NRS Mowbray Lite Plus User manual

30st
190kg
To fit the seat:
Place the seat on the frame in the correct
position, with the front of the seat and curve
of the armrests facing forwards, figure 2.
Push down firmly on the seat until it snaps
into position on both the front and rear cross
bars.
To install the Mowbray Lit Plus:
Place the frame over the toilet ensuring that
the internal splash guard is central over the
toilet bowl, figure 1.
User Instrucons
N53909 Mowbray Lite Plus
Maximum User Weight
General Safety Warning
Please ensure these instructions are fully read and
implemented. Failure to do so may result in injury.
Retain these instructions in a safe place for future
reference.
1.0 Intended Purpose
The Mowbray Lite Plus is designed to assist users
when lowering onto and rising from the toilet. The
frame provides a stable support when getting on
and off the toilet and the moulded seat offers a
comfortable seating position. The seat lid adds
discreet style and helps to improve cleanliness and
hygiene.
2.0 Safety Precautions
Do not exceed the maximum user weight 30st
190kg.
Do not attempt to stand or climb on the product.
Ensure all legs are set at equal height to avoid
rocking.
3.0 Unpacking
Remove packaging and check all parts carefully,
see figure 3. If any parts appear damaged do not
assemble and contact your supplier immediately.
4.0 Assembly Instructions
To fit the crossbars:
Push the crossbars onto the tube stubs on
the LH & RH frames.
Set to the desired width, align the holes and
insert the ‘e-clips’.
Ensure that both cross bars are set to the same
width.
To fit the legs:
Insert the leg extensions inside the LH & RH
frames and slide to the desired height.
Align the holes and insert the ‘e-clips’.
Use the markings on the legs to ensure that all four
legs are secured at the same height to prevent
rocking and instability.
Figure 1 – Seat Lid
Open
Figure 2 – Seat Lid
Closed
1
Figure 3 - Contents
1
Toilet Seat & Lid X 1
4
Crossbar X 2
2
LH Frame X 1
5
Leg Extension X 4
3
RH Frame X 1
6
‘E-clip’ X 8
2
3
4
6
5
5
1

NRS Healthcare is a Leading Supplier of Community Equipment and
Daily Living Aids, to view our full range, visit our website:
www.nrshealthcare.co.uk
UI/N53909 /02/18/Iss 2
5.0 Optional Floor Fixing Kit
The floor fixing kit provides a permanent fixing
solution for the Mowbray Lite Plus. It helps to
prevent the frame from moving out of position or
becoming unstable during use.
F11572 – Mowbray Floor Fixing Kit
Available as an accessory from NRS Healthcare.
Call Customer Services 0345 121 8111 or visit
www.nrshealthcare.co.uk
5.1 Fitting Instructions
Adjust the toilet frame to the desired width, see
Section 4.
To fit the legs:
Remove the original leg extensions by
removing the ‘e-clips’ and sliding them out
of the frame.
Insert the four leg extensions and position
at the desired height.
Align the holes and insert the ‘e-clip’.
Ensure that all four legs are secured at the same
height to prevent rocking and instability.
Please note the height cannot be adjusted once the
legs are secured to the floor.
To fix to the floor:
Choose a fixing method which is suitable for the
construction of the floor. A total of 12 screws must
be used, 3 per leg, figure 4.
6.0 Cleaning
Clean regularly using a general purpose, neutral
detergent and warm water.
Please check the suitability of the cleaning products
before use. Do not use abrasive cleaners or cloths
as these could permanently damage the surface
and invalidate any warranty.
To disinfect, wipe with a dilute bleach solution and
rinse thoroughly with fresh water.
Allow the product to dry fully prior to use/storage.
7.0 Maintenance
Check that all fixing clips are inserted correctly and
that there is no excessive movement.
If a floor fixing kit has been fitted, check the fixing
screws are secure.
Inspect the product regularly for signs of wear or
damage, pay particular attention to the condition of
the ferrules.
Any suspected faults or damage should
immediately be reported to the supplier and the
product taken out of use.
8.0 Product Disposal
Product should be thoroughly cleaned prior to
disposal.
Product is manufactured from metal and plastic and
can be disposed of through Local Authority
Household Waste and Recycling Centres or
through local Trade Waste Collectors.
9.0 Product Guarantee
NRS Healthcare guarantee this product for a period
of 12 months, from the date of purchase, against
faulty materials and workmanship. This guarantee
does not cover; abuse, misuse, interference or
tampering with any part of the product.
Any guarantee issued by NRS Healthcare does not
affect your statutory rights.
NRS Healthcare
Sherwood House, Cartwright Way,
Forest Business park, Bardon Hill,
Coalville, Leicestershire, LE67 1UB, UK
Tel. Head Office: 0330 100 0098
Tel. Customer Services: 0345 121 8111
Email: [e-mail]
Floor Fixing
Leg
Fixing Screws
(Not Included)
‘E-Clip’
Location
Figure 4 –
Installing the
Floor Fixing Kit,
M24308.
