ..................................... 6 - 7
Getting Started ........................................................ 8 - 9
Operation ........................................................... 10 - 11
Maintenance ........................................................ 12 - 14
Cleaning ............................................................ 15 - 16
Specications............................................................ 17
Warranty Information .....................................................18

4 5
Uses & Features
Warning
Cautions
Uses
• Cleans and refreshes air in your vehicle
Features
• Cleanable Unit Body and Filter
• Replaceable ION Generator
• Quiet Operation
• Convenient Design
• 4 Hour Auto Shut-Off
NOTE: For your safety, please read through these cautions before using the
ClearAir Vehicle Air Purier.
Do not change settings on the unit while driving.
Do not place in a location that will obstruct your view while driving.
Do not block either air vent.
Be careful with liquids near the unit.
Unplug this unit before cleaning or maintenance.
Unplug this unit when not in use.
Mechanical or electrical maintenance must be performed by the manufacturer or
licensed professional. Failure to adhere to this will void your warranty.
If there is any damage to the unit or wiring, stop using immediately and contact the
manufacturer for repairs or replacement.
The ClearAir Vehicle Air Purier is not a medical device and should not be used to alleviate
any medical issues that you may have. Please consult your physician before using the ClearAir
Vehicle Air Purier if you are worried that the machine could cause adverse effects.

6 7
Diagrams & Control Panel Information Diagrams & Control Panel Information
Air Vent Out
Mode/Fan Speed
Fan Speed Indicator
Ion Generator Replacement Light
Ion Generator Lifetime Reset
Clean Filter Light
Ion Generator
DC Power Plug In
Filter
DC Power Adapter
7
7
8
8
9
9
10
11
2
2
3
3
4
4
5
5
6
6
10

8 9
Getting Started Getting Started
Slide the plate down and off the unit.
Place the DC Plug in the DC Power Plug In and situate the
cord in one of its two cable ports along the side of the unit.
Replace the Rear Unit Cover.
Secure the Power Plug into the Vehicle’s 12V outlet.
Place the unit in a cup holder or another secure location that
will not distract the driver.

10 11
Operation Operation
NOTE: To improve the Ion Output, use the ClearAir Vehicle Air Purier in conjunction with your
vehicle’s Air Conditioning.
WARNING: Do not change settings on the ClearAir Vehicle Air Purier while driving your vehicle.
Push the Mode Button once. The unit will now run in
Low Output Mode. (Denoted by One Arrow on Fan Speed Indicator)
Pushing the Mode Button again will change to High Output
Mode. (Denoted by Two Arrows on Fan Speed Indicator)
NOTE: The ClearAir Vehicle Air Purier will save the last mode used when you turn your
vehicle OFF and back ON.
NOTE: The ClearAir Vehicle Air Purier has an automatic shut-off feature that will power
the unit down after 4 hours; this is to help prevent a battery drain if your outlet is not
controlled by your vehicle’s ignition.
Pushing the Mode Button a third time will turn the unit OFF.

12 13
Maintenance Maintenance
In order to keep your ClearAir Vehicle Air Purier functioning at its best, you will need to
perform small maintenance tasks throughout the life of the unit.
Slide the plate down and off the unit.
The Ion Generator Replacement Indicator will light up to notify you
if the Ion Generator is damaged or is in need of a replacement.
If a replacement Ion Generator is needed, contact Dr. Mercola’s
Customer Service Department at (847) 252-4355.
WARNING: Remove the Power Plug from your vehicle’s 12V outlet before performing any
maintenance. Failure to do so could result in an electrical shock.
Remove the screw that holds the Ion Generator in place.
Disconnect the Power Cable and remove the Ion Generator.
Replace the Ion Generator and the screw that holds it in place.
Ion Generator Replacement Indicator
16,000 Hours Estimated Lifetime

14 15
Maintenance
(continued from page 13)
Cleaning
Replace the Rear Cover and plug the unit back into the
vehicle’s 12V outlet.
Turn the ClearAir Vehicle Air Purier on and hold the Reset
Button for 3+ Seconds. The Ion Generator Indicator Light will
ash twice, turn off, and begin monitoring the new Ion Generator.
6
Your ClearAir Vehicle Air Purier will need to be cleaned from time to time in order to
keep it functioning to its best ability.
WARNING: Remove the Power Plug from the vehicle’s 12V outlet before performing any
cleaning. Failure to do so could result in an electrical shock.
WARNING: Your unit should not be cleaned with harsh chemical cleaners. This may result in
damaging your unit. For best results, use a damp cloth to wipe down and clean
the unit.
Slide the plate down and off the unit.
Wash the Rear Cover/Filter with water under a faucet. Scrub
thoroughly with a non-abrasive cloth or sponge.

16 17
Cleaning
(continued from page 15)
Specifications
Thoroughly dry and replace the Rear Cover.
Turn the ClearAir Vehicle Air Purier on and hold the Reset
Button for 3+ seconds. Once completed, the Clean Filter
Indicator Light will turn off.
Voltage...............................................12V DC | 0.18 A
Dimensions ...................................6.4” H x 2.8” W x 2.2” D
Weight ......................................................8.64 oz.
Effective Area ..............................................106 cu. ft.

18 19
Warranty Information Notes
Your ClearAir Vehicle Air Purier is warranted to be free from all defects in material and workmanship in
normal household use for a period of 1 Year from date of purchase. The warranty is granted only to the original
purchaser and members of his or her immediate household. The warranty is subject to the following provisions.
Any damages or malfunctions caused by negligence, abuse, or use not in accordance with the Owner’s Manual
are not covered by this warranty. If the unit is dropped, damaged, or immersed in or splashed with liquids, these
are not covered by this warranty. Likewise, any defects or damages caused by unauthorized service are not
covered. Mercola.com Health Resources, LLC will, at its option, repair or replace a defective ClearAir Vehicle
Air Purier that is covered by this warranty. As a matter of warranty policy, Mercola.com Health Resources, LLC
will not refund the customer’s purchase price. To obtain warranty service you must return the defective ClearAir
Vehicle Air Purier along with proof of purchase to Mercola.com Health Resources, LLC. All delivery charges on
parts, or units, submitted under this warranty shall be borne by purchaser. Unless this Warranty is expressly
renewed or extended by Mercola.com Health Resources, LLC, any repaired or replaced part of unit shall be
warranted to the original purchaser only for the length of the unexpired portion of the original warranty.
FURTHER LIMITATIONS AND EXCLUSIONS ARE AS FOLLOWS: Any warranty that may be implied in connection
with your purchase or use of the ClearAir Vehicle Air Purier, including any warranty of merchantability is limited
to the duration of this warranty. Some states do not allow limitations on how long an implied warranty lasts, so
the above limitations may not apply to you.
Your relief for the breach of this warranty is limited to the relief expressly provided above. In no event shall
Mercola.com Health Resources, LLC be liable for any consequential or incidental damages you may incur in
connection with your purchase or use of the ClearAir Vehicle Air Purier. Some states do not allow the exclusion
or limitation of incidental or consequential damages, so the above limitation or exclusion may not apply to you.
This warranty gives you specic legal rights, and you may also have other rights which vary from state to state.
______________________________________________________________________________________________
______________________________________________________________________________________________
______________________________________________________________________________________________
______________________________________________________________________________________________
______________________________________________________________________________________________
______________________________________________________________________________________________
______________________________________________________________________________________________
______________________________________________________________________________________________
______________________________________________________________________________________________
______________________________________________________________________________________________
______________________________________________________________________________________________
______________________________________________________________________________________________
______________________________________________________________________________________________
______________________________________________________________________________________________
______________________________________________________________________________________________
______________________________________________________________________________________________
______________________________________________________________________________________________
______________________________________________________________________________________________

DISTRIBUTED BY: NHP
125 SW 3rd Place, Cape Coral, FL 33991 USA
(877) 985-2696
Made in China
20278-v400N
